RIDER BEST QS-10603 BLUETOOTH SPEAKER User Manual 1
Rider best,Inc BLUETOOTH SPEAKER 1
User manual
1.Stylish fashionable and elegant appearance
2.Strong bass,clear ang rich vocal
3.Music playing through BT,USB,SD and line in connection
2
Panel Function
DIGITAL AUDIO PLAYER
MODE
LED
0
+2
+4
+6
+8
+10
0
+2
+4
+6
+8
+10
-2
-4
-6
-8
-10
-2
-4
-6
-8
-10
MASTER EQUALIZATION
POWER M IXE R 5-WAY PROFESSIO NAL SPEA KER
100H z 50 0Hz 1KHz 4KHz 1 0K Hz
AUX INP UT
LR
ON
OFF
ON
OFF
POWER LIGHTS
AC INPUT
AC12 0V 60Hz
ANT
Re mo te
MODEL:QS-J1502
MADE IN CHINA JS
1. Source Volume Control
2. Treble Control
3. BASS Control
4. Echo Control
5. Mic Volume Control
6. Mic Input Jacks
7. Power ON/OFF Switch
8. USB Function Display
10. EQ adjustment
11. USB/SD/FM/BT Playback Controls
a.MODE
b.Previous/CH- Button
c.Next/CH+ Button
d.Play/Pause/FM SCAN Button
9. USB/SD Input port
12.Receiving Head
1
2
3
4
5
6
7
8
9
10
11
USB
SD
MP3
AUX
FM
MHZ
12
13
14. Aux input
13. Lights ON/OFF Switch
15. Fan cooling air outlet
14
15
16
16. FM antenna
17
17. AC Voltage Input: 120V-60Hz
Light Flashing Alternatively
After Power On
3
Function Description
General Function Description
1.Master Volume :Turnning to adjust master volume.
2.Treble Volume :Turnning to adjust volume.
3.Bass Volume :Turnning to adjust volume.
4.Echo Effect Volume :Turnning to adjust volume.
5.Mic Volume :Turnning to adjust volume.
6.mode:change to other mode when operating,sequence:
AUX-BLUE-FM-USB/SD.priority to play in usb or micro sd mode when
insert usb or micro sd
Mp3 Function Description
1.USB:Playing when insert the USB when save with Mp3 music.
2.Micro SD:Playing when insert the Micro SD when save with Mp3 music.
3.AUX:Playing when Plug in the AUX cable and connected with music device.
4.Play/Pause Button: In USB or Micro SD mode,press to play or pause.
5.Skip -&+ Button: With playing music in USB or Micro SD mode,short press
to go back or forwatd music,long press to adjust volume
BT Function Description
1.pairing:press Mode Button To Blue Mode ,speaker Will Be
Under Automatic Pairing Mode,led Display Shows "blue",pair The
Bt Compatible Device By Selecting "QS-J1502" From The Listed
Devices, Speaker Wlii Call Out "connected" After Paired Successful,
Blue Pairing System Will Be Off There Is No Device Connecting
Afrer 5 Minutes.
2.Music Playing: press play/pause,Skip +/- Button to play music.
5
Technical Specifications
Packing
QS-J1502 Speaker *1
Adpater *1
User Manual *1
PORTABLE ACTIVE SPEAKER
SYSTEM WITH TROLLEY
QS-J1502
BT AUDIO STREAMING
Feature
Display Descripation
1. : USB flashes when playing
2. : USB pause display
3. : Read U disk display
4. : Read SD card display
USB MP3
SD
5. : FM display when playing
FM MHZ
1
USB
SD
MP3
AUX
FM
MHZ
Lighting Function Decription
4
AC 120V/60Hz
15", 4 OHMS
3", 4 OHMS
100W(Max.)
Remote Control Functions
PORTABLE ACTIVE SPEAKER
SYSTEM WITH TROLLEY
QS-J1502
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
