45235 BW Wireless Monitor
INSTALLATION
INSTRUCTIONS
Congratulations on your purchase of the JASCO™ Wireless Camera
system(45235 Wireless monitor) All JASCO™ Wireless Cameras
includes high quality video and audio components. The 45235 BW
Wireless monitor System is a combined wireless camera and video
monitor/ receiver. The 45235 BW Wireless monitor surveillance
system is an ideal combination for monitoring the porch, watching the
yard, pool, pets or the baby. It is also suited to many small business
applications.
PRODUCTION FEATURES
_900MHz wireless technology
_Plug‘n’play installation
_High resolution black and white video camera
_Built-in microphone transmits sound from camera to TV
_High quality audio and video components for long life
_Supports up to 2 cameras
_Auto/Manual switching between cameras and channels LED
indicated
_IR LED enable night vision.
_AC or battery operation (batteries not included)
_Sound detection and alert
_Alert Volume and sound detection sensitivity are adjustable.
_Has one A/V output jack
_Channel lock
SYSTEM Contents
Please check and identify all the parts before proceeding with the
installation.
❑ Wireless Camera ❑ Monitor
❑ Fixing kit ❑ 1 x 9V Camera Adapter
❑ 1 x 13.5V Monitor
SETUP INSTRUCTIONS
Camera Transmitter
1. Unpack the Camera/ Transmitter
2. Decide on wall or desk/table mounting the camera. If wall mounting
there is a useful drilling guide on the back cover of these
instructions. The camera can be adjusted for both by rotating the
camera head to the required position.
3. Decide whether to connect using AC power or battery (not
included). If using batteries please install appropriative LI polymer
batteries. If using the power adapter, remove Battery and connect
power jack. Make sure the camera is positioned no more than 51/2
feet from an AC power outlet.
4. Select the channel on the slide switch under the camera housing by
switching Left or Right. Switch is preset to Channel 1.
The Camera/Transmitter installation is now complete.
Monitor/ Receiver
1. Unpack the Monitor/Receiver.
2. Plug the monitor power adapter into the power jack and plug the
power adapter into any AC power outlet. Turn on the monitor by
pressing front push button. Alternatively remove the battery
compartment lid on the underside of the unit and install 10 x C type
batteries (not included).
3. The Monitor/ Receiver installation is now complete.
Optimizing the 45235 BW Wireless mon Video System
The 900MHz video signals pass easily through your home’s interior
walls, but the signal may be reflected by power wires or plumbing
inside the wall. Usually a slight adjustment of the Monitor/Receiver
and/or Camera/Transmitter antenna will improve reception. Take care
not to force the antennas past their lock positions.
Sound level can be adjusted using the volume control knob on the
front of the Monitor/Receiver.
Adjust Brightness/Contrast as required using controls on the rear of
the Monitor/Receiver.
If needed the Vertical Hold can also be adjusted at the rear.
Adjust sound trigger sensitivity as required using controls on the rear
of the monitor.
The alert volume can also be adjusted on the rear of the monitor.
The most common source of interference are microwave ovens and
mobile phones. Try to avoid mounting the Monitor/Receiver near a
microwave oven or other source of RF interference such as cordless
phones.
Sound detecting on monitor
Monitor has a sound detecting function, when the sound level from
cameras is great than presetting level on monitor, an audio alert will
sound on the monitor. The volume control for the alert is on the rear of
the monitor. Additionally a red light will flash on the front of the
monitor.
ADDING ADDITIONAL CAMERS
You can add up to 2 additional cameras to your system.
45235-Wireless Camera Accessory
(Includes Wireless Camera, Power Adapter and Fixing Kit)
Channel Selection
In “Manual Mode” individual channels may be selected. Pressing the
button on the right will select “Manual” and the“Manual”LED
indicator will turn green. When the sound from cameras is great than
monitor’s presetting level, an audio alert will sound on the channel
selected.
In “Auto Cycle Mode” the Monitor/Receiver searches between the
channels available. To select “Auto” press the button on the left and
the “Auto” LED indicator will turn green. When the sound from
cameras is great than monitor’s presetting level, an audio alert will
sound; you need to check which camera was triggered by the sound.
To avoid searching empty channels, which do not have a camera
connected, make sure the slide switch on the rear of the
Monitor/Receiver has the corresponding switch in the correct position
for each camera. Example shows a 2-camera installation.
Cycle Time Setting (Time taken to switch between cameras)
To alter the cycle time press both of the buttons on the front of the unit
simultaneously. Each beep is one extra second of cycle time added.
The cycle time can be verified by flashing LED when you release, one
flash stand for one second. Cycle time can be set between 2-30
seconds. The cycle time is preset to 4 seconds.
USING THE 45235 SYSTEM WITH A VCR
You can connect a VCR to the 45235 System. This allows you to
record the picture from your Monitor/Receiver.
TROUBLE SHOOTING
If you are having trouble operating this product, please consult the guide below:
SYMPTOM REMEDIES
No camera picture
1. Check all connectors. Make sure camera(s) and receiver are
switched ON.
2. Ensure camera(s) and receiver are set to correct channel(s).
3. Make sure camera is within range of receiver.
Blank monitor
1. Make sure receiver is switched ON.
2. If using AC adapter, make sure it is plugged in.
3. If using batteries, make sure they are installed correctly, or
try recharging(replacing) them.
Interference on camera
1. Make sure each camera (transmitter) is within range, and
that no large obstructions are blocking the signal.
2. Try repositioning the camera, receiver or both to improve the
reception quality.
3. If a camera is positioned close to the receiver, point antenna
away from the receiver.
4. Reposition other nearby equipment transmitting on the
900MHz frequency.
Audio problems
1. Ensure the volume is turned up sufficiently on the Monitor
(or TV).
2. Make sure the sound is within the microphone range.
3. If the unit emits a loud wailing sound (feeds back), try
moving the camera away from the receiver or angle the
receiver differently.
SPECIFICATIONS
Camera
TV System PAL or NTSC
Integrated Lens 5.6mm, F2.0 fixed focus
Resolution 360 horizontal TV Lines
Signal/Noise Ratio 46 dB
High-Speed Electronic Shutter 1/60 - 1/15,000 sec
Image Sensor 1/4” CMOS
Min. Illumination 0.1 lux
Current Consumption 80~140mA
Overall Size 2.35”W x2.74Hx3.16D
Frequency Range 910 - 920 GHz
Modulation FM
Video Signal/Noise Ratio 46db
Audio Signal/Noise Ratio 45db
Channel Selection Electronic tuning
Case Finish UV resistant ABS plastic
Receiver/Monitor
Frequency Range 910 - 920 GHz
Signal/Noise Ratio 40dB
Operating
Temperature
-10
o
C
to
+40
o
C
Output
Audio/Video
Humidity
Less
than
85%
Current
Consumption
Approx.
800
mA
Overall
Size
5.7”
W
x
7.28”
H
x
8.46”
D
WARRANTY
This product has a one year manufacturer’s warranty which covers
parts and labor only. In the unlikely event that you encounter a
problem, the unit should be returned to Customer Care,
FCC NOTE:
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the
user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
DRILLING
TEMPRATE
If
you
decide
to
mount
the
camera
on
a
wall,
use
this
page
as
a
guide
for
drilling
the
required
holes
