Radwin 5XACULC Outdoor Subscriber Radio Unit User Manual

Radwin Ltd. Outdoor Subscriber Radio Unit

Contents

User manual

SU Pro, SU Air
Outdoor Subscriber Radio Unit
REFERENCE GUIDE
Regulatory Compliance
FCC/IC - Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules and IC RSS standards. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
It is the responsibility of the installer to ensure that when using the outdoor
antenna kits, only those antennas certified with the product are used. The use
of any antenna other than those certified with the product is expressly
forbidden by FCC 47 CFR Part 15.204 and IC RSS standards.
Il est de la responsabilité de l'installateur de s'assurer que lorsque vous
utilisez les kits d'antennes extérieures, seules les antennes certifiés avec le
produit sont utilisés. L'utilisation d'une antenne autre que ceux qui sont
certifiés avec le produit est expressément interdite par la réglementation FCC
partie 47 CFR 15.204 et IC normes RSS.
Outdoor units and antennas should be installed ONLY by experienced
installation professionals who are familiar with local building and safety codes
and, wherever applicable, are licensed by the appropriate government
regulatory authorities. Failure to do so may void the product warranty and
may expose the end user or the service provider to legal and financial
Caution liabilities. Resellers or distributors of this equipment are not liable for injury,
damage or violation of regulations associated with the installation of outdoor
units or antennas. The installer should configure the output power level of
antennas according to country regulations and antenna type.
SU Pro, SU Air Reference Guide i
Warning
Avertissement
Les unités extérieures et les antennes doivent être installés que par des
professionnels expérimentés d'installation qui sont familiers avec les normes
locales et les codes de sécurité et, si applicable, sont agréées par les autorités
gouvernementales de réglementation compétents. Ne pas le faire peut annuler
la garantie du produit et peuvent exposer l'utilisateur final ou le fournisseur de
services d'obligations juridiques et financiers.
Revendeurs ou distributeurs de ces équipements ne sont pas responsables des
blessures, des dommages ou violation des règlements liés à l'installation des
unités extérieures ou des antennes. L'installateur doit configurer le niveau de
puissance de sortie des antennes conformément aux réglementations
nationales et le type d'antenne.
This equipment should be installed and operated with a minimum distance of
50cm between
the radiator and your body.
Warning
Cet équipement doit être installé et utilisé à une distance minimale de 50cm
entre le radiateur et votre corps.
The module is granted to operate under FCC Rules in the 2.4 / 4.9 / 5.4 /
5.8 GHz bands.
Warning
This device complies with Part 15 of the FCC rules and with Industry Canada license-
exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Cet appareil est conforme la norme d'Industrie Canada exempts de licence RSS (s). Son
fonctionnement est soumis aux deux conditions suivantes:
1. Cet appareil ne peut pas causer d'interférences, et
2. Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent
causer un mauvais fonctionnement de l'appareil.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numrique de la classe B est conforme la norme NMB-003 du Canada
SU Pro, SU Air Reference Guide ii
Prudence
Overview
The ‘SU Pro, SU Air’ is an Outdoor Subscriber Radio Unit operating in the 4.9 – 5.8 GHz
frequency bands. It is a TDD OFDM radio supporting 10 MHz, 20 MHz, 40 MHz and 80 MHz
channel bandwidths. The 2.4 GHz WiFi interface supports standard 802.11/n HT-20, HT-40
operation modes.
It supports cross polarized 2x2 MIMO antenna configuration for PtP and PtMP systems. The
‘SU Pro, SU Air’ also features an on-board WiFi 2.4 GHz interface module for short range
control purposes. The ‘SU Pro, SU Air’ is powered by a 24Vdc PoE device.
The ‘SU Pro, SU Air’ is certified with the FCC ID: Q3K-5XACULC and IC: 5100A- 5XACULC.
Condition of Use
The ‘SU Pro, SU Air’ is a proprietary radio device and can only be deployed and maintained
by RADWIN professional installers or its authorized subcontractors
FCC rules and IC Regulation Restrictions
The ODU firmware is factory programmed to operate under the FCC rules and Industry
Canada regulation restrictions. The firmware is locked and inaccessible by any third party.
As a result of the above the user interface allows both the installer and the user to control
the ODU only within the boundaries of the regional restrictions.
Antennas
The ‘SU Pro, SU Air’ is certified with a 17 dBi integrated flat crossed dual pole antenna type
covering both Point-to-Point and Point-to-Multipoint systems.
Certified Antenna
Following are the antennas certified for use with the ‘SU Pro, SU Air’:
Antenna Type
Manufacturer
Model
Number
Frequency
Range
Antenna Max
Gain (dBi)
Dual Pole
Integrated
RADWIN Ltd.
MP0188280
4940-4990
14
5150-5350
16
5470-5725
17
5725-5850
16
Omni
RADWIN Ltd.
On-Board
2400-2483.5
3
SU Pro, SU Air Reference Guide 1
Maximum Output Power
5725 – 5850 MHz band - FCC/IC
The maximum output power can be set as follows, when operating in the 5.8 GHz band,
under FCC 47 CFR Part 15.407 New Rules and IC RSS-247 regulations. The power values
are for PtP systems and PtMP systems. For PtMP systems the total EIRP is limited to 36
dBm. Therefore the output power of these systems will be reduced to comply with 36 dBm
EIRP limit.
The highest conducted output power shall be limited to 29 dBm in all channel bandwidths
4940 – 4990 MHz band - FCC/IC
The maximum output power can be set as follows, when operating in the 4.9 GHz band,
under FCC 47 CFR Part 90Y Rule and IC RSS-111 regulations.
10 MHz: 21.0 dBm
20 MHz: 21.0 dBm
5150 – 5250 MHz band – FCC
The maximum output power can be set as follows when transmitting in the 5.1 GHz band,
under FCC 47 CFR Part 15.407 New Rules and regulations.
The total EIRP limit for PtP applications is 45 dBm.
The total EIRP limit for PtMP applications is 36 dBm.
The total EIRP limit for PtMP applications when transmitting at elevations above 30° relative
to the horizon is 21 dBm.
10 MHz: 26.0 dBm
20 MHz: 28.0 dBm
40 MHz: 28.0 dBm
80 MHz: 29.0 dBm
2400 – 2483.5 MHz band - FCC/IC
The maximum output power can be set as follows, when operating in the 2.4 GHz band,
under FCC 47 CFR Part 15.247 and IC RSS-247 regulations. The power values are for Wi-Fi
systems for HT-20 and HT-40 Channel BW.
The highest conducted output power shall be limited to 26 dBm in all channel bandwidths
5250 – 5350 MHz band – FCC/IC
The maximum output power can be set as follows, when operating in the 5.3 GHz band. The
total EIRP limit is 30 dBm.
10 MHz: 11.0 dBm
20 MHz: 14.0 dBm
40 MHz: 14.0 dBm
80 MHz: 14.0 dBm
SU Pro, SU Air Reference Guide 2
5470 – 5725 MHz band – FCC/IC
The maximum output power can be set as follows, when operating in the 5.4 GHz band. The
total EIRP limit is 30 dBm.
10 MHz: 10.0 dBm
20 MHz: 13.0 dBm
40 MHz: 13.0 dBm
80 MHz: 13.0 dBm
Channel Bandwidths and Frequency Range
Radio parameters accessed by end-user
The following parameters can be accessed by user:
1. Output Power
2. Frequency channel
3. Channel bandwidth
SU Pro, SU Air Reference Guide 3
Channel BW
[MHz]
Center Freq. Range
[MHz]
10
5730 - 5845
20
5735 - 5840
40
5745 - 5825
80
5765 - 5810
10
4945 - 4985
20
4950 - 4980
10
5160 - 5245
20
5165 - 5240
40
5170 - 5230
80
5190 - 5210
20
2412 - 2462
40
2422 - 2452
10
5255 - 5340
20
5260 - 5340
40
5270 - 5330
80
5290 - 5310
10
5480 - 5715
20
5485 - 5710
40
5495 - 5700
80
5520 - 5680
