PROFESSIONAL INSTALLATION
FCC ID: Q3KRW2054
APPLICANT: RADWIN LTD.
CORRESPONDENCE REFERENCE NUMBER: 39808
FORM 731 CONFIRMATION NUMBER: EA621082
Letter Exhibit identifying the specific expertise and the training required by the professional installers for
installing devices certified under FCC ID: Q3KRW2054
RADWIN ensures that the device FCC ID: Q3KRW2054 is limited to professional installation, by the
following:
Marketing
The device is not sold retail to the general public or by mail order. RADWIN Ltd. sells the device only to its carefully
selected certified distributors.
Professional installation
The device must be installed and controlled by specially trained professionals. RADWIN Ltd. provides all its
distributors with training seminars which focus on installation and maintenance and officially certifies
personnel who pass RADWIN Ltd. training to perform installation and maintenance. The installation
requires knowledge in radio equipment handling and technical knowledge concerned with operation of
RADWIN's device. Installation guidelines must be followed to ensure proper operation of the device.
Application
The intended use is generally not for the general public. It is generally for industry/commercial use. RADWIN's end-
users include cellular and fixed carriers, telecom/internet service providers and IT departments of utility companies
and enterprises.
www.radwin.com
Address goes here Address goes here Address goes here
Installation Guidelines for Professional Installers:
The following installation guidelines are required to install a device certified under FCC ID: Q3KRW2054
specifically operating under the 5.4 GHz DFS band:
1. Before installing any device, determine the exact coordinates of the location in which the device will be installed.
2. Check the distance of each device to the closest TWDR (Terminal Weather Doppler Radar) using the WISPA
sponsored database http://www.spectrumbridge.com/udia/home.aspx
3. In case that the distance of the device is within 35 Km radius form a TWDR location proceed according the
following steps:
a. Register the device in the WISPA sponsored database http://www.spectrumbridge.com/udia/home.aspx
b. Under installation process disable the frequencies that are 30 MHz above and below the TWDR center
frequency.
c. Note that for under the 5.4 GHz band the frequency range between 5.600 to 5.650 GHz is not included in
the available channels list.
