Cat. No. 19-1205

OWNER’S MANUAL

Please read before using this equipment.

BTX-124

VHF FM Business Band Transceiver

with CTCSS

19-1205.fm Page 1 Tuesday, August 3, 1999 10:30 AM

FEATURES

Your RadioShack BTX-124 VHF FM

Business Band Transceiver with CTCSS

is a portable, two-way business radio

service transceiver that you can carry al-

most anywhere. The transceiver is com-

pact and light, making it an ideal choice

for your business needs.

Your transceiver has these features:

Pro

rammable Channels A and B —

let you operate the transceiver on two

different frequencies.

Preset Frequencies — let you quickly

begin operation on either 154.600 MHz

(Channel A, green dot) or 154.570 MHz

(Channel B, blue dot).

PLL-Controlled Circuitr

— provides

accurate and stable channel selection.

ustable Squelch — helps eliminate

noise between transmissions.

CTCSS (Continuous Tone Control

Squelch S

stem) — helps reduce inter-

ference from other systems in the area

operating on the same frequency.

Built-In Modulation Limiter Circuit —

automatically adjusts for a wide variety

of voice levels to ensure an understand-

able transmission.

h/Low Power — lets you save pow-

er by selecting a suitable transmitting

power for long or short distances.

Batter

Low and Transmit Indicator

— shows the battery pack’s condition

and lights when you transmit or receive.

Removable and Rechar

eable Bat-

ter

Pack — lets you use one battery

pack while you charge another (addi-

tional packs available).

Supplied Batter

Char

er — conve-

niently recharges your transceiver’s bat-

tery pack.

Earphone Jack and External Micro-

phone Jack — let you use an earphone

or external microphone to help ensure

understandable communications in

noisy areas.

Belt Pouch — protects your transceiver

and lets you easily carry it on your belt.

We recommend you record your trans-

ceiver’s serial number here. The num-

ber is on the back of the transceiver.

Serial Number___________________

RadioShack is a registered trademark used by Tandy Corporation.

19-1205.fm Page 2 Tuesday, August 3, 1999 10:30 AM

CONTENTS

FCC Re

ulations ................................................................................................... 4

FCC License Required ..................................................................................... 4

FCC Part 90 Rules ........................................................................................... 4

Preparation ............................................................................................................ 6

Charging the Battery Pack ............................................................................... 6

Checking the Battery Power ...................................................................... 7

Using the Belt Clip ........................................................................................... 7

Using an Earphone .......................................................................................... 7

Connecting an Antenna ................................................................................... 8

Using an External Microphone ......................................................................... 8

Operation ............................................................................................................... 9

Why Use CTCSS? ......................................................................................... 10

Operational Hints ........................................................................................... 10

Additional FCC Re

ulations .............................................................................. 11

Maintenance ........................................................................................................ 12

Specifications ..................................................................................................... 13

19-1205.fm Page 3 Tuesday, August 3, 1999 10:30 AM

FCC REGULATIONS

FCC LICENSE REQUIRED

The Federal Communications Commis-

sion (FCC) requires you to have a li-

cense before you operate this

transceiver. Unless you qualify to oper-

ate on the supplied frequencies, you

must apply for a frequency through the

PCIA (Personal Communication Indus-

try Association), a non-profit organiza-

tion that assigns frequencies nationwide

to help prevent conflicts between differ-

ent businesses using transceivers in the

same area. For more information about

getting a license, contact the PCIA at

800-759-0300, extension 3068 (in Vir-

ginia 703-739-0300, extension 3068).

For other questions concerning the li-

cense application, contact the FCC at

717-337-1212, or write:

FCC

P.O. Box 1040

Gettysburg, PA 17325

For the latest FCC application form and

instructions, call the FCC’s fax-on-de-

mand service from a fax machine at 1-

202-418-0177 and request one or more

of the following documents:

All forms and instructions 000600

Form 600 instructions only 006001

Main Form 600 only 006002

Form 600 schedules only 006003

If you do not have a fax machine, you

can call the Government Forms Distri-

bution Center at 1-800-418-FORM and

request that the form and instructions be

mailed to you.

This transceiver is intended for use in

the operation of commercial activities,

educational, philanthropic, or ecclesias-

tical institutions, and hospitals, clinics,

or medical associations.

FCC PART 90 RULES

You must be familiar with Part 90 of

FCC Rules

before you operate your

transceiver. The operation instructions

in this manual conform to Part 90, but

do not cover all items in Part 90.

Overall, Part 90 states that:

• You must have a valid license

before you use the transceiver.

• As licensee, you are responsible for

proper operation of all transceivers

operating under your license author-

ity.

• You can let unlicensed persons

operate this transmitter, as long as

you take precautions to prevent

unauthorized transmissions.

19-1205.fm Page 4 Tuesday, August 3, 1999 10:30 AM

• You must use this transceiver only

for the commercial use of your busi-

ness, and only when other commer-

cial channels (such as the

telephone) are either not available

or not practical.

• You must always yield the operating

frequency to communications that

involve the safety of life or property.

• You must take reasonable precau-

tions to prevent harmful interference

to other services operating on the

same frequency.

• You must not transmit program

material of any kind used in connec-

tion with commercial broadcasting.

• You must not provide a service that

is normally handled by telephone or

telegraph unless such broadcasts

involve the safety of life or property

or in emergencies such as an earth-

quake, hurricane, flood or a similar

disaster where normal communica-

tion channels are disrupted.

• During each transmission or

exchange of transmissions, you

must identify your station with the

call sign issued to you by the FCC,

or once each 15 minutes during

periods of continuous operation.

• You must keep a written record of

any maintenance or modification

made to the transceiver, and you

must make this record available for

inspection upon demand by the

FCC.

Violating any of the provisions of Part 90

can result in fines and/or confiscation of

equipment.

Your transceiver might cause TV or ra-

dio interference even when it is operat-

ing properly. To determine whether your

transceiver is causing the interference,

turn off your transceiver. If the interfer-

ence goes away, your transceiver is

causing it. Try to eliminate the interfer-

ence by:

• Moving your transceiver away from

the receiver

• Contacting your local RadioShack

store for help

19-1205.fm Page 5 Tuesday, August 3, 1999 10:30 AM

PREPARATION

Before you use the transceiver, you

must be properly licensed by the FCC. If

you are licensed to use one or both of

the supplied frequencies, you can im-

mediately use the transceiver.

If you are licensed on different frequen-

cies, your local RadioShack store must

send the transceiver to an authorized

service facility to have the frequencies

programmed into the transceiver. You

must tell the store the frequency you are

licensed for and any desired CTCSS

tone (the factory preset is 100.0 Hz).

See “Why Use CTCSS?” on Page 11 for

more information about CTCSS.

CHARGING THE BATTERY

PACK

You must charge the battery pack with

the supplied battery charger before you

use it the first time, and whenever the

battery becomes low.

You can charge the battery pack with it

attached to the transceiver or removed.

To attach the battery pack, slide it onto

the transceiver. To remove the battery

pack, press down and slide RELEASE in

the direction of the arrow, then slide off

the pack.

Follow these steps to charge the battery

pack.

1. If the transceiver is on, turn VOL

counterclockwise until it clicks to

turn it off.

2. Plug the charger’s barrel plug into

the CHRG jack on the side of the

ILLUSTRATION

19-1205.fm Page 6 Tuesday, August 3, 1999 10:30 AM

battery pack, then connect the charger to a standard AC outlet.

ILLUSTRATION

19-1205.fm Page 7 Tuesday, August 3, 1999 10:30 AM

Note: Charging time is 14 to 16

hours.

Cautions:

• To prevent permanent battery power

loss, never charge the batteries in

an area where the temperature is

above about 80°F. The charger

does not operate at all at tempera-

tures below 32°F or above 113°F.

• Never use any other charger to

recharge the transceiver’s battery

pack. This could permanently dam-

age your transceiver or the battery

pack.

Important: This transceiver uses a re-

chargeable nickel-cadmium battery

pack. At the end of the battery pack’s

useful life, it must be recycled or dis-

posed of properly. Contact your local,

county, or state hazardous waste man-

agement authorities for information on

recycling or disposal programs in your

area. Some options that might be avail-

able are: municipal curbside collection,

drop-off boxes at retailers such as your

local RadioShack store, recycling collec-

tion centers, and mail-back programs.

Checking the Battery Power

1. Rotate VOL clockwise until it clicks

to turn on the transceiver.

2. Press the push-to-talk button on the

left side of the transceiver. If

BUSY•TX/LO BATT lights red, there

is sufficient battery power for trans-

mission. If the indicator lights yellow,

you need to recharge the battery

pack.

Using the Belt Clip

The supplied belt clip lets you easily clip

the transceiver to your belt. Use a small

Phillips screwdriver to secure the clip to

the transceiver’s back with the supplied

screws and washers, then attach it to

your belt.

Using an Earphone

To listen privately or to hear better in a

noisy area, you can plug a monaural

earphone into the EAR jack on the top of

the transceiver. This automatically dis-

connects the speaker.

ILLUSTRATION

19-1205.fm Page 8 Tuesday, August 3, 1999 10:30 AM

CONNECTING AN

ANTENNA

Attach the flexible antenna to the anten-

na jack on top of the transceiver. Place

the antenna connector’s slots over the

antenna jack’s tabs, squeeze the base

of the antenna, and push down and turn

the connector until the antenna locks

into place.

Instead of the supplied antenna, you

can connect an optional antenna. The

BNC antenna jack on your transceiver

makes it easy to use with a variety of

antennas, such as an external mobile

antenna or an outdoor base antenna.

Caution: Never connect an antenna

that is not specifically tuned for the

transceiver’s frequency range.

Warning: When installing or removing a

base station antenna, use extreme cau-

tion. If it starts to fall, let it go! It could

contact overhead power lines. If the an-

tenna touches the power line, contact

with the antenna, mast, cable, or guy

wires can cause electrocution and

death! Call the power company to re-

move the antenna. Do not attempt to do

so yourself.

USING AN EXTERNAL

MICROPHONE

An external microphone can make it

easier to use the transceiver when you

clip it to your belt. Plug the microphone’s

cable connector into the MIC jack on top

of the transceiver. This automatically

disconnects the transceiver’s micro-

phone.

Note: The transceiver’s push-to-talk

button still works with an external micro-

phone attached.

ILLUSTRATION

19-1205.fm Page 9 Tuesday, August 3, 1999 10:30 AM

OPERATION

1. Turn VOL clockwise to turn on the

transceiver.

2. Select Channel A or B using the

CHANNEL switch on the top of the

transceiver.

3. To conserve battery power, set

POWER

LO. If the person you

transmit to has trouble receiving

your signal, set POWER to HI.

4. To transmit, hold down push-to-talk,

then hold your transceiver about 3

inches from your mouth and speak

slowly in a normal tone of voice. The

BUSY•TX/LO BATT indicator lights

red.

5. When you finish your message,

release push-to-talk. The BUSY•TX/

LO BATT indicator lights green

when you receive a transmission.

6. Adjust VOL to a comfortable listen-

ing level.

7. If you are not using CTCSS, wait

until there is no signal on the chan-

nel, then slowly turn SQL/CTCSS

clockwise until the background

noise stops.

Note: Do not turn SQL/CTCSS too

far clockwise because you might cut

out weak signals.

If you are using CTCSS (see “Why

Use CTCSS?” on Page 11), turn

SQL/CTCSS counterclockwise until it

clicks.

8. To turn off the transceiver, turn VOL

counterclockwise.

ILLUSTRATION

19-1205.fm Page 10 Tuesday, August 3, 1999 10:30 AM

WHY USE CTCSS?

CTCSS (Continuous Tone-Coded

Squelch System) helps eliminate inter-

ference between different users of the

same frequency. When CTCSS is

turned on, the transceiver transmits a

selected tone with your transmission.

This tone is too low for you to hear, but

other transceivers can detect it. If CTC-

SS is turned on and set to the same

tone on the receiving transceiver, it only

receives those transmissions that in-

clude the tone.

If two different groups operate transceiv-

ers in the same area on the same fre-

quency, they do not hear each other’s

broadcasts if they both use CTCSS and

each select a different CTCSS tone.

There are 38 different CTCSS tones

available. The CTCSS tone default for

this unit is 100 Hz. See “Available CTC-

SS Tones” on Page 15 for a complete

list. Only authorized RadioShack Ser-

vice Centers can change the CTCSS

tone.

OPERATIONAL HINTS

Your transceiver’s range varies depend-

ing on factors such as position, terrain,

and battery condition. Buildings absorb

transmitted signals and, if they contain

metal, might completely block the sig-

nals. Trees and heavy cloud formations

have a similar effect, though not as se-

vere. If you are near a lake or the ocean,

you might get excellent range.

To ensure maximum range, operate the

transceiver with the battery pack fully

charged. As the voltage decreases, the

range decreases.

19-1205.fm Page 11 Tuesday, August 3, 1999 10:30 AM

ADDITIONAL FCC REGULATIONS

The Business Radio Service is under the jurisdiction of the Federal Communica-

tions Commission (FCC). Any adjustments or alterations that would alter the perfor-

mance of the transceiver so it no longer meets the original FCC type acceptance or

would change the frequency-determining method are strictly prohibited.

Replacement or substitution of crystals, transistors, ICS, regulator diodes, or any

other component that is of a unique nature with components other than those rec-

ommended can violate the technical regulations of the FCC rules or violate type ac-

ceptance requirement of the rules.

Before you operate the transceiver, you must obtain your license. It is illegal to

transmit without the appropriate license, which you can get by submitting a complet-

ed FCC Form 600 to the FCC (or through the PCIA if you do not qualify for either of

the supplied frequencies). Furthermore, you are required to understand Part 90 of

the

FCC Rules and Regulations

prior to operating your transceiver. It is the user’s

responsibility to see that this unit is operating at all times in accordance with the

FCC Rules and Regulations

19-1205.fm Page 12 Tuesday, August 3, 1999 10:30 AM

MAINTENANCE

Your RadioShack BTX-124 VHF FM Business Band Transceiver with CTCSS is an

example of superior design and craftsmanship. The following suggestions will help

you care for your transceiver so you can enjoy it for years.

Keep the transceiver dry. If it gets wet, wipe it dry immediately. Liquids

might contain minerals that can corrode the electronic circuits.

Use and store the transceiver only in normal temperature environ-

ments. Temperature extremes can shorten the life of electronic devic-

es, damage batteries, and distort or melt plastic parts.

Keep the transceiver away from dust and dirt, which can cause pre-

mature wear of parts.

Handle the transceiver gently and carefully. Dropping it can damage

circuit boards and cases and can cause the transceiver to work im-

properly.

Use only fresh batteries of the required size and type. Batteries can

leak chemicals that damage your transceiver’s electronic parts.

Wipe the transceiver with a damp cloth occasionally to keep it looking

new. Do not use harsh chemicals, cleaning solvents, or strong deter-

gents to clean the transceiver.

Modifying or tampering with the transceiver’s internal components can cause a mal-

function and might invalidate your transceiver’s warranty and void your FCC authori-

zation to operate it. If your transceiver is not performing as it should, take it to your

local RadioShack store for assistance.

19-1205.fm Page 13 Tuesday, August 3, 1999 10:30 AM

SPECIFICATIONS

Transmitter

Frequency Coverage ........................................................ 150.775 to 155.985 MHz

Frequency Tolerance .................................................................................. ±1.5 kHz

Modulation Type ................................................................................................... FM

Modulation Distortion ........................................................................................... 9%

CTCSS Tone Deviation ............................................................................... ±0.8 kHz

Maximum Deviation ....................................................................................... ±5 kHz

Minimum Operating Voltage ........................................................................... 7 Volts

RF High Power Output (8.4 V) ..................................................... 2 Watts ±0.2 Watt

RF Low Power Output ............................................................... 0.6 Watts ±0.2 Watt

Current Drain at High Power ........................................................................ 700 mA

Current Drain at Low Power ......................................................................... 450 mA

Receiver

Frequency Range ............................................................. 150.775 to 155.985 MHz

Auto Output Power at 10% THD ................................................................ 0.25 Watt

Signal-to-Noise Ratio (20 dB) ...................................................................... 0.75 µV

Working Voltage .......................................................................................... 8.4 Volts

Adjacent Channel Rejection ............................................................................ 45 dB

Audio Distortion .................................................................................................... 5%

Squelch Sensitivity (Start) .............................................................................. 0.5 µV

Distortion (1 mV Input 4.3 kHz) ............................................................................ 5%

Current Drain at Maximum Power ................................................................ 200 mA

Current Drain at Standby ............................................................................... 60 mA

19-1205.fm Page 14 Tuesday, August 3, 1999 10:30 AM

Factory Defaults

Channel A 154.600 MHz

Channel B 154.570 MHz

CTCSS Tone 100 Hz

Available CTCSS Tones

General

Power Supply 8.4 Volts DC

Antenna Length 163 mm

Dimensions (HWD) 21/2 × 1

1/2 × 6

Inches (65 × 35 × 160 mm)

Weight 14.66 oz (416 g)

Specifications are typical; individual

units might vary. Specifications are sub-

ject to change and improvement without

notice.

Frequency (Hz)

67.0 97.4 136.5 192.8

71.9 100.0 141.3 203.5

74.4 103.5 146.2 210.7

77.0 107.2 151.4 218.1

79.7 110.9 156.7 225.7

82.5 114.8 162.2 233.6

85.4 118.8 167.9 241.8

88.5 123.0 173.8 250.3

91.5 127.3 179.9

94.8 131.8 186.2

19-1205.fm Page 15 Tuesday, August 3, 1999 10:30 AM

RadioShack

A Division of Tandy Corporation

Fort Worth, Texas 76102

5A7 Printed in Hong Kong

NOTES

Limited One-Year Warranty

This product is warranted by RadioShack against manufacturing defects in material and workman-

ship under normal use for one (1) year from the date of purchase from RadioShack company-owned

stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HEREIN, Ra-

dioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING

THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED

IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED

HEREIN. EXCEPT AS PROVIDED HEREIN, RadioShack SHALL HAVE NO LIABILITY OR RE-

SPONSIBILITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY

LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFOR-

MANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, IN-

CLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE, LOSS

OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR ANY INDIRECT, SPECIAL, INCIDEN-

TAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RadioShack HAS BEEN ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES.

Some states do not allow the limitations on how long an implied warranty lasts or the exclusion of in-

cidental or consequential damages, so the above limitations or exclusions may not apply to you.

In the event of a product defect during the warranty period, take the product and the RadioShack

sales receipt as proof of purchase date to any RadioShack store. RadioShack will, at its option, un-

less otherwise provided by law: (a) correct the defect by product repair without charge for parts and

labor; (b) replace the product with one of the same or similar design; or (c) refund the purchase

price. All replaced parts and products, and products on which a refund is made, become the prop-

erty of RadioShack. New or reconditioned parts and products may be used in the performance of

warranty service. Repaired or replaced parts and products are warranted for the remainder of the

original warranty period. You will be charged for repair or replacement of the product made after the

expiration of the warranty period.

This warranty does not cover: (a) damage or failure caused by or attributable to acts of God, abuse,

accident, misuse, improper or abnormal usage, failure to follow instructions, improper installation or

maintenance, alteration, lightning or other incidence of excess voltage or current; (b) any repairs

other than those provided by a RadioShack Authorized Service Facility; (c) consumables such as

fuses or batteries; (d) cosmetic damage; (e) transportation, shipping or insurance costs; or (f) costs

of product removal, installation, set-up service adjustment or reinstallation.

This warranty gives you specific legal rights, and you may also have other rights which vary from

state to state.

RadioShack Customer Relations, Dept. W, 100 Throckmorton St., Suite 600, Fort Worth, TX 76102

We Service What We Sell

3/97

19-1205.fm Page 16 Tuesday, August 3, 1999 10:30 AM

Radio Shack Btx 124 Users Manual 19 1205

BTX-124 to the manual 07e56e96-64b3-4d36-8864-8ac07b7f4c53

Navigation menu

Versions of this User Manual:

Views

Navigation
