RTX CT8122 Cordless DECT Handset User Manual RTX8122 Quick Reference Guide 120904

RTX Hong Kong Ltd. Cordless DECT Handset RTX8122 Quick Reference Guide 120904

Users Manual

DECT model RTX8122d/ RTX8122s DECT Handset Reference Guide 1
RTX8122d Front View
RTX8122d Side View
Package Contents
- RTX8122d/ RTX8122s DECT Handset
- Battery
- Belt clip (incl. name plate cover)
- Name plate cover
- This Reference Guide
- Additional Information sheet
Main Menu Items Top Line Icons
Contacts Signal strength
Central Directory Battery status
Calls Ringer off
Settings Microphone muted
Calendar Keypad locked
Accessories Missed call
Messaging Voice Mail present indication
Reference Guide
RTX8122d/ RTX8122s DECT Handset
2 DECT model G566d/ G566s DECT Handset Reference Guide
GETTING STARTED
Press and hold for a few seconds.
When the display of your phone is dark, press any key to activate your phone (phone in Idle
mode).
Press and then (toggle function).
1. Press and then type the number you want to reach OR
2. Press and then type the number you want to reach (speakerphone call) OR
3. Type the number you want to reach and then or OR
4. Press soft key or , select the required contact and press soft key ,
or .
Press or, for speakerphone call, .
Press .
During a call, press and dial the number of the party you want to consult. Press
to toggle between the two parties.
Press to transfer the call.
During a call, press ³9ROXPHXS´or ³9ROXPHGRZQ´ on the side of the phone.
During a call, press ; to deactivate: press again.
Press soft key . To turn the microphone on again, press soft key .
In Idle mode, press , use the navigation keys to select and press soft key .
1. Press soft key , then enter the text of your message OR
2. Use the navigation keys to select a stored draft message and press soft key
Then press soft key , select the type of the message (normal or urgent) and choose the
UHTXLUHGGHVWLQDWLRQV:KHQ³0HVVDJHVHQW´LVJLYHQLQWKHGLVSOD\\RXUPHVVDJHKDVEHHQ
sent successfully.
In Idle mode, press soft key , select the contact you want to assign to a speed
dialling key and press soft key . Choose and press soft key .
Use the navigation keys to scroll to the appropriate number (2..9) and press soft key .
In Idle mode, press , use the navigation keys to select and press soft key .
Use the navigation keys to select (Connectivity) and press soft key . Use the
navigation keys to select (Register) and press soft key .
Enter the requested registration information (contact your System Administrator for this).
Wait for the registration to be completed.
Register the handset
Assigning a contact to a speed dialling key
Write and send a text messa
g
e
Mute the microphone durin
g
a call
Use the s
p
eaker
p
hone
Chan
g
e the volume
Make an enquiry call
End a call
Answer a call
Make a call
Lock/unlock your phone
Activating your phone
Turning the phone on and off
DECT model RTX8122d/ RTX8122s DECT Handset Reference Guide 3
MENU FUNCTIONS
In Idle mode, press to access the main menu. Use the navigation keys to go to the
required menu, menu tab and menu item. Use soft key (or press ) to select the
chosen menu or menu item/tab. Other soft keys may provide additional options.
To go back one step in the menu or leave it altogether, press .
1. Contacts
x List of contacts
2. Central Directory
x Select required contact by name
3. Calls
x All calls
x Answered calls
x Dialed calls
x Missed calls
4. Settings
x General settings
- Time & Date
- Language (Supported: English, Spanish, German,
French, Italian, Dutch, Danish, Swedish, Turkish, Polish
& Norwegian)
- Shortcuts (for the navigation keys)
- LED signal
¾ Green LED
¾ Yellow LED
¾ Red LED
- Security
¾ Automatic key lock
¾ Change PIN
¾ Proxy password
¾ Phone lock
- Handset name
- Reset settings
- Status
x Audio settings
- Ring volume
- Ring external/internal/unknown
- Ring normal/urgent/emergency message
- Alert volume
- Alert tone
- Increasing ring & Increasing alert
- Vibrator
- Key sound
- Confirmation sound
- Coverage warning & Charger warning
x Display
- Wallpaper
- Startup screen
- Power save
Settings (continued)
x Calls
- Units
- Answer mode
- Caller filter
- Emergency call
- Voicemail number
- Silent charging
- Missed call time
x Connectivity
- Register
- Deregister
- Select network
- Edit network
5. Calendar
x Manage your appointments
6. Accessories
x Alarms
x Calculator
x Stopwatch
7. Messaging
x Drafts
x Inbox
x Sent messages
x Settings
Menu list
Usin
g
the menu
Actions on calls lists:
¾ Call
¾ View details
¾ Send message
¾ Save as contact
¾ Add to contact
¾ Edit before call
¾ Delete
(
all
)
Additional Information G266/G566 Page 4
Additional Information G266/G566
Only use this product in countries where the relevant authorities have
authorised its operation.
Charge the battery only:
1. While installed in the handset in combination with the Gx66 Desktop
Charger powered by USB Power Supply NEC EU9170351 or EU9170362.
2. In the spare battery charging slot in the Gx66 Desktop Charger powered
by USB Power Supply NEC EU9170351 or EU9170362.
3. While installed in the handset in combination with the Gx66 Multi
Charger Rack powered by Power Supply NEC EU917034.
4. In one of the spare battery charging slots of the Gx66 Multi Charger Rack
powered by Power Supply NEC EU917034.
5. While installed in the handset and connecting the handset by means of a
USB to mini USB cable directly to USB Power Supply NEC EU9170351 or
EU9170362.
If so required other USB outputs supplying 5V/1000mA or 5V/900mA can be
used instead of the mentioned NEC USB Power Supplies.
The G266/G566 is fitted with a 3.7V/1100mAh/4.1 Wh Lithium-Ion battery3
which can be charged for 300 ʹ 500 charge cycles (fully charged to fully
discharged). A typical life expectancy for the battery is 2 to 3 years.
Always observe the following with respect to the battery:
x Only use the battery delivered with the G266/G566 (or a spare battery
of the recommended type ʹ NEC article code: 9600 017 87001).
x Never disassemble, customize or short-circuit batteries.
x Do not expose the battery ƚŽƚĞŵƉĞƌĂƚƵƌĞƐŝŶĞdžĐĞƐƐŽĨϲϬ϶;ϭϰϬ϶&Ϳ.
1 Original product Friwo FW7712 with EU style mains plug
2 Original product Friwo FW7713 with changeable mains plug for USA, UK or AUS
3 Manufacturer: Shenzhen DRN Battery CO. Ltd, supplier model no. RTR001F01
Additional Information G266/G566 Page 5
x Before placing the G266/G566 in the desktop charger, make sure the
battery is installed properly (see User Manual) and the battery cover is
securely in place.
x Do not charge the batteries by any other means! Using any other
charger may damage the battery and/or the G266/G566 and might even
cause the battery to explode.
Like any radio-based equipment, the G266/G566 can potentially cause
interference with other equipment. However due to the very low
transmission power level the chances for interference is very small. Research
proves that operational DECT phones (and thereby the G266/G566) normally
ĚŽŶ͛ƚŝŶĨůƵĞŶĐĞĞůĞĐƚƌŽŶŝĐĞƋƵŝƉŵĞŶƚ͘ Even so it is advised not to place the
G266/G566 near sensitive electronic equipment. When the G266/G566 is
operated in straight nearness of sensitive electronic equipment incidental
influences can appear. You are advised not to place the G266/G566 on or
close (less than 10cm) to this kind of equipment, even in standby mode.
Do not rely on the G266/G566 as your only means of communication when
making indispensable calls (e.g. an emergency call).
Observe all warnings and instructions contained in the G266/G566 User
Manual.
When using the G266/G566 and its accessories observe the following:
x Do not expose the G266/G566 to rain or moisture, nor use the handset
near water.
x Do not use the G266/G566 on premises subject to explosive hazards.
x Do not expose the G266/G566 to high temperatures or direct sunlight
for an extended period of time.
x Plug the AC adaptor in a wall outlet socket near the equipment for easy
access/removal of the AC adaptor. Take care that the power cord does
not cause a trip hazard.
Please also use the other documentation supplied with the various parts of
your telephone system.
Additional Information G266/G566 Page 6
For countries in the European Union
Be sure to dispose of these products as well as its packing
material in an environmentally compatible way.
Electrical equipment, including the battery, should not be
disposed of as municipal waste.
These products should be taken to a designated facility where the
best available treatment, recovery and recycling techniques are available.
At www.nec-unified.com/weee you can find information about separate
disposal and environmentally sound recycling.
For countries outside the European Union
Disposal of electrical and electronic products in countries outside the
European Union should be done in line with the local regulations. If no
arrangement has been made with NEC or your supplier, please contact the
local authorities for further information.
Additional Information G266/G566 Page 7
ýHVN\
³1(&8QLILHG6ROXWLRQV´WtPWRSURKODãXMHåHWHQWR³G266/G566´MHYHVKRGČVH]iNODGQtPLSRåDGDYN\DGDOãtPL
SĜtVOXãQêPLXVWDQRYHQtPLVPČUQLFH(6
http://www.nec-unified.com/doc
Dansk
8QGHUWHJQHGH ³1(& 8QLILHG 6ROXWLRQV´ HUNOUHU KHUYHG DW I¡OJHQGH XGVW\U ³G266/G566´  RYHUKROGHU GH
væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
http://www.nec-unified.com/doc
Deutsch
+LHUPLW HUNOlUW ³1(& 8QLILHG 6ROXWLRQV´ GDVV VLFK GDV *HUlW ³G266/G566´ LQ hEHUHLQVWLPPXQJ PLW GHQ
grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
http://www.nec-unified.com/doc
Eesti
.lHVROHYDJD NLQQLWDE ³1(& 8QLILHG 6ROXWLRQV´ VHDGPH ³G266/G566´ YDVWDYXVW GLUHNWLLYL (h
põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.
http://www.nec-unified.com/doc
English
+HUHE\ ³1(& 8QLILHG 6ROXWLRQV´ GHFODUHV WKDW WKLV ³G266/G566´ LV LQ FRPSOLDQFH ZLWK WKH HVVHQWLDO
requirements and other relevant provisions of Directive 1999/5/EC.
http://www.nec-unified.com/doc
Español
3RU PHGLR GH OD SUHVHQWH ³1(& 8QLILHG 6ROXWLRQV´ GHFODUD TXH HO³G266/G566´  FXPSOH FRQ ORV UHTXLVLWRV
esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
http://www.nec-unified.com/doc
ǼȜȜȘȞȚțȒ
ȂǼ ȉǾȃ ȆǹȇȅȊȈǹ Ǿ NEC ǼȃȅȆȅǿǾȂǼȃǼS ȁȊSǼǿS ǻǾȁȍȃǼǿ ȅȉǿ ³ G266/G566´ ȈȊȂȂȅȇĭȍȃǼȉǹǿ
ȆȇȅȈȉǿȈȅȊȈǿȍǻǼǿȈǹȆǹǿȉǾȈǼǿȈȀǹǿȉǿȈȁȅǿȆǼȈȈȋǼȉǿȀǼȈǻǿǹȉǹȄǼǿȈȉǾȈȅǻǾīǿǹȈǼȀ
http://www.nec-unified.com/doc
Français
3DU OD SUpVHQWH ³1(& 8QLILHG 6ROXWLRQV´ GpFODUH TXH ODSSDUHLO ³ G266/G566´ HVW FRQIRUPH DX[ H[LJHQFHV
essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.
http://www.nec-unified.com/doc
Íslenska
+pUPHèOêVLU³1(&8QLILHG6ROXWLRQV´\ILUìYtDè³ G266/G566´HU tVDPUPLYLèJUXQQNU|IXURJDèUDUNU|IXU
sem gerðar eru í tilskipun 1999/5/EC.
http://www.nec-unified.com/doc
Additional Information G266/G566 Page 8
Italiano
&RQODSUHVHQWH³1(&8QLILHG6ROXWLRQV´GLFKLDUDFKHTXHVWR³G266/G566´qFRQIRUPHDLUHTXLVLWLHVVHQ]LDOLHG
alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
http://www.nec-unified.com/doc
Latviski
$U ãR ³1(& 8QLILHG 6ROXWLRQV´ GHNODUƝ ND ³G266/G566´ DWELOVW 'LUHNWƯYDV (. EnjWLVNDMƗP SUDVƯEƗP XQ
citiem ar to VDLVWƯWDMLHPQRWHLNXPLHP
http://www.nec-unified.com/doc
/LHWXYLǐ
âLXR³1(&8QLILHG6ROXWLRQV´GHNODUXRMDNDGãLV³G266/G566´DWLWLQNDHVPLQLXVUHLNDODYLPXVLUNLWDV(%
Direktyvos nuostatas.
http://www.nec-unified.com/doc
Malti
+DZQKHNN ³1(& 8QLILHG 6ROXWLRQV´ MLGGLNMDUD OL GDQ ³G266/G566´ MLNNRQIRUPD PDO-ƫWLƥLMLHW HVVHQ]MDOL X PD
SURYYHGLPHQWLRƫUDMQUHOHYDQWLOLKHPPILG-Dirrettiva 1999/5/EC.
http://www.nec-unified.com/doc
Magyar
$OXOtURWW ³1(& 8QLILHG 6ROXWLRQV´ Q\LODWNR]RP KRJ\ D ³G266/G566´  PHJIHOHO D YRQDWNR]y DODSYHW}
követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
http://www.nec-unified.com/doc
Nederlands
+LHUELMYHUNODDUW³1(&8QLILHG6ROXWLRQV´GDWKHWWRHVWHO³G266/G566´LQRYHUHHQVWHPPLQJLVPHWGHHVVHQWLsOH
eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.
http://www.nec-unified.com/doc
Norsk
³1(&8QLILHG6ROXWLRQV´HUNOUHUKHUYHGDWXWVW\UHW³G266/G566´HULVDPVYDUPHGGHJUXQQOHJJHQGHNUDYRJ
øvrige relevante krav i direktiv 1999/5/EF.
http://www.nec-unified.com/doc
Polski
1LQLHMV]\P1(&8QLILHG6ROXWLRQVGHNODUXMH]H³G266/G566´MHVW]JRGQ\]Z\PDJDQLDPLLLQQ\PLZDUXQNDPL
Dyrektywy 1999/5/EC.
http://www.nec-unified.com/doc
Português
³1(& 8QLILHG 6ROXWLRQV´ GHFODUD TXH HVWH ³G266/G566´ HVWi FRQIRUPH FRP RV UHTXLVLWRV HVVHQFLDLV H RXWUDV
disposições da Directiva 1999/5/CE.
http://www.nec-unified.com/doc
Slovensko
³1(&8QLILHG6ROXWLRQV´L]MDYOMDGDMHWD³G266/G566´YVNODGX]ELVWYHQLPL]DKWHYDPLLQRVWDOLPLUHOHYDQWQLPL
GRORþLOLGLUHNWLYH(6
http://www.nec-unified.com/doc
Additional Information G266/G566 Page 9
Slovensky
³1(& 8QLILHG 6ROXWLRQV´ WêPWR Y\KODVXMH åH ³G266/G566´ VSĎĖD ]iNODGQp SRåLDGDYN\ D YãHWN\ SUtVOXãQp
ustanovenia Smernice 1999/5/ES.
http://www.nec-unified.com/doc
Suomi
³1(& 8QLILHG 6ROXWLRQV´ YDNXXWWDD WlWHQ HWWl ³G266/G566´ W\\SSLQHQ ODLWH RQ GLUHNWLLYLQ (< ROHHOOLVWHQ
vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
http://www.nec-unified.com/doc
Svenska
+lUPHGLQW\JDU ³1(& 8QLILHG6ROXWLRQV´ DWWGHQQD³ G266/G566´ står I överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.
http://www.nec-unified.com/doc
FCC information
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
x Reorient or relocate the receiving antenna.
Re
g
ulatory Information United States
NEC Nederland BV
Anton Philipsweg 1
1223 KZ Hilversum
The Netherlands
Additional Information G266/G566 Page 10
x Increase the separation between the equipment and receiver.
x Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
x Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by NEC could void the user's authority
to operate the equipment.
Privacy of communications may not be ensured when using this equipment.
Exposure to Radio Frequency (RF) Signals
This wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission (FCC)
of the U.S. Government. These limits are part of comprehensive guidelines
and establish permitted levels of RF energy for the general population. The
guidelines are based on the safety standards previously set by both U.S. and
international standards bodies. These standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and
health. This device and its antenna must not be co-located or operating in
conjunction with any other antenna or transmitter.
This product has been shown to be capable of compliance for localized
specific absorption rate (SAR) for uncontrolled environment/general
population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had
been tested in accordance with the measurement procedures specified in
FCC/OET Bulletin 65 Supplement C (2001) and IEEE 1528-ϮϬϬϯ͟
For body worn operation, this handset has also been tested and meets the
FCC RF exposure guideline when used with the belt clip supplied with this
product. Use of other accessories may not ensure compliance with FCC RF
exposure guidelines.
Hearing Aid Compatibility (HAC/VC)
The G266 and G566 DECT Handsets meet the FCC standard for Hearing Aid
Compatibility.
Additional Information G266/G566 Page 11
IC Information
Privacy of communications may not be ensured when using this equipment.
Operation of this equipment is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
Under Industry Canada regulations, this radio transmitter may only operate
using an antenna of a type and maximum (or lesser) gain approved for the
transmitter by Industry Canada. To reduce potential radio interference to
other users, the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communication.
Exposure to Radio Frequency (RF) Signals
This wireless telephone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set the Ministry of Health (Canada), Safety Code 6.
These limits are part of comprehensive guidelines and establish permitted
levels of RF energy for the general population. The guidelines are based on
the safety standards previously set by both U.S. and international standards
bodies. These standards include a substantial safety margin designed to
assure the safety of all persons, regardless of age and health.
This device and its antenna must not be co-located or operating in
conjunction with any other antenna or transmitter. This device has been
shown to be capable of compliance for localized specific absorption rate
(SAR) for uncontrolled environment/general population exposure limits
specified in ANSI/IEEE Standard C95.1:1992 and has been tested in
accordance with the measurement procedures specified in IEEE 1528-2003.
Hearing Aid Compatibility (HAC/VC)
The G266 and G566 DECT Handsets meet the IC CS-03 issue 9 Part V standard
for Hearing Aid Compatibility.
Re
g
ulator
y
Information Canada
DECT model G566d/ G566s DECT Handset Reference Guide 1
G566d Front View G566d Side View
Package Contents
- G566d/ G566s DECT Handset
- Battery
- Belt clip (incl. name plate cover)
- Name plate cover
- This Reference Guide
- Additional Information sheet
Main Menu Items Top Line Icons
Contacts Signal strength
Central Directory Battery status
Calls Ringer off
Settings Microphone muted
Calendar Keypad locked
Accessories Missed call
Messaging Voice Mail present indication
Reference Guide
G566d/ G566s DECT Handset
2 DECT model G566d/ G566s DECT Handset Reference Guide
GETTING STARTED
Press and hold for a few seconds.
When the display of your phone is dark, press any key to activate your phone (phone in Idle
mode).
Press and then (toggle function).
1. Press and then type the number you want to reach OR
2. Press and then type the number you want to reach (speakerphone call) OR
3. Type the number you want to reach and then or OR
4. Press soft key or , select the required contact and press soft key ,
or .
Press or, for speakerphone call, .
Press .
During a call, press and dial the number of the party you want to consult. Press
to toggle between the two parties.
Press to transfer the call.
During a call, press ³9ROXPHXS´or ³9ROXPHGRZQ´ on the side of the phone.
During a call, press ; to deactivate: press again.
Press soft key . To turn the microphone on again, press soft key .
In Idle mode, press , use the navigation keys to select and press soft key .
1. Press soft key , then enter the text of your message OR
2. Use the navigation keys to select a stored draft message and press soft key
Then press soft key , select the type of the message (normal or urgent) and choose the
UHTXLUHGGHVWLQDWLRQV:KHQ³0HVVDJHVHQW´LVJLYHQLQWKHGLVSOD\\RXUPHVVDJHKDVEHHQ
sent successfully.
In Idle mode, press soft key , select the contact you want to assign to a speed
dialling key and press soft key . Choose and press soft key .
Use the navigation keys to scroll to the appropriate number (2..9) and press soft key .
In Idle mode, press , use the navigation keys to select and press soft key .
Use the navigation keys to select (Connectivity) and press soft key . Use the
navigation keys to select (Register) and press soft key .
Enter the requested registration information (contact your System Administrator for this).
Wait for the registration to be completed.
Register the handset
Assigning a contact to a speed dialling key
Write and send a text messa
g
e
Mute the microphone durin
g
a call
Use the s
p
eaker
p
hone
Chan
g
e the volume
Make an enquiry call
End a call
Answer a call
Make a call
Lock/unlock your phone
Activating your phone
Turning the phone on and off
DECT model G566d/ G566s DECT Handset Reference Guide 3
MENU FUNCTIONS
In Idle mode, press to access the main menu. Use the navigation keys to go to the
required menu, menu tab and menu item. Use soft key (or press ) to select the
chosen menu or menu item/tab. Other soft keys may provide additional options.
To go back one step in the menu or leave it altogether, press .
1. Contacts
x List of contacts
2. Central Directory
x Select required contact by name
3. Calls
x All calls
x Answered calls
x Dialed calls
x Missed calls
4. Settings
x General settings
- Time & Date
- Language (Supported: English, Spanish, German,
French, Italian, Dutch, Danish, Swedish, Turkish, Polish
& Norwegian)
- Shortcuts (for the navigation keys)
- LED signal
¾ Green LED
¾ Yellow LED
¾ Red LED
- Security
¾ Automatic key lock
¾ Change PIN
¾ Proxy password
¾ Phone lock
- Handset name
- Reset settings
- Status
x Audio settings
- Ring volume
- Ring external/internal/unknown
- Ring normal/urgent/emergency message
- Alert volume
- Alert tone
- Increasing ring & Increasing alert
- Vibrator
- Key sound
- Confirmation sound
- Coverage warning & Charger warning
x Display
- Wallpaper
- Startup screen
- Power save
Settings (continued)
x Calls
- Units
- Answer mode
- Caller filter
- Emergency call
- Voicemail number
- Silent charging
- Missed call time
x Connectivity
- Register
- Deregister
- Select network
- Edit network
5. Calendar
x Manage your appointments
6. Accessories
x Alarms
x Calculator
x Stopwatch
7. Messaging
x Drafts
x Inbox
x Sent messages
x Settings
Menu list
Usin
g
the menu
Actions on calls lists:
¾ Call
¾ View details
¾ Send message
¾ Save as contact
¾ Add to contact
¾ Edit before call
¾ Delete
(
all
)
Additional Information G266/G566 Page 4
Additional Information G266/G566
Only use this product in countries where the relevant authorities have
authorised its operation.
Charge the battery only:
1. While installed in the handset in combination with the Gx66 Desktop
Charger powered by USB Power Supply NEC EU9170351 or EU9170362.
2. In the spare battery charging slot in the Gx66 Desktop Charger powered
by USB Power Supply NEC EU9170351 or EU9170362.
3. While installed in the handset in combination with the Gx66 Multi
Charger Rack powered by Power Supply NEC EU917034.
4. In one of the spare battery charging slots of the Gx66 Multi Charger Rack
powered by Power Supply NEC EU917034.
5. While installed in the handset and connecting the handset by means of a
USB to mini USB cable directly to USB Power Supply NEC EU9170351 or
EU9170362.
If so required other USB outputs supplying 5V/1000mA or 5V/900mA can be
used instead of the mentioned NEC USB Power Supplies.
The G266/G566 is fitted with a 3.7V/1100mAh/4.1 Wh Lithium-Ion battery3
which can be charged for 300 ʹ 500 charge cycles (fully charged to fully
discharged). A typical life expectancy for the battery is 2 to 3 years.
Always observe the following with respect to the battery:
x Only use the battery delivered with the G266/G566 (or a spare battery
of the recommended type ʹ NEC article code: 9600 017 87001).
x Never disassemble, customize or short-circuit batteries.
x Do not expose the battery ƚŽƚĞŵƉĞƌĂƚƵƌĞƐŝŶĞdžĐĞƐƐŽĨϲϬ϶;ϭϰϬ϶&Ϳ.
1 Original product Friwo FW7712 with EU style mains plug
2 Original product Friwo FW7713 with changeable mains plug for USA, UK or AUS
3 Manufacturer: Shenzhen DRN Battery CO. Ltd, supplier model no. RTR001F01
Additional Information G266/G566 Page 5
x Before placing the G266/G566 in the desktop charger, make sure the
battery is installed properly (see User Manual) and the battery cover is
securely in place.
x Do not charge the batteries by any other means! Using any other
charger may damage the battery and/or the G266/G566 and might even
cause the battery to explode.
Like any radio-based equipment, the G266/G566 can potentially cause
interference with other equipment. However due to the very low
transmission power level the chances for interference is very small. Research
proves that operational DECT phones (and thereby the G266/G566) normally
ĚŽŶ͛ƚŝŶĨůƵĞŶĐĞĞůĞĐƚƌŽŶŝĐĞƋƵŝƉŵĞŶƚ͘ Even so it is advised not to place the
G266/G566 near sensitive electronic equipment. When the G266/G566 is
operated in straight nearness of sensitive electronic equipment incidental
influences can appear. You are advised not to place the G266/G566 on or
close (less than 10cm) to this kind of equipment, even in standby mode.
Do not rely on the G266/G566 as your only means of communication when
making indispensable calls (e.g. an emergency call).
Observe all warnings and instructions contained in the G266/G566 User
Manual.
When using the G266/G566 and its accessories observe the following:
x Do not expose the G266/G566 to rain or moisture, nor use the handset
near water.
x Do not use the G266/G566 on premises subject to explosive hazards.
x Do not expose the G266/G566 to high temperatures or direct sunlight
for an extended period of time.
x Plug the AC adaptor in a wall outlet socket near the equipment for easy
access/removal of the AC adaptor. Take care that the power cord does
not cause a trip hazard.
Please also use the other documentation supplied with the various parts of
your telephone system.
Additional Information G266/G566 Page 6
For countries in the European Union
Be sure to dispose of these products as well as its packing
material in an environmentally compatible way.
Electrical equipment, including the battery, should not be
disposed of as municipal waste.
These products should be taken to a designated facility where the
best available treatment, recovery and recycling techniques are available.
At www.nec-unified.com/weee you can find information about separate
disposal and environmentally sound recycling.
For countries outside the European Union
Disposal of electrical and electronic products in countries outside the
European Union should be done in line with the local regulations. If no
arrangement has been made with NEC or your supplier, please contact the
local authorities for further information.
Additional Information G266/G566 Page 7
ýHVN\
³1(&8QLILHG6ROXWLRQV´WtPWRSURKODãXMHåHWHQWR³G266/G566´MHYHVKRGČVH]iNODGQtPLSRåDGDYN\DGDOãtPL
SĜtVOXãQêPLXVWDQRYHQtPLVPČUQLFH(6
http://www.nec-unified.com/doc
Dansk
8QGHUWHJQHGH ³1(& 8QLILHG 6ROXWLRQV´ HUNOUHU KHUYHG DW I¡OJHQGH XGVW\U ³G266/G566´  RYHUKROGHU GH
væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
http://www.nec-unified.com/doc
Deutsch
+LHUPLW HUNOlUW ³1(& 8QLILHG 6ROXWLRQV´ GDVV VLFK GDV *HUlW ³G266/G566´ LQ hEHUHLQVWLPPXQJ PLW GHQ
grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
http://www.nec-unified.com/doc
Eesti
.lHVROHYDJD NLQQLWDE ³1(& 8QLILHG 6ROXWLRQV´ VHDGPH ³G266/G566´ YDVWDYXVW GLUHNWLLYL (h
põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.
http://www.nec-unified.com/doc
English
+HUHE\ ³1(& 8QLILHG 6ROXWLRQV´ GHFODUHV WKDW WKLV ³G266/G566´ LV LQ FRPSOLDQFH ZLWK WKH HVVHQWLDO
requirements and other relevant provisions of Directive 1999/5/EC.
http://www.nec-unified.com/doc
Español
3RU PHGLR GH OD SUHVHQWH ³1(& 8QLILHG 6ROXWLRQV´ GHFODUD TXH HO³G266/G566´  FXPSOH FRQ ORV UHTXLVLWRV
esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
http://www.nec-unified.com/doc
ǼȜȜȘȞȚțȒ
ȂǼ ȉǾȃ ȆǹȇȅȊȈǹ Ǿ NEC ǼȃȅȆȅǿǾȂǼȃǼS ȁȊSǼǿS ǻǾȁȍȃǼǿ ȅȉǿ ³ G266/G566´ ȈȊȂȂȅȇĭȍȃǼȉǹǿ
ȆȇȅȈȉǿȈȅȊȈǿȍǻǼǿȈǹȆǹǿȉǾȈǼǿȈȀǹǿȉǿȈȁȅǿȆǼȈȈȋǼȉǿȀǼȈǻǿǹȉǹȄǼǿȈȉǾȈȅǻǾīǿǹȈǼȀ
http://www.nec-unified.com/doc
Français
3DU OD SUpVHQWH ³1(& 8QLILHG 6ROXWLRQV´ GpFODUH TXH ODSSDUHLO ³ G266/G566´ HVW FRQIRUPH DX[ H[LJHQFHV
essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.
http://www.nec-unified.com/doc
Íslenska
+pUPHèOêVLU³1(&8QLILHG6ROXWLRQV´\ILUìYtDè³ G266/G566´HU tVDPUPLYLèJUXQQNU|IXURJDèUDUNU|IXU
sem gerðar eru í tilskipun 1999/5/EC.
http://www.nec-unified.com/doc
Additional Information G266/G566 Page 8
Italiano
&RQODSUHVHQWH³1(&8QLILHG6ROXWLRQV´GLFKLDUDFKHTXHVWR³G266/G566´qFRQIRUPHDLUHTXLVLWLHVVHQ]LDOLHG
alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
http://www.nec-unified.com/doc
Latviski
$U ãR ³1(& 8QLILHG 6ROXWLRQV´ GHNODUƝ ND ³G266/G566´ DWELOVW 'LUHNWƯYDV (. EnjWLVNDMƗP SUDVƯEƗP XQ
citiem ar to VDLVWƯWDMLHPQRWHLNXPLHP
http://www.nec-unified.com/doc
/LHWXYLǐ
âLXR³1(&8QLILHG6ROXWLRQV´GHNODUXRMDNDGãLV³G266/G566´DWLWLQNDHVPLQLXVUHLNDODYLPXVLUNLWDV(%
Direktyvos nuostatas.
http://www.nec-unified.com/doc
Malti
+DZQKHNN ³1(& 8QLILHG 6ROXWLRQV´ MLGGLNMDUD OL GDQ ³G266/G566´ MLNNRQIRUPD PDO-ƫWLƥLMLHW HVVHQ]MDOL X PD
SURYYHGLPHQWLRƫUDMQUHOHYDQWLOLKHPPILG-Dirrettiva 1999/5/EC.
http://www.nec-unified.com/doc
Magyar
$OXOtURWW ³1(& 8QLILHG 6ROXWLRQV´ Q\LODWNR]RP KRJ\ D ³G266/G566´  PHJIHOHO D YRQDWNR]y DODSYHW}
követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
http://www.nec-unified.com/doc
Nederlands
+LHUELMYHUNODDUW³1(&8QLILHG6ROXWLRQV´GDWKHWWRHVWHO³G266/G566´LQRYHUHHQVWHPPLQJLVPHWGHHVVHQWLsOH
eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.
http://www.nec-unified.com/doc
Norsk
³1(&8QLILHG6ROXWLRQV´HUNOUHUKHUYHGDWXWVW\UHW³G266/G566´HULVDPVYDUPHGGHJUXQQOHJJHQGHNUDYRJ
øvrige relevante krav i direktiv 1999/5/EF.
http://www.nec-unified.com/doc
Polski
1LQLHMV]\P1(&8QLILHG6ROXWLRQVGHNODUXMH]H³G266/G566´MHVW]JRGQ\]Z\PDJDQLDPLLLQQ\PLZDUXQNDPL
Dyrektywy 1999/5/EC.
http://www.nec-unified.com/doc
Português
³1(& 8QLILHG 6ROXWLRQV´ GHFODUD TXH HVWH ³G266/G566´ HVWi FRQIRUPH FRP RV UHTXLVLWRV HVVHQFLDLV H RXWUDV
disposições da Directiva 1999/5/CE.
http://www.nec-unified.com/doc
Slovensko
³1(&8QLILHG6ROXWLRQV´L]MDYOMDGDMHWD³G266/G566´YVNODGX]ELVWYHQLPL]DKWHYDPLLQRVWDOLPLUHOHYDQWQLPL
GRORþLOLGLUHNWLYH(6
http://www.nec-unified.com/doc
Additional Information G266/G566 Page 9
Slovensky
³1(& 8QLILHG 6ROXWLRQV´ WêPWR Y\KODVXMH åH ³G266/G566´ VSĎĖD ]iNODGQp SRåLDGDYN\ D YãHWN\ SUtVOXãQp
ustanovenia Smernice 1999/5/ES.
http://www.nec-unified.com/doc
Suomi
³1(& 8QLILHG 6ROXWLRQV´ YDNXXWWDD WlWHQ HWWl ³G266/G566´ W\\SSLQHQ ODLWH RQ GLUHNWLLYLQ (< ROHHOOLVWHQ
vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
http://www.nec-unified.com/doc
Svenska
+lUPHGLQW\JDU ³1(& 8QLILHG6ROXWLRQV´ DWWGHQQD³ G266/G566´ står I överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.
http://www.nec-unified.com/doc
FCC information
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
x Reorient or relocate the receiving antenna.
Re
g
ulatory Information United States
NEC Nederland BV
Anton Philipsweg 1
1223 KZ Hilversum
The Netherlands
Additional Information G266/G566 Page 10
x Increase the separation between the equipment and receiver.
x Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
x Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by NEC could void the user's authority
to operate the equipment.
Privacy of communications may not be ensured when using this equipment.
Exposure to Radio Frequency (RF) Signals
This wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission (FCC)
of the U.S. Government. These limits are part of comprehensive guidelines
and establish permitted levels of RF energy for the general population. The
guidelines are based on the safety standards previously set by both U.S. and
international standards bodies. These standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and
health. This device and its antenna must not be co-located or operating in
conjunction with any other antenna or transmitter.
This product has been shown to be capable of compliance for localized
specific absorption rate (SAR) for uncontrolled environment/general
population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had
been tested in accordance with the measurement procedures specified in
FCC/OET Bulletin 65 Supplement C (2001) and IEEE 1528-ϮϬϬϯ͟
For body worn operation, this handset has also been tested and meets the
FCC RF exposure guideline when used with the belt clip supplied with this
product. Use of other accessories may not ensure compliance with FCC RF
exposure guidelines.
Hearing Aid Compatibility (HAC/VC)
The G266 and G566 DECT Handsets meet the FCC standard for Hearing Aid
Compatibility.
Additional Information G266/G566 Page 11
IC Information
Privacy of communications may not be ensured when using this equipment.
Operation of this equipment is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
Under Industry Canada regulations, this radio transmitter may only operate
using an antenna of a type and maximum (or lesser) gain approved for the
transmitter by Industry Canada. To reduce potential radio interference to
other users, the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communication.
Exposure to Radio Frequency (RF) Signals
This wireless telephone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set the Ministry of Health (Canada), Safety Code 6.
These limits are part of comprehensive guidelines and establish permitted
levels of RF energy for the general population. The guidelines are based on
the safety standards previously set by both U.S. and international standards
bodies. These standards include a substantial safety margin designed to
assure the safety of all persons, regardless of age and health.
This device and its antenna must not be co-located or operating in
conjunction with any other antenna or transmitter. This device has been
shown to be capable of compliance for localized specific absorption rate
(SAR) for uncontrolled environment/general population exposure limits
specified in ANSI/IEEE Standard C95.1:1992 and has been tested in
accordance with the measurement procedures specified in IEEE 1528-2003.
Hearing Aid Compatibility (HAC/VC)
The G266 and G566 DECT Handsets meet the IC CS-03 issue 9 Part V standard
for Hearing Aid Compatibility.
Re
g
ulator
y
Information Canada

Navigation menu
