User Manual
![](/img.php?id=3629319&img=bg1.png)
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, (2) This device must
accept any interference received, including interference that may cause undesired
operation.
FCC Part 15 Class B-specific
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Warning
Changes or modifications not expressly approved by the party responsible for compliance
could void the user‘s authority to operate the equipment.
Radiation Exposure Statement
This equipment complies with the FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 20 centimeters between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
Clover Network, Inc.
415 N Mathilda Ave, Sunnyvale, CA 94085, USA
EU Declaration of Conformity
Hereby, Clover Network. Inc. declares that the radio equipment type, C500 & P550 are in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address:
help.clover.com/eu-compliance
The frequency band and the maximum transmitted power in EU are listed below:
WLAN (C500)
2400MHz - 2483.5MHz: 19.5 dBm (EIRP)
5150MHz – 5250MHz: 21 dBm (EIRP)
5250MHz – 5350MHz: 21.5 dBm (EIRP)
5470MHz – 5725MHz: 22 dBm (EIRP)
NFC (P550)
NFC is only turned on within 60s when the contactless payment will be made and its max.
power is 26 dBuA/m at 3m.
Restrictions in AT/BE/BG/CZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/CY/LV/LI/LT/LU/HU/MT/NL/
NO/PL/PT/RO/SI/SK/TR/FI/SE/CH/UK/HR. 5150MHz-5350MHz is for indoor use only.
Caution: Exposure to Radio Frequency Radiation
This equipment complies with EU radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
Tablet:
Model: C500
FCC ID: HFS-C500
Printer (Optional):
Model: P500
EU Importer
Marketplace Merchant Solutions Ltd
Unit 9, Richview Office Park, Clonskeagh, Dublin 14, Ireland
Waste Electrical and Electronic Equipment-WEEE
NOTE: This product is covered electronic equipment under the European Union’s Waste
from Electrical and Electronic Equipment (“WEEE”) Directive (2012/19/EU). The WEEE
Directive requires that covered equipment be collected and managed separately from
typical household waste in all EU member states. Please follow the guidance of your local
environmental authority or ask the shop where you purchased the product for collection or
recycling options.
Printer:
Model: P550
FCC ID: HFS-P550
Clover Station
Quick Start Guide
Kurzanleitung • Instructions de démarrage
Guía de inicio rápido • Guida introduttiva
![](/img.php?id=3629319&img=bg2.png)
U.S.A: clover.com/setup
Europe: eu.clover.com/setup
5v/2A 5v/1A
12
1
2
3
4
5
6
Press power button until Clover logo appears.
Einschalttaste gedrückt halten bis Clover logo erscheint.
Tenere premuto il tasto di alimentazione fino
a quando non compare il logo Clover.
Presione el botón de encendido hasta
que el logo de Clover aparezca.
Appuyez sur le bouton d’alimentation jusqu'à
ce que le logo Clover s'affiche.
