User manual
TinyCon_CLI
Var：V1.0.1
Date：2014/08/21
1 Ralinwi Nanjing electronic technology co., LTD.
CLI
Introduce
CLI is a user terminal interface for TinyCon2005, which provides users a set of the
command operation interface, convenient user testing and checking information.
How to enable CLI
Hardware connection
CLI work on TinyCon2005 UART interface, so you need to TinyCon2005 UART
interface and through the derivation of additional circuit or device connected to a
computer；If you are using a TinyWiEV - 1000 development board, then TinyWiEV -
1000 development board has UART derivation, using a mini USB cable to connect to
the computer.
Enter CLI
Enter CLI，Must make TinyWiEV - 1000 board dial switch to 1 (high level). In this
case, the TinyCon2005 is powered on or reset automatically enter CLI mode, the
terminal screen displays：
‘>’ is the CLI command prompt，You can type the command after the prompt.
TinyCon2005 after receiving the command began to perform, and returns the result.
Hello！Tinycon2000L
>
2 Ralinwi Nanjing electronic technology co., LTD.
CLI Command introduce
？
Displays help information
Grammar
？
Parameter
Void
ipconfig
According to the network connection Settings.
Grammar
ipconfig
Parameter
Void
Examples
The following example shows the ipconfig command output
>ipconfig
ip addr: 192.168.2.115
netmask: 225.225.225.0
gateway: 192.168.2.1
dns1: 192.168.2.1
hwaddr: 64e425101106
3 Ralinwi Nanjing electronic technology co., LTD.
ping
Through to the other host sends the
ICMP Echo Request
to check whether the
connection is normal.
Grammar
ping [target_name] [count]
Parameter
target_name：Specify the target name, IP address or host name.
count：Specifies the number of Echo Request message to be sent.The default is 4.
Examples
The following example shows the output of the ping command：
To ping the target address for 192.168.2.108 and sent 10 Echo Request message,
input：
reset
system reset
Grammar
>ping 192.168.2.108 10
> ping 192.168.2.108
PING 192.168.2.108(192.168.2.108): 120(148) data bytes
128 bytes from 192.168.2.108: icmp_seq=1 time=24 ms
128 bytes from 192.168.2.108: icmp_seq=2 time=32 ms
128 bytes from 192.168.2.108: icmp_seq=3 time=26 ms
128 bytes from 192.168.2.108: icmp_seq=4 time=20 ms
--- 192.168.2.108 ping statistics ---
4 packets transmitted, 4 received, 0% packet loss, time 102 ms
4 Ralinwi Nanjing electronic technology co., LTD.
reset
Parameter
Void
restore
Restore the factory default Settings, and reset the system.
Grammar
restore
Parameter
Void
info
Displays information about the drive module.
Grammar
info
Parameter
Void
Examples
The following example shows the info command output：
> info
Model: TinyCon2000L
SN: N/A
MAC addr: 64.E4.25.10.11.06
Firmware: V0.1.0
Hardware: V0.5
5 Ralinwi Nanjing electronic technology co., LTD.
iw
iw is a set of commands used to dynamic configuration module of WLAN.
iw connect
With the given Parameter to connect an AP.
Grammar
iw connect <SSID, [key], [wep_key id ]>
Parameter
SSID
Specified SSID to connect AP, if there are Spaces among SSID is needed to use
"" SSID included. For example：“ test 123”.
[key]
Set keys. if the security type for wep, Set keys type 5 or 13 ASCII characters; If
the security type for wpa_psk, wpa2_psk input 8 ~ 63 ASCII characters.
[wep_key id]
Set the wep key serial number, 0 ~ 3.
Examples
SSID to connect to the test, encryption mode to open AP, input：
SSID to connect to the test, for WEP encryption mode, the key is 12345, AP
wep_key id 0, input：
>iw connect test
>iw connect test 12345 0
6 Ralinwi Nanjing electronic technology co., LTD.
SSID to connect to the test, encryption mode to connected wpa2-psk, key for
12345678 AP, input：
iw disconnect
Disconnect with the AP.
Grammar
iw disconnect
Parameter
Void
Examples
Need to disconnect from the current AP connection, input：
iw ap
create the AP mode
Grammar
iw ap <SSID> <channel> [<WPA2 PSK>]
Parameter
SSID
Specified to create AP SSID.
channel
Specify to create AP channel.
>iw connect test 12345678
>iw disconnect
7 Ralinwi Nanjing electronic technology co., LTD.
[WPA2 PSK]
Specify to create AP key, this is optional. Don't use that encryption is open, if
used, the encryption mode is WPA2, 8 ~ 63 ASCII characters must be entered.
Examples
Need to set the ssid to test, channel 1, encryption mode for the open AP, input：
Need to set the ssid to test, channel 1, encryption mode is WPA2, the key is
12345678, input：
iw scan
Command equipment to perform scan, and return the scan results.
Grammar
iw scan
Parameter
Void
Notes：
This command will trigger device performs a scan;Command will block until the
return to the scan results.
Scan the format of the returned results
BSSID RSSI SECURITY WPS-ID SSID
Examples
>iw ap test 1
>iw connect test 1 12345678
8 Ralinwi Nanjing electronic technology co., LTD.
The following example shows the scan command output：
iw rssi
Show the current rssi.
Grammar
iw rssi
Parameter
Void
Examples
The following example shows the rssi output of commands：
iw info
Show the current configuration module of WLAN.
Grammar
iw info
Parameter
Void
Examples
> iw scan
BSSID RSSI SECURITY WPS-ID SSID
00:22:c3:81:98:3a -94 WPA/WPA2 -1 New AP
d4:ca:6d:87:28:ba -94 WPA/WPA2 -1 aibo
00:22:c3:81:96:24 -94 WPA/WPA2 -1 woxu wireless
[3 : 3]
>iw rssi
RSSI=-60
9 Ralinwi Nanjing electronic technology co., LTD.
The following example shows the info command output：
iw sc
Using simple_config to connect to the Internet
Grammar
iw sc
Examples
control module quick access networks with android APP , the result of the
example below shows that this command：
> iw info
RSSI: -60
state: running
op mode: station
security: wpa2-psk
SSID: aibo
channel: 6
> iw sc
SC Start
[1]Perform channel-round scan *ch1*ch2*ch3*ch4*ch5*ch6*ch7*ch8*ch9*ch10*ch11
Start scan to learn AP's security mode: * 3
[AP Profile]
ssid: New AP
security: WPA2
password: 1234567899
Try to connect target AP +++++++
connected to New AP
DHCP: Started
netif_set_ipaddr: netif address being changed
netif: IP address of interface st set to 192.168.2.111
netif: netmask of interface st set to 255.255.255.0
netif: GW address of interface st set to 192.168.2.1
SC End(0)
10 Ralinwi Nanjing electronic technology co., LTD.
cfg
cfg is a set of commands, used in DUT mode set and get the module parameters.
cfg s wifi ssid
Set the needs to connect a AP.
Grammar
cfg s wifi ssid <SSID>
Parameter
SSID
Specified SSID to connect AP, if there are Spaces among SSID is needed to use
"" SSID included. For example：“ test 123”.
Examples
To connect to the AP, SSID is aibo, input：
cfg s wifi key
Set the needs to connect the AP's key
Grammar
cfg s wifi key [key]
Parameter
[key]
Set keys. if the security type for wep, Set keys type 5 or 13 ASCII characters; If
> cfg s wifi ssid aibo
11 Ralinwi Nanjing electronic technology co., LTD.
the security type for wpa_psk, wpa2_psk input 8 ~ 63 ASCII characters..
Examples
Need to connect the AP's key is
aiboaibo
, input：
cfg s wifi sec
Set the needs to connect AP encryption mode.
Grammar
cfg s wifi sec <sec>
Parameter
<sec>
Set the encryption mode.
0
No encryption，open
1
For WEP encryption mode，The default wep_key id is 0
2
encryption mode is wpa/wpa2
Examples
Need to connect the AP encryption mode to open (0), input：
cfg s wifi join
> cfg s wifi key aiboaibo
> cfg s wifi sec 0
12 Ralinwi Nanjing electronic technology co., LTD.
Set the module to AP connection mode.
Grammar
cfg s wifi join <join_type>
Parameter
join_type
The connection between the module and the AP
0
Do not connect the AP.
1
Automatically connected AP.
7
Module used in AP mode.
Examples
Automatically connected AP, so join_type is set to 1, input：
cfg s wifi ch
Module used in AP mode, set up AP radio channel.
Grammar
cfg s wifi ch <channel>
Parameter
Channel
> cfg s wifi join 1
13 Ralinwi Nanjing electronic technology co., LTD.
Assigned module in AP mode selection radio channel, 2.4G of effective
channel for 1 ~ 13, the corresponding value is 0 ~ 12.
Examples
Configuration of the AP radio channel for 5, input：
cfg s uart baud
Set baud rate of the module UART interface
Grammar
cfg s uart baud <baudrate>
Parameter
baudrate
Set module UART baud rate, the default baud rate is 115200.
Examples
Set the baud rate to 9600, input：
cfg s uart data
Set data bits of the module UART interface
Grammar
cfg s uart data <databits>
Parameter
databits
> cfg s wifi ch 4
> cfg s uart baud 9600
14 Ralinwi Nanjing electronic technology co., LTD.
set module UART interface data bits
0
Data bits are 8
1
Data bits are 9
Examples
Set the data bits is 8 bit, input：
cfg s uart stop
Set stop bit of the module UART interface
Grammar
cfg s uart stop <stopbits>
Parameter
Stopbits
set module UART interface stop bit
0
stop bit are 1
1
stop bits are 2
Examples
Set the stop bit is 1，input：
> cfg s uart data 0
> cfg s uart stop 0
15 Ralinwi Nanjing electronic technology co., LTD.
cfg s uart parity
Set Parity bit of the module UART interface.
Grammar
cfg s uart parity <paritybits>
Parameter
paritybits
The parity bit of the module UART interface
0
No
1
Odd
2
Even
Examples
Set up for the no parity,input：
cfg s ip dhcp
Set the module enable or disable DHCP.
Grammar
cfg s ip dhcp <ip_dhcp>
Parameter
> cfg s uart parity 0
16 Ralinwi Nanjing electronic technology co., LTD.
ip_dhcp
the module enable or disable DHCP.
0
Disable
1
enable
Examples
Set the DHCP enable,input：
cfg s ip ipadd
Set the module IP address
Grammar
cfg s ip ipadd <ipaddr>
Parameter
ipaddr
The specified module IP address
Examples
The IP address to set up the module for 192.168.1.165, input：
cfg s ip mask
Set the module subnet mask
>
cfg s ip dhcp 1
>
cfg s ip ipadd 192.168.1.165
17 Ralinwi Nanjing electronic technology co., LTD.
Grammar
cfg s ip mask <mask>
Parameter
mask
The specified module subnet mask
Examples
Set up the module of the subnet mask as 255.255.255.0, input：
cfg s ip gw
Set the module gateway address
Grammar
cfg s ip gw <gwaddr>
Parameter
gwaddr
The specified module gateway address
Examples
set up the gateway address as 192.168.1.1, input：
cfg s ip dns
Set the module DNS address
Grammar
>
cfg s ip mask 255.255.255.0
>
cfg s ip gw 192.168.1.1
18 Ralinwi Nanjing electronic technology co., LTD.
cfg s ip dns <dnsaddr>
Parameter
dnsaddr
The specified module DNS address
Examples
Set DNS address as 192.168.1.1，input：
cfg s sbr host
Set the host IP address to connect.
Grammar
cfg s sbr host <hostip>
Parameter
hostip
Specify the host IP address.
Examples
Set the host IP address as 192.168.1.164，input：
cfg s sbr remote
set the remote port，The port to port for the target host is consistent, otherwise
unable to communicate.
Grammar
>
cfg s ip dns 192.168.1.1
>
cfg s sbr host 192.168.1.164
19 Ralinwi Nanjing electronic technology co., LTD.
cfg s sbr remote <port>
Parameter
port
Specify the remote port
Examples
set up the remote port as 8080,input：
cfg s sbr proto
Select module to establish a network connection to use protocol, TCP or UDP.
Grammar
cfg s sbr proto <protocol>
Parameter
protocol
The specified module uses the network protocol
0
UDP
1
TCP
Examples
Set up the module using the network protocol is TCP, input：
> cfg s sbr remote 8080
> cfg s sbr proto 1
20 Ralinwi Nanjing electronic technology co., LTD.
cfg s sbr mode
Set the module to establish a network connection service mode, server or client.
Grammar
cfg s sbr mode <netmode>
Parameter
netmode
Specify the module to establish network connection service mode
0
client
1
server
Examples
Set up the module using the model for client, input：
cfg g wifi ssid
Get the AP SSID stored in the module.
Grammar
cfg g wifi ssid
Parameter
Void
Examples
> cfg s sbr mode 0
21 Ralinwi Nanjing electronic technology co., LTD.
The following example shows for the result of get the ssid：
cfg g wifi key
Get wifi password stored in the module
Grammar
cfg g wifi key
Parameter
Void
Examples
The following example shows for get the key results：
cfg g wifi sec
Get Wifi network encryption mode stored in the module
Grammar
cfg g wifi sec
Parameter
Void
Examples
The following example shows the result of get the sec：
> cfg g wifi ssid
aibo
> cfg g wifi key
aiboaibo
22 Ralinwi Nanjing electronic technology co., LTD.
cfg g wifi join
Get connection module with AP.
Grammar
cfg g wifi join
Parameter
Void
Examples
The following example shows the connecting way of obtaining module and AP：
cfg g wifi ch
Get the radio channel when module in AP mode is enabled
Grammar
cfg g wifi ch
Parameter
Void
Examples
The following example shows to get the results of the channel：
> cfg g wifi join
1
> cfg g wifi ch
13
> cfg g wifi sec
2
23 Ralinwi Nanjing electronic technology co., LTD.
cfg g uart baud
Get module UART interface baud rate
Grammar
cfg g uart baud
Parameter
Void
Examples
The following example shows get the results of the baud：
cfg g uart data
Get module UART interface data bits
Grammar
cfg g uart data
Parameter
Void
Examples
The following example shows the result of get data bits：
cfg g uart stop
> cfg g uart baud
115200
> cfg g uart data
0
24 Ralinwi Nanjing electronic technology co., LTD.
Get module UART interface stop bits
Grammar
cfg g uart stop
Parameter
Void
Examples
The following example shows the result of get stop bits：
cfg g uart parity
Get module UART interface parity bits
Grammar
cfg g uart parity
Parameter
Void
Examples
The following example shows the result of get parity bits：
cfg g uart flow
Get module UART interface flow type.
> cfg g uart stop
0
> cfg g uart parity
0
25 Ralinwi Nanjing electronic technology co., LTD.
Grammar
cfg g uart flow
Parameter
Void
cfg g ip dhcp
Get module DHCP status.
Grammar
cfg g ip dhcp
Parameter
Void
Examples
The following example shows the result of get DHCP status：
cfg g ip ipadd
Get module IP address
Grammar
cfg g ip ipadd
Parameter
Void
Examples
The following example shows the result of get IP address：
> cfg g ip dhcp
1
26 Ralinwi Nanjing electronic technology co., LTD.
cfg g ip mask
Get module subnet mask
Grammar
cfg g ip mask
Parameter
Void
Examples
The following example shows the result of get module subnet mask：
cfg g ip gw
Get module gateway address
Grammar
cfg g ip gw
Parameter
Void
Examples
The following example shows the result of get module gateway address：
> cfg g ip ipadd
192.168.1.165
> cfg g ip mask
255.255.255.0
> cfg g ip gw
192.168.1.1
27 Ralinwi Nanjing electronic technology co., LTD.
cfg g ip dns
get module DNS address
Grammar
cfg g ip dns
Parameter
Void
Examples
The following example shows the result of get module DNS address：
cfg g sbr host
Get stored in the module of the target host ip address.
Grammar
cfg g sbr host
Parameter
Void
Examples
The following example shows get target host IP address：
cfg g sbr remote
> cfg g ip dns
192.168.1.1
> cfg g sbr host
192.168.1.168
28 Ralinwi Nanjing electronic technology co., LTD.
Get target remote port.
Grammar
cfg g sbr remote
Parameter
Void
Examples
The following example shows the result of get target remote port：
cfg g sbr proto
Get the protocol used for module based network connection
Grammar
cfg g sbr proto
Parameter
Void
Examples
The following example shows the result of get the protocol：
cfg g sbr mode
> cfg g sbr remote
8080
> cfg g sbr proto
1
29 Ralinwi Nanjing electronic technology co., LTD.
Get the module service mode
Grammar
cfg g sbr mode
Parameter
Void
Examples
The following example shows get the target service mode：
cfg w
Save the configuration information, the command to save configuration
information to the module of the flash, if you don't use this command, the
configuration information knowledge exist in memory, once the module restart or
electricity, configuration information will be lost.
Grammar
cfg w
Parameter
Void
> cfg g sbr mode
1
30 Ralinwi Nanjing electronic technology co., LTD.
Pin Type IO Level Function
1 PB10 I/O FT I2C2_SCL / USART3_TX/TM2_CH3
2 PB11 I/O FT I2C2_SDA / USART3_RX/TM2_CH4
3 PB1 I/O FT ADC12_IN9/TM3_CH4
4 PB0 I/O FT ADC12_IN8/TM3_CH3
5 PA8 I/O FT USART1_CK
6 PA9 I/O FT USART1_TX
7 PA10 I/O FT USART1_RX
8 PA11 I/O FT USART1_CTS
9 PA12 I/O FT USART1_RTS
10 PA13 I/O FT JTMS-SWDIO
11 PA14 I/O FT JTCK-SWCLK
12 PA6 I/O FT ADC12_IN6
13 PA5 I/O FT DAC_OUT2
14 PA4 I/O FT DAC_OUT1
15 3.3V S
16 GND
17 GND
18 3.3V S
19 NRST
I
FT
20 PA0_W I/O FT WKUP/ ADC123_IN0/TM5_CH1
21 PC0 I/O FT ADC123_IN10
22 PC1 I/O FT ADC123_IN11
23 PC2 I/O FT ADC123_IN12
24 PC3 I/O FT ADC123_IN13
25 PA2 I/O FT USART2_TX/ ADC123_IN2 /TM2_CH3
26 PA3 I/O FT USART2_RX/ ADC123_IN3/TM2_CH4
27 PC4 I/O FT ADC12_IN14
28 PB12 I/O FT SPI2_NSS / I2S2_WS /I2C2_SMBA /
USART3_CK
29 PB13 I/O FT SPI2_SCK / I2S2_CK /USART3_CTS
30 PB14 I/O FT SPI2_MISO /USART3_RTS
31 PB15 I/O FT SPI2_MOSI / I2S2_SD
32 PC5 I/O FT ADC12_IN15
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
The modular can be installed or integrated in mobile or fix devices only. This modular cannot be
installed in any portable device, for example, USB dongle like transmitters is forbidden.
This modular complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter. This modular must be installed and operated with a minimum distance of 20 cm between the
radiator and user body.
If the FCC identification number is not visible when the module is installed inside another device, then
the outside of the device into which the module is installed must also display a label referring to the
enclosed module. This exterior label can use wording such as the following: “Contains Transmitter
Module FCC ID: 2ADGHTINYCON or Contains FCC ID: 2ADGHTINYCON
”
when the module is installed inside another device, the user manual of this device must contain below
warning statements;
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired
operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
The devices must be installed and used in strict accordance with the manufacturer's instructions as described in
the user documentation that comes with the product.
