LED LCD SMART TV
User's MANUAL
English Part No.: RN0332R61901
MADE FOR TODAY
SLD32A30RQ
MODEL
Date of Purchase
Please register your product at
Please keep your sales receipt and keep the record of the serial number
and the date of purchase in order to receive warranty parts and service.
The serial number is located at the back of the TV.
www.rca.com
Serial Number
Table of Contents
Preparation for Your New TV
Child Safety Guide
FCC Notice
Safety Precautions
Wall Mount Unit Specication
Product Specication
Limited Warranty for USA
Limitation of Warranty
United States Patents
Technical Support
Front Page
Preparation for Your New TV
Back Page
Congratulations on your purchase! As you enjoy your new product,
please keep these safety tips in mind :
The Issue Tune Into Safety
The home theater entertainment experience is a
growing trend and larger at panel displays are
popular purchases.
However, at panel displays are not always supported
on the proper stands of installed according to the
manufacturer’s recommendations.
Flat panel displays that are inappropriately situated
on dressers, bookcases, shelves, desks, speakers,
chests or cats may fall over and cause injury.
The consumer electronics industry is committed to
making home entertainment enjoyable and safe.
Use a mount that has been recommended by
the display manufacturer and/or listed by
an independent laboratory (such as UL, CSA,ETL ).
This Manufacturer Cares!
Wall Mounting IF YOU DICIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS
Caution and Warning
One size does NOT t all. follow the manufacturer's
recommandation for the safe installation and use of your
at panel display.
Carefully read and understand all enclosed instructions
for proper use of this product.
Don' t allow children to climb on or play with furniture and
television sets.
Don't place at panel displays on furniture that can easily
be used as steps, such as a chest of drawers.
Remember that children can become excited while watching
a program, especially on a "larger than life" at panel display.
Care should be taken to place or install the display where it
cannot be pushed, pulled over, or knocked down.
Care should be taken to route all cords and cables connected
to the panel display so that they cannot be pulled or grabbed
by curious children.
Child Safety Guide
Safety Precautions
FCC Notice
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water. For example, do not use near
a laundry tub, in a wet basement, or near a swimming pool, and the like.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions. Slots and openings in the cabinet
back or bottom are provided for ventilation, to ensure reliable operation
of the TV and to protect it from overheating. These openings must not
be blocked or covered. The openings should never be blocked by
placing the TV on a bed, sofa, rug, or other similar surface.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than the
other. A grounding-type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety.
If the provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
FCC Information
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio Communications.
However, there is no Guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning
theequipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit dierent from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Device complies with FDA radiation performance standards, 21 CFR
subchapter.
Caution: (Invisible) Laser Radiation when open.
Do not stare into beam.
Note: If there any changes or modications not expressly approved by the
party responsible for compliance could void the user’s authority to
operate the equipment.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specied by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid
injury from tip-over. A TV and cart combination should be moved
with care. Quick stops, excessive force, and uneven surfaces may
cause the TV and cart combination to overturn.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
For added protection for this TV receiver during a lightning storm, or
when it is left unused for long periods of time, unplug it from the wall
outlet and disconnect antenna or cable system.
This will prevent damage to the TV due to lightning and power line
surges.
14. Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been
dropped.
15. This TV should be operated only from the type of power supply
indicated on the rating label. If customer is not sure the type of
power supply in your home, consult your appliance dealer or local
power company. For TV remote control battery power, refer to the
operating instructions.
16. The TV set shall not be exposed to dripping or splashing. No objects
lled with liquids, such
as vases, shall be placed on the TV set.
17. Never push objects of any kind into this TV through openings as
they may touch dangerous voltage or other electrical parts that
could result in re or electric shock.
Never spill liquid of any kind into the TV.
18. Unplug the TV from the wall outlet before cleaning. Do not use
liquid or aero cleaners. Use a damp cloth for cleaning.
19. This TV should never be placed near or over a radiator or heat
resource. This TV should not be placed in a built-in installation such
as a bookcase or rack unless proper ventilation is provided or the
manufacturer's instructions have been adhered to.
20. Do not place this TV on an unstable cart, stand, tripod, bracket, or
table. The TV may fall, causing serious injury to someone, and serious
damage to the appliance.
21. Do not attempt to service this TV by yourself because opening or
removing covers may expose you to dangerous high voltage or
other hazards. Refer all servicing to qualied service personnel.
22. This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
23. WARNING: To prevent injury, this apparatus must be securely
attached to the oor/wall in accordance with the installation
instructions.
24. To reduce the risk of electric shock, the grounding of center pin of
plug must be maintained.
25. If an outside antenna or cable system is connected to the TV, be
sure the antenna or cable system is grounded to provide some
protection against voltage surges and built-up static charges.
Section 810 of the National Electrical Code, ANSI/NFPA NO.70,
provides information with respect to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrodes. (See gure A)
Before Turning On TV
Check Accessories
Check the accessories that are packed with your TV. (refer to Quick Start Guide)
Select TV Table Stand
Please refer to Quick Start Guide to carry out stand installing.
Select TV Location
Select a at, stable table to place your TV set. Please follow the
safety instructions when placing the TV.
Connection and Using
After placing your TV properly, you can connect the TV with power supply and cable components.
For further information, see “E-User’s Manual” page 6.
Note: If you need detailed information for your TV, please refer to E-User’s Manual and Quick Start Guide.
If you have any doubts about your ability
to safely install your at panel display,
contact your retailer about professional installation.
Follow all instructions supplied by the display
and wall mount manufacturers.
Make sure that the wall where you are mounting
the display is appropriate. Some block construction.
If you are unsure, contact a professional installer.
A minimum of two people are required for installation.
Flat panel displays can be heavy.
The minimum separation generally be used is at least 20 cm.
SLD32A30RQ
31.5 inches
American TV standard
ATSC/NTSC system
VHF : 2~13 UHF : 14~69
CATV : 1~135
Storage Temperature is
-20℃ ~ +60℃, -4℉ ~ +140℉
Operating Temperature is
0℃ ~ + 50℃, + 32℉ ~ + 122℉
Storage Humidity : Less than
85%RH (No condensation)
Operation Humidity : Less than
80%RH (No condensation)
AC 100-120V, 60Hz
RF input Cable/Antenna × 1
AV x 1 (with component)
Component x 1
HDMI × 3
Audio input L-AUDIO IN-R x1
Digital Audio Out × 1
L-AUDIO OUT-R x1
1366 x 768
Component/HDMI mode 480i, 480p, 720p, 1080i
With stand 28.8"H x 18.1"H x 7.9"D
Without stand 28.8"H x 17.1"H x 2.9"D
With stand 11.7 LBS (5.3kg)
Without stand 11.0 LBS (5.0kg)
< 42W
Standard IEEE 802.11 b/g/n
Frequency Band 2.412 ~ 2.4835 GHz ISM band
Sequrity WEP, TKIP, AES, WPA, WPA2
FCC ID XOMIPD32P619
Wi-Fi Module
Power Consumption
Weight
Dimensions
Model
Temperature
Humidity
Resolution
Diagonal Display Size
Television System
Channel Coverage
Power Supply
Video input
Audio output
Connection
Interface
Wall Mount Information
Model Unit Dimension (unit:mm) Screw
SLD32A30RQ VESA 200 x 100 M6 screws, length 20mm
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water. For example, do not use near
a laundry tub, in a wet basement, or near a swimming pool, and the like.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions. Slots and openings in the cabinet
back or bottom are provided for ventilation, to ensure reliable operation
of the TV and to protect it from overheating. These openings must not
be blocked or covered. The openings should never be blocked by
placing the TV on a bed, sofa, rug, or other similar surface.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than the
other. A grounding-type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety.
If the provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specied by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid
injury from tip-over. A TV and cart combination should be moved
with care. Quick stops, excessive force, and uneven surfaces may
cause the TV and cart combination to overturn.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
For added protection for this TV receiver during a lightning storm, or
when it is left unused for long periods of time, unplug it from the wall
outlet and disconnect antenna or cable system.
This will prevent damage to the TV due to lightning and power line
surges.
14. Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been
dropped.
15. This TV should be operated only from the type of power supply
indicated on the rating label. If customer is not sure the type of
power supply in your home, consult your appliance dealer or local
power company. For TV remote control battery power, refer to the
operating instructions.
16. The TV set shall not be exposed to dripping or splashing. No objects
lled with liquids, such
as vases, shall be placed on the TV set.
17. Never push objects of any kind into this TV through openings as
they may touch dangerous voltage or other electrical parts that
could result in re or electric shock.
Never spill liquid of any kind into the TV.
18. Unplug the TV from the wall outlet before cleaning. Do not use
liquid or aero cleaners. Use a damp cloth for cleaning.
19. This TV should never be placed near or over a radiator or heat
resource. This TV should not be placed in a built-in installation such
as a bookcase or rack unless proper ventilation is provided or the
manufacturer's instructions have been adhered to.
20. Do not place this TV on an unstable cart, stand, tripod, bracket, or
table. The TV may fall, causing serious injury to someone, and serious
damage to the appliance.
21. Do not attempt to service this TV by yourself because opening or
removing covers may expose you to dangerous high voltage or
other hazards. Refer all servicing to qualied service personnel.
22. This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
23. WARNING: To prevent injury, this apparatus must be securely
attached to the oor/wall in accordance with the installation
instructions.
Safety Strap
Caution: Pushing, pulling or climbing on the TV may cause the TV
falling. Do not let chlidren climb or hang on the TV. Always place the
TV on a sturdy, level, stable surface that can hold the weight of TV.
And if possible, secure the TV according to the instruction below.
Note: The fastening components such as screws are not supplied with TV.
Step one: Insert the M6 mounting screws into the upper two wall
mounting screw holes and fasten them (Figure B).
Step two: Insert anchors to wall and connect the bolts and anchors
with ropes or chains (Figure C).
Note A. The wall mount is not contained in the accessories sold with
television. We only provide the installing specications but not the wall
mount itself. If you need the mount, please consult with the local dealer
for a VESA wall mount. B. We strongly suggest to set the wall mount with
equipments of specication we ordered. If not, inappropriate installing
may cause damage to device or people. C. We suggest that you keep your
TV at least 2.36 inches(60mm) from the wall to prevent cable interference.
Warnings
1. Do not set up the wall mount by yourself. Please contact qualied
professionals for installation.
2. The TV should not be mounted on walls or surfaces which have an
angle more than 10 degrees with vertical direction. Otherwise the TV
set may fall.
3. The walls for mounting must have enough strength to hold the
whole weight of TV set. For example, concrete wall and brickwork
are eligible. Do not place the mount on soft walls such as earth walls
and plasterboard.
4. If spare parts of dierent specications (such as screws) are used
during mounting, consult with qualied professionals to make sure
these parts are safe and eective.
5. Before attaching the base to wall, ensure the holes for anchors are
in keeping with the installing rules. Otherwise there may exist some
potential problems.
6. Do not place any heating source under your television. Or else, it
can cause re.
7. Do not place the TV near anything dripping. Transducers and high
voltage wires should be kept far away from the apparatus too. Or
else, it may cause creepage, electric shock or bad resonance.
8. Do not place TV in a location where collision or vibration is liable
to happen.
9. In order to avoid unexpected falling of the TV set, do not put any
strong force on TV or wall mount after installing.
10. Be sure to unplug the TV before installing. Keep anything hard or
sharp away from the screen panel to prevent the scung.
11. After installing, if there is any need to move the cabinet, please
contact the qualied professionals.
Coverage - Labor
For a period of 12 months from date of purchase of your RCA product,
we will pay an authorized RCA service center the labor charge to repair
any defects in materials or workmanship in your television. If your
television is unrepairable we will provide you with a refurbished unit of
the same or better model.
Coverage - Parts
For a period of 12 months from date of purchase of your RCA product,
we will pay an authorized RCA service center for the new, or at our
option, refurbished replacement parts needed to repair any defects in
material or workmanship in your television. If your television is
unrepairable we will provide you with a refurbished unit of the same
or better model.
Coverage - LED LCD Panel
For a period of 12 months from date of purchase of your RCA product,
we will pay an authorized RCA service center for the new, or at our
option, refurbished LED LCD panel needed to repair any defects in
material or workmanship in your television. If your television is
unrepairable we will provide you with a refurbished unit of the same
or better model.
How to Obtain Service
For assistance (U.S.A) - if you purchased RCA product in U.S.A, please
call 1-888-977-6722.
Or visit www.rca.com
The service representative will review your options for service.
As a convenience we oer three ways to obtain warranty service. You
may mail your product to the address provided by the service
representative, you may take your product to an authorized service
center, or you may request in home service (servicer will determine if
product is serviceable in home or must be taken back to local service
center for repair). Service representative will supply instructions for
preferred service.
At the time of service proof of purchase such as original receipt, will
be required. Only 37” LCD size and above are applicable for in-home-
service.
Items Not Covered By Limited Warranty
Your limited warranty does not cover the following items:
-Un-installation, installation and adjustment of customer controls
and operating instruction.
-Batteries and customer replacement fuses -Damage due to misuse,
abuse, negligence or neglect including but, not limited to, damage
resulting from exposure to moisture, humidity or salt.
-Inability to receive a signal due to problems not caused by the
product.
-Damage to the product due to images burnt into the screen.
-Product purchased or serviced outside of Country of Original
Purchase.
-i.e. Purchased USA can not be serviced in Mexico/Purchased in
Mexico can not be serviced in USA.
-Product modied or incorporated into other products.
-Damage due to acts of nature, including but not limited to,lightning
damage or ooding.
-Service calls which do not involve any defect in materials or
workmanship.
Wall Mounting
Unit Specication
Product Specication
Limited Warranty for USA
Limitation of Warranty
Commercial Use Excluded
This limited warranty only applies to products used for personal use
and does not cover any product used for institutional, commercial or
rental purposes.
THIS LIMITED WARRANTY IS THE SOLE AND
EXCLUSIVE WARRANTY APPLICABLE TO THIS
PRODUCT. ON CORP US, INC., THE MANUFACTURER
OF THIS PRODUCT, DISCLAIMS ALL OTHER
WARRANTIES, EXPRESSED OR IMPLIED (INCLUDING
ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE). NO VERBAL OR
WRITTEN INFORMATION GIVEN BY ON CORP US, INC., ITS
AGENTS, INDEPENDENT CONTRACTORS, SALES
REPRESENTATIVES, EMPLOYEES, RETAIL DEALERS,
WHOLE SALE DISTRIBUTORS OR ANY OTHER THIRD
PARTY SHALL CREATE A GUARANTY OR INCREASE.
EXPAND OR MODIFY THE SCOPE OF THIS LIMITED
WARRANTY.
THIS LIMITED WARRANTY PROVIDES THE SOLE AND
EXCLUSIVE REMEDY FOR THE CONSUMER OF REPAIR
OR REPLACEMENTOF THE PRODUCT. ON CORP US,
INC. SHALL NOT BE LIABLE FOR SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES
ARISING OUT OF THE USE OF THEP RODUCT OR
ARISING OUT OF A BREACH EXPRESSED OR IMPLIED
WARRANTY ON THIS PRODUCT.
THIS LIMITED WARRANTY AND THE DISCLAIMERS
CONTAINED HEREIN ARE GOVERNED BY THE LAWS
OF THE STATE OF INDIANA. EXCEPT TO THE EXTENT
PROHIBITED BY APPLICABLE LAW, ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE IS LIMITED TO
APPLICABLE LIMITED WARRANTY PERIOD(S) SET
FORTH ABOVE.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS
AND YOU ALSO MAY HAVE OTHER RIGHTS THAT
VARY FROM STATE TO STATE.
24. To reduce the risk of electric shock, the grounding of center pin of
plug must be maintained.
25. If an outside antenna or cable system is connected to the TV, be
sure the antenna or cable system is grounded to provide some
protection against voltage surges and built-up static charges.
Section 810 of the National Electrical Code, ANSI/NFPA NO.70,
provides information with respect to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrodes. (See gure A)
HDMI, the HDMI logo, and High-Denition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC
United States Patents
U.S Patent No. 5,511,096
U.S Patent No. 5,621,761
U.S Patent No. 5,703,887
U.S Patent No. 5,745,522
U.S Patent No. 5,511,082
U.S Patent No. 5,371,902
U.S Patent No. 5,233,629
U.S Patent No. 5,408,502
U.S Patent No. 5,311,546
U.S Patent No. 5,696,518
U.S Patent No. 5,475,716
U.S Patent No. 5,537,420
U.S Patent No. 5,519,733
U.S Patent No. 5,579,348
U.S Patent No. 5,363,408
U.S Patent No. 5,321,725
Technical Support
Your Product Includes Free Lifetime Tech Support
We can help with
• New product setup
• Connecting your devices
• Technical problems
We welcome any questions or suggestions from you.
Feel free call us at one of the numbers provided below.
Our customer service representatives will be more than
happy to assist you over the phone.
ON Corp US, Inc.
10920 Via Frontera, Ste 540
San Diego, CA 92127, U.S.A.
2015 ON Corporation
RCA is a trademark of RCA Trademark Management
SAS used under license to ON Corporation.
200mm
100 mm
Table
Contact us
Phone 1-888-977-6722
Homepage www.rca.com
Hours of operation
6 AM - 10 PM Monday - Sunday CST
Note: Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
