User Manual.pdf
Jing Si E-Book
Quick Start Guide
TZ-901 E-Reader
EXXXX
TZ-901 Quick Start Guide
2
DRAFT v3
DRAFT v3
DRAFT v3
DRAFT v3
NOTES:
• If any of the items is damaged or missing, contact your
retailer.
• Do not put your TZ-901 E-Reader in an environment with
direct sunlight or with a temperature above 50oC. Doing so
may damage your TZ901 E-Reader.
• Refer to the user manual saved in your TZ-901 E-Reader for
more information.
Package contents
Micro USB cable
TZ-901 E-Reader Power adapter
Quick start guide
Jing Si E-Book
TZ-901
Leather holster Technical documentations
and warranty card
DRAFT v3
TZ-901 Quick Start Guide
3
DRAFT v3
DRAFT v3
DRAFT v3
Getting to know your TZ901 E-Reader
Touch screen
panel Previous/Scroll
up button
Next/Scroll
down button
Home button
Power button
Top view
Front view
TZ-901 Quick Start Guide
4
DRAFT v3
DRAFT v3
DRAFT v3
DRAFT v3
Bottom view
Audio speakers
Left view
Volume button
Speaker/Headset
port
microSD card slot
micro USB 2.0 port
Right view
Battery charge
indicator
DRAFT v3
TZ-901 Quick Start Guide
5
DRAFT v3
DRAFT v3
DRAFT v3
Charging your TZ-901 E-Reader
Charge your TZ-901 E-Reader for six (6) hours before
using it in battery mode for the rst time.
Connect the micro USB cable to the power adapter.
Plug the micro USB connector into your TZ-901 E-Reader.
Plug the power adapter into a grounded power outlet.
To charge your TZ-901 E-Reader:
TZ-901 Quick Start Guide
6
DRAFT v3
DRAFT v3
DRAFT v3
DRAFT v3
Turning your TZ-901 E-Reader on
To turn your TZ-901 E-Reader on, press the power button for
about three (3) seconds.
NOTES:
• To wake your TZ-901 E-Reader from standby mode, press the
power button.
• In the event that your TZ-901 E-Reader becomes
unresponsive, press and hold the power button and the
Home button at the same time to restart your TZ-901 E-
Reader.
DRAFT v3
TZ-901 Quick Start Guide
7
DRAFT v3
DRAFT v3
DRAFT v3
Saving les in your TZ-901 E-Reader
NOTE: Your TZ-901 E-Reader supports e-books in ePub, PDF,
CBZ, and TXT formats.
IMPORTANT! To save audio les and book les, ensure that
you save them in their corresponding folders. Save the audio
les in audio folder and e-book les in book folder.
To save les from your compter to your TZ-901 E-Reader:
1. Plug the micro USB connector into your TZ-901 E-Reader.
2. Plug the micro USB cable to your computer’s USB port.
3. On your TZ-901 E-Reader, tap Connect to PC.
4. On your computer, open Computer > TZ-901 then save
your les in your TZ-901 E-Reader.
TZ-901 Quick Start Guide
8
DRAFT v3
DRAFT v3
DRAFT v3
DRAFT v3
Installing your TZ-901 E-Reader to the
leather holster
To install your TZ-901 E-Reader to the leather holster:
3. Snap the lower end
corners of the TZ-901
E-Reader to the leather
holster’s holders in
place.
1. Open the bundled leather holster.
holder
holder
holder
holder
2. Place the TZ-901 E-
Reader facing up then
insert and slide it to the
leather holster until it
ts to the holders, as
shown.
DRAFT v3
TZ-901 Quick Start Guide
9
DRAFT v3
DRAFT v3
DRAFT v3
Appendices
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is
subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received,
including interference that may cause undesired
operation.
This equipment has been tested and found to comply with
the limits for a class B digital device, pursuant to Part 15
of the Federal Communications Commission (FCC) rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee
that interference will not occur in a particular installation.
If this equipment causes harmful interference to radio or
television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to
correct the interference by doing one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
TZ-901 Quick Start Guide
10
DRAFT v3
DRAFT v3
DRAFT v3
DRAFT v3
• Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
Changes or modications not expressly approved by the party
responsible for compliance could void the user‘s authority to
operate the equipment.
The antenna(s) used for this transmitter must not be co-
located or operating in conjunction with any other antenna or
transmitter.
RF Exposure Information (SAR)
This device meets the government’s requirements for
exposure to radio waves. This device is designed and
manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government.
The exposure standard employs a unit of measurement
known as the Specic Absorption Rate, or SAR. The SAR limit
set by the FCC is 1.6 W/kg. Tests for SAR are conducted using
standard operating positions accepted by the FCC with the
EUT transmitting at the specied power level in dierent
channels.
DRAFT v3
TZ-901 Quick Start Guide
11
DRAFT v3
DRAFT v3
DRAFT v3
The highest SAR value for the device as reported to the FCC is
1.27 W/kg when placed next to the body.
The FCC has granted an Equipment Authorization for this
device with all reported SAR levels evaluated as in compliance
with the FCC RF exposure guidelines. SAR information on
this device is on le with the FCC and can be found under
the Display Grant section of www.fcc.gov/oet/ea/fccid after
searching on FCC ID: VRSTZ901.
