Rayson Technology BT520 BLUETOOTH SPEAKER User Manual

Rayson Technology Co., Ltd. BLUETOOTH SPEAKER

User Manual

Charge Your Speaker
Charge the speaker with the supplied
micro USB cable. The charging
indicator lights while charging and
turns off when fully charged.
When the battery power is low, the
speaker says “Battery low.”
LIT Speaker
We hope you enjoy your LIT Speaker
from RadioShack. Please read this user’s
guide before using your new speaker.
Bluetooth Function
Compatible with any Bluetooth
enabled device
Speakerphone
Built in microphone to answer
incoming calls on connected phones
USB Charging
Convenient USB charging from any
USB port
Package Contents
LIT Speaker
Three Pairs of Speaker Grilles
Micro USB Cable
User’s Guide
Cool LED Colors and Patterns
Detects and matches grille colors or
displays 18 distinct light patterns!
Pairing a Device
1.
Activate your device’s Bluetooth
function (refer to the user’s guide).
2.
Slide the speaker MAIN POWER
switch to ON. The speaker will
search for a device. If the main
power is on, press and hold the
Power button on the front of the
speaker.
3.
When LIT SPEAKER appears in your
device’s Bluetooth list, pair it to your
device.
Note: When turned on, the speaker
searches for a device. If the most
recently connected device is available,
the speaker connects automatically.
Disconnecting Devices
To disconnect your device, press and hold the
Bluetooth button until the speaker says, “Pairing.”
You can also disconnect using your device.
Playing Your Music
You can control playback
through your device or
with the speaker’s control
buttons.
Your speaker returns
to Standby mode if the
Bluetooth connection is
broken for 10 minutes.
Note: Your speaker
includes an AUX IN
jack. When the AUX IN
is connected, Bluetooth
and some of the speaker
controls are disabled;
use the device’s playback
controls instead.
Skip
Play/
Answer
Vol.
Power
Setting LED Patterns
Slide the LED CONTROL switch to GRILLE
for lights that match the installed grilles.
Slide the LED CONTROL switch to
MANUAL to enable the LED patterns.
Press the Pattern Control button
repeatedly to select one of these LED
patterns:
• Multi-color flash (random)
• Steady (red, blue, or green)
• Comet tail (red, blue, or green)
• Chasing (red, blue, or green)
• Loop (red, blue, and green)
LED CONTROL
Bluetooth
Power
Pattern Control
Battery Safety Instructions:
• Donotburnorburybatteries.Donot
punctureorcrush.Donotdisassemble.
• Donotdisposeoflithiumbatteriesinthe
trash.Recycleatyourlocalretailstore.
• Useonlychargersratedforlithiumcells.
Besurethecharger’svoltageandcurrent
settingsarecorrect.
• Iftheelectrolyteinthecellsgetsonyour
skin,thoroughlywashwithsoapandwater.If
intheeyes,rinsethoroughlywithcoolwater.
Immediatelyseekmedicalattention.
Charging Indicator
4000520_UG_EN_092713.indd 1-5 9/27/2013 11:21:30 AM
Limited Warranty
RadioShack warrants this product against defects in
materials and workmanship under normal use by the
original purchaser for ninety (90) days after the date of
purchase from a RadioShack-owned store or an authorized
RadioShack franchisee or dealer. RADIOSHACK MAKES
NO OTHER EXPRESS WARRANTIES.
This warranty does not cover: (a) damage or failure
caused by or attributable to abuse, misuse, failure to
follow instructions, improper installation or maintenance,
alteration, accident, Acts of God (such as floods or lightning),
or excess voltage or current; (b) improper or incorrectly
performed repairs by persons who are not a
RadioShack
Authorized Service Facility; (c) consumables such as fuses
or batteries; (d) ordinary wear and tear or cosmetic damage;
(e) transportation, shipping or insurance costs; (f) costs of
product removal, installation, set-up service, adjustment
or reinstallation; and (g) claims by persons other than the
original purchaser.
Should a problem occur that is covered by this warranty,
take the product and the
RadioShack
sales receipt as
proof of purchase date to any
RadioShack
store in the U.S.
RadioShack
will, at its option, unless otherwise provided
by law: (a) repair the product without charge for parts and
labor; (b) replace the product with the same or a comparable
product; or (c) refund the purchase price. All replaced parts
and products, and products on which a refund is made,
become the property of
RadioShack
. New or reconditioned
parts and products may be used in the performance of
warranty service. Repaired or replaced parts and products
are warranted for the remainder of the original warranty
period. You will be charged for repair or replacement of the
product made after the expiration of the warranty period.
RADIOSHACK EXPRESSLY DISCLAIMS ALL WARRANTIES AND
CONDITIONS NOT STATED IN THIS LIMITED WARRANTY.
ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW,
INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY
AND, IF APPLICABLE, THE IMPLIED WARRANTY OF FITNESS
FOR A PARTICULAR PURPOSE, SHALL EXPIRE ON THE
EXPIRATION OF THE STATED WARRANTY PERIOD.
EXCEPT AS DESCRIBED ABOVE, RADIOSHACK SHALL HAVE
NO LIABILITY OR RESPONSIBILITY TO THE PURCHASER OF
THE PRODUCT OR ANY OTHER PERSON OR ENTITY WITH
RESPECT TO ANY LIABILITY, LOSS OR DAMAGE CAUSED
DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE
OF THE PRODUCT OR ARISING OUT OF ANY BREACH
OF THIS WARRANTY, INCLUDING, BUT NOT LIMITED TO,
ANY DAMAGES RESULTING FROM INCONVENIENCE
AND ANY LOSS OF TIME, DATA, PROPERTY, REVENUE, OR
PROFIT AND ANY INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES, EVEN IF RADIOSHACK HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Some states do not allow limitations on how long an implied
warranty lasts or the exclusion or limitation of incidental
or consequential damages, so the above limitations or
exclusions may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights which
vary from state to state. You may contact
RadioShack
at:
RadioShack
Customer Relations
300 RadioShack Circle
Fort Worth, TX 76102 04/08
www.RadioShack.com
FCC Information
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
If you cannot eliminate the interference, the FCC requires that you stop using your equipment. Changes
or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Using Your Speakerphone
If you connect through Bluetooth and receive a call,
press the Play/Answer button to answer the call,
or press and hold the
button to reject the call.
Speak into the microphone,
and press the Play/Answer
button again to end the
call.
Press and hold the Play/
Answer button to redial the
last number dialed.
Press
the Play/Answer
button
twice to enable the
voice control function.
Speaker Notes and Caution
• ToresetthespeakerpresstheSkip Forwardbuttonfor6seconds.
• Whenturnedon,thespeakerattemptstoreconnectwiththemostrecentdevice.
Ifthatdeviceisnotavailable,thespeakerwillsearchforanotherdevice.
• CAUTION:Becarefulwhen
unpackingandhandlingyour
LitSpeaker.
» Droppingitcanbreakthe
transparenthousing.
» Pressingorpokingthe
speakerconesorpassive
radiatorcancausedamage.
Play/Answer
Skip Forward
Microphone
Mounting Grilles
The grilles attach magnetically.
When the LED CONTROL switch
is set to GRILLE, the speaker
detects the grille color and lights
in a matching pattern.
Each grille has a notch along its
edge. When mounting the grilles,
align the notch to the bottom of
the speaker.
Feel free to mix
and match colors!
Printed
in China 09A13
4000520
©2013 RadioShack Corporation. All rights
reserved. RadioShack is a registered
trademark used by RadioShack Corporation.
Power Input ................................................DC 5V, 1A
Output ....................................................4W (2W × 2)
Frequency Response ........................ 120 – 14000Hz
Drivers ........................................................40mm × 2
Bluetooth Connection Range................30 ft. (9.1m)
Bluetooth Protocol ...................V4.0 + EDR, Class 2
S/N Ratio ............................................................ 55dB
Impedance .............................................................4Ω
Battery Capacity ....................................... 1600mAh
Battery Operation Life .....11 hours (without LEDs),
..................................................... 7 hours (with LEDs)
Specifications are subject to change and
improvement without notice. Actual product may
vary from the images found in this document.
Speaker Cones (2) Passive Radiator
Specifications
4000520_UG_EN_092713.indd 6-10 9/27/2013 11:21:37 AM
