Keypads & Readers 9212i
9212iLW
ZL9212
In or Out... we make it Easy!®
9 Series Digital Access Control
9212iLW
Dimensions
3-3/8”x 5-1/8” x 5/8”
(85.7mm x 130.2mm x 15.9mm)
Highlights
• Interior Use (9212i)
• Exterior or Interior Use (9212iLW)
• Accommodates 120 Users
• Microprocessor and EEPROM
Technology
• Keypad Programmable
• 2-Year Limited Warranty
Applications
INTERIOR/EXTERIOR
Ideal for traffic control applications
• Commercial
• Office Buildings
• Warehouses
• Industrial
• Residential
• Healthcare Facilities
Stand-Alone
Flush Mount
Keypads
The 9212 Series keypads are designed
for basic access control or code control
for up to four individual devices.
These keypads are the perfect choice
for controlling electric or electromag-
netic locks, security systems, elevator
control, gate controls, or other types of
equipment requiring on/off or
momentary control inputs.
9212i
Dimensions
2-3/4”x 4-1/2” x 1-1/4”
(69.8mm x 114.3mm x 31.8mm)
Features
• Keypad programmable
• Single-gang flush-mount design
• 120 user capability
• Electronics mounted on back
of keypad
• Stainless steel faceplate
• Three LED’s to indicate status and
provide user with visual PIN entry
confirmation
• Field selectable 12-24 VAC/VDC
9212i - Interior Use Only
• Input trigger for Request to Exit or
other open circuit contact
• Up to 4 independant outputs
assignable by code
• All outputs programmable for latched
or timed operation
9212iLW- Interior & Exterior Use
• Backlit, hardened keys
• Heavy chrome plated trim ring
• Key press feedback via sounder and
yellow LED
• Built-in assignable sounder
• Bi-color Red/Green LED indicates
relay status
©2011 RUTHERFORD CONTROLS INT’L CORP. WWW.RUTHERFORDCONTROLS.COM
USA: 2517 SQUADRON COURT, SUITE 104, VIRGINIA BEACH, VA 23453 • CANADA: 210 SHEARSON CRESCENT, CAMBRIDGE, ON N1T 1J6
PHONE • 1.800.265.6630 • 519.621.7651 • FAX: 1.800.482.9795 • 519.621.7939 • E-MAIL: SALES@RUTHERFORDCONTROLS.COM
R10/11SH
®
Specifications 9212i
9212iLW
In or Out... we make it Easy!®
NOTE: Not to scale. Specications are subject to change without notice.
©2011 RUTHERFORD CONTROLS INT’L CORP. WWW.RUTHERFORDCONTROLS.COM
USA: 2517 SQUADRON COURT, SUITE 104, VIRGINIA BEACH, VA 23453 • CANADA: 210 SHEARSON CRESCENT, CAMBRIDGE, ON N1T 1J6
PHONE • 1.800.265.6630 • 519.621.7651 • FAX: 1.800.482.9795 • 519.621.7939 • E-MAIL: SALES@RUTHERFORDCONTROLS.COM
Description of Features
Memory 120 users. Non-volatile EEPROM memory means your codes and instructions will be there
whether you remove power for ve minutes or ve years. This is standard on all models.
Main Relay
9212i series features a Form C relay (9212i rated at 5A @ 24VDC and 9212iLW rated
at 2A) tough enough to handle virtually any low-voltage equipment or electronic locking
device.
Programming
All programming is accomplished entirely from the front of the keypad. LED and/or
sounder guidance makes programming a snap and changing codes a matter of seconds for
an authorized user.
Auxiliary Outputs
(9212i only)
Each output to be individually timed from 1 to 90 seconds or act as a toggle switch.
Outputs may be triggered individually (9212i only) or in combination by any user code.
Outputs have 50mA negative voltage.
Accessories
Power
Supplies
Avalable in Canada & the USA:
T1003 Plug-In/UL transformer 12VDC–1.5Amp
10-5 PDD-FT Power Supply (w/power distribution device - re trigger output),12VDC–5 amp, 24VDC–3Amp
10-5 Power Supply only 12VDC–5Amp / 24VDC–3Amp
9310RB Relay Board, 12/24VDC–10Amp
Available in the USA ONLY:
10-175UL Power Supply (w/re alarm interface) 12/24 VDC - 1.75Amp
Available in CANADA ONLY:
1012NR Power Supply, no relay 12VDC - 1Amp
1024NR Power Supply, no relay 24VDC - 1Amp
1012 FPD-1A Power Supply (w/re panel disconnect) 12VDC - 1Amp
1024 FPD-1A Power Supply (w/re panel disconnect) 24VDC - 1Amp
1012 FPD-2A Power Supply (w/re panel disconnect) 12VDC - 2Amp
1024 FPD-2A Power Supply (w/re panel disconnect) 24VDC - 2Amp
RCI also offers a complete line of Electromagnetic Locks, Electric Strikes,
Power Supplies, Switches, Keypads & Readers, Exit Devices, Systems & Door Hardware.
Integrated Access Control
For complete integrated Access Control applications, ask about our QuickSystems® Access Control Systems.
These convenient QuickSystems® provide the features of a full stand-alone Access Control System – all in one box at one low price.
