RF Technology 50A 25 - 50 MHz Base Station Transceiver User Manual Exciter operations manual

RF Technology Pty Ltd 25 - 50 MHz Base Station Transceiver Exciter operations manual

Exciter operations manual

Eclipse Series
RF Technology
rfinfo@rftechnology.com.au
November, 2001
T50 Transmitter
Operation and Maintenance Manual
This manual is produced by RF Technology Pty Ltd
10/8 Leighton Place, Hornsby NSW 2077 Australia
Copyright © 2001 RF Technology
Page 2 RF Technology T50
CONTENTS CONTENTS
Contents
1 Operating Instructions 5
1.1 Front Panel Controls and Indicators 5
1.1.1 PTT 5
1.1.2 Line 5
1.1.3 POWER LED 6
1.1.4 TX LED 6
1.1.5 ALARM LED 6
2 Transmitter Internal Jumper Options 7
2.1 Serial I/O Parameters 7
2.2 Line Terminators 7
2.3 Exciter Low Battery Level 7
2.4 External PA Parameters 7
2.5 LOOP Volts Select 7
2.6 Direct Audio (TONE) Select 8
2.7 Direct Audio (TONE) High Pass Filter Select 8
2.8 Transmit Time 8
2.9 Channel Selectable Parameters 8
3 Transmitter I/O Connections 8
3.1 25 Pin Connector 8
3.2 9 Pin Front Panel Connector 9
4 Channel and Tone Frequency Programming 10
4.1 Setting Options 10
4.2 Setting Channel Parameters 11
5 Circuit Description 13
5.1 T50 Master Schematic (Sheet 1) 13
5.2 Microprocessor (Sheet 2) 13
5.3 Audio Processing Section (Sheet 3) 13
5.4 Line Input Processing Section (Sheet 4) 13
5.5 Tone Generation Section (Sheet 5) 20
5.6 Frequency Synthesiser (Sheet 6) 21
5.6.1 The Modulation PLL 21
5.6.2 The Channel PLL 22
5.6.3 The External Reference Divider 23
5.6.4 The DAC 23
5.6.5 The VCOs and the RF Output 24
5.7 Voltage Controlled Oscillators (Sheet 7) 24
5.8 1W Broadband HF Power Amplifier (Sheet 8) 26
5.9 Power Generation Section (Sheet 9) 26
6 Field Alignment Procedure 27
6.1 Standard Test Equipment 27
6.2 Invoking the Calibration Procedure 28
6.3 The “Miscellaneous” Calibration Procedure 28
6.4 The “Reference” Calibration Procedure 29
RF Technology T50 Page 3
CONTENTS CONTENTS
6.5 The “Deviation” Calibration Procedure 31
6.6 The “Tone Deviation” Calibration Procedure 32
6.7 The “Line” Calibration Procedure 33
6.8 The “Power” Calibration Procedure 34
7 Specifications 36
7.1 Overall Description 36
7.1.1 Channel Capacity 36
7.1.2 CTCSS 37
7.1.3 Channel Programming 37
7.1.4 Channel Selection 37
7.1.5 Microprocessor 38
7.2 Physical Configuration 38
7.3 Front Panel Controls, Indicators and Test Points 38
7.3.1 Controls 38
7.3.2 Indicators 38
7.3.3 Test Points 38
7.4 Electrical Specifications 38
7.4.1 Power Requirements 38
7.4.2 Frequency Range and Channel Spacing 39
7.4.3 Frequency Synthesizer Step Size 39
7.4.4 Frequency Stability 39
7.4.5 Number of Channels 39
7.4.6 Antenna Impedance 39
7.4.7 Output Power 39
7.4.8 Transmit Duty Cycle 39
7.4.9 Spurious and Harmonics 39
7.4.10 Carrier and Modulation Attack Time 40
7.4.11 Modulation 40
7.4.12 Distortion 40
7.4.13 Residual Modulation and Noise 40
7.4.14 600Ω Line Input Sensitivity 40
7.4.15 Test Microphone Input 40
7.4.16 External Tone Input 40
7.4.17 T/R Relay Driver 40
7.4.18 Channel Select Input / Output 41
7.4.19 DC Remote Keying 41
7.4.20 PTT in 41
7.4.21 Programmable No-Tone Period 41
7.4.22 Firmware Timers 41
7.4.23 CTCSS 42
7.5 Connectors 42
7.5.1 RF Output Connector 42
7.5.2 Power and I/O Connector 42
7.5.3 External Reference Connector (optional) 42
Page 4 RF Technology T50
1. CONTENTS CONTENTS
A Engineering Diagrams 43
A.1 Block Diagram 43
A.2 Circuit Diagrams 43
A.3 Component Overlay Diagrams 43
B Parts List 44
C EIA CTCSS Tones 60
RF Technology T50 Page 5
1 OPERATING INSTRUCTIONS
1 Operating Instructions
1.1 Front Panel Controls and Indicators
1.1.1 PTT
A front-panel push-to-talk (PTT) button is provided to facilitate bench and field tests
and adjustments. The button is a momentary action type. When keyed, audio from the
line input is disabled so that a carrier with subtone is transmitted. The front-panel
microphone input is not enabled in this mode, but it is enabled when the PTT line on
that socket is pulled to ground.
The PTT button has another function when transmission is keyed up, and the TX LED
light is showing. If there is a “forward power low” alarm (the ALARM LED flashes
three times, then pauses), pressing this will cause the ALARM LED to flash 6, 7, 8, or 9
times before the pause (see Table 2). This will indicate what has caused the low power
alarm.
1.1.2 Line
The LINE trimpot is accessible by means of a small screwdriver from the front panel of
the module. It is used to set the correct sensitivity of either line input or the direct
audio input. It is factory preset to give 60% of rated deviation with an input of 0dBm
(1mW on 600Ω equivalent to 775mV RMS or about 2.2V peak-to-peak) at 1kHz. The
nominal 60% deviation level may be adjusted by measuring between pins 6 and 1 on the
test socket, and adjusting the pot. By this means an input sensitivity from approximately
-12dBm to +12dBm may be established.
An internal, software selectable, option, provides an extra gain step of 20dB. This,
effectively changes the input sensitivity to –32 to –8dBm.
WARNING
Changes or modifications not expressly approved by
RF Technology could void your authority to operate this
equipment. Specifications may vary from those given in
this document in accordance with requirements of local
authorities. RF Technology equipment is subject to
continual improvement and RF Technology reserves the
right to change performance and specification without
further notice.
Page 6 RF Technology T50
1.1.3 Power Led 1 OPERATING INSTRUCTIONS
LED Flash Cadence Fault Condition
9 flashes, pause External PA failure
8 flashes, pause Low dc supply on External PA
7 flashes, pause External PA Over Current Condition
6 flashes, pause External PA Over Temperature
5 flashes, pause Synthesizer unlocked
3 flashes, pause Unable to communicate with External PA
2 flashes, pause The current channel is not programmed or the frequency
is out of range.
1 flash, pause Low dc supply voltage
LED ON continuously Transmitter timed out
Table 1: Interpretations of LED flash cadence (TX LED Off)
LED Flash Cadence Fault Condition
9 flashes, pause External PA failure (if PTT is pressed)
8 flashes, pause Low dc supply on External PA (if PTT is pressed)
7 flashes, pause External PA Over Current Condition(if PTT is pressed)
6 flashes, pause External PA Over Temperature(if PTT is pressed)
4 flashes, pause Either PLL is near operational limit
3 flashes, pause Forward Power Out of Range(if PTT is not pressed)
2 flashes, pause Reverse Power ratio exceeded.
1 flash, pause Low dc supply voltage
LED ON continuously Transmitter timed out
Table 2: Interpretations of LED flash cadence (TX LED On)
1.1.3 POWER LED
The PWR LED shows that the dc supply is connected to the receiver and that the
microprocessor is not being held in a RESET state.
1.1.4 TX LED
The TX LED illuminates when the transmitter is keyed. It will not illuminate (and an
ALARM cadence will be shown) if the synthesizer becomes unlocked, or the output
amplifier supply is interrupted by the microprocessor.
1.1.5 ALARM LED
The Alarm LED can indicate several fault conditions if they are detected by the self test
program. The alarm indicator shows the highest priority fault present. See Tables 1
and 2.
RF Technology T50 Page 7
2 TRANSMITTER INTERNAL JUMPER OPTIONS
2 Transmitter Options
There are NO internal jumpers in the T50.
There are many software selectable options. Some options are selected on a per channel
basis, and some are defined globally (i.e. the parameter is fixed irrespective of which
channel is selected). Below is a description of these global parameters
2.1 Serial I/O Parameters
There are two serial ports. There is the main serial port which is brought out to the front
panel connector. This is referred to as PORT0. There is another serial port which is for
factory use only. It is referred to as PORT1.
The baud rate, parity, and whether hardware flow control is enabled can be defined for
PORT0. PORT0 is set by default to 57.6Kbps, with No parity, and No Hardware Flow
Control.
2.2 LINE Terminators
There are two main audio inputs, plus a direct audio (TONE) input. The direct audio
input is a High Impedance Balanced DC input, but the two audio inputs are AC coupled
(> 10Hz) inputs which can be High Impedance(HiZ), or 600 ohm inputs. Each input
can be software selected to be HiZ, or 600 ohms.
2.3 Exciter Low Battery Level
This is factory set to 24.0V, and defines the level of the DC supply that will cause an
Exciter dc supply low alarm.
2.4 External PA Parameters
There are several user definable parameters associated with the external PA provided
with each exciter.
These are the PA low battery alarm level (default is 26V), the PA Set Forward Power
Level (defaults to 100W), the Forward Power Low Alarm Level (defaults to 90%), and
the Reverse Power Alarm Level (defaults to 25% - corresponding to a VSWR of 3:1).
2.5 LOOP Volts Select
Normally the transmitter will key up if dc current is sensed flowing in either direction
between Line1+ and Line1- (>=1mA). If this option is selected, then a 12Vdc supply is
Page 8 RF Technology T50
2.6 Direct Audio (TONE) Select 2 TRANSMITTER INTERNAL JUMPER OPTIONS
applied to the pair through 660 ohms of source impedance. (It would be expected,
normally, that if this option is selected, then the option to remove the 600 terminator
from Line1, would also be selected). If dc current flows from having applied this
potential, then the transmitter will key up.
2.6 Direct Audio (TONE) Select
Normally any signal applied to the TONE+/TONE- pair is ignored. If this option is
selected then a Direct Audio input will be mixed with any audio received on either of
the other two lines.
2.7 Direct Audio (TONE) High Pass Filter Select
Normally the Direct Audio, and the CTCSS outputs are passed through a 250Hz, low
pass filter. This filter can be bypassed by selecting this option.
2.8 Transmit Time
This parameter defines a maximum time limit for continuous transmission. It is
expressed in seconds and can be arbitrarily large (months in fact). If it is set to zero
seconds, then the transmitter can stay keyed up permanently.
2.9 Channel Selectable Parameters
Each channel defines two complete set of parameters. One set of parameters is used
when a transmitter keys up from the PTT-in input, and the other set is used when the
transmitter keys up from the LOOP-in, the PTT switch, or the microphone PTT input.
Each set defines what frequency to use, what CTCSS sub-tone (if any) to use, what
maximum line deviation to use, what tone deviation to use, what transmit delay (a delay
applied from PTT-in or LOOP-in to transmission), what transmit tail (delay from PTT-
in, or LOOP-in, to transmission being stopped, and No-TONE period (a period of extra
transmission in which No Tone is applied after PTT-in or LOOP-in has been released.
As well as these parameters, which Line (or Lines) can be selected, and whether the
Lines should have Flat frequency response or have Pre-emphasis applied. Also, it can
Enable or disable the extra 20dB gain pad.
Note that both Line1 and Line 2 can be selected (each with or without pre-emphasis),
and if so, then the two signals will be mixed, and the Line potentiometer will adjust the
level of them both.
3 Transmitter I/O Connections
3.1 25 Pin Connector
The female D-shell, 25 pin, connector is the main interface to the transmitter. The pin
connections are described in table 3.
RF Technology T50 Page 9
3 TRANSMITTER I/O CONNECTIONS 3.2 9 Pin Front Panel Connector
Function Signal Pins Specification
dc power +28Vdc(in)
0 Vdc
+5Vdc(out)
+12Vdc(out)
13, 25
1, 14
17
15
+24 to 32 Vdc
Common Voltage
Output for external Logic(100mA)
Output for an external relay(120mA)
Serial
Communications SCLK
MOSI
CH_EN
PA_CS
SPARE_SEL
12
6
18
24
5
Serial Clock
Bi-directional Data Pin
Enables Channel Select Shift Register
Enables PA A/D chip
Spare Select (for future use)
600Ω/HiZ Line Line1+
Line1- 8
19 Transformer Isolated Balanced 0dBm
Input
600Ω/HiZ Line Line2+
Line2- 10
22 Transformer Isolated Balanced 0dBm
Input
Direct PTT input 11 Ground to key PTT
T/R Relay driver
output 23 Open collector, 250mA /12V
Sub-Audible Tone
Input Tone+
Tone- 9
21 >10kΩ, dc coupled
Table 3: Pin connections and explanations for the main 25-pin, D connector.
3.2 9 Pin Front Panel Connector
The female D-shell, 9 pin, front panel connector is an RS232 interface for serial
communications to a terminal, a terminal emulator, or to a computer. The pin
connections are described in table 4.
Function Pins Specification Pin name on IBM PC
TXD 2 Transmit Data (Output) RxD
RXD 3 Receive Data (Input) TxD
RTS 8 Request To Send (Output) CTS
CTS 7 Clear To Send (Input) RTS
DTR 6 Data Terminal Ready(Output) DSR
DSR 1 Data Set Ready (Input) DCD
GND 5 GND GND
Table 4: Pin connections for the front panel 9 pin D connector.
The pinout for the connector has been chosen so that a straight-through BD9 male to
DB9 female cable can connect the transmitter to any male DB9 serial port on an IBM
PC compatible computer.
Note that for connection to a modem, a cross-over cable will be required.
Page 10 RF Technology T50
4 CHANNEL PROGRAMMING AND OPTION SELECTION
4 Channel Programming and Option Selection
Channel and tone frequency programming is most easily accomplished with RF
Technology Eclipse50 software. This software can be run on an IBM compatible PC
and can be used to calibrate a T50, R50, and PA50 as well as program channel
information. See the Eclipse 50 users manual for further information.
But the T50 also has its own stand-alone high level interface, which can be accessed
from a VT100 compatible terminal, or terminal emulator (such as HyperTerm which is
available as a standard accessory with Windows).
The pertinent aspects of this High Level Interface are described below.
4.1 Setting Options
Note that any text in italics, represents data output by the T50 firmware, rather than
command line data sent to the T50 firmware.
The T50, after powering up, will issue a command prompt of the form:
T50>
Via a terminal, or a terminal emulator, a user can type various commands in. The basic
command to read parameters is:
T50> read par parameter_name
Where “parameter_name” is one of the following:
Parameter Name Parameter Function Default Value Parameter
Range
LOOP_GEN Generate a LOOP potential
(see 2.5) Off Text: Off or
On
PA_SET_FWD_PWR Output Power of the PA (see
2.4) 100.0 (Watts) Floating
point number
20.0 – 150.0
PA_LOW_BAT Low Battery Alarm Level (see
2.4) 26.0 (Volts) Floating
Point
Number
< 32.0
REV_PWR_ALARM Sets the maximum level of
reverse power. At this level of
reverse power, forward power
is automatically decreased so
that this reverse power level is
never exceeded. It also sets
the ratio of forward power,
which if exceeded causes the
reverse power alarm condition
to be asserted
25.0 (% of
PA_SET_FWD_PWR)
25.0 (% of current
forward power)
Floating
Point
Number
0.0 – 99.9
RF Technology T50 Page 11
4 CHANNEL PROGRAMMING AND OPTION SELECTION
Parameter Name Parameter Function Default Value Parameter
Range
LOW_PWR_ALARM Level of Output Power when
the low power alarm condition
occurs (see 2.4)
90.0 (% of
PA_SET_FWD_PWR) Floating
Point
Number
0.0 – 99.9
TRANSMIT_TIME Maximum Time that the
transmitter can stay keyed up 0 (Seconds: Note that
zero seconds implies
no transmit time limit)
Decimal
number:
0 - 9999999
BAUD_RATE0 Port 0 Baud Rate 57600 (BPS) Decimal
number:
300 - 115200
PARITY0 Port 0 Parity None Text: None,
Even, or Odd
FLOW_CONTROL Port 0 Flow Control Off (“On” not yet
available) Text: Off
Table 5: Some User Defined Parameters.
Note that the parameter names have been shown in upper case, but they can be typed in
upper or lower case.
A parameter can be changed, or added, by typing
T50> set par parameter_name=parameter_value
As for parameter names, the parameter value can be Upper or Lower case if it is a text
value, as against a numeric value.
4.2 Setting Channel Parameters
One can read the data from an existing channel by entering the command:
T50> read chan chan_number
Where chan_number is a number from 0 to 99.
Entering new channel values, or modifying existing ones is possible from the command
line interface, but it is not recommended. It can be done by typing the following at a
command prompt:
T50> set chan chan_number parameter_list
Where chan_number is a number from 0 to 99.
The format of the parameter_list is quite complex. It has 14 fields. Each field can be
separated by a colon(:), comma(,), space, or tab.
For example set chan 0 25.0,35.0,100.0,120.0,0,5,2,0,5,2,10,11,0,3
Page 12 RF Technology T50
4 CHANNEL PROGRAMMING AND OPTION SELECTION
Field1: Transmit Frequency (in MHz) if PTT-in is asserted. This is 25.0 MHz in the
example.
Field2: Transmit Frequency (in MHz) if the exciter is keyed up by anything but PTT-in
being asserted. This is 35.0 MHz in the example.
Field3: CTCSS Tone (in Hz) if PTT-in is asserted. This is 100Hz in the example.
Field4: CTCSS Tone (in Hz) if the exciter is keyed up by anything but PTT-in being
asserted. This is 120Hz in the example.
Fields 5,6,7: These define the start-up delay (in hundredths of a second), the transmit
tail (in seconds), and the no tone period (in tenths of a second) if the exciter
keys up from PTT-in being asserted.
Fields 8,9,10: These define the start-up delay (in hundredths of a second), the transmit
tail (in seconds), and the no tone period (in tenths of a second), if the exciter
keys up from anything other than PTT-in being asserted.
Field 11: Selects the line parameter if PTT-in being asserted caused the exciter to key
up. In the example it has disabled the 20dB gain pad, and enabled pre-
emphasis on Line 2 (Line 1 is disabled).
Field 12: Selects the line parameter if anything other than PTT-in being asserted caused
the exciter to key up. In the example it has disabled the 20dB gain pad, and it
would enable pre-emphasis on Line 1 and Line2 (i.e. audio on each input is
mixed).
Field 13: Selects the Tone deviation and the Maximum Line deviation if the exciter
keys up from PTT-in being asserted In the example, it has selected the default
maximum line deviation (5kHz), and the default tone deviation of 750Hz. (See
Tables 7 and 8)
Field 14: Selects the Tone deviation and the Maximum Line deviation if the exciter
keys up from anything other than PTT-in being asserted. In the example, it
has selected a maximum deviation of 2.5kHz, and a maximum tone deviation
of 375Hz. (See Tables 7 and 8)
Least Significant BCD digit of Fields 13 or 14 Maximum Deviation
0 5.0kHz
1 4.0kHz
2 3.0kHz
3 2.5kHz
4 2.0kHz
5 1.5kHz
6 User Specified(default: 4.5kHz)
Table 7: Maximum Deviations
RF Technology T50 Page 13
4 CHANNEL PROGRAMMING AND OPTION SELECTION
Most Significant BCD digit of Fields 13 or 14 Nominal Tone Deviation
0 750Hz
1 500Hz
2 375Hz
3 250Hz
4 150Hz
5 User Specified (default: 600Hz)
Table 8: Maximum Tone Deviations (when Max Dev is 5kHz)
Note that the actual maximum tone deviations depend on the maximum deviations. If a
maximum deviation of 4kHz was chosen, and a nominal tone deviation of 250 Hz, the
actual maximum tone deviation would be 250*4.0/5.0 = 200Hz.
If the Eclipse50 Software is not used to program the exciter, it is recommended that the
programming information is prepared using a spreadsheet and/or a text editor, and the
resulting file is then downloaded, as a text file, to the firmware using, for example,
HyperTerm.
Note that if using HyperTerm to download the text file, at 57600 bits per second or
higher speeds, the connection properties may need to be changed to add a 10
millisecond delay after each line of text is sent.
5 Circuit Description
The following descriptions should be read as an aid to understanding the block and
schematic diagrams given in the appendix of this manual.
There are 9 sheets in the schematic in all.
5.1 T50 Master Schematic (Sheet 1)
Sheet 1, referred to as the “T50 Master Schematic”, is a top level sheet, showing five
circuit blocks, and their interconnection with each other, as well as the interconnection
with all connectors and external switches.
JP12 is the connector, on the printed circuit board, for the microphone input.
P3 represents the rear female DB25 connector.
J1 is the nominal 1W RF output (BNC) connector, which is used to connect to the
External Power Amplifier.
J4 is an optional BNC connector for an external reference clock. If an external
reference clock, with power level from +5 to +26dBm is attached here, the firmware
will automatically track the channel VCO to the reference.
Page 14 RF Technology T50
5 CIRCUIT DESCRIPTION
Note that the external reference frequency is limited to:
500kHz, or any multiple
any multiple of 128KHz greater than or equal to 4
any multiple of 160KHz greater than or equal to 3
P1 is the front panel DB9 RS-232 connector for attachment to a terminal, a terminal
emulator, or to an IBM PC running the Eclipse50 software.
JP2 is for the attachment of an LCD display module. This has been included for later
development.
JP3 is a specialised connector for test and factory configuration use only.
RV100 represents the front panel LINE potentiometer.
SW1 represents the PTT test pin.
D102, D103, and D104 represent the three front panel LEDs.
5.2 Microprocessor (Sheet 2)
Sheet 2 describes the basic microprocessor circuitry.
The core CPU is the Motorola XC68HC12A0. It is configured in 8 bit data width
mode.
The CPU is clocked by a 14.7456MHz crystal oscillator circuit (top left) comprising the
JFET Q202, and two switching transistors Q203 and Q204.
The CPU contains an 8 channel A/D converter whose inputs are identified as AN0,
AN1, …, AN7.
AN7 and AN6 are used as LOCK detect inputs from the two Phase Locked Loop (PLL)
circuits (see 5.6)
AN5 is used to sense whether or not the dc supply is within spec or not.
AN4 is multiplexed between the LINE control potentiometer and the Channel reference
crystal’s temperature sense. Which analogue input drives this analogue input, is defined
by the state of TEMP_LEVEL_IN which is a CPU output signal.
AN3 and AN1 are inputs from the PLL circuits that sense the bias voltage on the VCO
control varactor for each VCO.
AN2 is used to sense the average peak voltage of the audio input.
AN0 is used to sense the average peak voltage of the RF output.
RF Technology T50 Page 15
5 CIRCUIT DESCRIPTION
FRDY is an output from the flash. It goes low when the Flash starts to write a byte of
data, or erase a block, or erase the whole chip, and it returns to its default high state
when the action requested has completed.
FPSW1 is the switch input from the PTT Test pin.
FPSW2, and FPSW3 are two pins that have been reserved for future use as switch
inputs.
LOOP/VOLTS_SEL is a CPU output that when high applies 12V of dc feed to the
audio output.
TONE_DEV_U/D and TONE_DEV_INC are CPU outputs that are used to control the
digital potentiometer that sets the TONE deviation level. (see 5.5)
EXT_TONE_SEL is a CPU output that when low enables differential analogue input
from the TONE+/TONE- pair. (see 5.5)
LINEINP_ADSEL is a serial bus select pin. It selects the quad Digital to Analogue
converter (DAC) that sets the levels for the two Line input Voltage Controlled
Amplifiers, the output RF power amplifier bias voltage, and the LCD bias circuit. (see
5.4)
LINEINP_DSEL is also a serial bus select pin. It is used to select the shift register that
is used to control most of the analogue switches in the audio Line input circuitry, as
well as the digital POT used to set the maximum deviation level. (See 5.4)
PWR_CNTRL_HIGH is a CPU output that can be low, tri-state, or high. This adjusts,
slightly, the range of the power amplifier bias circuitry allowing finer control of the
output power level. (see 5.4 and 5.8)
CTCSS_SEL is a serial bus select pin. It is used to select the FX805 chip(U500), which
is used to generate CTCSS tones. (see 5.5)
CHAN_PLL_SEL is a serial bus select pin. It is used to select the PLL chip in the
Channel PLL circuit (U604). (See 5.6)
SIGGEN_ADSEL is a serial bus select pin. It is used to select the quad DAC in the RF
area. This DAC controls the reference oscillator bias voltages, and the BALANCE
voltage controlled amplifier. (See 5.6)
CHAN_VCO_EN is a CPU output that enables (when high) the Channel VCO. (See 5.6
and 5.7)
EXT_REF_DIV is a CPU timer input. It is the output of the external reference clock
divided by 3200. The software can measure what the reference frequency is, and then
use this input to calculate the frequency error of the channel PLL reference oscillator. It
can then adjust the channel reference oscillator to reduce this error to less than 0.3ppm.
(See 5.6)
Page 16 RF Technology T50
5 CIRCUIT DESCRIPTION
SPARE_SEL is a serial bus select. It has been reserved for future use, and has been
brought out to the rear DB25 connector. (see 5.1)
CH_EN is a serial bus select. It is brought out to the rear panel and is used to interface
to the channel encoder on the rear daughter-board. (See 5.1)
Any GPS pulses are isolated from the on-board electronics by the opto-isolator U212.
The output of that opto-isolator is then connected to the GPS timer input of the CPU.
The software assumes that any GPS pulses are 1 second apart and can use this input to
measure the frequency error of the channel PLL reference oscillator. . It can then adjust
the channel reference oscillator to reduce this error to less than 0.3ppm. (See 5.1)
TERM_EN2 and TERM_EN1 are used to enable (when low) 600 ohm termination of
Line2, and Line1 respectively. (See 5.3)
Fo_MOD_2, and Fo_CHAN_2 are the Fo outputs from the Modulation PLL and the
Channel PLL divided by two. They should be 200Hz square waves, except for brief
periods when frequencies are being changed. (See 5.6)
LCD_DB7 is an input used to sense if the LCD display module is busy processing the
last command sent to it.
ECLK is a pin that at start-up only, should have the CPU system clock of 7.3728MHz
on it.
TX_LED, ALARM_LED, are CPU outputs that drive (when low) the TX LED, and the
ALARM LED on.
T/R_RELAY_H, when high, drives the T/R RELAY output low, and also enables the
RF power amplifier. The T/R RELAY output can activate at least one conventional
12V relay. (See 5.1)
SCLK, and MOSI are used as the core of a serial bus. SCLK is a clock pin, and MOSI
is a bi-directional data pin.
PA_CS is a serial select pin. It is passed, via the rear DB25 connector to the External
Power Amplifier (PA). (See 5.1)
DBGTX_TTL, DBGRX_TTL are RS232 transmit and receive (TTL) data pins which
are connected to the debug port after conversion to/from RS232 compatible voltage
levels by U202 and U201.
TXD_TTL, RXD_TTL, RTS_TTL, CTS_TTL, DTR_TTL, DSR_TTL, are RS232 data
pins which are connected to the main front panel serial port after conversion to/from
RS232 compatible voltage levels by U202 and U201.
PTT_uPHONE is a CPU input and it reflects the state of the PTT pin on the microphone
handset.
TONE_INT is a CPU input that comes from the FX805 (U500). This pin is used to
indicate when a Tone has been decoded, or there is some other need to service the
FX805. As yet this pin is not used in the T50. (See 5.5)
RF Technology T50 Page 17
5 CIRCUIT DESCRIPTION
LOOP_DET is a CPU pin that is asserted low if there is dc loop current detected
through the centre tap input of Line2. (See 5.3)
FILTER_OFF is a CPU output that is used to by-pass, when low, the low pass filter in
the Tone Input Circuitry. (See 5.5)
PTT-in is an input from the rear DB25 connector that causes the INT pin of the CPU to
be asserted (low) when 1mA of current is drawn via that pin. If PTT-in is pulled to
ground, through a resistance of at most 3.9kohms, it will cause INT to be asserted. If it
is pulled low via a 2K2 resistor, and as many as three diodes in series, it will still cause
the INT pin to be asserted. This latter example shows that quite complex diode logic
can be used on this pin.
BKGD is a bi-directional I/O pin used to communicate with the core of the CPU. It is
connected to the debug port and is utilised by specialised hardware to control the CPU
externally, even without any firmware being present in the Flash.
DEV_H_L is a CPU output that can be used to generate a test signal in the audio path.
It is currently not used. (See 5.4)
The RESET pin is both a low active input and a low active output to the CPU. If
generated externally to the CPU, it forces the CPU into reset, and if the CPU executes a
RESET instruction this pin will be driven low by the CPU.
Whenever there is insufficient volts (< 4.65V) on pin 2 of the MC33064D (U203), it
will keep its RES output low. After the voltage has met the right level it will assert its
output low for another 200 milliseconds. Thus the CPU will be held in reset until VCC
is at the correct level. Thus the PWR_OK LED will only light when VCC is within
specification, and RESET has been released.
S200 is a momentary push-button switch that, when pressed, will cause the CPU to be
reset.
MOD_PLL_SEL is a serial bus select pin. It is used to select the Modulation PLL chip
(U602). (See 5.6)
LCD_RS, LCD_R/W, and LCD_E are reserved for interfacing to an LCD display
module. Note that this feature has not been implemented.
U205 is used to select whether the Flash or RAM is to be read or written.
U207 is a single supply, 5V, TSOP40 Flash chip of size 8, 16, or 32 Megabits, and is
used to store the firmware.
U208 is a 1, or 4, Megabit Static RAM in an SOP-32 package, and is used for both code
and data. The code in the RAM is copied from the Flash, at start-up.
Page 18 RF Technology T50
5 CIRCUIT DESCRIPTION
5.3 Audio Processing Section (Sheet 3)
Sheet 3 is a schematic, which itself refers to two other sheets.
Sheet 3 shows how the two Line inputs go to audio transformers T300 and T301, are
then optionally terminated by analogue switches U301B, and U301C, before being
passed to the audio input stages described by Sheet 4.
It also shows how the Direct Audio (TONE) signal is passed to the Tone circuitry (sheet
5).
It also shows how dc current in Line1 will cause the opto-isolator (U300) to generate
the CPU input LOOP_DET.
Relay RL300 is used to drive current back through an externally generated dc loop,
when the CPU output LOOP/VOLTS_SEL is high.
The output of the Tone circuitry and the Audio circuitry is mixed (summed) and
amplified by U302. It is then passed through a high order low pass filter (3.1kHz),
before being attenuated by digital POT U303.
The Digital POT (U303) sets the Maximum deviation.
U302C then adds 6dB of gain before sending the audio to the modulator.
R317, D307, and C304, act as an average peak detector. This enables the CPU to
determine the size of signals being handled by the audio section.
Note that the Line inputs, and the TONE input, are protected by transils and fuses
against accidental connection to damaging voltages. The fuses (F300, F301, and F302)
are not user replaceable. They are surface mount devices and must be replaced by
authorised service personnel.
5.4 Line Input Processing Section (Sheet 4)
The two audio inputs are passed, after transformer coupling, to sheet 4.
In Sheet 4, the two Line Inputs are input to a transconductance amplifier (U402A, and
U402B). A transconductance amplifier is a current controlled, current amplifier, i.e. it
amplifies input current, but its level of amplification is controlled by the level of current
that is injected into pin1 or pin16. By converting a DAC output into a current, and
converting the input voltage into an input current, U402A and U402B are converted into
Voltage Controlled voltage Amplifiers(VCAs).
Two of the DAC outputs are converted to currents by U400B, U400C, Q401, and Q400,
and these currents are used to control the gain of the transconductance amplifiers.
The input voltages are converted to current by the input load resistors R402, and R403.
The output currents are converted to voltages by resistors R420 and R424.
RF Technology T50 Page 19
5 CIRCUIT DESCRIPTION
The outputs of the transconductance amplifiers are buffered by the darlington buffers
provided with the amplifiers (U402C, and U402D).
The output of each VCA is then amplified by U405B and U405C respectively.
The level of amplification of each VCA is adjusted in software in accordance with any
adjustments made to the LINE POT. The software converts the linear range of the
LINE POT into a logarithmic scale, such that if the LINE POT is wound down to zero,
the amplification of each VCA is reduced by 12db relative to its centre position.
Similarly if the POT is wound to its maximum position, both amplifiers increase their
gain by 12dB.
The outputs of these amplification stages are then attenuated. Analogue switches
U404A and U404Bare used to select which attenuation circuit is used for Line 2, and
U404D and U404C are used to select which attenuation circuit is used for Line 1.
If the resistive divider formed by R425, R426, and R439 is selected then the Line 2
audio signal frequency response is unaffected (it is Flat). If the reactive divider defined
by C402, R431, and R439 is selected, then higher frequencies of the Line 2 audio signal
are attenuated less than lower frequencies, i.e. Pre-emphasis is applied to the audio
signal.
Line 1 has an identical circuit.
The outputs of these pre-emphasis/flat frequency response attenuators are then buffered
by U405A, and U405D respectively.
The microphone input is amplified by U400D, after being limited by D400. It is passed
through a pre-emphasis network (defined by C404, R433, and R436), and is enabled, or
disabled by switch U403D.
The outputs of the Line 1 conditioning circuit, the Line 2 conditioning circuit, and the
microphone input amplifier, are then mixed (summed) and amplified by U407A. Its
output is, in turn, amplified by U407B, but the gain of U407B is either 2.7 or 27
depending on the state of analogue switch U403B.
The CPU is capable of injecting a clipped (saturated) signal into the audio path. This
can be achieved via the two digital outputs DEV_H_L and TEST_DEV. This is
currently not used.
The output of U407B is passed (signal LINE_INP) to the Line Level Sense circuitry
(sheet 3) so that the CPU can determine the input line level.
U407B’s output is also passed to the limiter defined by D402, and D401. Resistors
R442, and R444 are used to “soften” the clipping, i.e. to “round off” the edges as the
voltage hits the clipping levels. This reduces the level of the lower order harmonics
produced.
U407C then buffers the output for mixing with the tone output circuitry.
Page 20 RF Technology T50
5 CIRCUIT DESCRIPTION
The PWR_CNTRL_RAW DAC output is used to control the bias to the on-board RF
amplifier (see Sheet 8). The CPU output pin PWR_CNTRL_HIGH is effectively
summed with the DAC output to define three control ranges:
State of PWR_CNTRL_HIGH PWRCNTRL Voltage Range
TriState 2.98 – 5.86
Low (0V) 0.6 – 3.0
High (5V) 3.55 - 5.96
Table 9: Power Control Ranges.
Note that in practice only the last two power ranges are used. The last is used when the
External Power Amplifier is the 38-50MHz model, and the middle is used otherwise.
U401 is an octal shift register and octal latch combined. When there is a rising edge on
LINEINP_DEN, the 8 shift register outputs are latched into the octal latch. The outputs
of the octal latch are the outputs Q0 to Q7. Thus the last 8 data bits clocked onto MOSI,
by SCLK, before LINEINP_DEN is clocked high, will appear on Q0 to Q7. This,
therefore, forms an inexpensive means for the CPU to increase its number of outputs.
U406 is a quad 8 bit DAC. The CPU communicates with the DAC via SCLK, MOSI,
and the select signal LINEINP_ADSEL, which is low when the DAC is selected.
U302B is used to convert the DAC output into a bias level for the LCD. The bias level,
would be adjusted for temperature, and as per a calibration procedure. Note that, at this
stage, the LCD display option is not developed.
5.5 Tone Generation Section (Sheet 5)
U500 is a CTCSS tone encoder and decoder. The integrated circuit is also capable of
generating and receiving DCS signals, but at this stage this has not been implemented.
The CPU accesses U500 via the serial bus using MOSI, SCLK, and the low active
Select signal CTCSS_SEL.
The output of the tone generator is mixed (summed) with any signals that are allowed
through analogue switch U301D.
U502 is set up as a balanced differential amplifier. The resistors R530, R531, R508,
R509, R510, R532, R533, and R511, are precision resistors to improve the CMRR of
the differential amplifier.
U502A amplifies, as well as mixes, the two audio inputs, and its output is either passed
through a low pass filter (at 250Hz), or not, depending on the state of analogue switch
U301A.
The output of U502C is then attenuated by a digital POT, before being buffered by
U502D.
RF Technology T50 Page 21
5 CIRCUIT DESCRIPTION
The digital POT performs two functions. It is used to help set the maximum CTCSS
tone deviation. It does this in conjunction with U500, as it is also possible for the
CTCSS tones that are launched by U500 to be adjusted using software.
The second function of the digital POTs is enabled when U301D is enabled. The level
of attenuation by the digital POT is adjusted (by software) in line with adjustments
made by users to the LINE Potentiometer on the front panel.
R526, D502, and D503, form a limiter, that prevents any signal arriving from the TONE
pair from ever exceeding 3kHz deviation.
5.6 Frequency Synthesiser (Sheet 6)
This circuit also includes Sheet 7 as a block diagram. Sheet 7 contains the schematic
for the two Voltage Controlled Oscillators.
There are two complete Phase Locked Loops. One is called the Modulation PLL, and
the other is referred to as the Channel PLL.
The Modulation PLL does change frequencies slightly, but by less than +/- 240kHz.
The Channel PLL is the principal PLL that changes frequencies when the exciter
changes frequency.
As its name suggests, modulation is performed on the Modulation PLL.
The modulation is a conventional 2 point FM modulation. Modulation by signals,
whose frequency components are well below the PLL loop frequency, is effected by
modulating the reference oscillator of the Modulation PLL. Frequencies well above the
PLL loop frequency are effected by modulating the Modulation VCO directly, and
frequencies in the cross-over region are a combination of the two.
The heart of this schematic are the two PLL chips U602, and U604.
Each is, in fact, a dual PLL chip, but only one PLL in each is used. All that is used of
the second PLL chip is its dividers. The outputs of these dividers can be switched to the
FoLD output pin, which is then converted to a square wave by a further division of 2 by
U606A and U606B.
By using the second PLL’s dividers it is possible to divide the reference oscillator, and
the VCO output down to frequencies that can be handled by the Timer inputs of the
CPU, without causing excessive interrupt load to the CPU.
5.6.1 The Modulation PLL
U602 and the Modulation VCO (see Sheet 7) form the modulation PLL. U602 acts as
its own crystal oscillator for its reference oscillator. X600 is a 5ppm, 12MHz, crystal.
Its resonant point is adjusted by the bias applied to varactor D600.
Page 22 RF Technology T50
5 CIRCUIT DESCRIPTION
The bias applied to varactor D600 is a combination of the potentials at two DAC
outputs (MOD_ADJ and MOD_ADJ_FINE), plus the modulating signal arriving at
MOD_IN (which is the same signal as MOD_OUT in Sheet 3).
The summing of these three voltages is performed by U607.
The Phase detector output of the PLL chip is then passed through the loop filter network
defined by C612, R618, C625, R617, C613, and C718 (see Sheet 7). L713 is used to
filter out any residual noise (outside of the audio bandwidth), including the phase
detector frequency, and/or any switch-mode noise from the dc voltage rails.
The loop filter signal is then fed as a control voltage to the Modulation VCO
(MOD_PLL_IN).
The output of the Modulation VCO is connected back to the PLL for phase detection via
signal path MOD_VCO_OUT.
The phase detector output is also buffered and attenuated for the analogue input of the
CPU. This is the function of U600, R622, and R625. In this way the CPU can monitor
the VCO bias to ensure that it is within specification (>0.5V, and < 4.5V).
The FoLD pin, of U602, can be used for many purposes. It can be connected to the
output of any of the 4 internal dividers, or be used as a LOCK-DETECT monitor, or as
a user programmable output pin. In this circuit it is used as a LOCK-DETECT output
when the frequency is being changed, but otherwise it is connected internally to the
unused reference divider of U602, to deliver a 400Hz pulse train to FoLD.
U602 is set up with a phase detector frequency of 20kHz.
5.6.2 The Channel PLL
U604 and the Channel VCO (see Sheet 7) form the Channel PLL. U604 acts as its own
crystal oscillator for its reference oscillator. X601 is a 5ppm, 12MHz, crystal. Its
resonant point is adjusted by the bias applied to varactor D601.
The bias applied to varactor D601 is adjusted by the CHAN_ADJ DAC output.
The Phase detector output of U604 is then passed through the loop filter network
defined by C622, R620, C626, R619, C623, and C725 (see Sheet 7). L718 is used to
filter out any residual noise (outside of the audio bandwidth), including the phase
detector frequency, and/or any switch-mode noise from the dc voltage rails.
The loop filter signal is then fed as a control voltage to the Channel VCO
(CHAN_PLL_IN).
The output of the Channel VCO is connected back to the PLL for phase detection via
signal path CHAN_VCO_OUT.
The phase detector output is also buffered and attenuated for the analogue input of the
CPU. This is the function of U608, R623, and R624. In this way the CPU can monitor
the VCO bias to ensure that it is within specification (>0.5V, and < 4.5V).
RF Technology T50 Page 23
5 CIRCUIT DESCRIPTION
The FoLD pin, of U604, can be used for many purposes. It can be connected to the
output of any of the 4 internal dividers, or be used as a LOCK-DETECT monitor, or as
a user programmable output pin. In this circuit it is used as a LOCK-DETECT output
when the frequency is being changed, but otherwise it is connected internally to the
unused reference divider of U604, to deliver a 400Hz pulse train to FoLD.
U604 is set up with a phase detector frequency of 31.25kHz.
The signal CHAN_VCO_EN is an output from the CPU that is used to turn on (when
High) or turn off (when low) the Channel VCO.
5.6.3 The External Reference Divider
The external Reference Input (EXT_REF_IN) is buffered by an attenuator network
formed by R628,R633, and R630 in parallel with R635. This also forms a 50 ohm
termination network for the reference input.
R628 is a 1 watt resistor, and so, in theory levels as high as +30dBm can be accepted.
To be safe, though, the largest signal that is approved to be accepted is +26dBm.
Q600 is set up as a switching transistor, and with a sufficiently high input signal level (>
+5dBm), it will clock U605.
U605 is set up as a divide by 128 circuit, and its output is then divided by U606 by 25.
The two unused, divide by two, stages of U606 are then used to convert the 400Hz
FoLD pulse trains into 200Hz square waves for the Timer inputs of the CPU.
5.6.4 The DAC
U601 is a quad DAC. It is programmed by the CPU via the serial bus (SCLK and
MOSI). It is selected by the low active signal SIGGEN_ADSEL.
Three of its outputs are used to adjust the reference oscillators.
In the presence of a GPS 1Hz pulse input, or an external reference oscillator, the
software will automatically track the channel VCO to these external inputs. (GPS has
priority over an external reference).
The modulation reference oscillator is always tracked as closely as possible to the
Channel reference oscillator. Because of this need for very close tracking, two DAC
outputs are summed. In this way, the CPU is given coarse, as well as fine control.
The CPU can sense a phase difference of 136ns in 4 seconds, i.e. as little as 0.034ppm
between the two PLL reference oscillators. Each step of the MOD_ADJ_FINE DAC
output will move the frequency about one eighth of this amount.
The other DAC output (BALANCE) is used to adjust the BALANCE VCA (see sheet
7).
Page 24 RF Technology T50
5 CIRCUIT DESCRIPTION
The user programmable digital output of the DAC (MOD_VCO_EN) is used to enable
the modulation VCO (when High)
5.6.5 The VCOs and the RF Output
These are more closely described in 5.7, but it is worth noting that there are three
primary outputs of the VCOs. There is each VCO output itself, but also the signal
VCO_OUT. This is the difference frequency between them.
Generally the modulation VCO is set to oscillate at 320MHz. To get an output of
40MHz, the Channel VCO is set to 280MHz.
But if you wanted an output frequency of, for example, 40.00125MHz, then the
modulation VCO would change to 319.78125 MHz (i.e. it drops by 218.75kHz), and the
Channel VCO would become 279.78MHz (i.e. dropping by 220kHz).
By such small changes in the modulation VCO (maximum delta is +/- 240kHz), each
multiple of 1250Hz can be accommodated, but without any need to ever change the two
phase detector frequencies.
5.7 Voltage Controlled Oscillators (Sheet 7)
JFETS Q704, and Q705 are the heart of two Colpitts oscillators.
The capacitor feedback divider for Q704 (modulation VCO) is defined by C732 and
C733, and this shapes the negative impedance looking into the drain of Q704.
In the Channel VCO, C740 is effectively in series with Cgs of Q705. These, then define
the negative impedance looking into the drain of Q705.
L716, in parallel with L726 forms the tank coil for the modulation oscillator, and the
resonant capacitance is defined by the series combination of C750 and the capacitance
across D701. L712 has +ve reactance and it acts to reduce the minimum effective
capacitance seen back through C750, thereby increasing the tuning range slightly.
Similarly, L719 is the tank coil for the channel oscillator, and the resonant capacitance
is defined by the series combination of C751 and the capacitance across D704. L717
has +ve reactance and it acts to reduce the minimum effective capacitance seen back
through C751, thereby increasing the tuning range slightly.
The VCO frequencies are controlled by the bias applied to D701 and D704 respectively,
which is set by signals MOD_PLL_IN and CHAN_PLL_IN. These signals are the
phase detector outputs from the Modulation PLL and the Channel VCO respectively
(see Sheet 6).
Diodes D700 and D703 are used to provide some AGC for the JFETs. These Schottky
diodes will increase the –ve bias on the gate of the JFETs (thereby decreasing the drain
RF Technology T50 Page 25
5 CIRCUIT DESCRIPTION
current) if the oscillation level should increase, and similarly the gate bias will reduce if
the –ve peaks of the oscillation should reduce.
The Modulation bias is also adjusted by the modulation input (2PORT_MOD). This
signal is amplified by a VCA. The BALANCE DAC output is converted to a current by
U707 and Q700, and that then is used to set the gain of the VCA. The output of the
VCA is then attenuated by R725/R729, and this bias is then applied to varactor D701.
Note that the modulation bias is in anti-phase to the PLL bias.
Each VCO has its own gyrator feed circuit (Q707 and Q702). This is done to remove
any possible noise on the voltage rails from effectively modulating either VCO.
The drain current of each VCO can be switched off or on by MOSFETs Q701 and
Q703. Q701 is switched on when MOD_VCO_EN is high. MOD_VCO_EN is the user
programmable digital output from DAC U601 (see Sheet 6). Q703 is switched on when
the CPU output CHAN_VCO_EN (see Sheet 2) is high.
The output of each VCO is “sniffed”, by a high impedance attenuator. In the
modulation VCO, R737 in series with the 50 ohm input impedance of U702 forms this
attenuator. In the Channel VCO, R745, R736, and the input impedance of U706 form
one such attenuator, and R741 in series with the input impedance of U703 forms the
other.
U702 amplifies the modulation VCO signal, which is then amplified again by U701,
then filtered to reduce harmonics, before arriving at the LO input of MX700 at a level of
around +5 - +7dBm.
The output of U702 is also attenuated by R733, and then re-amplified before becoming
MOD_VCO_OUT. MOD_VCO_OUT is then passed to the Modulation PLL (U602,
see Sheet 6). U703’s primary role is to ensure that noise that becomes coupled by the
PLL chip, back onto its VCO input, does not couple back into the path to the mixer. If
this isn’t done, then the mixer’s LO input contains many harmonics of the reference
oscillator.
U703 performs both an amplification role, and an isolation role similar to U703’s. Its
output (CHAN_VCO__OUT) is fed back to the Channel PLL (U604, see Sheet 6).
U706 and U701 are both designed to be in “gain compression”, i.e. their outputs are
saturating, so that significant changes in their input levels will not significantly change
their output levels. U706, though, starts its gain compression at about 10dB lower than
U701. In this way, variations in output level caused by variations in the parameters of
the JFETS Q704, and Q705, will not significantly modify the levels of signals arriving
at the mixer MX700.
The output of U706 is attenuated by the network R714, R742, and R724, and then it is
filtered to reduce the VCO harmonics as much as possible. This filtered VCO output is
then brought to the RF pin of the mixer at a level of about –20 to –22dBm.
The output of the mixer is then run through a low pass filter to remove frequencies other
than (Fmod - Fvco). U700 then amplifies this signal to a level of about –6 to –8dBm.
Page 26 RF Technology T50
5 CIRCUIT DESCRIPTION
The external output signal of T/R_RELAY, which is asserted low whenever the exciter
is keyed up, is used to switch MOSFET Q706 off. When Q706 is off, amplifier U700 is
enabled. When T/R_RELAY is high, then U700 is deprived of bias current and
VCO_OUT is then completely disabled.
5.8 1W Broadband HF Power Amplifier (Sheet 8)
The HF output of Sheet 7 (VCO_OUT) becomes the primary input to this circuit
(RF_IN).
This RF input is first amplified to a level of about +2 to +4dBm by U800, then it is
amplified by Q801 to about +20dBm (with full bias), and then it is amplified by Q804
and Q805 to +30dBm. The output stage gain is less above about 42MHz, so that the
peak output power falls to about +26dBm at 50MHz.
The effective gain of Q801 is controlled by adjusting the bias level (PWRCNTRL).
This can vary from 0.6V to nearly 6V, and is adjusted by a DAC output and a CPU
digital output, in Sheet 4.
The software monitors the forward power sense in the External Power Amplifier(PA) as
well as the Reverse Power, temperatures, drain currents etc. It does this via the serial
bus (formed by SCLK and MOSI) and the select pin for the ADC converter on the
External PA (PA_CS).
The software then automatically adjusts the PWRCNTRL bias to:
1) Keep the forward power at the level defined by parameter PA_SET_FWD_PWR
(see 4.1), unless,
2) If the reverse power is higher than
PA_SET_FWD_PWR*REV_PWR_ALARM/100.0 then the forward power is
reduced until the reverse power stops exceeding this limit, or,
3) The temperature of the PA output stage FETs exceeds 120C, in which case
forward power is reduced until this stops occurring.
5.9 Power Generation Section (Sheet 9)
There are three switch mode dc-dc converters in the board. These use monolithic
converters based on the National LM2595. Two of the converters are 12V converters
and one is a 5V converter.
The power in to the whole exciter is the voltage rail 28V.
U907 converts this down to 12V.
RF Technology T50 Page 27
6 FIELD ALIGNMENT PROCEDURE 6.1 Standard Test Condition
U908 is set up as an inverter, and uses the 12V rail to create –12V.
U909 converts the +12V rail to +5V for all the digital circuitry.
The +12V rail is used to power the two on-board relays, as well as up to one extra off-
board relay. It is also dropped, via a linear regulator (U910) to produce the +10V rail,
which in turn is dropped by another linear regulator U911 to produce +5Q, which, in
turn, is dropped by a further linear regulator (U912) to produce +2.5V.
Similarly U913, U914, and U915 are linear regulators that produce –10V, -5V, and –
2.5V from the –12V output of U908.
+10, +5Q, and +2.5V, -10V, -5V, and –2.5V rails are used in the audio and RF sections.
D911 is a 4.096V (3%) reference diode. Its output is buffered by U906 which then
produces a reference voltage rail Vref, which is used by the CPU’s A/D converter, and
the DACs, and also in the voltage to current converters of the VCAs (see Sheet 4, and
Sheet 7).
6 FIELD ALIGNMENT PROCEDURE
6.1 Standard Test Equipment
Some, or all of the following equipment will be required:
• AF signal generator, 75 - 3000Hz frequency range, with output level set to 387mV
RMS and, if the microphone input is to be tested, 10mV rms output.
• Power supply set to 28Vdc, with current >10A.
• RF 50Ω load(s), 250W rated, return loss <-20dB, and total attenuation of 50dB
• Reference Oscillator. At least +5dBm output.
The external reference frequency is limited to:
500kHz, or any multiple,
any multiple of 128KHz greater than or equal to 4,
any multiple of 160KHz greater than or equal to 3
The accuracy should be at least 0.5ppm, preferably 0.1ppm
• RF Peak Deviation Meter
• True RMS AC voltmeter, and a DC voltmeter.
• RF Power Meter (accurate to 2%, i.e. 0.17dB)
• Some means of measuring Reverse Power, and a known 3:1 mismatched load.
Page 28 RF Technology T50
6 FIELD ALIGNMENT PROCEDURE
6.2 Invoking the Calibration Procedure
The T50 has in-built firmware to perform calibration. This firmware requests the user
for information as to meter readings, and/or to attach or adjust the AF signal generator.
The firmware based calibration program can be accessed from a terminal, a terminal
emulator, or the Eclipse50 terminal emulator.
As for Section 4.1, the firmware, after power up, issues the following prompt:
T50>
Via a terminal, or a terminal emulator, a user can type various commands in. The basic
command to start the calibration procedure is:
T50> cal calibration_type
Where “calibration_type” is one of:
a) misc: Miscellaneous parameters are defined and calibrated
b) dev: Maximum deviations are set (automatically forces a “cal line” and a “cal
tone”)
c) line: Line1, Line 2, Dir Aud (Tone), and microphone inputs are tested and
calibrated.
d) pwr: The External PA attached to this unit is calibrated.
e) ref: The reference oscillators are adjusted and calibrated
f) tone: The maximum tone deviations are calibrated
g) all : (which does all the above)
6.3 The “Miscellaneous” Calibration Procedure
T50> cal misc
This procedure should not normally be invoked as part of any field maintenance.
The program will print out the Model Name and Serial Number of the exciter. If these
parameters haven’t already been defined (e.g. at an initial calibration, at the factory, the
service personnel will be prompted to enter these values).
Then it will ask the operator to enter the value of Vref (as measured at TP913, see 5.9).
Measure the voltage, at TP913 (Vref)
and type it on the command line...
Unless the reference diode D911 has been replaced, this should not be done. The user
should simply hit the Enter key to bypass this operation. If, though, D911 has been
replaced for some reason, then, the lid of the unit should be removed, and the voltage
measured. TP913 can be found just above JP12 (near the centre of the exciter).
RF Technology T50 Page 29
6 FIELD ALIGNMENT PROCEDURE
Then the exciter low battery alarm level will be asked for. If the current value is
acceptable, the User need only hit the Enter key on the keyboard. If another value is
preferred, then that value can be typed in.
For example:
The Exciter's Low Battery Alarm is 24V
If this is correct enter <RET>,
else enter the new value: 26
In this example, the low Battery Alarm level is changed to 26V.
The next request for the User should always be ignored.
The Exciter's default Modulation VCO Frequency is 320MHz
If this is correct enter <RET>
else enter the new value:
This parameter is for future use only. Please always hit the Enter key.
Then the user will be prompted for serial port baud rates, parities etc. Please leave these
parameters unchanged unless you are familiar with how to change such parameters on
your PC. The Eclipse50 software will expect 57600 BPS, and No Parity, and No Flow
Control. Note well, that if you do change any of these, the change will not take effect
until you power down the exciter and then power it up again. (As an alternative to
power cycling the exciter, and if the cover is off the exciter, you may simply press
switch momentary push-button S200 (see 5.2).
The next thing the calibration program tests is the state of the LINE pot. The program
will ask the user to adjust this pot. If the Potentiometer is below centre, it will ask the
user to adjust it up (i.e. adjust it clockwise). If it is above centre, it will ask the user to
adjust it down (i.e. adjust it counter clockwise). When the POT has been centred, or,
the User hits the Enter key, the program will terminate.
This last step is normally only done as part of a factory install, and it is done to ensure
that the POT is centred before being shipped to customers. For field maintenance
purposes, the step should be skipped in order to leave the LINE POT at the setting
formerly desired.
6.4 The “Reference” Calibration Procedure
T50> cal ref
To compensate for crystal ageing and other parameters that drift, the following
procedure should be performed approximately once per year.
If your exciter is fitted with the external reference option (an extra BNC connector on
the rear panel), the user can connect an external reference directly to the rear BNC
connector. If the exciter does not have this option, then the top cover of the exciter
Page 30 RF Technology T50
6 FIELD ALIGNMENT PROCEDURE
should be removed and an external reference oscillator should be connected via a 50
ohm probe to J4 (just to the right of the DC voltage regulators and converters).
The external reference clock, should have a power level from +5 to +26dBm and any
frequency that meets the following criteria:
500kHz, or any multiple,
any multiple of 128KHz, greater than or equal to 4,
any multiple of 160KHz, greater than or equal to 3,
No User input is required, except to hit the Enter key when the external reference is
connected. The firmware will automatically adjust both reference oscillators, and save
the new DAC adjustments in FLASH (as parameters) to be used to centre the oscillators
each time the unit powers up.
The user should see the following output. (Note that the temperatures, frequencies,
error values, serial number, etc, indicated are examples only)
Connect an external reference input or the clock output
from a GPS receiver to the GPS input.
Enter <RET> when this has been done.
External Reference is 10.0MHz
Ensure that the displayed reference frequency (10.0MHz in the above example) is the
same as the frequency of your oscillator.
Waiting for a GPS clock.
. . . . . .
The system waits here for a GPS reference to be seen. At this stage, this method of
calibrating the clocks has not been validated by RFT Engineering, so do not attempt to
use this option as yet.
Then the firmware continues.
Have not observed a GPS clock
System Frequency relative to external clock is 7372654.32
The crystal temperature is 22C.
Waiting up to 1 minute for clocks to stabilise.
. . . . . .
The crystal temperature is 22 C
The channel ref error = 1 cnts or, 1.63 Hz
The mod ref error = 1 cnts or, 1.63Hz
RF Technology T50 Page 31
6 FIELD ALIGNMENT PROCEDURE
The user may see the following error message.
The Model Name is T50
and the Serial Number is 002313
Please take note of the Model, DAC values, serial number and
crystal temperature, and report this problem to RFT Engineering.
If this message is seen, it indicates a potential fault condition. If the final text indicates
that the channel and mod reference errors are within specification (the last text output),
then the unit is able to be used, but nonetheless, it is advisable that an e-mail be sent to
RF Technology indicating the problem. Such a problem may be caused by a crystal
having aged to such an extent, that it is getting close to the region where it may soon, no
longer be adjusted, or that, with further degradation, the low frequency performance
may be compromised.
As no other calibration procedure requires the top cover to be removed, you should
replace the cover, should you have had to remove it for this procedure.
6.5 The “Deviation” Calibration Procedure
T50> cal dev
This procedure should not normally be invoked as part of any field maintenance. The
only conceivable time that it might ever be used, would be if a non standard maximum
deviation was required.
The first stage begins with the following message:
This procedure sets the Balance and Max Deviation Levels
Connect an audio signal generator to the Line 1 inputs
Set the output to be a sine wave, 388mV rms and 75Hz
Disconnect the RF connection to the PA
and connect a deviation meter to the exciter's BNC output.
Note that the nominal output power of the exciter’s output is 1W. Whilst the power
level is not set to the maximum level, the deviation meter should either have an input
power rating of at least +30dBm, or suitable attenuation is required between the exciter
and the deviation meter. Note that for this test the nominal RF output frequency is
37.5MHz.
Enter + or - to increase or decrease the deviation,
and <RET> when the deviation is 5kHz
?
Here the user can hit the +, p, or P, keys to increase the deviation, or -, m, or M keys to
decrease it. In response, the firmware, which has opened up the maximum deviation
digital POT (U303) to maximum gain is adjusting the Line1 VCA accordingly.
When the deviation is as close to 5kHz as can be obtained, the User should hit their
Enter key.
Page 32 RF Technology T50
6 FIELD ALIGNMENT PROCEDURE
Then the firmware will make the following request.
Change the signal generator frequency to 1kHz
When this has been done, the User needs to hit the Enter key, and the following will
appear again.
Enter + or - to increase or decrease the deviation,
and <RET> when the deviation is 5kHz
?
In response to the +, or – keys (or m, p, M, or P), the firmware adjusts the BALANCE
VCA accordingly. The user should do this until the deviation is as close to that
achieved at 75Hz as possible.
That now sets the balance.
The firmware will now prompt the user for a “User specified Deviation”. This is a
deviation other than the following standard deviations, 5.0kHz, 4.0kHz, 3.0kHz,
2.5kHz, 2.0kHz, and 1.5kHz. At the factory, it is set to 4.5kHz.
Enter the User Specified Deviation (kHz): 4.5
In this example, the user has specified 4.5kHz deviation.
Then the software will automatically set the Hi-Gain option on, which will cause the
output to got to somewhere between 7 and 9kHz deviation, and it will be very clipped.
Then the user will be prompted, as it was for the Balance adjustment, to enter keys to
set the deviation to as close to 5kHz as possible, whilst still being lower than 5kHz.
That sets the deviation setting for U303 for 5kHz maximum deviation. This is then
followed by the same procedure to set the 4kHz maximum deviation setting, then 3kHz,
2.5khz, 1.5kHz, and then the User Specified Deviation (e.g. 4.5kHz).
The least significant BCD digit of the deviation parameter, in a channel setting, selects
the appropriate maximum deviation when the exciter keys up. (See 4.2 and Table 7). In
this way, for example, it may be possible to allocate frequencies in the band 30-40MHz
on 12.5kHz channel spacing, and on 20kHz channel spacing over the band 25-30MHz.
6.6 The “Tone Deviation” Calibration Procedure
T50> cal tone
This procedure should not normally be invoked as part of any field maintenance. The
only conceivable time that it might ever be used, would be if a non standard maximum
tone deviation was required.
RF Technology T50 Page 33
6 FIELD ALIGNMENT PROCEDURE
This procedure is similar to the maximum deviation procedure (See 6.5). The Line 1
and Line 2 audio paths are turned off for this procedure, as is the Direct Audio (TONE)
input. The only signal sent to the modulator is a tone of 107.2Hz.
The program starts off, with the following message:
This procedure sets the maximum tone deviations for a
Max Deviation of 5kHz. Note that the actual maximum
tone deviations automatically scale with the Max Deviation.
eg a 500Hz tone deviation would be a 250Hz tone deviation
when a 2.5kHz Max Deviation was chosen.
Disconnect the RF connection to the PA,
and connect a deviation meter to the exciter's BNC output.
The audio is being switched off, and 107.2Hz tone generated
Enter the User Specified Tone Deviation(Hz):
The user is expected to connect up the deviation meter, and enter the User Specified
Maximum Tone Deviation. This is a deviation that is different to the standard
deviations of 750Hz, 500Hz, 375Hz, 250Hz, and 150Hz. The factory default for this is
600Hz.
Thence a procedure that is almost identical to that used for setting maximum deviations
is used to set these tone deviations. There is one significant difference, though, and that
is, as well as using + (or p, or P), and – (or m, or M) keys to step the deviation up or
down, one can also use the < key, or the > key. These last two keys will step down, or
up, the level of signal transmitted by U500, whereas the other keys will modify the
setting of the digital POT U503 (see 5.5).
6.7 The “Line” Calibration Procedure
T50> cal line
This procedure should not be used as part of any usual field maintenance, unless any
component has been replaced that might affect the gain of any of the audio inputs.
Note that if the deviations are calibrated, then this procedure will be automatically
invoked.
The program begins:
Calibrating Line 1 and Line 2 audio levels
Attach an audio signal generator to Line 1
Set the output to be a sine wave, 388mV rms and 1kHz
Disconnect the RF connection to the PA
and connect a deviation meter to the exciter's BNC output.
Enter + or - to increase or decrease the deviation,
and <RET> when the deviation is 3kHz
Page 34 RF Technology T50
6 FIELD ALIGNMENT PROCEDURE
?
This is the same mechanism that is used in 6.5 and 6.6. The user enters +, p, or P to
increase the Line 1 gain, to increase the deviation, or, -, m, or M to decrease the gain.
The user hits the Enter key when the desired deviation is set.
Now attach the audio signal generator to Line 2
Enter + or - to increase or decrease the deviation,
and <RET> when the deviation is 3kHz
?
Again the user enters +, p, or P to increase the Line 2 gain, to increase the deviation, or,
-, m, or M to decrease the gain. The user hits the Enter key when the desired deviation
is set.
The firmware goes on to open the microphone audio path (note that the microphone
PTT switch does not need to be depressed for this). Note also that the application of a
10mV test input is a factory only test. An adequate test in field testing, would be to
speak into the microphone and see that the deviation meter responded accordingly.
Testing the microphone input.
Attach an audio signal generator to the microphone input.
Set the output to be a sine wave, 10mV rms and 1kHz.
Ensure that the deviation is between 2.7 and 3.3kHz
Enter <RET> when measurement complete.
Alert Engineering if there is a failure.
Then the Direct Audio input (with the low pass filter off) is tested.
Testing the Tone input.
Attach an audio signal generator to the Tone input.
Set the output to be a sine wave, 388mV rms, and 1kHz.
Enter + or - to increase or decrease the deviation,
and <RET> when the deviation is 3kHz
?
And then user then follows the same procedure as defined for setting the Line 1 and
Line 2 gains. Note that the digital POT does not provide the same linearity as the VCAs
used in the line input audio circuits. As such it may not be possible to set the deviation
to exactly 3kHz.
6.8 The “Power” Calibration Procedure
T50> cal pwr
All Power Amplifiers are calibrated ex-factory. All the important parameters, such as
the forward and reverse power sense adjustment, and drain bias settings are not
dependent on the exciter, and thus any factory calibrated PA50 power amplifier can be
connected to, and work correctly with any T50 exciter. The frequency range of the
amplifier is defined by three jumper settings on the external PA, which the CPU can
RF Technology T50 Page 35
6 FIELD ALIGNMENT PROCEDURE
detect. Thus the CPU knows (on power up) what frequencies are, or are not, possible to
be used with the PA.
The exciter does store some PA specific parameters, such as the Serial Number of the
PA, and also some offset values for the pre-amp drain current, and the output stage
drain current. These latter offsets improve the accuracy of the over current alarm
testing, (but are not strictly necessary). In order to set these parameters, it is advised
that this procedure be performed every time an exciter is used with a new External
Power Amplifier. Note that many of the stages can be skipped if they have been
performed before.
The program begins:
This procedure is used to calibrate an External Power Amplifier.
The existing PA's SERIAL NO is: 002356
Enter the new PA serial no:
Simply hit the Enter key here if the Serial Number is correct.
Take the lid off a PA, and set all three
bias Pots (R238,R239, and R240) fully clockwise.
Enter <RET> when done.
Now we will set the Bias currents in the PA.
Attach power to the PA.
Attach a calibrated millivoltmeter between TP100(+ve lead)
and TP101(-ve lead). Adjust R238 until the meter reads 50mV
Enter <RET> when done
Attach the calibrated millivoltmeter between TP102(+ve lead)
and TP103(-ve lead). Adjust R239 until the meter reads 10mV
Enter <RET> when done.
Adjust R240 until the meter reads 20mV
Enter <RET> when done.
Unless one of the RF power transistors has been replaced, the user should simply skip
these last four stages by hitting the Enter key four times.
Attach the Power Amplifier to the Exciter,
and ensure the PA is powered up.
Attach the PA output to a reflectometer, the reflectometer to a 50dB
(nominal) attenuator, and the attenuator to a calibrated power meter
Enter <RET> when this has been done");
Adjust C209 in the Power Amplifier
until there is a minimum in the dc voltage measured at TP204
Enter <RET> when done.
Page 36 RF Technology T50
7.1 Overall Description 7 SPECTFICATIONS
Adjust the Forward Power Sense POT (R228) until
the measured output power (adjusted for the attenuator and
reflectometer losses) is equal to the Preset Forward Power.
Enter <RET> when done.
Unless something has been modified in the power sense circuits, these last three stages
should be skipped by simply hitting the Enter key three times.
This next step is necessary, and it allows the firmware to compute an offset in the output
stage drain current, so that the exciter’s ability to measure the output stage drain current
is significantly more accurate.
Measure the voltage across TP102(+ve lead)
and TP103(-ve lead), and enter the value measured
This next step is also necessary, and it allows the firmware to compute an offset in the
pre-amp stage drain current, so that the exciter’s ability to measure the pre-amp stage
drain current is significantly more accurate.
Measure the voltage across TP100(+ve lead)
and TP101(-ve lead), and enter the value measured
The next two stages can be skipped by simply hitting the Enter key twice.
Attach the reflectometer to an open circuit
Enter <RET> when this has been done
Adjust the Reverse Power Sense POT (R227) until
the displayed reverse power equals 50W.
Enter <RET> when this has been done.
This then completes all the calibration procedures.
7 SPECIFICATIONS
7.1 Overall Description
The transmitter is a frequency synthesized, narrow band, HF, FM unit, used to drive an
external 120 watt amplifier. All necessary control and 600 Ω line interface circuitry is
included.
7.1.1 Channel Capacity
Although most applications are single channel, it can be programmed for up to 100
channels, numbered 0-99. This is to provide the capability of programming all channels
into all of the transmitters used at a given site. Where this facility is used in conjunction
RF Technology T50 Page 37
7 SPECIFICATIONS 7.1.2 CTCSS
with channel-setting in the rack, exciter modules may be “hot-jockeyed” or used
interchangeably. This can be convenient in maintenance situations.
Channel information consists of two independent and complete sets of information,
which may differ or be the same. One set defines the parameters to be used, if the unit
is keyed up from PTT-in being “grounded”, and the other set defines the parameters to
be used if the unit is keyed up for any reason other than PTT-in being “grounded”.
The parameters that can be defined on a per channel basis are:
a) The frequency
b) The CTCSS tone (if any) to be generated
c) The delay from the initiation of the exciter to RF output being generated
(Is specified in hundredths of a second, 0 – 999)
d) The transmit tail; the length of time after the exciter is released before
transmission stops. (Is specified in seconds 0 – 999).
e) The No Tone period; a length of time after the expiry of (d) in which
transmission continues, but with no tone being generated. (Is specified in
tenths of a second, 0 –999)
f) Whether audio from Line 1, or Line 2, or both, (or neither!) is enabled,
and whether or not Pre-emphasis is required, or not, on each line, and
whether or not an extra gain pad (of 20dB) is required.
g) What Nominal Tone Deviation, and Maximum Deviation should be used
(See Tables 7 and 8)
7.1.2 CTCSS
Full EIA subtone Capability is built into the modules. The CTCSS tone can be
programmed for each channel. This means that each channel number can represent a
unique RF and tone frequency combination.
7.1.3 Channel Programming
The channel information is stored in non-volatile memory and can be programmed via
the front panel connector using a PC, and/or RF Technology software.
7.1.4 Channel Selection
Channel selection is by eight channel select lines connected to the rear panel that
mounts on the rear DB25 female connector.
A BCD active high code applied to the lines selects the required channel. This can be
supplied by pre-wiring the rack connector so that each rack position is dedicated to a
fixed channel. Alternatively, thumb-wheel switch panels are available.
Page 38 RF Technology T50
7.1.5 Microprocessor 7 SPECIFICATIONS
7.1.5. Microprocessor
A microprocessor is used to control the synthesizer, tone squelch, PTT functions,
external reference monitoring, calibration, fault monitoring and reporting, output power
level control, volume adjustment, line selection, option setting, and facilitate channel
frequency programming.
7.2 Physical Configuration
The transmitter is designed to fit in a 19 inch rack mounted sub-frame. The installed
height is 4 RU (178 mm) and the depth is 350 mm. The transmitter is 63.5 mm or two
Eclipse modules wide.
7.3 Front Panel Controls, Indicators, and Test Points
7.3.1 Controls
Transmitter Key - Momentary Contact Push Button
Line Input Level - screwdriver adjust multi-turn pot
7.3.2 Indicators
Power ON - Green LED
Tx Indicator - Yellow LED
Fault Indicator - Flashing Red LED
7.3.3 Test Points
There are no front panel test points. All important test points are monitored by the
firmware.
7.4 Electrical Specifications
7.4.1 Power Requirements
Operating Voltage - 16 to 32 Vdc
Current Drain - 1A Maximum, typically 0.25A Standby
Polarity - Negative Ground
RF Technology T50 Page 39
7 SPECIFICATIONS 7.4.2 Frequency Range and Channel Spacing
7.4.2 Frequency Range and Channel Spacing
The T50, as a single model, covers the full band, and all channel spacing.
Frequency 25 kHz 20kHz 15kHz 12.5 kHz 10 kHz 7.5 kHz 6.25 kHz
25 - 50 MHz T50 T50 T50 T50 T50 T50 T50
7.4.3 Frequency Synthesizer Step Size
The specified frequency can be any multiple of 1250Hz.
7.4.4 Frequency Stability
±5 ppm over 0 to +60 C, standard
±2 ppm over -20 to +60 C, optional
7.4.5 Number of Channels
100, numbered 00 - 99
7.4.6 RF Output Impedance
50Ω
7.4.7 Output power
The T50 needs an external PA50 power amplifier.
The output power is factory set to 100W by default, the reverse power level is set to
fold back the output power when the PA50 sees a load with VSWR of 3:1 or higher (i.e.
when the reverse power is 25% or more of the forward power).
7.4.8 Transmit Duty Cycle
100%
7.4.9 Spurious and Harmonics
Less than 0.25
µ
W, when connected to a PA50 operating at an output power level of
100W.
Page 40 RF Technology T50
7.4.10 Carrier and Modulation Attack Time 7 SPECIFICATIONS
7.4.10 Carrier and Modulation Attack Time
Less than 25ms. Certain models have RF envelope attack and decay times controlled in
the range 200
µ
s< tr/f <2ms according to regulatory requirements.
7.4.11 Modulation
Type - Two point direct FM with optional pre-emphasis
Frequency Response - ±1 dB of the selected characteristic from 300-3000Hz
Maximum Deviation - Maximum deviation set on a per channel basis to 1.5, 2.0, 2.5,
3.0, 4,0, or 5.0 kHz. A User Specified Maximum deviation can be preset as well.
(Please request this when ordering the unit).
7.4.12 Distortion
Modulation distortion is less than 3% at 1 kHz and 60% of rated system deviation.
7.4.13 Residual Modulation and Noise
The residual modulation and noise in the range 300 - 3000 Hz is typically less than -
50dB with 5kHz maximum deviation (i.e. a test level of 3kHz).
7.4.14 600Ω
ΩΩ
Ω Line Input Sensitivity
Adjustable from -32 to +12 dBm for rated deviation on two symmetric, independent,
transformer coupled Line inputs.
7.4.15 Test Microphone Input
200Ω dynamic, with PTT
7.4.16 External Tone Input
Compatible with R500 tone output
7.4.17 T/R Relay Driver
An open drain MOSFET output is provided to operate an antenna change over relay or
solid state switch. The transistor can sink up to 250mA. A 1W flywheel diode connects
to the 12V rail to prevent damage to the FET from inductive kick from a relay coil.
RF Technology T50 Page 41
7 SPECIFICATIONS 7.4.20 Channel Select Input/Output
7.4.18 Channel Select Input/Output
Coding - 8 lines, BCD coded 00 - 99
Logic Input Levels - Low for <1.5V, High for >3.5V
Internal 10K pull down resistors select channel 00 when all inputs are O/C.
7.4.19 DC Remote Keying
An opto-coupler input is provided to enable dc loop keying over balanced lines or local
connections. The circuit can be connected to operate through the 600Ω line.
7.4.20 PTT in
An external input that when “grounded” with at least 1mA of current, will cause the
exciter to key up. The current is drawn from the PTT in input which attempts to “pull
up” anything that “grounds” it. It can be “grounded” with a short to 0V, or any
resistance up to 3.9k ohm. If the resistance of the “ground connection” is less than 2.2k
ohms, then up to three diodes in series can be part of the grounding path. This allows
systems installers to use quite complex diode logic to enable or disable exciters.
It would normally be “grounded” by the COS output of a receiver.
7.4.21 Programmable No-Tone Period
A No-Tone period can be appended to the end of each transmission to aid in eliminating
squelch tail noise which may be heard in mobiles with slow turn off decoders. The No-
Tone period can be set from 0-99.9 seconds in 0.1 second increments.
7.4.22 Firmware Timers
The controller firmware includes some programmable timer functions.
Repeater Hang Time(Transmit Tail) - A short delay or ``Hang Time'' can be
programmed to be added to the end of transmissions. This is usually used in talk
through repeater applications to prevent the repeater from dropping out between mobile
transmissions. The Hang Time can be individually set on each channel for 0 - 999
seconds.
Time Out Timer - A time-out or transmission time limit can be programmed to
automatically turn the transmitter off. The time limit can be set from 0-10million
seconds. The timer is automatically reset when the PTT input is released. Zero seconds
disables the timer, and allows continuous transmission.
Page 42 RF Technology T50
7.4.25 CTCSS 7 SPECIFICATIONS
7.4.23 CTCSS
CTCSS tones can be provided by an internal encoder or by an external source connected
to the external tone input. The internal CTCSS encoding is provided by a subassembly
PCB module. This provides programmable encoding of any tone, accurate to 0.1Hz,
including all EIA tones, from 67.0Hz to 257Hz.
7.5 Connectors
7.5.1 RF Output Connector
BNC connector on the module rear panel.
7.5.2 Power & I/O Connector
25-pin “D” Female Mounted at the top of the rear panel
7.5.3 External Reference Connector (optional)
BNC connector mounted in the middle of the rear panel connector.
RF Technology T50 Page 43
A ENGINEERING DIAGRAMS
A Engineering Diagrams
There is only one printed circuit board covering all models of the T50. There is only
one option for this product, which is the external reference clock option. That option
adds a rear connector, and a small length of coaxial cable and a fixed coaxial cable
mount to the parts list.
Unlike other products in the Eclipse range, CTCSS is no longer an option. All units
have the ability to transmit CTCSS tones.
A.1 Block Diagram
Figure 1 shows the block signal flow diagram.
A.2 Circuit Diagrams
Figure 2 shows the detailed circuit diagram with component numbers and values for the
main (exciter) PCB. Figure 3 shows the detailed circuit diagram with component
numbers and values for the higher-power PA variation. Figure 4 shows the detailed
circuit diagram with component numbers and values for the lower-power PA variation.
A.3 Component Overlay Diagrams
Figure 5 shows the PCB overlay guide with component positions for the main (exciter)
PCB. Figure 6 shows the detailed circuit diagram with component numbers and values
for the higher-power PA variation. Figure 7 shows the detailed circuit diagram with
component numbers and values for the lower power PA variation.
T50 PARTS LIST
Page 44 RF Technology T50
B T50 Parts List
Main PCB Assembly Parts
Ref Description Part Number
C100 Four EMI filters in a 1206 package, 100pF 34/NFA3/1100
C101 Four EMI filters in a 1206 package, 100pF 34/NFA3/1100
C102 Four EMI filters in a 1206 package, 100pF 34/NFA3/1100
C103 Four EMI filters in a 1206 package, 100pF 34/NFA3/1100
C201 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C202 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C203 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C204 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C205 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C206 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C207 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C208 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C209 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C210 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C211 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C212 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C214 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C215 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C216 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C217 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C219 3u3F SMD, Electrolytic cap, A body, 10% 42/STA1/03U3
C220 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C221 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C222 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C224 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C225 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C226 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C227 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C300 22uF Electrolytic Capacitor, 35V, Bipolar 41/BP01/022U
C301 22uF Electrolytic Capacitor, 35V, Bipolar 41/BP01/022U
C302 2n2F Cer. Cap, NPO, 1206, 5% 46/26N1/02N2
C304 3u3F SMD, Electrolytic cap, A body, 10% 42/STA1/03U3
C305 10nF Cer. Cap, NPO, 1206, 5% 46/26N1/010N
C306 120pF Cer. Cap, NPO, 0603, 5% 46/63N1/120P
C307 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C308 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C309 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C310 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C311 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C312 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C400 33uF SMD, low ESR Electrolytic cap, C body 41/SELC/033U
C401 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C402 3n3F Cer. Cap, NPO, 1206, 5% 46/26N1/03N3
C403 3n3F Cer. Cap, NPO, 1206, 5% 46/26N1/03N3
C404 3n3F Cer. Cap, NPO, 1206, 5% 46/26N1/03N3
C405 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
T50 PARTS LIST
RF Technology T50 Page 45
Ref
C406
Description
100nF, 25V, Y5V, decoupler, 0603
Part Number
46/63Y1/100N
C407 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C408 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C409 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C410 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C411 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C412 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C413 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C414 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C415 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C416 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C417 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C418 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C419 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C422 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C423 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C425 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C426 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C427 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C428 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C500 22pF Cer. Cap, NPO, 0603, 5% 46/63N1/022P
C501 22pF Cer. Cap, NPO, 0603, 5% 46/63N1/022P
C502 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C503 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C506 100pF Cer. Cap, NPO, 0603, 5% 46/63N1/100P
C507 100pF Cer. Cap, NPO, 0603, 5% 46/63N1/100P
C508 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C509 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C510 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C511 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C513 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C514 Ceramic Capacitor, 16V, 22nF, X7R, 22nF,10% 45/X7R1/022N
C515 100nF, 50V, NPO, TH, 5mm 47/2007/100N
C516 1n2F Cer. Cap, NPO, 1206, 5% 46/26N1/01N2
C600 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C601 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C602 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C603 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C604 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C605 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C606 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C607 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C608 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C609 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C610 470pF Cer. Cap, NPO, 0603, 5% 46/63N1/470P
C611 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C612 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C613 Ceramic Capacitor, 16V, 220nF, X7R, 10% 45/X7R1/220N
C614 15pF Cer. Cap, NPO, 0603, 5% 46/63N1/015P
C615 15pF Cer. Cap, NPO, 0603, 5% 46/63N1/015P
C616 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
T50 PARTS LIST
Page 46 RF Technology T50
Ref Description Part Number
C617 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C619 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C620 33pF Cer. Cap, NPO, 0603, 5% 46/63N1/033P
C621 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C622 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C623 Ceramic Capacitor, 16V, 220nF, X7R, 10% 45/X7R1/220N
C624 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C625 3u3F SMD, Electrolytic cap, A body, 10% 42/STA1/03U3
C626 3u3F SMD, Electrolytic cap, A body, 10% 42/STA1/03U3
C627 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C628 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C629 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C630 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C631 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C634 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C635 8p2F Cer. Cap, NPO, 0603, 5% 46/63N1/08P2
C636 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C637 56pF Cer. Cap, NPO, 0603, 5% 46/63N1/056P
C638 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C639 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C640 8p2F Cer. Cap, NPO, 0603, 5% 46/63N1/08P2
C641 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C642 100pF Cer. Cap, NPO, 0603, 5% 46/63N1/100P
C643 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C644 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C645 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C646 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C648 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C649 10pF Cer. Cap, NPO, 0603, 5% 46/63N1/010P
C650 10pF Cer. Cap, NPO, 0603, 5% 46/63N1/010P
C651 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C652 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C700 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C701 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C702 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C703 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C704 22pF Cer. Cap, NPO, 0603, 5% 46/63N1/022P
C705 22pF Cer. Cap, NPO, 0603, 5% 46/63N1/022P
C706 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C707 22pF Cer. Cap, NPO, 0603, 5% 46/63N1/022P
C708 22pF Cer. Cap, NPO, 0603, 5% 46/63N1/022P
C709 22pF Cer. Cap, NPO, 0603, 5% 46/63N1/022P
C710 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C711 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C712 3u3F SMD, Electrolytic cap, A body, 10% 42/STA1/03U3
C713 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C714 150pF Cer. Cap, NPO, 0603, 5% 46/63N1/150P
C715 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C716 22pF Cer. Cap, NPO, 0603, 5% 46/63N1/022P
C717 3p9F Cer. Cap, NPO, 0603, 5% 46/63N1/03P9
C718 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
T50 PARTS LIST
RF Technology T50 Page 47
Ref Description Part Number
C719 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C720 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C721 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C722 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C723 3u3F SMD, Electrolytic cap, A body, 10% 42/STA1/03U3
C724 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C725 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C726 3p9F Cer. Cap, NPO, 0603, 5% 46/63N1/03P9
C727 15pF Cer. Cap, NPO, 0603, 5% 46/63N1/015P
C728 15pF Cer. Cap, NPO, 0603, 5% 46/63N1/015P
C729 15pF Cer. Cap, NPO, 0603, 5% 46/63N1/015P
C730 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C731 15pF Cer. Cap, NPO, 0603, 5% 46/63N1/015P
C732 5p6F Cer. Cap, NPO, 0603, 5% 46/63N1/05P6
C733 12pF Cer. Cap, NPO, 0603, 5% 46/63N1/012P
C734 3p9F Cer. Cap, NPO, 0603, 5% 46/63N1/03P9
C735 3p9F Cer. Cap, NPO, 0603, 5% 46/63N1/03P9
C736 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C737 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C738 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C739 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C740 47pF Cer. Cap, NPO, 0603, 5% 46/63N1/04P7
C742 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C743 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C745 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C746 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C747 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C748 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C749 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C750 22pF Cer. Cap, NPO, 0603, 5% 46/63N1/022P
C751 33pF Cer. Cap, NPO, 0603, 5% 46/63N1/033P
C752 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C753 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C754 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C755 47pF Cer. Cap, NPO, 0603, 5% 46/63N1/047P
C756 10pF Cer. Cap, NPO, 0603, 5% 46/63N1/010P
C757 120pF Cer. Cap, NPO, 0603, 5% 46/63N1/120P
C758 120pF Cer. Cap, NPO, 0603, 5% 46/63N1/120P
C759 47pF Cer. Cap, NPO, 0603, 5% 46/63N1/047P
C760 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C761 22pF Cer. Cap, NPO, 0603, 5% 46/63N1/022P
C762 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C763 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C764 6p8F Cer. Cap, NPO, 0603, 5% 46/63N1/06P8
C765 56pF Cer. Cap, NPO, 0603, 5% 46/63N1/056P
C770 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C771 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C772 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C773 Ceramic Capacitor, 16V, 1uF, Y5V 45/Y5X7/1U16
C774 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C775 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
T50 PARTS LIST
Page 48 RF Technology T50
Ref Description Part Number
C776 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C801 100nF Cer. Cap, X7R, 1206, 10% 46/3310/100N
C802 1n2F Cer. Cap, X7R, 0603, 10% 46/63X1/01N2
C803 47pF Cer. Cap, NPO, 0603, 5% 46/63N1/047P
C804 470pF Cer. Cap, NPO, 0603, 5% 46/63N1/470P
C805 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C806 1n2F Cer. Cap, X7R, 0603, 10% 46/63X1/01N2
C807 1p8F Cer. Cap, NPO, 0603, 5% 46/63N1/01P8
C808 100nF Cer. Cap, X7R, 1206, 10% 46/3310/100N
C810 100uF Electrolytic Capacitor, 35V 41/2001/100U
C811 1p8F Cer. Cap, NPO, 0603, 5% 46/63N1/01P8
C812 100pF Cer. Cap, NPO, 0603, 5% 46/63N1/100P
C813 56pF Cer. Cap, NPO, 0603, 5% 46/63N1/056P
C815 33pF Cer. Cap, NPO, 0603, 5% 46/63N1/033P
C816 10pF Cer. Cap, NPO, 0603, 5% 46/63N1/010P
C818 68pF Cer. Cap, NPO, 0603, 5% 46/63N1/068P
C819 68pF Cer. Cap, NPO, 0603, 5% 46/63N1/068P
C820 470pF Cer. Cap, NPO, 0603, 5% 46/63N1/470P
C821 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C822 10nF Cer. Cap, X7R, 0603, 10% 46/63X1/010N
C823 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C824 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C825 220pF Cer. Cap, NPO, 0603, 5% 46/63N1/220P
C826 3u3F SMD, Electrolytic cap, A body, 10% 42/STA1/03U3
C827 10 uF Electrolytic capacitor 41/2001/010U
C829 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C901 100uF SMD, low ESR Electrolytic cap, D body 41/SELD/100U
C902 470uF Electrolytic Capacitor, Low ESR, 35V 41/200L/470U
C903 33uF SMD, low ESR Electrolytic cap, C body 41/SELC/033U
C904 3u3F SMD, Electrolytic cap, A body, 10% 42/STA1/03U3
C915 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C920 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C923 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C924 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C925 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C926 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C927 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C928 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C929 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C930 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C931 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C932 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C933 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C934 100nF, 25V, Y5V, decoupler, 0603 46/63Y1/100N
C935 470uF Electrolytic Capacitor, Low ESR, 35V 41/200L/470U
C936 33uF SMD, low ESR Electrolytic cap, C body 41/SELC/033U
C937 100uF SMD, low ESR Electrolytic cap, D body 41/SELD/100U
C938 100uF SMD, low ESR Electrolytic cap, D body 41/SELD/100U
C939 100uF SMD, low ESR Electrolytic cap, D body 41/SELD/100U
C940 33uF SMD, low ESR Electrolytic cap, C body 41/SELC/033U
C941 33uF SMD, low ESR Electrolytic cap, C body 41/SELC/033U
T50 PARTS LIST
RF Technology T50 Page 49
Ref Description Part Number
C942 33uF SMD, low ESR Electrolytic cap, C body 41/SELC/033U
C943 33uF SMD, low ESR Electrolytic cap, C body 41/SELC/033U
C944 33uF SMD, low ESR Electrolytic cap, C body 41/SELC/033U
C945 33uF SMD, low ESR Electrolytic cap, C body 41/SELC/033U
D102 Radially mounted LED 21/1010/LEDR
D103 Radially mounted LED 21/1010/LEDY
D104 Radially mounted LED 21/1010/LEDG
D200 Dual Series Diode 21/3010/AV99
D202 Gen. Purpose 1N4004 diode in SMD pkg 24/SMA1/4004
D203 Zener Diode 21/1040/C3V3
D300 Bi-directional Transil 24/TRSL/012V
D301 Bidirectional Transil 24/TRSL/012V
D302 Bidirectional Transil 24/TRSL/012V
D303 Dual Series Diode 21/3010/AV99
D304 Dual Series Diode 21/3010/AV99
D305 Dual Series Diode 21/3010/AV99
D306 Gen. Purpose 1N4004 diode in SMD pkg 24/SMA1/4004
D307 Dual Schottky, Comm. Cathode, Diode 24/3BAT/54C1
D400 Dual Series Diode 21/3010/AV99
D401 Dual Series Diode 21/3010/AV99
D402 Dual Series Diode 21/3010/AV99
D403 Dual Series Diode 21/3010/AV99
D500 Dual Series Diode 21/3010/AV99
D501 Dual Series Diode 21/3010/AV99
D502 Dual Series Diode 21/3010/AV99
D503 Dual Series Diode 21/3010/AV99
D600 Voltage Controlled Capacitor 21/3060/V109
D601 Voltage Controlled Capacitor 21/3060/V109
D700 Schottky diode 21/3030/0017
D701 Voltage Controlled Capacitor 21/3060/V109
D703 Schottky diode 21/3030/0017
D704 Voltage Controlled Capacitor 21/3060/V109
D800 Dual Schottky, Comm. Cathode, Diode 24/3BAT/54C1
D906 Power Fast Schottky diode 24/BRM1/40T3
D907 Power Fast Schottky diode 24/BRM1/40T3
D908 Power Fast Schottky diode 24/BRM1/40T3
D909 Power Fast Schottky diode 24/BRM1/40T3
D910 Gen. Purpose 1N4004 diode in SMD pkg 24/SMA1/4004
D911 4.096V Reference Diode 29/VREF/0001
F300 SMD (1206 pkg), 125mA fuse 39/1206/A125
F301 SMD (1206 pkg), 125mA fuse 39/1206/A125
F302 SMD (1206 pkg), 125mA fuse 39/1206/A125
J1 BNC Connector 35/5BNC/RA01
JP12 4 Pin SIL Header 35/2501/0004
JP2 14 Pin SIL Header 35/2501/0014
JP3 10 pin DIL Header 35/7026/0010
L100 Ferrite, 1206 pkg, 120 ohm, 3A 37/P034/0001
L101 Ferrite, 1206 pkg, 600 ohm, 200mA 37/P033/0001
L102 Ferrite, 1206 pkg, 600 ohm, 200mA 37/P033/0001
L104 Ferrite, 1206 pkg, 600 ohm, 200mA 37/P033/0001
L200 220uH Choke 37/3320/P103
T50 PARTS LIST
Page 50 RF Technology T50
Ref Description Part Number
L202 Ferrite, 1206 pkg, 600 ohm, 200mA 37/P033/0001
L203 Ferrite, 1206 pkg, 600 ohm, 200mA 37/P033/0001
L204 Ferrite, 1206 pkg, 600 ohm, 200mA 37/P033/0001
L205 Ferrite, 1206 pkg, 600 ohm, 200mA 37/P033/0001
L500 Ferrite, 1206 pkg, 600 ohm, 200mA 37/P033/0001
L600 Ferrite, 1206 pkg, 600 ohm, 200mA 37/P033/0001
L700 27nH Inductor 37/8551/027N
L701 39nH Inductor 37/8551/039N
L702 27nH Inductor 37/8551/027N
L703 27nH Inductor 37/8551/027N
L704 47nH Inductor 37/8551/047N
L705 27nH Inductor 37/8551/027N
L706 330nH Inductor 37/3320/330N
L708 330nH Inductor 37/3320/330N
L709 330nH Inductor 37/3320/330N
L710 330nH Inductor 37/3320/330N
L711 330nH Inductor 37/3320/330N
L712 220nH Inductor 37/8551/220N
L713 220uH Choke 37/3320/P103
L714 330nH Inductor 37/3320/330N
L715 330nH Inductor 37/3320/330N
L716 Inductor - Air Core, 12.5nH 37/AC51/12N5
L717 100nH Inductor 37/8551/100N
L718 220uH Choke 37/3320/P103
L719 Inductor - Air Core, 18.5nH 37/AC51/18N5
L720 220nH Inductor 37/8551/220N
L721 270nH Inductor 37/85T1/270N
L722 220nH Inductor 37/8551/220N
L723 330nH Inductor 37/3320/330N
L724 330nH Inductor 37/3320/330N
L725 3u3H Choke 37/3320/P101
L726 82nH Inductor 37/8551/082N
L800 Ferrite, 1206 pkg, 600 ohm, 200mA 37/P033/0001
L801 Ferrite, 1206 pkg, 600 ohm, 200mA 37/P033/0001
L803 Inductor - Air Core, 538nH 37/AC52/558N
L804 Inductor - Air Core, 538nH 37/AC52/558N
L805 Inductor - Air Core, 120nH 37/AC52/120N
L806 Inductor - Air Core, 169nH 37/AC52/169N
L807 220uH Choke 37/3320/P103
L808 3u3H Choke 37/3320/P101
L809 180nH Inductor 37/8551/180N
L810 1uH Choke 37/3320/P200
L811 3u3H Choke 37/3320/P101
L901 33uH Choke 37/3320/P102
L902 SMD High Current, Shielded, 220uH Choke 37/MSP1/220U
L903 SMD High Current, Shielded, 330uH Choke 37/MSP1/330U
L904 SMD High Current, Shielded, 220uH Choke 37/MSP1/220U
L905 220uH Choke 37/3320/P103
L906 Ferrite, 1206 pkg, 120 ohm, 3A 37/P034/0001
L907 Ferrite, 1206 pkg, 120 ohm, 3A 37/P034/0001
L908 Ferrite, 1206 pkg, 120 ohm, 3A 37/P034/0001
T50 PARTS LIST
RF Technology T50 Page 51
Ref Description Part Number
L909 Ferrite, 1206 pkg, 120 ohm, 3A 37/P034/0001
M1 Tinned BeCu, used as RF screen. 94/BECU/24XH
M1C RF Screen Cover (Small) 80/9209/0001
M2 Conductive Foam Inserts 83/0001/0000
MX700 +7dBm0 Mixer, Surface Mount 37/MIXR/P028
P1 DB9 Female with filtered pins 35/5012/009F
P3 DB25 Female with filtered pins 35/5012/025F
Q200 Gen. Purpose NPN transistor in SOT-23 27/3020/3904
Q201 N channel, Enhancement Mode MOSFET 27/30B5/5138
Q202 N Channel Junction FET(low Freq) 27/3020/5484
Q203 NPN Switching transistor in SOT-23 27/3020/2369
Q204 NPN Switching transistor in SOT-23 27/3020/2369
Q205 Gen. Purpose PNP transistor in SOT-23 27/3010/3906
Q206 Gen. Purpose NPN transistor in SOT-23 27/3020/3904
Q300 N channel, Enhancement Mode MOSFET 27/30B5/5138
Q301 Gen. Purpose PNP transistor in SOT-23 27/3010/3906
Q302 Gen. Purpose PNP transistor in SOT-23 27/3010/3906
Q400 Gen. Purpose PNP transistor in SOT-23 27/3010/3906
Q401 Gen. Purpose PNP transistor in SOT-23 27/3010/3906
Q402 Gen. Purpose PNP transistor in SOT-23 27/3010/3906
Q500 Gen. Purpose PNP transistor in SOT-23 27/3010/3906
Q501 Gen. Purpose PNP transistor in SOT-23 27/3010/3906
Q600 Gen. Purpose NPN transistor in SOT-23 27/3020/3904
Q700 Gen. Purpose PNP transistor in SOT-23 27/3010/3906
Q701 N channel, Enhancement Mode MOSFET 27/30B5/5138
Q702 Gen. Purpose NPN transistor in SOT-23 27/3020/3904
Q703 N channel, Enhancement Mode MOSFET 27/30B5/5138
Q704 N Channel Junction FET(UHF) 27/3030/J309
Q705 N Channel Junction FET(UHF) 27/3030/J309
Q706 N channel, Enhancement Mode MOSFET 27/30B5/5138
Q707 Gen. Purpose NPN transistor in SOT-23 27/3020/3904
Q801 SOD-89A RF Transistor(1W) 27/300B/FQ17
Q804 SOD-89A RF Transistor(1W) 27/300B/FQ17
Q805 SOD-89A RF Transistor(1W) 27/300B/FQ17
R100 0805, 1%, 4K7 resistor 51/8511/04K7
R101 0805, 1%, 4K7 resistor 51/8511/04K7
R102 0805, 1%, 4K7 resistor 51/8511/04K7
R103 1206 180R resistor 51/3380/0180
R104 1206 270R resistor 51/3380/0270
R105 0805, 1%, 4K7 resistor 51/8511/04K7
R201 0805, 1%, 1K resistor 51/8511/010K
R202 0805, 1%, 1K resistor 51/8511/010K
R203 0805, 1%, 1K resistor 51/8511/010K
R204 0805, 1%, 1K resistor 51/8511/010K
R205 0805, 1%, 2K2 resistor 51/8511/02K2
R206 0805, 1%, 2K2 resistor 51/8511/02K2
R207 0805, 1%, 68K resistor 51/8511/068K
R208 0805, 1%, 22K resistor 51/8511/022K
R209 0805, 1%, 330R resistor 51/8511/330R
R210 0805, 1%, 1K resistor 51/8511/010K
R211 0805, 1%, 220R resistor 51/8511/220R
T50 PARTS LIST
Page 52 RF Technology T50
Ref Description Part Number
R212 0805, 1%, 220R resistor 51/8511/220R
R213 0805, 1%, 1M resistor 51/8511/01M0
R214 1206 180R resistor 51/3380/0180
R215 0805, 1%, 120R resistor 51/8511/120R
R216 0805, 1%, 1K resistor 51/8511/01K0
R217 0805, 1%, 1K resistor 51/8511/010K
R218 0805, 1%, 1K resistor 51/8511/010K
R219 0805, 1%, 1K resistor 51/8511/010K
R220 0805, 1%, 1K resistor 51/8511/010K
R221 0805, 1%, 560R resistor 51/8511/560R
R222 0805, 1%, 1K resistor 51/8511/01K0
R223 0805, 1%, 1K resistor 51/8511/010K
R224 0805, 1%, 1K resistor 51/8511/010K
R225 0805, 1%, 1K resistor 51/8511/010K
R226 1206 180R resistor 51/3380/0180
R227 0805, 1%, 56R resistor 51/8511/056R
R228 0805, 1%, 1K resistor 51/8511/010K
R229 0805, 1%, 1K resistor 51/8511/010K
R230 0805, 1%, 120R resistor 51/8511/120R
R231 0805, 1%, 120R resistor 51/8511/120R
R232 0805, 1%, 560R resistor 51/8511/560R
R233 0805, 1%, 22K resistor 51/8511/022K
R234 0805, 1%, 1K resistor 51/8511/01K0
R235 0805, 1%, 4K7 resistor 51/8511/04K7
R236 0805, 1%, 22K resistor 51/8511/022K
R237 0805, 1%, 47K resistor 51/8511/047K
R238 0805, 1%, 1K resistor 51/8511/01K0
R239 0805, 1%, 1K resistor 51/8511/01K0
R240 0805, 1%, 1K resistor 51/8511/010K
R241 0805, 1%, 47R resistor 51/8511/047R
R242 0805, 1%, 47K resistor 51/8511/047K
R243 0805, 1%, 220R resistor 51/8511/220R
R244 0805, 1%, 10R resistor 51/8511/010R
R245 0805, 1%, 1K resistor 51/8511/010K
R300 0805, 1%, 27R resistor 51/8511/027R
R301 0805, 1%, 27R resistor 51/8511/027R
R302 0805, 1%, 27R resistor 51/8511/027R
R303 0805, 1%, 27R resistor 51/8511/027R
R304 0805, 1%, 330R resistor 51/8511/330R
R305 0805, 1%, 330R resistor 51/8511/330R
R306 0805, 1%, 10R resistor 51/8511/010R
R307 0805, 1%, 4K7 resistor 51/8511/04K7
R308 0805, 1%, 2K2 resistor 51/8511/02K2
R309 0805, 1%, 560R resistor 51/8511/560R
R310 0805, 1%, 560R resistor 51/8511/560R
R311 0805, 1%, 22K resistor 51/8511/022K
R312 0805, 1%, 22K resistor 51/8511/022K
R313 0805, 1%, 22K resistor 51/8511/022K
R314 0805, 1%, 1K resistor 51/8511/010K
R315 0805, 1%, 22K resistor 51/8511/022K
R316 0805, 1%, 1K resistor 51/8511/010K
T50 PARTS LIST
RF Technology T50 Page 53
Ref Description Part Number
R317 0805, 1%, 1K resistor 51/8511/01K0
R318 0805, 1%, 120K resistor 51/8511/120K
R319 0805, 1%, 120K resistor 51/8511/120K
R320 0805, 1%, 120K resistor 51/8511/120K
R321 0805, 1%, 68K resistor 51/8511/068K
R322 0805, 1%, 68K resistor 51/8511/068K
R323 0805, 1%, 68K resistor 51/8511/068K
R324 0805, 1%, 1K resistor 51/8511/01K0
R325 0805, 1%, 47K resistor 51/8511/047K
R326 0805, 1%, 47K resistor 51/8511/047K
R327 0805, 1%, 47K resistor 51/8511/047K
R328 0805, 1%, 1K resistor 51/8511/010K
R329 0805, 1%, 1K resistor 51/8511/010K
R330 0805, 1%, 47K resistor 51/8511/047K
R331 0805, 1%, 47K resistor 51/8511/047K
R332 0805, 1%, 68K resistor 51/8511/068K
R333 0805, 1%, 1K resistor 51/8511/01K0
R335 0805, 1%, 22K resistor 51/8511/022K
R336 0805, 1%, 22K resistor 51/8511/022K
R400 0805, 1%, 330R resistor 51/8511/330R
R401 0805, 1%, 270R resistor 51/8511/270R
R402 0805, 1%, 22K resistor 51/8511/022K
R403 0805, 1%, 22K resistor 51/8511/022K
R404 0805, 1%, 56K resistor 51/8511/056K
R405 0805, 1%, 5K6 resistor 51/8511/05K6
R406 0805, 1%, 1K resistor 51/8511/010K
R407 0805, 1%, 1K resistor 51/8511/010K
R408 0805, 1%, 5K6 resistor 51/8511/05K6
R409 0805, 1%, 120K resistor 51/8511/120K
R410 0805, 1%, 47K resistor 51/8511/047K
R411 0805, 1%, 47K resistor 51/8511/047K
R412 0805, 1%, 1K resistor 51/8511/010K
R413 0805, 1%, 1K resistor 51/8511/01K0
R414 0805, 1%, 560R resistor 51/8511/560R
R415 0805, 1%, 560R resistor 51/8511/560R
R416 0805, 1%, 560R resistor 51/8511/560R
R417 0805, 1%, 560R resistor 51/8511/560R
R418 0805, 1%, 5K6 resistor 51/8511/05K6
R419 0805, 1%, 22K resistor 51/8511/022K
R420 0805, 1%, 120K resistor 51/8511/120K
R421 0805, 1%, 22K resistor 51/8511/022K
R422 0805, 1%, 120K resistor 51/8511/120K
R423 0805, 1%, 1K resistor 51/8511/010K
R424 0805, 1%, 1K resistor 51/8511/010K
R425 0805, 1%, 22K resistor 51/8511/022K
R426 0805, 1%, 22K resistor 51/8511/022K
R427 0805, 1%, 47K resistor 51/8511/047K
R428 0805, 1%, 22K resistor 51/8511/022K
R429 0805, 1%, 22K resistor 51/8511/022K
R430 0805, 1%, 47K resistor 51/8511/047K
R431 0805, 1%, 270K resistor 51/8511/270K
T50 PARTS LIST
Page 54 RF Technology T50
Ref Description Part Number
R432 0805, 1%, 270K resistor 51/8511/270K
R433 0805, 1%, 270K resistor 51/8511/270K
R434 0805, 1%, 4K7 resistor 51/8511/04K7
R435 0805, 1%, 1K resistor 51/8511/01K0
R436 0805, 1%, 4K7 resistor 51/8511/04K7
R437 0805, 1%, 47K resistor 51/8511/047K
R438 0805, 1%, 47K resistor 51/8511/047K
R439 0805, 1%, 4K7 resistor 51/8511/04K7
R440 0805, 1%, 4K7 resistor 51/8511/04K7
R442 0805, 1%, 4K7 resistor 51/8511/04K7
R443 0805, 1%, 4K7 resistor 51/8511/04K7
R444 0805, 1%, 4K7 resistor 51/8511/04K7
R445 0805, 1%, 47K resistor 51/8511/047K
R446 0805, 1%, 1K resistor 51/8511/010K
R447 0805, 1%, 47K resistor 51/8511/047K
R448 0805, 1%, 1K resistor 51/8511/010K
R449 0805, 1%, 5K6 resistor 51/8511/05K6
R450 0805, 1%, 120K resistor 51/8511/120K
R451 0805, 1%, 47K resistor 51/8511/047K
R452 0805, 1%, 1K resistor 51/8511/010K
R453 0805, 1%, 1K resistor 51/8511/010K
R454 0805, 1%, 1K resistor 51/8511/010K
R455 0805, 1%, 1K resistor 51/8511/010K
R456 0805, 1%, 47K resistor 51/8511/047K
R457 0805, 1%, 1K resistor 51/8511/010K
R458 0805, 1%, 4K7 resistor 51/8511/04K7
R459 0805, 1%, 4K7 resistor 51/8511/04K7
R460 0805, 1%, 4K7 resistor 51/8511/04K7
R461 0805, 1%, 120K resistor 51/8511/120K
R462 0805, 1%, 1K resistor 51/8511/010K
R463 0805, 1%, 120K resistor 51/8511/120K
R464 0805, 1%, 270K resistor 51/8511/270K
R465 0805, 1%, 100K resistor 51/8511/100K
R466 0805, 1%, 2K2 resistor 51/8511/02K2
R467 0805, 1%, 4K7 resistor 51/8511/04K7
R500 0805, 1%, 47K resistor 51/8511/047K
R501 0805, 1%, 47K resistor 51/8511/047K
R502 0805, 1%, 47K resistor 51/8511/047K
R503 0805, 1%, 22K resistor 51/8511/022K
R504 0805, 1%, 560R resistor 51/8511/560R
R505 0805, 1%, 1K resistor 51/8511/010K
R506 0805, 1%, 1K resistor 51/8511/010K
R507 0805, 1%, 1M resistor 51/8511/01M0
R508 0805, 0.5%, 50ppm, 7K5 resistor 51/85P1/07K5
R509 0805, 0.5%, 50ppm, 7K5 resistor 51/85P1/07K5
R510 0805, 0.5%, 50ppm, 7K5 resistor 51/85P1/07K5
R511 0805, 0.5%, 50ppm, 7K5 resistor 51/85P1/07K5
R512 0805, 1%, 1K resistor 51/8511/010K
R513 0805, 1%, 1K resistor 51/8511/010K
R514 0805, 1%, 1K resistor 51/8511/010K
R516 0805, 1%, 680R resistor 51/8511/680R
T50 PARTS LIST
RF Technology T50 Page 55
Ref Description Part Number
R517 0805, 1%, 47K resistor 51/8511/047K
R518 0805, 1%, 47K resistor 51/8511/047K
R519 0805, 1%, 47K resistor 51/8511/047K
R520 0805, 1%, 47K resistor 51/8511/047K
R521 0805, 1%, 47K resistor 51/8511/047K
R522 0805, 1%, 68K resistor 51/8511/068K
R523 0805, 1%, 1K resistor 51/8511/01K0
R525 0805, 1%, 1K resistor 51/8511/010K
R526 0805, 1%, 2K2 resistor 51/8511/02K2
R527 0805, 1%, 47K resistor 51/8511/047K
R528 0805, 1%, 47K resistor 51/8511/047K
R529 0805, 1%, 47K resistor 51/8511/047K
R530 0805, 0.5%, 50ppm, 7K5 resistor 51/85P1/07K5
R531 0805, 0.5%, 50ppm, 7K5 resistor 51/85P1/07K5
R532 0805, 0.5%, 50ppm, 7K5 resistor 51/85P1/07K5
R533 0805, 0.5%, 50ppm, 7K5 resistor 51/85P1/07K5
R600 0805, 1%, 4K7 resistor 51/8511/04K7
R602 0805, 1%, 27K resistor 51/8511/027K
R603 0805, 1%, 27K resistor 51/8511/027K
R604 0805, 1%, 100K resistor 51/8511/100K
R605 0805, 1%, 27K resistor 51/8511/027K
R606 0805, 1%, 5K6 resistor 51/8511/05K6
R607 0805, 1%, 5K6 resistor 51/8511/05K6
R608 0805, 1%, 2K2 resistor 51/8511/02K2
R609 0805, 1%, 1K resistor 51/8511/010K
R610 0805, 1%, 47K resistor 51/8511/047K
R611 0805, 1%, 2K2 resistor 51/8511/02K2
R612 0805, 1%, 100K resistor 51/8511/100K
R613 0805, 1%, 47R resistor 51/8511/047R
R614 0805, 1%, 47R resistor 51/8511/047R
R615 0805, 1%, 47R resistor 51/8511/047R
R616 0805, 1%, 47R resistor 51/8511/047R
R617 0805, 1%, 1K resistor 51/8511/01K0
R618 0805, 1%, 1K resistor 51/8511/01K0
R619 0805, 1%, 680R resistor 51/8511/680R
R620 0805, 1%, 680R resistor 51/8511/680R
R621 0805, 1%, 4K7 resistor 51/8511/04K7
R622 0805, 1%, 5K6 resistor 51/8511/05K6
R623 0805, 1%, 5K6 resistor 51/8511/05K6
R624 0805, 1%, 22K resistor 51/8511/022K
R625 0805, 1%, 22K resistor 51/8511/022K
R628 1218 1W 68R resistor 51/8251/068R
R629 0805, 1%, 270K resistor 51/8511/270K
R630 0805, 1%, 120R resistor 51/8511/120R
R631 0805, 1%, 47R resistor 51/8511/047R
R632 0805, 1%, 47R resistor 51/8511/047R
R633 1206 120R resistor 51/3380/0120
R634 0805, 1%, 120R resistor 51/8511/120R
R635 0805, 1%, 560R resistor 51/8511/560R
R636 0805, 1%, 220R resistor 51/8511/220R
R637 0805, 1%, 5K6 resistor 51/8511/05K6
T50 PARTS LIST
Page 56 RF Technology T50
Ref Description Part Number
R638 0805, 1%, 5K6 resistor 51/8511/05K6
R639 0805, 1%, 1K resistor 51/8511/010K
R646 0805, 1%, 4K7 resistor 51/8511/04K7
R647 0805, 1%, 1K resistor 51/8511/010K
R648 0805, 1%, 4K7 resistor 51/8511/04K7
R649 0805, 1%, 1K resistor 51/8511/010K
R650 0805, 1%, 5K6 resistor 51/8511/05K6
R700 0805, 1%, 120R resistor 51/8511/120R
R701 0805, 1%, 47R resistor 51/8511/047R
R702 0805, 1%, 120R resistor 51/8511/120R
R703 0805, 1%, 120R resistor 51/8511/120R
R704 0805, 1%, 120R resistor 51/8511/120R
R705 0805, 1%, 220R resistor 51/8511/220R
R706 0805, 1%, 220R resistor 51/8511/220R
R707 0805, 1%, 220R resistor 51/8511/220R
R708 0805, 1%, 4K7 resistor 51/8511/04K7
R709 0805, 1%, 1K resistor 51/8511/010K
R710 0805, 1%, 2K2 resistor 51/8511/02K2
R711 0805, 1%, 100K resistor 51/8511/100K
R713 0805, 1%, 100K resistor 51/8511/100K
R714 0805, 1%, 56R resistor 51/8511/056R
R715 0805, 1%, 1K resistor 51/8511/010K
R716 0805, 1%, 47R resistor 51/8511/047R
R717 0805, 1%, 1K resistor 51/8511/010K
R718 0805, 1%, 120R resistor 51/8511/120R
R719 0805, 1%, 1K resistor 51/8511/010K
R720 0805, 1%, 100K resistor 51/8511/100K
R722 0805, 1%, 22K resistor 51/8511/022K
R723 0805, 1%, 1K resistor 51/8511/010K
R724 0805, 1%, 56R resistor 51/8511/056R
R725 0805, 1%, 22K resistor 51/8511/022K
R726 0805, 1%, 47R resistor 51/8511/047R
R727 0805, 1%, 22K resistor 51/8511/022K
R729 0805, 1%, 10R resistor 51/8511/010R
R730 0805, 1%, 220R resistor 51/8511/220R
R731 0805, 1%, 560R resistor 51/8511/560R
R732 0805, 1%, 22K resistor 51/8511/022K
R733 0805, 1%, 330R resistor 51/8511/330R
R734 0805, 1%, 4K7 resistor 51/8511/04K7
R735 0805, 1%, 22K resistor 51/8511/022K
R736 0805, 1%, 1K resistor 51/8511/01K0
R737 0805, 1%, 1K resistor 51/8511/01K0
R738 0805, 1%, 220R resistor 51/8511/220R
R739 0805, 1%, 1K resistor 51/8511/010K
R740 0805, 1%, 120R resistor 51/8511/120R
R741 0805, 1%, 4K7 resistor 51/8511/04K7
R742 0805, 1%, 820R resistor 51/8511/820R
R743 0805, 1%, 560R resistor 51/8511/560R
R744 0805, 1%, 1K resistor 51/8511/010K
R745 0805, 1%, 220R resistor 51/8511/220R
R802 0805, 1%, 47R resistor 51/8511/047R
T50 PARTS LIST
RF Technology T50 Page 57
Ref Description Part Number
R803 0805, 1%, 100R resistor 51/8251/100R
R804 1206 10R resistor 51/3380/0010
R805 1206 10R resistor 51/3380/0010
R806 0805, 1%, 100R resistor 51/8251/100R
R807 0805, 1%, 100R resistor 51/8251/100R
R808 0805, 1%, 10R resistor 51/8511/010R
R809 0805, 1%, 27R resistor 51/8511/027R
R810 0805, 1%, 10R resistor 51/8511/010R
R811 0805, 1%, 27R resistor 51/8511/027R
R812 0805, 1%, 220R resistor 51/8511/220R
R813 0805, 1%, 100R resistor 51/8251/100R
R816 0805, 1%, 1K resistor 51/8511/010K
R819 7W Axial 68R resistor 55/5W51/068R
R823 0805, 1%, 4K7 resistor 51/8511/04K7
R918 0805, 1%, 47K resistor 51/8511/047K
R919 0805, 1%, 47K resistor 51/8511/047K
R920 0805, 1%, 1K resistor 51/8511/01K0
R921 0805, 1%, 560R resistor 51/8511/560R
R922 0805, 1%, 220R resistor 51/8511/220R
R923 0805, 1%, 1K resistor 51/8511/01K0
R924 0805, 1%, 560R resistor 51/8511/560R
R925 0805, 1%, 220R resistor 51/8511/220R
R926 0805, 1%, 2K2 resistor 51/8511/02K2
R927 0805, 1%, 220R resistor 51/8511/220R
R928 0805, 1%, 220R resistor 51/8511/220R
R929 0805, 1%, 220R resistor 51/8511/220R
R930 0805, 1%, 220R resistor 51/8511/220R
R931 0805, 1%, 220R resistor 51/8511/220R
R932 0805, 1%, 220R resistor 51/8511/220R
R933 0805, 1%, 560R resistor 51/8511/560R
R934 0805, 1%, 560R resistor 51/8511/560R
R935 0805, 1%, 120R resistor 51/8511/120R
R936 0805, 1%, 120R resistor 51/8511/120R
RL300 12V Telecommunications DPDT Relay 96/2000/012V
RV100 100K, 11 turn, linear Pot. 53/THH1/100K
S200 4mm SMD PB switch 31/SMPB/0001
SW1 C&K PB Switch 31/0005/E121
T300 High Isolation Audio Transformer 37/2040/5065
T301 High Isolation Audio Transformer 37/2040/5065
TP102 Test Point 35/2501/0001
TP300 Test Point 35/2501/0001
TP301 Test Point 35/2501/0001
TP302 Test Point 35/2501/0001
TP303 Test Point 35/2501/0001
TP305 Test Point 35/2501/0001
TP500 Test Point 35/2501/0001
TP501 Test Point 35/2501/0001
TP908 Test Point 35/2501/0001
TP909 Test Point 35/2501/0001
TP910 Test Point 35/2501/0001
TP911 Test Point 35/2501/0001
T50 PARTS LIST
Page 58 RF Technology T50
Ref Description Part Number
TP912 Test Point 35/2501/0001
TP913 Test Point 35/2501/0001
TP914 Test Point 35/2501/0001
TP915 Test Point 35/2501/0001
TP916 Test Point 35/2501/0001
TP917 Test Point 35/2501/0001
U201 Quad CMOS RS232 Driver SMD (SO-14) 29/14C8/9A01
U202 Quad CMOS RS232 Driver SMD (SO-14) 29/14C8/8001
U203 Under-voltage sensor and Reset Generator 29/MC33/064D
U204 Motorola Embedded 8/16 bit microcontroller 29/68HC/12A0
U205 One of 8 Selector 29/2030/C138
U207 4 Megabyte TSOP (Std.) 5V (only) Flash 29/P006/0001
U208 1,2,4 Megabit RAM in SOP package 29/SRAM/P013
U209 Octal Latch 29/2030/C374
U212 Hi Speed, TTL compatible, opto-isolator 26/N137/0001
U300 Opto-isolator with Darlington Output 25/1010/4N35
U301 Quad SPST Analog Switch - low Rds On 29/00DG/411C
U302 Low Power Quad Operational Amplifier 29/000L/M224
U303 32 position digital pot. 29/MAX5/161L
U400 Low Power Quad Operational Amplifier 29/000L/M224
U401 8-bit Shift reg. with output latch 29/2030/C595
U402 Transconductance Amplifier 29/0LM1/3700
U403 Quad SPST Analog Switch - low Rds On 29/00DG/411C
U404 Quad SPST Analog Switch - low Rds On 29/00DG/411C
U405 Low Power Quad Operational Amplifier 29/000L/M224
U406 Voltage Output, Quad 8 bit DAC 29/00MA/X534
U407 Low Power Quad Operational Amplifier 29/000L/M224
U500 CTCSS and DCS encoder/decoder 29/00FX/805L
U502 Low Power Quad Operational Amplifier 29/000L/M224
U503 32 position digital pot. 29/MAX5/161L
U600 Gen. Purp. R2R Op. Amp. 29/1M55/P021
U601 Voltage Output, Quad 8 bit DAC 29/00MA/X534
U602 Dual PLL 29/LMX2/335L
U603 Temperature Sensor 29/0001/LM61
U604 Dual PLL 29/LMX2/335L
U605 Dual, Ripple Carry, 4 bit binary counter 29/2030/C393
U606 Dual 4 bit, ripple carry, decade counters 29/2030/C390
U607 Gen. Purp. R2R Op. Amp. 29/1M55/P021
U608 Gen. Purp. R2R Op. Amp. 29/1M55/P021
U700 MMIC Amplifier 24/3010/VAM6
U701 MMIC Amplifier 24/3010/211L
U702 MMIC Amplifier 24/3010/VAM6
U703 MMIC Amplifier 24/3010/VAM6
U704 Transconductance Amplifier 29/0LM1/3700
U705 MMIC Amplifier 24/3010/VAM6
U706 MMIC Amplifier 24/3010/VAM6
U707 Gen. Purp. R2R Op. Amp. 29/1M55/P021
U800 MMIC Amplifier 24/3010/211L
U906 Gen. Purp. R2R Op. Amp. 29/1M55/P021
U907 Simple (Buck) Switcher, 5V, 1A output 29/REG1/0N12
U908 Simple (Buck) Switcher, 5V, 1A output 29/REG1/0N12
T50 PARTS LIST
RF Technology T50 Page 59
Ref Description Part Number
U909 Simple (Buck) Switcher, 5V, 1A output 29/REG2/00N5
U910 LDO Adjustable Positive Voltage Regulator
(800mA) 29/00LM/1117
U911 Positive Adjustable Voltage Reg. in SO8 package 29/000L/M317
U912 Positive Adjustable Voltage Reg. in SO8 package 29/000L/M317
U913 Positive Adjustable Voltage Reg. in SO8 package 29/000L/M337
U914 Positive Adjustable Voltage Reg. in SO8 package 29/000L/M337
U915 Positive Adjustable Voltage Reg. in SO8 package 29/000L/M337
X200 14.7456 MHz Crystal, 30ppm, SMD 33/14M7/0001
X500 4.0 MHz Crystal 32/2049/04M0
X600 12.0 MHz Crystal, 5ppm, SMD 33/12M0/0001
X601 12.0 MHz Crystal, 5ppm, SMD 33/12M0/0001
Page 60 RF Technology T50
C – EIA CTCSS TONES
Frequency EIA Number
No Tone
67.0 A1
71.9 B1
74.4 C1
77.0 A2
79.7 C2
82.5 B2
85.4 C3
88.5 A3
91.5 C4
94.8 B3
100.0 A4
103.5 B4
107.2 A5
110.9 B5
114.8 A6
118.8 B6
123.0 A7
127.3 B7
131.8 A8
136.5 B8
141.3 A9
146.2 B9
151.4 A10
156.7 B10
162.2 A11
167.9 B11
173.8 A12
179.9 B12
186.2 A13
192.8 B13
203.5 A14
210.7 B14
218.1 A15
225.7 B15
233.6 A16
241.8 B16
250.3 A17

Navigation menu
