Radeum FA03 Adapter for wireless devices for two-way radios User Manual User guide
Radeum, Inc. (DBA FreeLinc) Adapter for wireless devices for two-way radios User guide
Radeum >
User guide
Introduction and General Information
Congratulations, and thank you for
choosing FreeLinc products to enhance
your two-way radio communications.
Each FreeLinc Adapter is compatible with
other FreeLinc wireless communication
accessories that use cutting-edge Near
Field Magnetic Induction communication
(NFMI) wireless technology. NFMI supports
mobility, freedom-of-motion, exceptional
battery life, audio integrity, ease-of-use,
durability, secure communications and
comfort. This is the rst technology of its
kind to be implemented into practical voice
and audio solutions for two-way radios.
Thank you for choosing FreeLinc.
Anthony J. Sutera
CEO
Parts of the Product - Adapter
Diagram/Terms
Illustrated below are the components of
your FreeLinc Adapter.
Push-to-Talk Button Indicator Light
General Operation
Using Your FreeLinc Wireless Accessory for
the First Time
Step One: Attach Adapter
Attach your FreeLinc FA3 Adapter to the
accessory interface of your portable radio
(see your portable radio’s user manual if
you need assistance locating the accessory
interface). Use the thumb screw to secure
the adapter to your radio (see diagram).
When properly attached, the spring-loaded
pins should align with the contacts on the
accessory interface of your portable radio
and the adapter should t securely.
Note: Do not overtighten the thumb screw.
Adapter Indicator Light
The indicator light on your FreeLinc FA3
Adapter indicates wireless communication
status as follows:
BEHAVIOR INDICATION
Green Flashing Link Active
Red Flashing Seek Mode
Orange Flashing Vox Mode
Not Illuminated Sleep Mode
Troubleshooting
For up-to-date troubleshooting
information, please visit www.freelinc.com
and click the “support” link. To contact a
customer service representative, call
1-866-467-1199.
General Operation
Step Two: Turn On Adapter
Turn on your portable radio and set the
toggle switch to “ON” (see diagram).
This will automatically silence the speaker
on your portable radio and route all of your
communications to the FreeLinc wireless
accessory.
Note: For information on how to operate
this product with a FreeLinc accessory,
please refer to your user manual that came
with the accessory.
mation
Caution: To reduce the risk of re or injury
to persons, read and follow these
instructions.
Do not use liquid cleaners or aerosol
cleaners as they may damage the adapter
or nish of the adapter. Use a dry cloth to
clean the external portions of the adapter.
Do not stick anything inside the product as
this may damage internal components. This
product conforms to the following safety
standards:
ANSI/UL 60950-1 1st Ed.
CAN/CSA C22.2 No. 60950-1-03
EN 60950-1 1st Ed.
Safety Information
On/O Toggle
Switch
Thumb Screw
TOP VIEW
Warranty
I. What this warranty covers and for how long:
a. Radeum, Inc., doing business as FreeLinc (“FreeLinc”),
warrants to Purchaser that its FreeLinc manufactured
products (“Product”) will substantially conform to
FreeLinc’s published specications, as of the date of
the Purchaser’s purchase of the Product, and for one
(1) year from the date of purchase (the “Warranty
Period”).
b. Rechargeable batteries will be replaced during the
warranty period if the battery develops leakage.
c. FreeLinc, at its option, will at no charge either repair,
replace, or refund the purchase price for warranted
Product during the warranty period provided it is
returned in accordance with the terms of this
warranty to the place of purchase. Repair, at FreeLinc’s
option, may include the replacement of parts or
boards with functionally equivalent reconditioned
or new parts or boards. Replaced parts or boards
are warranted only for the balance of the original
Warranty Period. All replaced parts or Product shall
become the property of FreeLinc.
d. This express limited warranty is extended by FreeLinc
to the original end user purchaser only and is not
assignable or transferable to any other party. This is
the complete warranty for Product manufactured
by FreeLinc. FreeLinc assumes no obligations or
liability for additions or modications to this warranty
unless made in writing and signed by an ocer of
FreeLinc. Unless made in a separate written agree-
ment between FreeLinc and the original end user
purchaser, FreeLinc does not warrant the installation,
maintenance or service of warranted Product.
III. How to get warranty service:
a. Purchaser shall notify FreeLinc of any nonconfor-
mance during the warranty period, and obtain a writ-
ten return material authorization (“RMA”) and an RMA
number for the nonconforming Product from FreeLinc.
b. Purchaser shall return the nonconforming Product to
the place of purchase freight prepaid.
IV. Limitation of Liability:
a. This warranty sets forth the full extent of FreeLinc’s
responsibilities regarding the Product. Repair,
replacement, or refund of the purchase price, at
FreeLinc’s option, is the exclusive remedy.
b. THE FOREGOING WARRANTIES ARE THE SOLE WAR-
RANTIES, EXPRESS OR IMPLIED, GIVEN BY FREELINC
IN CONNECTION WITH THE PRODUCT, AND FREELINC
DISCLAIMS ALL OTHER WARRANTIES EXPRESS OR
IMPLIED, INCLUDING WARRANTIES OF MERCHANTI-
BILITY, FITNESS FOR A PARTICULAR PURPOSE, AND
NONINFRINGEMENT OF THIRD-PARTY RIGHTS.
c. FREELINC SHALL NOT BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES IN
CONNECTION WITH THE PRODUCT, EVEN IF FREELINC
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
d. EXCEPT FOR CLAIMS FOR BODILY INJURY (including
death) AND CLAIMS FOR DAMAGE TO REAL PROPERTY
AND TANGIBLE PERSONAL PROPERTY, FREELINC’S
LIABILITY FOR ALL OTHER CLAIMS SHALL NOT EXCEED
THE AMOUNT PAID TO FREELINC FOR THE PRODUCT
GIVING RISE TO FREELINC’S LIABILITY. THIS LIMIT OF
LIABILITY ALSO APPLIES TO OUR MANUFACTURERS
AND DISTRIBUTORS. IT IS THE MAXIMUM AMOUNT
FOR WHICH WE ARE COLLECTIVELY RESPONSIBLE.
FCC Compliance
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the manufacturer’s instructions, may
cause interference harmful to radio communications.
There is no guarantee however, that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by comparing the equipment o
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
• Consult your supplier or an experienced radio technician
for assistance.
Warning: Changes or modications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate this
equipment.
FCC Compliance
®
e. FreeLinc is not responsible in any way for any
ancillary equipment not furnished by FreeLinc which
is attached to or used in connection with Product, or
for operation of the Product with any ancillary
equipment and all such equipment is expressly
excluded from this warranty. Because each system
which may use the Product is unique, FreeLinc
disclaims liability for range, coverage, or operation of
the system as a whole under this warranty.
II. What this warranty does not cover:
a. Defects or damage resulting from use of the Product
in other than its normal and customary manner.
b. Defects or damage from misuse, accident, water or
neglect.
c. Defects or damage from improper testing, operation,
maintenance, installation,
alteration, modication, or adjustment.
d. A Product subjected to unauthorized modications,
disassemblies, or repairs.
e. Product which has had the serial number removed or
made illegible.
f. Rechargeable batteries if the damage or defect is
caused by charging or using the battery in
equipment or service other than the Product for
which it is specied.
g. Freight costs related to Product returned for warranty
claims.
h. A product which, due to illegal or unauthorized
alteration of the software/rmware in the Product,
does not function in accordance with FreeLinc’s
published specications or the FCC type acceptance
labeling in eect for the Product at the time the
Product was purchased.
© 2005, 2006, 2007, 2008, Radeum Inc., DBA FreeLinc. All Rights Reserved.
Protected by one or more of the following U.S. Patents: 7.149.552,
7.254.366, 7.236.741, 7.215,924, 7.142.811, 7.035.608, 6.819.762,
6.459.882, 5.982.764, 5.912.925, 5.771.438
The FreeLinc Adapter Series may not be authorized for use in some countries.
Made in USA
Rev. 0608
®
FA3 Adapter
User Guide
