RM Acquisition 1000CA TND 740 User Manual DES 2083 TND740 QSG 012417 JS f indd

RM Acquisition LLC TND 740 DES 2083 TND740 QSG 012417 JS f indd

Contents

User Manual_20170310_v1 - A4C-1000CA_User Manual_partial 2

This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This device complies with FCC SAR exposure limits set forth for an uncontrolled
environment.
SAR compliance for using the equipment in close proximity to the human body has been
evaluated at 0mm.
This equipment must not be co-located or operating in conjunction with any other antenna
or transmitter.
End-users and installers must be provide with antenna installation instructions and consider
removing the no-collocation statement.
Caution!
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Canada Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
This equipment should be installed and operated with a minimum distance of 0mm
between the radiator and your body.
Cet équipement devrait être installé et actionné avec une distance minimum de 0mm entre
le radiateur et votre corps.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps qu'aucune
autre antenne ou émetteur.
2 3TND™ 740 Quick Start GuideTND™ 740 Quick Start Guide
Your TND™ 740 Unit
Caution: Important Safety Information
Navigation
• Use this device at your own risk.
• Attend to this device only when it is safe to do so.
• Traffi c laws and regulations always have priority over any
instructions from the navigation system.
NOTE: If you do not understand the spoken instructions or are unsure
of what to do, refer to the navigation map on your device.
Installation
• Make sure that the mount is securely mounted and properly
adjusted before each trip.
• Make sure that the mount does not impair the driver’s visibility.
• Do not attach the mount within the airbag deployment zone.
• Install the mount in a manner that minimizes risk in the event of
an accident.
• After installation, check all safety-related equipment to ensure that
it operates without interference from the device, its cables, or any
other accessories.
• Connect the vehicle charger to a 12V outlet only.
• The device can also be charged using a standard Micro USB charger.
Device
• Do not use sharp-edged objects on the device touch screen.
• The device is not waterproof and is not protected against
water damage.
• Protect the device from extreme temperatures. Operating
temperature for the device is between 32 degrees F and
120 degrees F.
• Do not open the device casing.
• Do not attempt to replace the battery. Contact Rand McNally
Customer Support with questions about the battery.
• Always follow local regulations when disposing of this device.
NOTE: Make sure that there are no kinks in the cable and that it will
not be damaged by any sharp objects.
NOTE: Use only a moist cloth to clean the device.
NOTE: Do not pull the cable to unplug the unit.
Your TND™ 740
Box Contents
1 TND™ 740 Unit
2 Smart mount
3 Bracket with suction cup
4 Vehicle charger
5 Micro USB charger
3
3
2
1
4
5
4 5TND™ 740 Quick Start GuideTND™ 740 Quick Start Guide
TND
™
740 Quick Start Guide
Your TND™ 740Install the Mount
NOTE: Follow all local laws and regulations governing the placement of the mount.
1. Select an area with a line of sight to the sky and GPS satellites.
2. Clean and dry the mounting area.
3. Remove the suction cup protective fi lm.
4. Attach the two pieces of the mount together and lock into place.
5. Adjust the angle of the mount.
6. Pull the suction cup lever up to release suction.
7. Plug the power cord into the mount and the vehicle's 12-volt power source.
8. Place and hold the mount suction cup against the mounting surface.
9. Press the suction cup lever down until it snaps into place.
10. Snap the tablet onto the mount.
11. Adjust the tablet so that it can be easily seen and
does not block the driver's line of sight.
DC in
(power)
AUX out
TND™ 740 TND™ 740 Smart Mount
8. Place and hold the mount suction cup against the mounting surface.
9. Press the suction cup lever down until it snaps into place.
11. Adjust the tablet so that it can be easily seen and
TND
™
740 Quick Start Guide
11. Adjust the tablet so that it can be easily seen and
Home
Power
Volume
DownUp
Micro USB
(power)
Micro SD card
6 7TND™ 740 Quick Start GuideTND™ 740 Quick Start Guide
Getting Started
1. Connect to the Internet.
Connect to the Wi-Fi hotspot on your smartphone or
to your home Wi-Fi network.
2. Register your device with Rand McNally for updates
and support.
NOTE: You will be required to register your device in order
to receive new updates.
TND™ 740 Operating System Home Screen
321 4 5 6 7
1 Settings
Opens Truck GPS preferences.
2 Wi-Fi® indicator
Opens Wi-Fi® settings and displays connection strength.
3 Bluetooth® indicator
Opens Bluetooth® settings and shows connectivity states.
4 Volume indicator
Opens volume control.
5 System update
Indicates if a system update is available.
Opens to initiate download.
6 Current time
Displays current time.
7 Battery power indicator
Displays current battery state.
Transferring User Information from Previous Device
To move or export user data from a previous Rand McNally TND™ device to a new Rand McNally TND™ device, please visit
the following website for specifi c instructions: randmcnally.com/tnd740-support
8 9TND™ 740 Quick Start GuideTND™ 740 Quick Start Guide
Features
1 Truck Tools
Select to enter truck information, set warnings, and access
other tools.
2 Maps
Show location on the map and view navigation instructions.
3 Destination
Choose a destination by History, Address Book, Points of
Interest, or Searching.
4 DriverConnect
Record, view, and track duty status through your device.
Also includes hours of service timers, vehicle inspection
reports, and more.
Restart Your TND™ 740
Rand McNally has designed TND™ 740 for speed and reliability. However, from time to time, all Android devices run into
problems. If your unit becomes unresponsive for any reason, it’s always best to restart the unit by turning it off and on
again.
Restarting the Device
1. Restart the unit by holding down the power button for 5 seconds, or until you see the Power Off screen.
2. Press Power Off.
3. Once the unit has shut down, press and hold the power button for 2 to 4 seconds to turn it back on.
If the unit is unresponsive and you don’t see the power down button appear on the screen, hold down the power button
for 10 to 15 seconds and the device will turn off completely. Once the unit has shut down, press and hold the power
button for 2 to 4 seconds to turn it back on.
For additional help and FAQs, visit randmcnally.com/support.
321
4
10 11
TND™ 740 Quick Start GuideTND™ 740 Quick Start Guide
More Information
For more information
• Rand McNally Website
randmcnally.com/tnd740
• Support
randmcnally.com/support
• Accessories
store.randmcnally.com
• Facebook
facebook.com/randmcnally
Customer Support
Call toll-free:
1-877-446-4863
E-mail:
support@randmcnally.com
Questions about using TND™ 740?
Our team is ready to help.
Trademarks
TND™ is a trademark of RM Acquisition, LLC, d/b/a Rand McNally.
InfoGation is a registered trademark of InfoGation Corporation.
Local search information provided by CityGrid Media.
Weather data provided by myweather.com.
Fuel prices provided by OPIS.
Traffic information provided by INRIX, Inc.
© 2017 Rand McNally. © 2017 HERE. All rights reserved.
Rand McNally follows a continuous improvement process and reserves
the right to provide enhancements that may not be reflected in the
pictures and specifications in this manual.
The information contained herein may be changed at any time without
prior notification. Neither this manual nor any parts thereof may be
reproduced for any purpose whatsoever without the express written
consent of Rand McNally, nor may it be transmitted in any form either
electronically or mechanically, including photocopying and recording.
All technical specifications, drawings, etc. are subject to copyright law.
12 13
TND™ 740 Quick Start GuideTND™ 740 Quick Start Guide
Warnings, End-User License Agreement, and Warranty
Pay attention to road conditions and street signs, and obey all traffic and safety laws. Traffic laws and current traffic conditions must always be observed and take precedence over the instructions issued by the Rand
McNally® navigation system. The User should be aware of situations where current traffic conditions and the instructions from the navigation system may be in conflict. Some states prohibit the use of windshield mounts and
may otherwise restrict the usage of navigation and other electronic devices in the vehicle. It is the User’s responsibility to operate his/her vehicle in a safe manner and to ensure compliance with all laws and regulations. The
use of the navigation system does not relieve the User of his/her responsibilities. .
If after reading the following terms and conditions, the User decides not to accept the terms, the User should not use this navigation system.
Rand McNally hereby grants you (“User”) a single-user non-exclusive, non-transferable license to use the Rand McNally navigation system, including software incorporated and associated data incorporated therein and aa
related documentation that accompanies the product (hereinafter referred to as the “Product” ) for User’s own internal business or personal use and not for resale or sublicense .
This Product is furnished under license and may be used only in accordance with the terms and conditions of this license. Except as permitted by such license, the contents of this Product may not be disclosed to third parties,
copied or duplicated in any form, in whole or in part, without the prior written permission of Rand McNally. This Product contains proprietary and confidential information of Rand McNally and its licensors. Rand McNally
grants User a limited license for use of this Product for its normal operation. By using the Product, User acknowledges that the contents of the Product are the property of Rand McNally and its licensors and are protected by
U.S. copyright, trademark and patent laws and international treaties.
THE USER MAY NOT:
• Use the Product on a network or le server, time-sharing or to process data for other persons.
• Use the Product to create any routing tables, les, databases or other compendiums.
• Copy, loan or otherwise transfer or sublicense the Product, its software or content.
• Modify or adapt the Product in any way, or decompile, disassemble, reverse engineer or reduce to human readable form the software incorporated in the Product.
• Alter, remove or obscure any copyright notice, trademark notice, or proprietary legend from the Product.
This license will terminate automatically if User fails to comply with any of the terms of this license, and in such case, User agrees to immediately stop using the Product. Rand McNally may revise or update the Product at its
sole discretion, but it is not obligated to furnish any revisions or updates to User.
RM Acquisition, LLC d/b/a Rand McNally warrants that the Product, and the component parts thereof, will be free of defects in workmanship and materials for a period of one (1) year from the date of purchase. This warranty
may be enforced only by the first consumer purchaser (“Customer”), provided that the product is utilized within the U.S.A. or Canada.
During the warranty term, Rand McNally will, without charge, repair or replace (with a new or newly reconditioned unit), at its option, defective Products or component parts. For repair or replacement of defective Products,
Customer must contact Rand McNally at 1-800-333-0136 for return authorization and instructions. Customer will be required to provide proof of date of first Customer purchase by providing a copy of the original sales
receipt for the warranty to be valid. The Customer must pay any initial shipping charges required to ship the Product to Rand McNally for warranty service, but the return charges will be at Rand McNally’s expense, if the
Product is found to be defective and is repaired or replaced under the terms of this warranty.
If the Product sent in is still under its original warranty, then following repair or replacement by Rand McNally, the new warranty is 90 days or to the end of the original one (1) year warranty, whichever is longer. If the
Product is out of warranty, Rand McNally shall have no obligation to repair or replace the Product, but if it does choose to repair or replace the Product, such repair or replacement shall be at Rand McNally’s then-current
cost. In such case, customer shall be responsible for all shipping charges associated with the shipment of the Product to Rand McNally and its return to the customer.
This warranty gives the Customer specific rights. Other rights may be available to Customer which vary from state to state.
Exclusions: This limited warranty does not apply: 1) to any product damaged by accident; 2) in the event of misuse or abuse of the product or as a result of unauthorized alterations or repairs; 3) if the serial number has been
altered, defaced or removed; 4) if the Product is used other than as provided in the documentation that accompanies the Product, or 5) if the owner of the product resides outside of the U.S.A. or Canada.
Warnings, End-User License Agreement, and Warranty
CAUTION: RAND MCNALLY MAKES NO WARRANTY AS TO THE ACCURACY OR COMPLETENESS OF THE INFORMATION IN THE PRODUCT, THE SOFTWARE OR THE DOCUMENTATION, AND DISCLAIMS
ANY AND ALL EXPRESS, IMPLIED OR STATUTORY WARRANTIES, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND ANY WARRANTY AS
TO QUALITY, PERFORMANCE, TITLE OR NON- INFRINGEMENT. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS AND/OR DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO SOME CONSUMERS.
IN NO EVENT WILL RAND MCNALLY OR ITS LICENSORS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
IT IS THE USER’S RESPONSIBILITY TO USE THIS PRODUCT PRUDENTLY AND IN ACCORDANCE WITH THE DOCUMENTATION. THIS PRODUCT IS INTENDED TO BE USED ONLY AS A TRAVEL AID AND MUST NOT BE USED FOR
ANY PURPOSE REQUIRING PRECISE MEASUREMENT OF DIRECTION, DISTANCE, LOCATION OR TOPOGRAPHY.
The User agrees to allow information provided by the User to Rand McNally to be used for internal business evaluation purposes, including, but not limited to, evaluating the effectiveness of the Product and the services
provided and methods to simplify or improve User experiences. Such information will not be provided to third parties in any way that discloses the identity of the User.
Rand McNally may make use of third party software in the Product. Notwithstanding the terms and conditions of this license, use of some third party materials included in the Product may be subject to such third party’s
terms and conditions. The third party copyright notices are provided at the end of this License.
The User agrees to indemnify, defend and hold Rand McNally and its licensors (including their respective licensors, suppliers, assignees, subsidiaries, affiliated companies, and the respective of officers, directors, employees,
shareholders, agents and representatives of each of them) free and harmless from and against any liability, loss, injury (including injuries resulting in death), demand, action, cost, expense or claim of any kind or character,
including but not limited to attorney’s fees, arising out of or in connection with any use or possession by the User of this Product.
These terms and conditions constitute the entire agreement between Rand McNally (and its licensors and suppliers) and the User pertaining to the subject matter hereof, and supersedes in their entirety any and all written or
oral agreements previously existing between us with respect to such subject matter. The terms and conditions (including the license) may be updated from time to time with or without notice.
The above terms and conditions shall be governed by the laws of Illinois, without giving effect to (i) its conflict of laws provisions, or (ii) the United Nations Convention for Contracts for the International Sale of Goods, which
is explicitly excluded. The User agrees to submit to the jurisdiction of Illinois courts for any and all disputes, claims and actions arising from or in connection with the User’s license and use of the Product hereunder.
User shall not export the Product in violation of any U.S. or foreign laws. Rand McNally’s licensors shall be third party beneficiaries of Rand McNally’s rights under this license, but are not parties hereto and have no
obligations hereunder.
By using this Product you agree to be bound both by the foregoing and to any additional terms of use found at www.randmcnally.com.
Actual toll costs may vary from estimates depending upon a number of factors including inaccurate or imprecise source data and variable toll costs, which are dependent upon vehicle characteristics (class, axle number,
weight, etc.) that vary across toll roads.
Restricted Rights Legend. For governmental agencies: Use, reproduction or disclosure is subject to restrictions set forth in subparagraph (c) (1) (iii) of the Right in Technical Data and Computer Software clause at
DFARS 52.227-7013, as amended.
Rand McNally, TripMaker, the Rand McNally logo and the globe design mark are registered trademarks and TND is a trademark of RM Acquisition, LLC, d/b/a Rand McNally.
Portions © 2017 HERE. All rights reserved. This data includes information taken with permission from Canadian authorities, including © Her Majesty the Queen in Right of Canada, © Queen’s Printer for Ontario.
© 2017 InfoGation. All rights reserved.
© 2017 Rand McNally. All rights reserved. U.S. Patent Nos. 7,580,791 and 8,214,141.

Navigation menu
