Quanta Microsystems UWAC4Z USB Wireless Adapter User Manual UserManual

Quanta Microsystems, Inc. USB Wireless Adapter UserManual

User Manual

User Manual
USB Wireless Adapter
Model
No.:
UWA-C4Z
V
ersion:
v0.3
Date:
Feb
09,
2012
Contents
1. Revision History ............................................................................................................... 4
2. Related Documents .......................................................................................................... 4
3. Overview ........................................................................................................................... 5
3.1. Scope......................................................................................................................5
3.2. Features .................................................................................................................. 5
3.3. Specification .......................................................................................................... 6
3.4. Interface definition................................................................................................. 7
3.5 RoHS & Green Parter Compliant .......................................................................... 7
3.6 EMI EMC certifications.........................................................................................7
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this
equipment.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
This device complies with RSS-210 of the Industry Canada Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux
appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions
suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce
dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de
provoquer un fonctionnement indésirable.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies
pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec
un minimum de 20 cm de distance entre la source de rayonnement et votre corps.
1. Revision History
Date Release Author Description
Apr 13, 2011 0.1 Jack Ong First release
Feb 06, 2012 0.2 Jack Ong Added Engineering Sheet
Feb 09, 2012 0.3 Jack Ong Added Housing drawing
2. Related Documents
Date Author Document(s)
3. Overview
3.1. Scope
This document describes the specifications of ZU210 IEEE
802.15.4 RF4CE ZigBee transceivers module. The low power
consumption and smaller size are suitable for consumer electronic. ZU210
also provides a cost-effective solution for short-range data links and networks.
3.2. Features
f
Extremely low cost
f
Ease of implementation
f
Reliable data transfer
f
Short range operation
f
Appropriate levels of security
Characteristic Min Typ Max Unit
DC Electrical Characteristics
Normal mode current --- TBD --- mA
Idle mode current TBD mA
Sleep mode current TBD
Transmit
Transmit Power 14 17 20 dBm
Transmit Center Frequency Tolerance -20 0 20 ppm
Error Vector Magnitude (EVM) (over temp.) --- 15 35 %
Receiver
Sensitivity for 1% Packet Error Rate (PER) --- -102 -95 dBm
Maximum Input Power -10 dBm
Channel Rejection for 1% PER
(desired signal -100 dBm)
+5 MHz (adjacent channel)
-5 MHz (adjacent channel)
+10 MHz (alternate channel)
-10 MHz (alternate channel)
---
---
---
---
45
45
56
56
---
---
---
---
dB
dB
dB
dB
3.3. Specification
f
Absolute Maximum Ratings
Rating Symbol Value Unit
Power Supply Voltage V
BATT
, V
DDINT
-0.3 to 5.5 Vdc
Storage Temperature Range Tstg -20 to 70 °C
f
Operating condition
Rating Symbol Min Typ Max Unit
Power Supply Voltage V
BATT
, V
DDINT
4.5 5 5.5 V
DC
Operation Temperature Rang T
A
-10 25 60 °C
Operation Frequency f 2.405 2.475 GHz
f
Characteristic (operating voltage=V
DC
; temperature=25°C)
3.4. Interface definition
f
Connector 4-PIN
Pin Pin Name
4 GND
3 D+
2 D-
1 VDD
3.5. RoHS & Green Parter Compliant
ZU210 is fully compliant to RoHS & Green Parter requirement.
3.6. EMI EMC certifications
ZU210 is fully compliant with FCC regulatory requirements.
