operation.
FCC ID: AAO1202054A
Addendum
12-2054
Wireless FM Transmitter
Connect to your audio source’s
LINE/MICROPHONE jack.
Low frequencies: 88.1, 88.3, 88.5, 88.7.
High frequencies: 107.1, 107.3, 107.5, 107.7
For best performance, select a frequency
that is not occupied by a strong local FM
station.
High-Low Band
frequency switch
Replace batteries when the amber
indicator dims or goes out.
Plug the power port adapter into
your vehicle’s power port.
For best reception,
position your FM
transmitter near
to your receiver’s
antenna.
5V DC jack
FCC ID: AAO1202054A
