User manual
1
Qolsys Z-Wave Plus Module
General Applications:
The Qolsys Z-Wave Plus Module features the 500 series Z-Wave Wireless Microcontroller silicon from
Sigma Designs, providing an air interface to certified Z-Wave devices. OEMs that integrate this module
will be able to connect to a variety of smart devices for home automation and control, for example:
thermostats, door locks, light bulbs, and electrical outlets. Note: these smart devices must be Z-Wave
certified.
Installation and Operation:
The module has a simple 8 pin header interface for power, reset, and UART connections. The mounting
screw is required for mechanical stability and to ensure a robust ground connection. The antenna is
permanently fixed to the module. Do not place any large pieces of metal around or near the antenna, as
it will inhibit performance. Do not modify the antenna in any way.
2
The Qolsys Z-Wave Plus Module operates at 908 MHz with an output power up to +4dBm. Data and
protocol specifications are beyond the scope of this document. Please contact Qolsys for the technical
specifications.
FCC Compliance:
FCCID: 2AAJXQS-ZWAVE
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
IC Compliance:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of the
device.
3
Cet appareil est conforme aux normes d’exemption de licence RSS d’Industry Canada. Son
fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer
d’interférence et (2) cet appareil doit accepter toute interférence, notamment les interférences qui
peuvent affecter son fonctionnement.
CAN ICES-3 (B)/NMB-3(B)
Warranty Information:
IMPORTANT! Changes or modifications not expressly approved by Qolsys Inc. will void the user’s
authority to operate the equipment, as well as warranty for the product.
