RAZOR USA 001 15155040 User Manual RipStikElectric MAN US 151207 indd

Safety Warnings ...........................................................................................1-2

Before You Begin.............................................................................................. 3

Charging the Battery ........................................................................................ 5

Pre-Ride Checklist ............................................................................................ 5

Repair and Maintenance.............................................................................7-10

Troubleshooting Guide ................................................................................... 11

RipStik Electric Parts ...................................................................................... 12

Warranty and Contact Information ................................................................ 14

WARNING: Riding a RipStik Electric does present potential risks and

caution is required. Like any riding product, a RipStik Electric has inherent

hazards associated with its use (for example, falling off or riding it into a

can and do present potential hazards plainly associated with their use, it is

well recognized THE NEED FOR EXERCISE OF PARENTAL RESPONSIBILITY IN

SELECTING RIDING PRODUCTS APPROPRIATE TO THE AGE OF A CHILD, OR

PARENTAL SUPERVISION IN SITUATIONS IN WHICH CHILDREN OF VARIOUS

AGES MAY HAVE ACCESS TO THE SAME RIDING PRODUCTS, IS IMPORTANT.

Not every product is appropriate for every age or size of child, and different

age recommendations are found within this category of product which are

intended to reflect the nature of the hazards and the expected mental or

is appropriate to fit or maintain control of the RipStik Electric. Keep this

product away from small children and remember that this product is intended

for use only by persons who are, at a minimum, completely comfortable and

competent while operating the product.

Razor recommends that children under the age of 9 not be permitted to

use this product. This recommendation is based not just on age or weight

or height – it reflects consideration of expected maturity and skills as well

as physical size. The recommended rider age of 9 years or older is only

an estimate and can be affected by the rider’s size, weight, or skills – not

every rider 9 years old or older will be suited to the product. Certainly, any

Persons with any mental or physical conditions that may make them

susceptible to injury, impair their physical dexterity or mental capabilities

to recognize, understand, and follow safety instructions and to be able to

understand the hazards inherent in the use of any ride-on product, should not

use or be permitted to use products inappropriate for their abilities. Persons

with heart conditions, head, back or neck ailments (or prior surgeries to these

areas of the body), or pregnant women, should be cautioned not to operate

serviceable condition. Check that the wheels are free of flat spots from

wear. The product should be maintained and repaired in accordance with

the manufacturer’s specifications, using only the manufacturer’s authorized

replacement parts, and should not be modified from the manufacturer’s

original design and configuration.

The normal powered top speed of this product will be approximately 10 mph

(16 km/h), which can be affected by conditions, such as rider weight, inclines

and battery charge level. Avoid excessive speeds that can be associated with

downhill rides.

Ride defensively. Watch out for potential obstacles that could catch your

wheel or force you to swerve suddenly or lose control. Be careful to avoid

pedestrians, skaters, skateboards, scooters, bikes, children or animals who

may enter your path, and respect the rights and property of others.

The RipStik Electric is intended for use on flat, dry surfaces, such as pavement

or level ground, without loose debris, such as sand, leaves, rocks or gravel.

withstand abuse from misuse, such as jumping, curb grinding or any other

type of stunts. Racing, stunt riding, or other maneuvers also enhance risk of

loss of control, or may cause uncontrolled rider actions or reactions.

Never allow more than one person at a time to ride the product.

Do not ride at night or when visibility is limited.

Never use near steps or swimming pools.

Do not allow hands, feet, hair, body parts, clothing, or similar articles to come

in contact with moving parts or wheels while the motor is engaged.

Do not touch electric motor when in use or immediately after riding.

Never use headphones or a cell phone to talk or text when riding.

Always wear proper protective equipment, such as an approved safety helmet

(with chin strap securely buckled), elbow pads, kneepads and wrist guards. A

helmet may be legally required by local law or regulation in your area. A long-

sleeved shirt, long pants, and gloves are recommended. Always wear athletic

shoes (lace-up shoes with rubber soles) and keep shoelaces tied and out of

the way of the wheels and motor. Never ride barefooted or in sandals.

The charger supplied with the product should be regularly examined for

damage to the cord, plug, enclosure and other parts. In the event of such

damage, the product must not be charged until the charger has been repaired

or replaced.

Use only with the recommended charger.

Use caution when charging.

The charger is not a toy. Charger should be operated by an adult.

Remove contents from box. Remove the separators that protect the components from damage during shipping. Inspect

the contents of the box for scratches, dents or kinked cables that may have occurred during shipping. Because the

RipStik Electric was assembled and packed at the factory, there should not be any problems, even if the box has a few

scars or dents.

No assembly required.

In the event of such damage,

the RipStik Electric must not be

charged until it has been repaired

or replaced.

Chargers have built-in overcharge

protection to prevent battery from

being overcharged.

during regular use, this is a normal

response and is no cause for

Wall outlet and product -

Green (charged)

even if light turns green prior to

6 hours.

WARNING: Battery charge

can deplete over time. Periodically

recharge battery when not in use.

Your electric product may not have a fully charged battery; therefore you must charge the battery prior to use. Be sure to

charge the battery in a clean, dry location away from direct sunlight, flames or sparks.

of time.

• Unplug charger from the wall outlet when not in use.

• Failure to recharge battery periodically may result in a

battery that will not accept a charge.

product is not in use. If the power switch is left on for

an extended period of time, the battery may reach a

stage at which it will no longer hold a charge.

• To ensure long battery life, never store the product in

and usage of the product.

charger into the charger port. The

light on the charger should turn

red during charging. The light will

turn green again when charging is

complete.

outlet. The light on the charger

should be green.

turn on, try a different outlet.

(Note: Charger design may vary from

feature, the RipStik Electric is

designed to cut power to the motor

when the remote knob is in the

“STOP” or neutral position.

(without having to kick start), if

the remote is in the “GO” position

motor assistance.

To slow more rapidly to a stop, move the remote knob down to the stop position and hold. This will engage dynamic

motor braking and the product will slow down more quickly.

Stepping off the product also works to stop, and releasing the remote knob will cut power to the motor.

remove the six (6) screws attaching

the deck plate to the platform.

Remove the deck plate.

tighten the six (6) screws attaching

the deck plate to the platform.

mm wrench, loosen the nut on the

caster and remove caster. Using

two (2) 5 mm Allen wrenches,

Secure in place with nut removed in

step 2. Re-attach wheel to caster.

Refer to step 2 above.

if unsure about any repair or

Using two (2) 5 mm Allen wrenches,

loosen coupling bolt and remove

wheel from caster.

in the center of the wheel is aligned

with the holes in the bearing before

inserting the coupling bolt.

Secure tightly into place.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

WARNING: Changes or modifications to this product not expressly approved by Razor USA LLC, could void the user’s authority to operate the equipment.

RipStik Electric.

This Limited Warranty will be void if the product is ever:

• used in a manner other than for recreation or transportation;

• modified in any way;

• rented.

The manufacturer is not liable for incidental or consequential loss or damage

due directly or indirectly to the use of this product.

Razor does not offer an extended warranty. If you have purchased an extended

warranty, it must be honored by the store at which it was purchased.

For your records, save your original sales receipt with this manual and write

Cerritos, CA 90703

+1 866 467 2967

Re:creation Limited

2 Meadows Business Park

Station Approach, Blackwater

Camberley, Surrey GU17 9AB

P.O. Box 3610

Cerritos, CA 90703

+81 50 7579 6622

Razor USA LLC (Europe)

Handelsweg 2

2742 RD Waddinxveen

+1 800 244 543

contact information is listed below:
