QBIC TECHNOLOGY FHD100 BOX PC User Manual
QBIC TECHNOLOGY CO.,LTD BOX PC
User Manual
This quick guide will help you go through installation quickly
The colour and the appearance may differ depending on the
product, and the specifications are subject to change without
prior notice to improve the performance.
Box PC FHD-100
Quick Start Guide
QUICK START GUIDE
Qbic Technology Co.,Ltd.
11F.-9,No.99.Sec.1, Xintai 5th Rd., Xizhi Dist., New Taipei City 221, Taiwan(R.O.C)
Tel: 886-2-2697-2000 FAX: 886-2-2697-2868
CARE AND WARNING
WARNING: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/panel PC technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,including interference that may
cause undesired operation.
Correct Disposal of this product. This marking indicates that this product should
not be disposed with other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environmental safe recycling.
“ FCC & CE RF Radiation Exposure Statement Caution: To maintain compliance with
the FCC & CE’s RF exposure guidelines, place the product at least 20cm from near by
persons. ”
Power Adapter information:
Model No.: KSASB0241200150D5
INPUT: 100-240V~50/60Hz 0.6A
OUTPUT: 12V 1.5A
QUICK START GUIDE
D
QUICK START GUIDEQUICK START GUIDE
AContents
BIndication
CInstallation
DC 12V
LAN
USB
USB
ADB
Micro SDHC
Reset
WiFi Antenna
Lock Hole
RS-232
Audio Out
S/PDIF
Setsrew*3
DC Power Adapter
1
1 2 3 4 5 6 7 8
9
10
11
12
13
14
2
3
4
5
6
7
8
9
10
11
12
HDMI
USB
13
14
1. Cables connection
Step 1 Step 2 Step 3 Step 4
Step 1 Step 2 Step 3
Step 1 Step 2 Step 3
2. Surface Mount
3. Glass Mount
Box PC
External Antenna
Air Mouse Cover Micro SD card cover
Quick Start Guide
DC Cover
VelcroHDMI Cable
Power Plug
( Provided by regions）
for UK
for EUfor US
for AU
Air mouse
(optional)
WA LL
WALL
WA LL
GLASS
GLASS
