REMOTE MONITORING

Scan ‘N View Yes

Dual Stream 1080p/720p/D1/CIF@12FPS

Simultaneous Users 10

QT H85

Supports QTH BNC HD Cameras

& Analog Cameras

DVR Technology BNC HD

Channels 8

Recording Resolution 4MP/ 3MP/ 1080p / 720p / 960H

Live Viewing Resolution 4K/2K/1080p/ CVBS (Spot Out)

Live Display FPS

Hard Drive

Remote Monitoring

Compatibility

Connects With

Monitor Connections

30 FPS

Supports 1 HDD up to 6TB 10

Simultaneous Users

Mac and PC

QTH BNC HD Cameras

HDMI, VGA, CVBS(Spot Out)

COMMUNICATION PORTS

Network RJ45 10/100 Mbps

USB 1 USB 2.0 (front panel)

eSATA None

COMPATIBILITY

Software Support QT View

Mobile Support iPhone, iPad, Android

Computer Support WinXP, Vista, Win7/8/10

Mac OS 10.7+

VIDEO, AUDIO & ALARM PORTS

Video in 8 BNC

Video Out HDMI, VGA, CVBS

Alarm In No

Alarm Out No

Audio In 1 RCA

Audio Out 1 RCA

RECORDING RESOLUTION OPTIONS

1080p Resolution 1920 x 1080 pixels

720P Resolution 1280 x 720 pixels

960H Resolution 960 x 480 pixels

RECORDING MODES

Recording Modes Manual, Time Schedule, Motion Detection, Sensor

Backup Methods PC, Flash, USB Hard Drive

Playback Speed

1080p at 12 FPS per channel 96 FPS total

720p at 30 FPS per channel 240 FPS total

960H at 30 FPS per channel 240 FPS total

Number Channels 8 Simultaneous Local Playback

PLAYBACK ON DVR

DVR

Video Compression H.264

Live Display Resolution 4K/2K/1080p/ CVBS (Spot Out)

Live Display FPS 30 FPS

Display Modes 1, 4, 8, Auto Sequence

Languages English, Chinese (Simplified & Traditional),

Czech, French, Portuguese, Spanish, Turkish,

Bulgarian, Greek, Italian, German, Russian,

Polish, Japanese, Indonesian, Thai, Hungarian,

Lithuanian, Vietnamese, Dutch, Swedish,

Norwegian, Persian, Arabic, Romanian

Control USB Mouse, Remote Control

Connectors / Cables HDMI Cable,

Mounting Hardware Screws for Hard Drives

Other Quick Start Guide

ACCESSORIES

3MP Resolution 2048 x 1536 pixels

4MP Resolution 2560 x 1440 pixels

3MP at 18 FPS per channel 144 FPS total

4MP at 12-15 FPS per channel 96-120 FPS total

1 USB 3.0 (back panel)

(QTH 85 cont’d…)

POWER

Power Supply

12v 2A

Power Consumption <15w (w/o HD)

PHYSICAL

Weight 3.3 lbs

Dimensions 11.75”W X 9.75”D X 2”H

Operating Temperature 14°– 130°F

HARD DRIVES

Maximum Size 6TB

Number Supported 1

PTZ

PTZ Support RS485

Supported Protocols COC, Null, Pelco D, Pelco D, Lilin, Minking, Neon, Star,

VIDO, DSCP, VISCA, Samsung, RM110, HY
