RTX RTX8055 1.9GHZ DECT MESSENGER User Manual M155 Reference Guide draft
RTX Hong Kong Ltd. 1.9GHZ DECT MESSENGER M155 Reference Guide draft
RTX >
USERS MANUAL
1. Display
2. Lower Key
3. Upper Key
4. Hand Strap
5. Charger Unit
6. On cradle LED
Display
Top row icons:
A constant receiving power symbol
shows good reception and transmission
power of radio signal.
Message Showing Indicator.
It shows the phone is in off-hook mode.
Flashes while connecting and receiving
calls
Phone book review mode. It shows
when Phone Book records are being
viewed.
Displayed when the ringer volume is set
to OFF
Battery charge more than 95%
Battery charge between 50% and 95%
Battery charge between 20% and 50%
Below 20%. A warning tone is played –
the battery capacity is low and the
handset needs charging.
Reference Guide
1
2
3
4
6
5
DECT Messenger – Quick Reference Guide
GETTING STARTED
On:
• Place the M155 on charger cradle or;
• Press the upper key.
Off: Select “Power off” from the menu.
The M155 is configured by sending special message strings to it. This allows configuring the
phone book , specify messages, change language or reset the product to factory settings.
Sending these special messages can be done from another messaging enabled DECT
handset or a Messenger application connected to the system.
In idle an SOS call is initiated by pressing and holding one of the two keys for 2 seconds.
If no SOS message has been defined a call to the first number (SOS number) in the phone
book list is set up. If a message has been defined the predefined SOS message will be sent
to the SOS number.
Select from the menu the (predefined) number (0 - 4) to which a call is to be set up. Press
the lower key to set up the call.
Press either the upper or the lower key to answer a call.
Press either the upper or the lower key to end a call.
Press and hold both the lower key for 2 seconds.
Select from the menu the (predefined) message that is to be sent. Press the lower key to
sent the message to the with the message defined number.
An incoming message is shown at the display.
When the message is too long to be displayed completely use the upper key to scroll
through the message.
Press the lower key for 2 seconds to acknowledge the message and to clear the display.
When the message contains a call back number then press the lower key to set up a
(voice) call to this number.
Incoming message
Send
a
n outgoing
message
Make an outgoing call
Configure the phone
Answer a c
all
End
a call
Re
ject
a call
Turning the phone on and off
Make a
n
SOS
call
DECT Messenger – Reference Guide
HOW TO WEAR?
The handset unit can be worn as a watch (A) or pendant (B) as indicating in below pictures.
The best position to use the phone for conversation is to keep 20cm distance between the
user and the handset. This is to ensure that the loudspeaker will not cause any harm to
your ears.
MENU FUNCTIONS
Press both keys at the same time to enter menu. Upper key will be used to toggle the
menu. Lower key will be used to select an item.
Using the menu
DECT Messenger – Reference Guide
Menu
Phone book
Audio
Language
Time
Connectivity
No. 1
No. 2
No. 3
No. 4
No. 5
Back
Ringtone
Notification
Back
Melody 1
...
Melody n
Back
ON
OFF
Back
English
Back
12h
24h
Back
AC code
Register
Deregister
Back
Mute
Messages
No. 1
No. 2
No. 3
No. 4
No. 5
Back
German
Spanish
Italian
French
PARK
Power off
Exit
Menu list
DECT Messenger – Reference Guide
Important safety information
Charge the M155 handset only in combination with
the M155 DECT Handset Desktop charger and the
KTEC KSLFB0500035W1UV-1 adapter that comes
with the product. Plug the corresponding AC plug
from the package and plug the KTEC
KSLFB0500035W1UV-1 adapter in a wall outlet
socket near the equipment for easy access/removal
of the AC/DC adaptor. Never attempt to open your
M155 handset or adapter, disassemble it; there are
no user-serviceable parts inside. The embedded
battery of the M155 needs no replacement during the
normal life time of the handset.
Important battery information
This product uses rechargeable Lithium-Polymer
batteries 3.7V, 400mAh, which is produced by
SHENZHEN BAK TECHNOLOGY CO., LTD. with
model number BAK402838P. Do not use any other
type, since this may present a risk of leakage, fire,
explosion or other hazardous situation. Never
disassemble, customize or short-circuit batteries. Do
not place battery in fire or heat the battery. Charge
the handset only in combination with M155 DECT
Handset Desktop charger and the KTEC
KSLFB0500035W1UV-1 adapter that comes with the
product.
Sensitive Electronic Environment
Any radio-based equipment can potentially cause
interference with other equipment and can be
interfered from other equipment. This also applies for
DECT equipment. However due to the very low
transmission power level the chances for interference
are very small. Research proves that operational
DECT phones normally don’t influence electronic
equipment however some precautions must be taken
into account for sensitive electronic equipment e.g.
sensitive laboratory equipment. When DECT phones
operate in straight nearness of sensitive electronic
equipment incidental influence can appear. You are
advised not to place the DECT phone on or close
(less than 10cm) to this kind of equipment, even in
standby mode. Please also use the other
documentation supplied with the various parts of your
telephone system.
Product disposal information
For countries in the European Union
The symbol depicted here has been
affixed to your product in order to
inform you that electrical and electronic
products should not be disposed of as
municipal waste.
Electrical and electronic products including the
cables, plugs and accessories should be disposed of
separately in order to allow proper treatment,
recovery and recycling. These products should be
taken to a designated facility where the best available
treatment, recovery and recycling techniques are
available. Separate disposal has significant
advantages: valuable materials can be re-used and it
prevents the dispersion of unwanted substances into
the municipal waste stream. This contributes to the
protection of human health and the environment.
Please be informed that a fine may be imposed for
illegal disposal of electrical and electronic products
via the general municipal waste stream. In order to
facilitate separate disposal and environmentally
sound recycling, arrangements have been made for
local collection and recycling. In case your electrical
and electronic products need to be disposed of
please refer to your supplier or the contractual
agreements that your company has made upon
acquisition of these products.
At www.nec-philips.com/weee you can find
information about separate disposal and
environmentally sound recycling.
For countries outside the European Union
Disposal of electrical and electronic products in
countries outside the European Union should be
done in line with the local regulations. If no
arrangement has been made with NEC or your
supplier, please contact the local authorities for
further information.
DECT Messenger – Reference Guide
Regulatory information Europe
Declaration of conformity
Česky
“NEC Philips Unified Solutions” tímto prohlašuje, že tento “M155”
je ve shodě se základními požadavky a dalšími příslušnými
ustanoveními směrnice 1999/5/ES.
http://www.nec-philips.com/doc
Dansk
Undertegnede “NEC Philips Unified Solutions” erklærer herved, at
følgende udstyr “ M155” overholder de væsentlige krav og øvrige
relevante krav i direktiv 1999/5/EF.
http://www.nec-philips.com/doc
Deutsch
Hiermit erklärt “NEC Philips Unified Solutions”, dass sich das
Gerät “ M155” in Übereinstimmung mit den grundlegenden
Anforderungen und den übrigen einschlägigen Bestimmungen der
Richtlinie 1999/5/EG befindet.
http://www.nec-philips.com/doc
Eesti
Käesolevaga kinnitab “NEC Philips Unified Solutions” seadme “
M155” vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud
direktiivist tulenevatele teistele asjakohastele sätetele.
http://www.nec-philips.com/doc
English
Hereby, “NEC Philips Unified Solutions”, declares that this “M155”
is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
http://www.nec-philips.com/doc
Español
Por medio de la presente “NEC Philips Unified Solutions” declara
que el “M155” cumple con los requisitos esenciales y
cualesquiera otras disposiciones aplicables o exigibles de la
Directiva 1999/5/CE.
http://www.nec-philips.com/doc
Ελληνική
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Η NEC Philips ΕΝΟΠΟΙΗΜΕΝΕS ΛΥSΕΙS ∆ΗΛΩΝΕΙ
ΟΤΙ “
M155
” ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩ∆ΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ
ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ∆ΙΑΤΑΞΕΙΣ ΤΗΣ Ο∆ΗΓΙΑΣ 1999/5/ΕΚ.
http://www.nec-philips.com/doc
Français
Par la présente “NEC Philips Unified Solutions” déclare que
l'appareil “ M155” est conforme aux exigences essentielles et aux
autres dispositions pertinentes de la directive 1999/5/CE.
http://www.nec-philips.com/doc
Regulatory information
Europe
Declaration of conformity
Íslenska
Hér með lýsir “NEC Philips Unified Solutions” yfir því að “M155” er
í samræmi við grunnkröfur og aðrar kröfur, sem gerðar eru í
tilskipun 1999/5/EC.
http://www.nec-philips.com/doc
Italiano
Con la presente “NEC Philips Unified Solutions” dichiara che
questo “M155” è conforme ai requisiti essenziali ed alle altre
disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
http://www.nec-philips.com/doc
Latviski
Ar šo “NEC Philips Unified Solutions” deklarē, ka “M155” atbilst
Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to
saistītajiem noteikumiem.
http://www.nec-philips.com/doc
Lietuvių
Šiuo “NEC Philips Unified Solutions” deklaruoja, kad šis “M155”
atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos
nuostatas.
http://www.nec-philips.com/doc
Malti
Hawnhekk, “NEC Philips Unified Solutions”, jiddikjara li dan “M155”
jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn
relevanti li hemm fid-Dirrettiva 1999/5/EC.
http://www.nec-philips.com/doc
Magyar
Alulírott, “NEC Philips Unified Solutions” nyilatkozom, hogy a
“M155” megfelel a vonatkozó alapvetõ követelményeknek és az
1999/5/EC irányelv egyéb elõírásainak.
http://www.nec-philips.com/doc
Nederlands
Hierbij verklaart “NEC Philips Unified Solutions” dat het toestel
“M155” in overeenstemming is met de essentiële eisen en de
andere relevante bepalingen van richtlijn 1999/5/EG.
http://www.nec-philips.com/doc
Norsk
“NEC Philips Unified Solutions” erklærer herved at utstyret “ M155”
er i samsvar med de grunnleggende krav og øvrige relevante krav
i direktiv 1999/5/EF.
http://www.nec-philips.com/doc
DECT Messenger – Reference Guide
Regulatory information
Europe
Declaration of conformity
Polski
Niniejszym, "NEC Philips Unified Solutions" deklaruje, ze “M155”
jest zgodny z wymaganiami i innymi warunkami Dyrektywy
1999/5/EC.
http://www.nec-philips.com/doc
Português
“NEC Philips Unified Solutions” declara que este “M155” está
conforme com os requisitos essenciais e outras disposições da
Directiva 1999/5/CE.
http://www.nec-philips.com/doc
Slovensko
“NEC Philips Unified Solutions” izjavlja, da je ta “M155” v skladu z
bistvenimi zahtevami in ostalimi relevantnimi določili direktive
1999/5/ES.
http://www.nec-philips.com/doc
Slovensky
“NEC Philips Unified Solutions” týmto vyhlasuje, že “M155” spĺňa
základné požiadavky a všetky príslušné ustanovenia Smernice
1999/5/ES.
http://www.nec-philips.com/doc
Suomi
“NEC Philips Unified Solutions” vakuuttaa täten että “M155”
tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja
sitä koskevien direktiivin muiden ehtojen mukainen.
http://www.nec-philips.com/doc
Svenska
Härmed intygar “NEC Philips Unified Solutions” att denna “M155”
står I överensstämmelse med de väsentliga egenskapskrav och
övriga relevanta bestämmelser som framgår av direktiv
1999/5/EG.
http://www.nec-philips.com/doc
0979
Regulatory information United
States
Interference information:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try
to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.”
Changes or modifications to this unit not expressly
approved by the party responsible for compliance
could void the user's authority to operate
the equipment.
Privacy of communications may not be ensured when
using this equipment.
Exposure to Radio Frequency (RF) Signals:
This wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF
energy for the general population. The guidelines are
based on the safety standards previously set by both
U.S. and international standards bodies. These
standards include a substantial safety margin
designed to assure the safety of all persons,
NEC PHILIPS Unified Solutions
Anton Philipsweg 1
1223 KZ Hilversum
The Netherlands
DECT Messenger – Reference Guide
regardless of age and health. This device and its
antenna must not be co-located or operating in
conjunction with any other antenna or transmitter.
This product has been shown to be capable of
compliance for localized specific absorption rate
(SAR) for uncontrolled environment/general
population exposure limits specified in ANSI/IEEE
Std. C95.1-1992 and had been tested in accordance
with the measurement procedures specified in
FCC/OET Bulletin 65 Supplement C (2001) and IEEE
1528-2003”
For body worn operation, this handset has also been
tested and meets the FCC RF exposure guideline.
Use of other accessories may not ensure compliance
with FCC RF exposure guidelines.
Regulatory information
Canada
Interference information:
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Privacy of communications may not be ensured when
using this equipment.
Exposure to Radio Frequency (RF) Signals:
This wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limit for exposure to radio
frequency (RF) energy set by the Ministry of Health
(Canada), Safety Code 6. These limits are part of
comprehensive guidelines and established permitted
levels of RF energy for the general population. These
guidelines are based on the safety standards
previously set by international standard bodies.
These standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
This device and its antenna must not be co-located
or operating in conjunction with any other antenna or
transmitter.
This device has been shown to be capable of
compliance for localized specific absorption rate
(SAR) for uncontrolled environment / general public
exposure limits specific in ANSI/IEEE C95.1-1992
and had been tested in accordance with the
measurement procedures specified in IEEE 1528-
2003.
For body worn operation, this handset has also been
tested and meets the RF exposure limits of IC RSS-
102. Use of other accessories may not ensure
compliance with IC RSS-102 RF exposure limits.
This Class B digital apparatus complies with
Canadian ICES-003
Cet appareil numérique de la classe B est conforme
á la norme NMB-003 du Canada.
Le présent materiel est conforme aux specifications
techniques applicables d’Industrie Canada
