Active Tag Operating Manual
Active Tag Operating Details
1.0
Power
+3V Coin
Cell
battery
Note: Battery should only be installed by
trained
personnel
1.1 Current consumption
Sleep: 700nA
Calibration (once every 4
th
transmission):
8.4mA
Transmitting: 17mA
2.0
Timing
Sleep: 2 Seconds
Ca
libration
(once every 4
th
transmission): 150uS
Transmitting: 600uS
3.0
Data
Flags
Company Code
Facility Code
Data
1 byte
1 byte
2 bytes
4
bytes
3.1 Flags
Output power
Sleep Time
Battery Removed
Battery Low
Switch Active
4 bits (7:4
)
1 bit (3)
1 bit (2)
1b
it (1)
1bit (0)
4.0 LED
The LED on the Active Tag flashes once every 10 seconds when the battery is low (based on number
of transmissions made over the life of the tag since last battery installation)
