Qingdao Magene Intelligence Technology T11 GRAVAT Smart Power Trainer User Manual
Magene Technology Co., Ltd. GRAVAT Smart Power Trainer
User Manual
User Manual
Product Name: GRAVAT Smart Power Trainer
Model: T11,T11A,T11B,T11C,T11D,T11E,
T11F,T11G,T11H,T11J
Brand:
Manufacture: Magene Technology Co., Ltd.
Thank you for purchasing GRAVAT Smart Power Trainer. Please do read this guide before
use. Visit www.magene.cn for more information about GRAVAT Smart Power Trainer.
Feel free to contact us at:
Email: service@magene.cn
TEL: 4006628297
QQ: 3337017453
Web: www.magene.cn
Keep children and pets away from GRAVAT Smart Power Trainer while in use.
Only use GRAVAT Smart Power Trainer on a stable, level surface. Before beginning or modifying any
exercise program, please consult your physician.
Do not put hands or objects near moving parts of GRAVAT Smart Power Trainer.
GRAVAT Smart Power Trainer may become too hot to touch when used for extended periods of time.
Do not attempt to dismount the bicycle when the flywheel is in motion.
Use caution when standing while riding on GRAVAT Smart Power Trainer.
Keep GRAVAT Smart Power Trainer away from water and fire.
GRAVAT Smart Power Trainer's built-in power meter
cannot tolerate fierce vibration. As showing in the
picture, use a zip tie to tighten the bolt to the frame of
GRAVAT Smart Power Trainer during the
transportation. Please remove the zip tie before using
GRAVAT Smart Power Trainer, or else the built-in
power meter won't work correctly.
In the box you will find your (1) GRAVAT Smart Power Trainer, (2) AC adapter, (3) quick release skewer, (4)
reversible axle spacer, and (5) ANT+ dongle. Remove your GRAVAT Smart Power Trainer Power Trainer and
accessories from the box. Be sure to save the protective packaging for transportation and storage.
Quick Start Guide
CAUTION
Unpacking
CAUTION
1. Place your GRAVAT Smart Power Trainer power trainer on a stable, level surface and ensure there is no
dangerous objects around.
2. Pivot the leg outward until it doesn't waggle.
3. Use the included AC power adapter to connect the trainer to a standard 100v～240v wall outlet.
The reversible axle spacer can be used to accommodate 130mm or 135mm spacing. A cyclocross or mountain
bike typically uses 135mm spacing. A typical road bike uses 130mm spacing. Please ensure the spacer
accommodate your bike. Next, install the quick release skewer; leave the skewer loose to allow for easy bicycle
installation.
SETUP
1. Shift your bicycle chain to the smallest
sprocket in the front and rear, then remove the
rear wheel.
2. Install your bicycle on the GRAVAT Smart
Power Trainer Power Trainer by aligning the
chain with the smallest sprocket on the
GRAVAT Smart Power Trainer and pressing
down to fully seat the dropouts on the
GRAVAT Smart Power Trainer Power Trainer's
axle.
3. Secure your bicycle by tightening the quick
release acorn nut and clamping the quick release lever shut.
4. CAUTION! Failure to properly tighten the quick release may result in property damage or personal injury. If
you are unsure of the proper tension please consult your local bike shop or contact Magene Tech for
assistance. Do NOT ride the GRAVAT Smart Power Trainer Power Trainer until the quick release skewer is
tightened.
Once the AC power adapter is connected, the LED at the top of the frame will blink red twice to green. Then you
will find ANT+ FE-C/Smart Trainer or Power Meter by searching through Onelap, Zwift or other training software,
as well as Bike Computers.
Visit www.onelap.cn to download Onelap(A free virtual riding software).
To connect to the GRAVAT Smart Power Trainer Power Trainer, your need to plug in the included ANT+
dongle into your PC.
Attaching Your Bicycle
Connecting to the GRAVAT Smart Power Trainer Power Trainer
If your training software or Bike Computers doesn't support smart trainer, you can search GRAVAT Smart
Power Trainer's built-in power meter to use it.
Please visit www.magene.cn to download GRAVAT Smart Power Trainer CALIBRATION TOOLBOX and do
calibration according to the instructions.
Please do a Zero-Calibration before fist use and after transportation to improve accuracy.
The recommended calibration period is 4 weeks, which should be shorten if in heavy use. To get the most
accurate data, warm-up 5 to 10 minutes before performing a Spindown-Calibration.
GRAVAT Smart Power Trainer
Status
Indicator
Power On
Blink red twice
Standby
Green
Working
Blink green
High Temperature
Blink red and green alternately
Error
Blink red
Calibration
Zero-Calibration
Spindown-Calibration
Indicator
FCC Caution.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure
condition without restriction.
