RADWIN 2000 JET,
RADWIN 5000 JET
3.x GHz Integrated Smart Antenna Outdoor
Radio Device
REFERENCE GUIDE
Regulatory Compliance
FCC/IC - Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules and IC RSS standards. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
RADWIN Ltd. is not responsible for any radio or communication interference caused by
using other than specified or recommended cables and battery or by unauthorized changes
or modifications to this equipment. Changes or modifications or modifications not expressly
approved by the manufacturer could void the user's authority to operate the equipment.
It is the responsibility of the installer to ensure that when using the outdoor
antenna kits, only those antennas certified with the product are used. The use
of any antenna other than those certified with the product is expressly
forbidden by FCC rules 47 CFR part 15.204 and IC RSS standards.
Il est de la responsabilité de l'installateur de s'assurer que lorsque vous
utilisez les kits d'antennes extérieures, seules les antennes certifiés avec le
produit sont utilisés. L'utilisation d'une antenne autre que ceux qui sont
certifiés avec le produit est expressément interdite par la réglementation FCC
partie 47 CFR 15.204 et IC normes RSS.
Outdoor units and antennas should be installed ONLY by experienced
installation professionals who are familiar with local building and safety codes
and, wherever applicable, are licensed by the appropriate government
regulatory authorities. Failure to do so may void the product warranty and
may expose the end user or the service provider to legal and financial
Caution liabilities. Resellers or distributors of this equipment are not liable for injury,
damage or violation of regulations associated with the installation of outdoor
units or antennas. The installer should configure the output power level of
antennas according to country regulations and antenna type.
RADWIN 2000 JET, RADWIN 5000 JET 3.x GHz Reference Guide i
Warning
Avertissement
Les unités extérieures et les antennes doivent être installés que par des
professionnels expérimentés d'installation qui sont familiers avec les normes
locales et les codes de sécurité et, si applicable, sont agréées par les autorités
gouvernementales de réglementation compétents. Ne pas le faire peut annuler
la garantie du produit et peuvent exposer l'utilisateur final ou le fournisseur de
services d'obligations juridiques et financiers.
Revendeurs ou distributeurs de ces équipements ne sont pas responsables des
blessures, des dommages ou violation des règlements liés à l'installation des
unités extérieures ou des antennes. L'installateur doit configurer le niveau de
puissance de sortie des antennes conformément aux réglementations
nationales et le type d'antenne.
This equipment should be installed and operated with a minimum distance of
53.6cm between
the radiator and your body when operating in the 3.65-
3.70 GHz band.
Warning
Cet équipement doit être installé et utilisé à une distance minimale de 53.6cm
entre le radiateur et votre corps lors d'opérations dans la bande de 3.65 à 3.7
GHz
The device is granted to operate under FCC/IC certification in the 3.65-3.70
GHz band only.
Warning
This device complies with Part 15 of the FCC rules and with Industry Canada license-
exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Cet appareil est conforme la norme d'Industrie Canada exempts de licence RSS (s). Son
fonctionnement est soumis aux deux conditions suivantes:
1. Cet appareil ne peut pas causer d'interférences, et
2. Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent
causer un mauvais fonctionnement de l'appareil.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numrique de la classe B est conforme la norme NMB-003 du Canada
RADWIN 2000 JET, RADWIN 5000 JET 3.x GHz Reference Guide ii
Prudence
Overview
The RADWIN 2000 JET, RADWIN 5000 JET 3.x GHz is an Integrated Smart Antenna Outdoor
Radio Device operating in the 3.65-3.70 GHz frequency band. It is a TDD OFDM radio
supporting 5 MHz, 10 MHz, 20 MHz and 40 MHz channel bandwidths.
The RADWIN 2000 JET, RADWIN 5000 JET incorporates an integrated phase array cross-
polarized active antenna that supports 2x2 and 3x3 MIMO configuration modes. The
antenna is software configurable to operate in 2x2 or 3x3 MIMO modes.
The RADWIN 2000 JET, RADWIN 5000 JET also supports software configurable capabilities
for PtP and PtMP deployment architecture.
The RADWIN 2000 JET model indicates PtP software configuration device.
The RADWIN 5000 JET model indicates PtMP software configuration device.
The device is certified under the FCC ID: Q3K–BSA3XS and IC: 5100A-BSA3XS
Condition of Use
The RADWIN 2000 JET, RADWIN 5000 JET is a RADWIN proprietary outdoor radio device.
The device is manufactured and assembled by RADWIN or its subcontractors. The device is
not for sale to the general public.
FCC rules and IC Regulation Restrictions
The ODU firmware is factory programmed to operate under the FCC rules and Industry
Canada regulation restrictions. The firmware is locked and inaccessible by any third party.
As a result of the above the user interface allows both the installer and the user to control
the ODU only within the boundaries of the regional restrictions.
Antenna
The RADWIN 2000 JET, RADWIN 5000 JET is certified with a proprietary RADWIN
manufactured integrated 3.x GHz Smart antenna type covering both Point-to-Point and
Point-to-Multipoint configurations. It supports 2x2 and 3x3 MIMO and is the only antenna to
be incorporated and marketed with the device.
RADWIN 2000 JET, RADWIN 5000 JET 3.x GHz Reference Guide 1
Maximum Output Power
3650 – 3700 MHz band - FCC/IC
The maximum EIRP must be set as follows, when operating in the 3.65 - 3.70 GHz band,
under FCC and IC regulations.
2x2 Configuration
3x3 Configuration
Radiation Exposure Evaluation
RADWIN 2000 JET and RADWIN 5000 3.x GHz systems - the calculated recommended safe
distance at density of 1mW/cm2 is 53.6cm.
RADWIN 2000 JET, RADWIN 5000 JET 3.x GHz Reference Guide 2
Channel BW
(MHz)
Center Freq. Range
(MHz)
Max EIRP
(dBm)
5
3652.5 – 3697
35.0
10
3655 – 3695
38.0
20
3661 – 3689
42.0
40
3675
43.0
Channel BW
(MHz)
Center Freq. Range
(MHz)
Max EIRP
(dBm)
5
3652.5 – 3697
36.0
10
3655 – 3695
39.0
20
3661 – 3689
42.0
40
3675
43.0
