Radeum FPTT Wireless PTT User Manual FPTT User Guide

Radeum, Inc. (DBA FreeLinc) Wireless PTT FPTT User Guide

User's Guide

PTT
Button
Pair
Button
Pairing
Press and hold the PTT button on the wireless PTT
module then Press and hold the small black button on
the adapter next to the LED for X sec and release both
buttons.
If the pairing was successful, the radio will start trans
If the pairing was successful, the radio will start trans-
mitting until the wireless PTT button is released.
Press and hold the wireless PTT button while you are
talking, release when nished.
The wireless PTT will not function unless the adapter is
linked up with a Remote device.
Battery
The battery in the wireless PTT module is a dispos-
able "watch style" battery. The battery is a CR2032
lithium type and is available in any Radio Shack,
Wal-Mart, etc...
Our current estimate on battery life is 3 months.
This is based on the button being held down 90 min-
utes per day, 5 days per week.
The battery can be accessed by prying the wireless
PTT housing apart. Remove the PCB from the plas-
tic housing and slide the battery out of the holder.
The new battery should be installed with the nega-
tive side toward the PCB and the positive side
toward the holder. When the new battery is in-
stalled, replace the PCB into the housing and snap
the housing back together.
This device complies with part 15 of the
FCC Rules.
Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any
interference received, including
interference received, including
interference that may cause
undesired operation.
