Rca Rt2350 Users Manual RT2600 EN Rev.2

RT2350 to the manual 7312bbd9-0e25-4901-9af3-bf10df7a3adc

2015-01-23

: Rca Rca-Rt2350-Users-Manual-274154 rca-rt2350-users-manual-274154 rca pdf

Open the PDF directly: View PDF .
Page Count: 31

EXPORTER

Thomson multimedia Inc.

P.O. Box 1976

Indianapolis, IN 46206 - 1976

Trademark(s) ® Registered

Marca(s) Registrada(s)

Marque(s) Deposée

55302850 Rev.1 (EN/F/E)

www.rca.com

www.rca.com/LatinAmerica

Printed in China / Impreso en China

IMPORTADOR

Comercializadora Thomson de Mexico, S.A. de C.V.

Miguel de Cervantes Saavedra 57

Col. Ampliacion Granada

C.P. 11529 Mexico D.F.

Telefono: (55)25 81 53 20

R.F.C.: CTM-980723-KS5

0151

MUTE

ON/STANDBY

BASS/TREBLE

VOLUME

LEVEL

HOME THEATER AUDIO VIDEO RECEIVER

PHONES

TUNING MEMORYFM/AM SETUP TEST TONE EQ DIGITAL INPUT

ST / MONO

SURR MODE

DSP MODE

VIDEO

V-AUX L - AUDIO - R

SOURCE

usermanual

RT2350/RT2350BK/RT2600

It is important to read this instruction book prior to using your new product for the first time.

Es importante leer este manual antes de usar por vez primera su euipo.

FCC Information

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two condi-

tions: (1) This device may not cause harmful

interference, and (2) this device must accept any

interference received, including interference that

may cause undesired operation.

In accordance with FCC requirements, changes or

modifications not expressly approved by Thomson

multimedia Inc. could void the user’s authority to

operate this product.

This device generates and uses radio frequency (RF)

energy, and if not installed and used properly, this

equipment may cause interference to radio and

television reception.

If this equipment does cause interference to radio

or television reception (which you can determine by

unplugging the unit), try to correct the interference

by one or more of the following measures:

• Re-orient the receiving antenna (that is, the

antenna for the radio or television that is

"receiving" the interference).

• Move the unit away from the equipment that is

receiving interference.

• Plug the unit into a different wall outlet so that

the unit and the equipment receiving interference

are on different branch circuits.

If these measures do not eliminate the interference,

please consult your dealer or an experienced

radio/television technician for additional

suggestions. Also, the Federal Communications

Commission has prepared a helpful booklet, "How

To Identify and Resolve Radio TV Interference

Problems." This booklet is available from the U.S.

Government Printing Office, Washington, DC 20402.

Please specify stock number 004-000-00345-4 when

ordering copies.

This product complies with DHHS Rules 21 CFR

Subchapter J. Applicable at the date of

manufacture.

Technical Specification

Product:

Dolby Digital Audio video receiver

Brand: RCA

Model: RT2350/RT2350BK/RT2600

Electrical current consumption

Power Supply: 120V ~ 60Hz

Power consumption: RT2350/RT2350BK - 165 Watts

RT2600 - 250 Watts

IMPORTER

Comercializadora Thomson de Mexico, S.A. de C.V.

Miguel de Cervantes Saavedra No. 57

Col. Ampliación Granada

C.P. 11529 Mexico D.F.

Telefono: (55)25 81 53 20

RFC: CTM-980723-KS5

For Your Safety

The AC power plug is polar-

ized (one blade is wider than

the other) and only fits into

AC power outlets one way. If

the plug won’t go into the

outlet completely, turn the

plug over and try to insert it

the other way. If it still won’t

fit, contact a qualified electri-

cian to change the outlet, or use a different one.

Do not attempt to bypass this safety feature.

CAUTION: TO PREVENT ELECTRIC SHOCK,

MATCH WIDE BLADE OF PLUG TO WIDE SLOT,

FULLY INSERT.

For Your Records

In the event that service should be required, you

may need both the model number and the serial

number. In the space below, record the date and

place of purchase, and the serial number:

Model No.

Remote Control No. CRK76-AD2

Date of Purchase

Place of Purchase

Serial No.

Service Information

This product should be serviced only by those spe-

cially trained in appropriate servicing techniques.

For instructions on how to obtain service, refer to

the warranty included in this Guide

RECORD

WARNING: TO PREVENT FIRE OR ELECTRICAL

SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT

TO RAIN OR MOISTURE.

SEE MARKING ON BOTTOM / BACK OF PRODUCT

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

THE EXCLAMATION

POINT WITHIN THE

TRIANGLE IS A

WARNING SIGN

ALERTING YOU OF

IMPORTANT

INSTRUCTIONS

ACCOMPANYING

THE PRODUCT.

THE LIGHTNING

FLASH AND ARROW-

HEAD WITHIN THE

TRIANGLE IS A

WARNING SIGN

ALERTING YOU OF

"DANGEROUS

VOLTAGE" INSIDE

THE PRODUCT.

CAUTION: TO REDUCE THE

RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER

(OR BACK). NO USER-

SERVICEABLE PARTS IN-

SIDE. REFER SERVICING

TO QUALIFIED SERVICE

PERSONNEL.

GEFAHR EINES 

ELEKTRISCHEN SCHLAGS

Table of Content

FCC Information

Getting Started

Unpacking the Receiver . . . . . . . . . . . . .2

Unpacking the Speakers . . . . . . . . . . . . .3

Inserting Batteries into Remote Control .3

Set Up and Maintenance of the

Receiver . . . . . . . . . . . . . . . . . . . . . . . . . .3

Protect your Components from

Overheating . . . . . . . . . . . . . . . . . . . . . . .3

Connecting to Audio-Visual

Components . . . . . . . . . . . . . . . . . . . . . .4

Digital Connection . . . . . . . . . . . . . . . . .5

Connecting Antennas . . . . . . . . . . . . . . .5

Connecting the Speakers . . . . . . . . . . . . .6

Connecting the Subwoofer . . . . . . . . . . .6

Positioning your Speaker . . . . . . . . . . . . .7

Front Speaker Placement . . . . . . . . . . . . .7

Surround Placement . . . . . . . . . . . . . . . .8

Advanced Surround Setting . . . . . . . . . .8

Test Tone / Channel Balance . . . . . . . . . .9

Connecting for Power . . . . . . . . . . . . . . .9

Using Headphones . . . . . . . . . . . . . . . . . .9

Factory Setting . . . . . . . . . . . . . . . . . . . . .9

Operating your Receiver

Receiver Controls . . . . . . . . . . . . . . . . . .10

Your Remote Control . . . . . . . . . . . . . . .11

Display . . . . . . . . . . . . . . . . . . . . . . . . . .12

Switching On/Off . . . . . . . . . . . . . . . . . .13

Selection of Audio/Video Source . . . . . .13

Using the Remote to Control Additional

Components . . . . . . . . . . . . . . . . . . . . . .14

Using the receiver to play a Source . . . .15

Operating the Radio . . . . . . . . . . . . . . .16

Advanced Sound Control

Sound Enhancement Systems . . . . . . . .19

Fine Setting of Components . . . . . . . . .20

Fine Setting of the Speakers . . . . . . . . .21

Advanced Setting . . . . . . . . . . . . . . . . .21

Care and Maintenance

Troubleshooting Tips . . . . . . . . . . . . . . .23

Receiver/Tuner Operation . . . . . . . . . .23

Remote Control Operation . . . . . . . . .23

General . . . . . . . . . . . . . . . . . . . . . . . .23

Cleaning the Exterior . . . . . . . . . . . . .23

Equipment Specifications . . . . . . . . . .23

Remote Codes

Cable Codes . . . . . . . . . . . . . . . . . . . . . .24

VCR Codes . . . . . . . . . . . . . . . . . . . . . . .24

TV Codes . . . . . . . . . . . . . . . . . . . . . . . .25

Satellite Receivers . . . . . . . . . . . . . . . . .26

Audio (RCA only) . . . . . . . . . . . . . . . . . .26

Laser disc Players . . . . . . . . . . . . . . . . . .26

Limited Warranty . . . . . . . . . . . . .27

Getting Started

Unpacking the Receiver

You should receive the following items:

MUTE BASS/TREBLE

VOLUME

LEVEL

HOME THEATER AUDIO VIDEO RECEIVER

PHONES

TUNING MEMORYFM/AM SETUP TEST TONE EQ DIGITAL INPUT

ST / MONO

SURR MODE

DSP MODE

SOURCE

VIDEO

V-AUX L - AUDIO - R

SOURCE

ON/STANDBY

+ -

One receiver unit

One pair of “AA”

batteries

One external FM Dipole

antenna

One external AM loop

antenna

one audio cable (two wires) with red

and white RCA connectors;

one video cable (single wire) with

yellow RCA connectors;

• one instruction book;

• one safety leaflet;

• one Quick Connection Guide

One RCA Universal

Remote Control

Getting Started

Unpacking The Speakers

• one set of speakers including 2 front speakers, 1

centre speaker, 1 subwoofer and 2 rear speakers.

• 6 speaker wires including:

Inserting Batteries into Remote Control

Insert two AA(R6) batteries according to the + and -

signs on the battery compartment. To use the remote

control, point it directly at your receiver. Whenever a

button is pressed, a red indicator will light up on the

remote control.

Install batteries as follows:

1. Remove battery compartment door by applying

thumb pressure on battery door and then lift the

door out and off the cabinet.

2. Insert 2 AA batteries in the compartment and

replace the compartment door.

Set up and Maintenance of the Receiver

• Provide spaces for sufficient ventilation as

indicated:

• Do not connect to the AC power cords until all

connections are completed.

• Do not use your set immediately after transferring

it from a cold place to a warm place: there is risk of

condensation.

• Do not expose your set to water and excessively

high temperatures.

• After having disconnected your set, clean the case

with a soft cloth, or with a slightly damp leather

chamois. Never use strong solvents.

Protect your Components from

Overheating

• Do not block ventilation holes in any component.

Arrange the components so that air can circulate

freely.

• Do not stack components directly on top of each

other.

• Allow adequate ventilation when placing your

components in a stand.

• Place an amplifier near the top shelf of the stand

so heated air rising from it will not affect other com-

ponents. If you have a satellite receiver, you should

place it on the top shelf.

1 X white/black wire for

front left speaker

1 X purple/black wire

for subwoofer

1 X green/black wire

for center speaker

1 X red/black wire for

front right speaker

1 X blue/black wire for

rear left speaker

1 X gray/black wire for

rear right speaker

10 cm/4"

5 cm/

10 cm/4"

10 cm/

MUTE

ON/STANDBY

BASS/TREBLE

VOLUME

LEVEL

HOME THEATER AUDIO VIDEO RECEIVER

PHONES

TUNING MEMORYFM/AM SETUP TEST TONE EQ DIGITAL INPUT

ST / MONO

SURR MODE

DSP MODE

SOURCE

VIDEO

V-AUX L - AUDIO - R

SOURCE

Getting Started

Connecting to Audio-Visual Components

OPTICAL 1

VCR

CD Player

Tape Deck

SAT

to LINE OUT

(Tape Deck)

to LINE IN ( Tape Deck )

to AUDIO OUT (CD)

to VIDEO OUT (SAT)

to AUDIO OUT (SAT)

to S-VIDEO OUT (SAT)

to S-VIDEO OUT (DVD)

to AUDIO OUT(DVD)

to VIDEO OUT (DVD)

to AUDIO OUT (TV)

to VIDEO IN (TV)

to S-VIDEO IN (TV)

to AUDIO OUT (VCR)

to VIDEO OUT (VCR)

to VIDEO IN (VCR)

to AUDIO IN (VCR)

DIGITAL CONNECTION

If you have a SAT receiver DVD player or CD player with a digital output, you can make

use of an optical digital cable (not supplied) or coaxial digital cable (not supplied) to

carry the audio portion of the signal and enjoy Dolby Digital sound quality. One optical

or coaxial cable is needed for each SAT receiver, DVD player or CD player. When

optical or coaxial cable is used, the analog audio cables are still needed if recording

through a tape or VCR is desired. This receiver provides one optical and one coaxial

digital input for the connection of your components. Please connect your components

(e.g. DVD, SAT or CD) to the appropriate digital inputs and press DIGITAL INPUT to

select the corresponding digital input source.

Note: Optical and coax cables carry only the audio portion of the signal. A video

connection must also be established for a SAT receiver and DVD player. S-video

provides the best connection for the video portion of the signal. Composite video (yellow

RCA connector) can also be used. It is

important that the same type of cable (S-video or composite) that is connected from the

Home Theater to the TV is used to connect the SAT receiver or DVD player to the Home

Theater.

FRONT TERMINAL

Remark: If you have a video camera,

video game machine, or an extra

VCR, connect it to VAUX input at the

front of the receiver

DIGITAL INPUT

Connect components

capable of outputing Dolby

Digital (e.g. DVD or SAT) or

standard PCM (CD) format

digital signals. Read section

on "Input Signal Setting"

under "Advanced Sound

Control" carefully to adjust

the matching input settings.

If your CD player is equipped with digital optical jacks, use of optical cable is preferred.

What you need is just one more optical digital connecting cable (not supplied). Plug it in

the digital input jack of the receiver and select OPTICAL on the receiver setting (see

details on pg 20 chapter "Input Signal Setting"). You can enjoy better sound quality

brought to you by the optical cable. When optical cable is used, analog cables are still

needed for recording to tape output.

S-VIDEO

If your video component has a S-Video jack

included, you can make use of it to enjoy

enhanced video quality by connecting it to the

relevant S-Video jack at the rear side of the

receiver. One S-video cable is needed for each

component. When S-Video cable is used,

composite video (yellow RCA connector) cable

must also be connected for VCR recording.

Note: Before plugging in the optical cable or 

S-Video cable, make sure to match the shape of

the plug and jack, otherwise, you will not be able to

plug in completely.

DVD

6 CH. EXTERNAL INPUT

SUBWOOFER

PRE OUT

OPTICAL 2

SUB

CEN

RT2600 ONLY

Getting Started

Digital Connections

Read instructions carefully when connecting compo-

nents to the receiver.

Digital In Jacks can accept Dolby Digital (AC-3), DTS

(RT2600 only) or PCM signals when compatible

components are connected.

Connecting the Antennas

The AM and FM antennas connect to the AM and FM

terminals on the system’s back panel.

They must be hooked up in order to receive clear

reception.

AM Loop Antenna and FM Indoor Antenna

1. Uncoil the Antenna wire and locate the base end

of the AM antenna and snap into place as shown

below in AM Loop Antenna.

2. Press down on the Antenna tab to open the termi-

nal

AM Loop Antenna

OPTICAL 1

6 CH. EXTERNAL INPUT

SUBWOOFER

PRE OUT

SUB

CEN

RT2600 ONLY

OPTICAL 2

OPTICAL 1

OPTICAL 2

SAT / DVD / CD Player / TV

COAXIAL DIGITAL IN (AUDIO)

Connect to coaxial digital output of

DVD, CD, SAT or other compatible

devices.

OPTICAL DIGITAL IN (AUDIO)

Optical Fiber Cable

Connect to optical digital output of

DVD, CD, SAT or other compatible

devices.

DVD / CD / SAT

RT2600 ONLY

HINT

• For FM reception, extend antenna to its full

length and arrange the Antenna as a T Shape

• For AM reception, rotate the antenna hori-

zontally to get better reception.

ANTENNA

LOOP

75Ω

OPTICAL 1

OPTICAL 2

6 CH. EXTERNAL INPUT

SUBWOOFER

PRE OUT

SUB

CEN

RT2600 ONLY

Getting Started

Connecting the Speakers

Speakers

There are 6 speakers equipped with the unit (2 front,

1 center, 2 rear, 1 subwoofer). In order to enjoy good

surround effects, all six speakers need to be

connected to the receiver.

At least two front speakers (left and right) are

required. For better sound quality, Center speaker,

rear speakers and Subwoofer should also be

connected. Adding center and rear speakers will

enhance surround effects. Adding a Subwoofer will

increase bass response.

If you want to enjoy full range of sound effects, with

small speakers, it is a must to use the subwoofer with

the speakers to maintain adequate bass signal.

Speaker wires

1 for each speaker, is

needed for connection. Twist the stripped ends of

speaker cord about 2/3 inch (15 mm). Press down on

the tab to open the terminal and insert the wire.

Release tab to lock wire in the

terminal.

To ease speaker connections, the speaker wires and

the terminals are color-coded.

• White/Black (Front Left Speaker),

• Red/Black (Front Right Speaker),

• Green/Black (Center Speaker)

• Blue/Black (Rear Left Speaker).

• Grey/Black (Rear Right Speaker).

• Purple/Black (Subwoofer)

Connect the L, R speakers at the back of the speakers

to the corresponding color on the receiver. Do the

same for center (with green/black terminal), rear

speaker and the subwoofer (with purple/black termi-

nal).

Speaker Polarity

When connecting the speakers, make sure the polari-

ties (“+” speaker wire to “+” on the receiver) of

speaker wires and terminals are matched. If the wires

are reversed, the sound will be distorted and will lack

bass (“out of phase” effect).

Connecting the Subwoofer

Connect the subwoofer with the speaker wire (pur-

ple/ black) provided.

This receiver offers a high flexibility for user to use a

large variety of speakers and subwoofers. For more

information please refer to section “Fine Setting of

the Speakers” in “Advanced Sound Control” on page

21.

SUB WOOFER

SPEAKER

LEFT

RIGHT

SUB WOOFER

FRONT

Use this jack on

the left back panel

to connect another

active subwoofer

other than the one

supplied.

REAR

CENTER

REAR SPEAKERS 

(SURROUND SOUND)

FRONT SPEAKERS

CENTER 

SPEAKERS

GREEN / BLACK

PURPLE / BLACK

RED / BLACK

WHITE / BLACK

GREY / BLACK

BLUE / BLACK

Release tab to lock wire in

the terminal.

NOTE: Make sure the insulation is completely removed from the

ends of the Antenna and speaker wires at all connection

points.

Antenna and Speaker Wire Connection

Push terminal tab down to

insert wire.

Getting Started

Positioning your speaker

1 Left, Right (Front Speakers)

They carry primarily music and sound effects

2 Center

In surround mode, the center speaker carries much of

the dialogue as well as music and effects. It should be

set between the left and right speakers.

3 Surround (Rear Speakers)

Their overall sound balance should be as close as pos-

sible to the front speakers. Proper placement is vital

to establish an evenly distributed sound field.

Subwoofer

A subwoofer is designed to reproduce powerful low

bass effects (explosions, the rumble of spaceships,

etc.) which dramatically heightens involvement with

the action on the screen. It is therefore recommend-

ed to connect subwoofers when small speakers are

used.

Magnetic shielding

Speakers placed less than two feet from the TV set

must be magnetically shielded in order to prevent

picture distortion. Front and center speakers provid-

ed with RT2350/RT2350BK/RT2600 are magnetically

shielded to protect your TV set.

It is not recommended to place the rear speakers

near the TV set.

Front Speaker Placement

Even if you can't duplicate this ideal home theater

setup exactly, the suggestions for speaker placement

that follow will help you get good results.

Alignment

Align the center speaker evenly with (A), or slightly

behind (B), the left and right speakers, but not ahead

of them.

Advanced Setting

Angle

Placing the left and right speakers to form a 45-

degree angle with your favorite viewing position will

duplicate the soundtrack mixer's perspective.

Height

The three speakers should be as close as possible to

the same height. This often requires placing the cen-

ter speaker directly atop (A) or beneath (B) the TV

set.

Courtesy Dolby Laboratories

Getting Started

Preferred surround placement

Location

If possible, place surround speakers to either side of

the listening area, not behind it.

Height

If space permits, install surrounds 2-3 feet above

viewers. This helps to minimize localization effects.

Aiming

Aiming surrounds straight across the room, not down

at viewers, helps create a more open, spacious sur-

round sound field.

Advanced Setting

Alternative Surround Placement

Rear wall

If rear wall mounting is the only choice, aim the

speakers at each other (A), towards the front (B) or

even towards the sidewalls (C, D). Experiment with

placement until surround sounds seem to envelop

you, rather than coming from behind you.

No adjacent walls

Surrounds can go on stands facing each other to

approximate the preferred sidewall mounting (A), or

to the sides or rear of the viewing area aimed

upwards. In the latter case, they can go right on the

floor, or preferably, a few feet off the floor such as

on end tables (B).

Courtesy Dolby Laboratories

Getting Started

Test Tone / Channel balance

Channel balance

Your receiver is equipped with a test signal generator

for balancing the channels. As the signal "travels"

from channel to channel, adjust the level controls

until each channel plays at the same loudness level.

Level adjustment & surround channel level

expectation

Even though you adjust the surround channel to be

as loud as the others on the test signal, you'll find

that on actual program material the surround chan-

nel is usually much lower than the front. Don't be

tempted to readjust the surround level; program pro-

ducers use surround mostly for subtle atmospherics

and ambience, and only rarely for special effects. A

good surround mix doesn't call attention to itself; if

it did, it would soon become distracting.

Connecting for Power

Make sure you connect all your

other electronic components and

the speakers before plugging

your receiver into the outlet.

Plug the power cord in the wall

outlet, matching the wide blade

of the plug with the wide slot in

the outlet. Be sure to insert the

plug completely.

Using Headphones

To listen privately through your

audio system, use the PHONES jack

on the receiver. However, make

sure you turn down the volume

before you put on the head-

phones. Increase the volume to the

desired level after headphones are

in place.

Once headphones are connected, “HEADPHONE

DOWN MIX 2 CHANNEL” will scroll on display. This

feature automatically converts multi-channel speaker

outputs to 2 channel stereo for your listening pleas-

ure.

Hearing Comfort & Well-Being

• Do not play your headset at a high volume.

Hearing experts advise against continuous extended

play.

• If you experience a ringing in your ears, reduce

volume or discontinue use.

Factory Setting

The unit is preset to the following settings when you

first power the receiver up right out of the box:

Function = Tuner

Volume setting = 45

Bass & treble = 0 dB

Speaker settings: Center, rear, front = small

Subwoofer = on

EQ: FLAT

NOTE

The system is equipped with Dolby Digital,

and manufactured under License from Dolby

Laboratories.

Dolby Digital

Manufactured under

license from Dolby

Laboratories. “Dolby”,

“Pro Logic” and the double-D symbol are trade-

NOTE

Reset to Factory Settings:

All preset radio stations and surround sound setting

will be lost after factory setting is restored. You may

restore factory setting with the following procedures:

1. Enter Standby mode

2. Press SURR. MODE key when holding SOURCE UP.

3. All preset stations will reset to FM87.5MHz and all

receiver settings restore to default settings as

described above.

Courtesy Dolby Laboratories

Manufactured under License from

Digital Theater Systems, Inc. US Pat.

No. 5,451,942 and other world wide

patents issued and pending. “DTS

Digital Surround”, are trademarks of Digital

MUTE BASS/TREBLE

VOLUME

LEVEL

HOME THEATER AUDIO VIDEO RECEIVER

PHONES

TUNING MEMORYFM/AM SETUP TEST TONE EQ DIGITAL INPUT

ST / MONO

SURR MODE

DSP MODE

SOURCE

VIDEO

V-AUX L - AUDIO - R

SOURCE

ON/STANDBY

Operating Your Receiver

Receiver Controls

1. STANDBY/ON

To turn the unit on/ off. When the system is turned on, the unit

will go to the mode it was in before powered off.

2. MUTE

To mute speakers and headphone out.

3. PHONES

Plug your headphones (not supplied) into it for your private

enjoyment. Speakers will be off when phones are inserted.

4. Source Buttons

To select sound source. For example, CD, SAT, Tuner etc.

5. Display

To display current status of the receiver.

6. Sound Control

Let you adjust the sound – volume, treble, bass & level.

• To change the VOLUME, turn the large knob.

• To adjust TREBLE or BASS, press relevant button and turn the

knob.

• Bass/Treble can only be activated under stereo mode.

Bass/Treble effects are only active when there is no custom

EQ effect. When pressing BASS/TREBLE, the unit will auto-

matically go to EQ OFF mode.

• To change the volume of individual speaker, press LEVEL but-

ton repeatedly to select the speaker, then turn the knob to

adjust the level.

7. DSP (Digital Sound Processor)

Press this button to select the DSP mode

(STADIUM/THEATER/CONCERT/CLUB/CHURCH/ARENA/DSP OFF)

you want.

8. SETUP FUNCTION

• To adjust the speaker size, speaker distance, speaker phase,

night mode, sleep and display dimmer.

• In SLEEP mode, you can set the receiver to turn off from 5 to

120 minutes.

9. TUNING

Press for about 2 seconds to search for next station.

Press once to review all preset stations in preset mode.

In normal mode, press to increase/decrease tuner frequencies.

10. SURR. MODE

Press repeatedly to select the surround mode you want. ( refer

to “Advanced Sound Control” on page 20)

11. MEMORY

Press to toggle between manual tuning mode and preset sta-

tion mode, Press and hold to manually store tuner station in

preset mode.

12. FM/AM

Press to choose between FM/AM in TUNER mode.

Press and hold to automatically search and save preset stations

(FM only).

FM/AM button can only switch tuner bands and can not select

Tuner source.

13. TEST tone

When pressing it briefly, a short noise (test tone) will be gener-

ated in the speakers one by one so that you can adjust the vol-

ume of individual speaker. (See page 9 for details)

14. EQ

Press repeatedly to select the desirable EQ mode (music style) –

FLAT, ROCK, POP, JAZZ, CLASSIC, VOCAL. Your choice will be

saved automatically.(Only available in Stereo mode)

15. DIGITAL INPUT/ ST / MONO

Press repeatedly to select the input device (analog / optical /

optical 2 (RT2600 only) / coaxial). In FM mode, press to toggle

between stereo and mono.

16. V-AUX Input

For convenient use of your digital camera, family game

machines, second VCR, etc.

2 3 4 7

13 14

15 16

Operating Your Receiver

Your Remote Control

Please be sure you have inserted the batteries into the

remote control (see relevant section on page 3.) You can

test it by pressing any button. If it works, the red LED

will light.

1. ON/OFF

To turn on or off the receiver and other auxiliary compo-

nents (see page 14 “Using the Remote to Control

Additional Components”).

2. Source Buttons

To turn on and select various audio/ video sources.

3. CH+, CH- (Channel Buttons)

To select programmed stations (in TUNER mode).

4. VOL (Volume Buttons)

To adjust the volume.

5. MUTE

To mute all audio outputs.

6. Adjustment Buttons

a. Press AUDIO button to activate the control, then

DSP/EQ/SETUP key.

b. Press the left and right buttons, , the display will toggle

among: SLEEP, Night mode, DIMMER, EQ and DSP.

c. When the display shows the setup you want to change,

press the up and down arrow buttons beside OK button to

make changes, then press OK to finalize your choice.

7. Number Buttons

To access directly a pre-set station (in TUNER mode) or to

peripheral devices .

8. MENU (Tuner Mode only)

• Press AM/FM

• To store Preset Stations. (For details, refer to "Storing and

Recalling Stations in Memory" on page 17.)

9. Operation Buttons

In TUNER mode, press AM/FM on the remote.

• Press REVERSE and FORWARD keys to tune down or up

the radio frequency.

• PLAY, RECORD, STOP and PAUSE keys are only for easy

control of external devices that are connected to your

receiver such as CD, VCR, DVD, TAPE, etc.. The remote con-

trol currently operates most Thomson, RCA and GE prod-

ucts, but it can be programmed to operate devices from

other manufacturers (For details, refer to “Using the

Remote to Control Additional Components” on page 14.

10. DIGITAL

Select the way your audio/video components are connected

to the receiver (Analog, Optical, Optical 2 (RT2600 only) or

Coaxial).

In TUNER mode, press to toggle between Stereo and Mono

sound.

11. LEVEL

Press to adjust the volume of each speaker. Press repeatedly

and the display will toggle among different channels (Left

front speaker, Right front speaker, Center speaker, Left rear

speaker, Right rear speaker, and Subwoofer). Press the VOL-

UME up and down arrow buttons for adjustment..

12. SURR (Surround Sound Control)

Press to change the surround sound settings. The display

will toggle among DOLBY DIGITAL, DOLBY PROLOGIC,

DOLBY PL2 MOVIE (RT2600 only), DOLBY PL2 MUSIC

(RT2600 only) , DTS (RT2600 only), STEREO.

13. LED indicator

Lights up whenever a key on the remote control is pressed.

NOTE

The remote buttons GO BACK•DISC,

GUIDE•RDM•PTY, INFO•RDS, INPUT•SEEK &

AUDIO do not work in tuner mode.

* 6 channels mode is available on RT2600 only.

Operating Your Receiver

SRS

• Audio output is in dts mode (RT2600 only)

• Audio output is in Dolby Digital mode.

• Audio output is in Dolby Pro Logic mode.

• Audio output is in Dolby Pro Logic II mode.

(RT2600 only)

• Tuner stereo signal detected.

• Tuner station detected.

• Speaker Icons.

• Unit in Sleep mode.

• Unit in Memory or Preset mode.

• Tuner frequency unit.

• EQ effect activated.

TUNED

SLEEP

MEMORY

KHz

MHz

Display

LS RS

LFE

Operating Your Receiver

Switching on/off

• To switch on the receiver, press ON/STANDBY

button once, or any source button on the remote

control.

• Standby: when the receiver is on, press the

ON/STANDBY button once to activate the standby

mode.

• To switch off the unit completely, unplug the

power cord from the socket

Selection of Audio/Video source

When one of the source buttons is pressed, the audio

and video input corresponding to the name will be

activated.

The receiver acts as a switching device between all

the sources that are plugged into it.

Example 1:

If you connect a DVD player to the DVD input

(audio + video) on the receiver and press the DVD

button, or press source button repeatedly until

DVD is selected, you will be able to have the sound

and image transmitted by the DVD.

Example 2:

Based on the example 1, the DVD is playing , if a

VCR is connected to the VCR 1 input (audio +

video) of the receiver, press the VCR button , or

press source button repeatedly until VCR is select-

ed, image and sound from the VCR source will

replace the DVD.

MUTE

ON/STANDBY

FM/AM

SOURCE

TUNI

FM/AM

SOURCE

FM/AM

SOURCE

Operating your Receiver

You can connect up to 7 audio/video sources to this

amplifier:

Source button Corresponding connector

(receiver front panel) (receiver back panel)

- DVD DVD IN (audio / video)

- SAT SAT IN (audio / video)

- VCR VCR IN/OUT (audio / video)

- V-AUX V-AUX IN (audio / video)

- CD CD IN (audio only)

- TV TV IN (audio only)

- TAPE TAPE IN/OUT (audio only)

- FM/AM built-in

When a source is selected, the source name will be

shown on the display.

Example: Press DVD to select DVD as the source to

the amplifier.

Using the Remote to Control Additional

Components

You can set your remote to control other components

(like CD, TV, DVD, TAPE, etc.). What you need is to

encode them in advance (not necessary for recent

RCA & Proscan models).

1. Turn on the component to be programmed.

2. Look up the brand and corresponding code num-

ber in the code list from page 24 to 26.

3. Press and hold the corresponding Source Button

(like VCR, TV, DVD) on the remote while entering

the code from the code list using the Number

Buttons.

4. Release the compo-

nent button, then press

ON•OFF to see if the

component will turn off.

5. If this does not work,

repeat steps 3 and 4 by trying to use the next code (if

available) listed for the brand of your component

until the component responds to the remote com-

mand.

NOTE

1. Your receiver has a built in tuner. Just con-

nect the appropriate antenna on the back of

the receiver and you will be able to listen to

radio stations. (See details in Tuner section)

2. Other sources can be connected to the

above standard source. Example: you can con-

nect a LD into the DVD inputs.

3. Refer to the "Connecting To Audio-Visual

Components" section for details on connec-

tion.

Operating your Receiver

Using the receiver to play a source

After having properly connected a source (DVD, CD,

VCR) to the receiver, you can partly control them

through the receiver.

Playing a DVD with the receiver

1. Connect a DVD player to the receiver (see connect-

ing your receiver for details)

2. Press ON/STANDBY to switch on the receiver

3. Select the DVD source.

4. Switch ON the DVD player and start playback

5. Switch ON your TV

6. Select the appropriate A/V channel on the TV

(refer to your TV manual for details) until the image

from the DVD player is displayed

7. Set the sound Mode if needed (see "Advanced

sound control" for details)

Example 1:

To play 5.1 Dolby Digital surround sound

Press SURR. MODE button until "Dolby Digital"

appears on the Display and all of the speaker'’ icons

light up.

Example 2:

DVD: You may also need to select the Dolby Digital

5.1 on the DVD disc menu to have the digital sur-

round enabled providing that the disc is encoded

with Dolby Digital 5.1 (please refer to the DVD

player and DVD disc instruction)

Example 3:

LD: You may need to select a different Audio

Channel on your LD (refer to your LD player manu-

al)

8. Adjust volume knob accordingly

NOTE

Once your remote is encoded, you can press

ON/OFF on the remote once to turn off the

component and then followed by the second

time quickly to turn off the receiver (i.e. this

unit). If you only want the receiver to be

turned off, select FM/ AM while the unit is ON

before pressing ON/OFF.

HINT

This remote may not operate all models of

the brands shown.

If batteries are removed from the battery

compartment of the remote control, all mem-

ory will be lost. You need to re-enter all

previously programmed codes again.

The buttons on the remote may not work

correspondingly with those on other brand

components. Experiment with the remote and

your components to see which buttons work.

If only a few functions operate, check to see if

another code set will work with more but-

tons.

NOTE

To play Dolby Digital or DTS sound, the source

must be connected to the receiver via the opti-

cal or coaxial terminal

Operating your Receiver

Operating the Radio

The receiver has a built-in tuner that allows for

AM/FM radio function.

Manual tuning

1. Connect the FM and AM antenna accordingly (see

"Connecting the Antenna" on page 5 section for

details)

2. Press ON/STANDBY to switch on the receiver.

3. Press SOURCE keys to enter TUNER mode.

4- To select band, press the FM/AM button to toggle

between AM/FM mode.

5- Tune the stations by pressing TUNING UP or

DOWN repeatedly until the desired station is found.

Alternatively, you can press and hold TUNING UP or

DOWN for about one second to activate the

automatic SEARCH function. In this mode the receiver

will automatically tune frequencies until it finds a

station

Select sound effect if needed by pressing Preset EQ or

DSP sound (see "Advance sound section" for details).

Selecting Mono or Stereo Sound

Press ST/MONO on the main unit or the DIGITAL

button on the remote control to toggle between

mono and stereo sound in FM tuner mode (when

available).

TUNING ME

SOURCE

FM/AM

NOTE

1. If there is interference, modify the location

of the antenna until the optimal sound is heard.

TV and other electronic devices could be the

cause of interferences so try to position the

antenna away from them.

2. Weak signal can affect the "auto Search

function". Adjust the antenna for better recep-

tion for more efficient search.

MUTE

ON/STANDBY

MEMORY

FM/AM TUNING

TUNI

FM/AM

SOURCE

ETUP TEST TONE EQ DIGITAL INPUT

ST / MONO

SURR MODE

DSP MODE

Operating your Receiver

Storing radio stations:

The receiver can store up to 40 radio stations in

memory. You can enter every single radio station

yourself or the receiver can store all available radio

station automatically in an ascending order.

Automatic preset storing : (FM only)

1. Select the band by pressing FM/AM

2- Press and hold

FM/AM on the main

unit for 3 seconds.

“MEMORY” will be dis-

played in red and will

blink during the auto-

matic storing process.

Radio frequencies will be scanned and radio station

stored automatically. When all available radio sta-

tions are stored or if all 40 memory locations are full,

the auto preset will stop.

Manual preset

1. Select FM or AM band by pressing FM/AM

repeatedly.

2. Tune to the radio station to be stored. (see

"Manual tuning" on page 16 above for details)

3. Press and hold the MEMORY button on the front

panel or MENU on the remote control. "MEMORY"

will flash and a preset number will be displayed on

the display.

4. Press TUNING

UP/DOWN, while

MEMORY is still flashing

to select the desired pre-

set memory location.

5. Press the MEMORY button on the front panel or

the remote control to store frequency in selected pre-

set location.

6. Repeat steps 1-5 to store other frequencies.

TUNING MEM

SOURCE

FM/AM

NOTE

Weak signal can affect the "Automatic Preset

Storing function" efficiency. Adjust the antenna

for the best reception for more efficient search.

MEMORY

FM/AM TUNING

TUNING MEM

SOURCE

FM/AM

TUNING ME

SOURCE

FM/AM

TUNING MEMORY

Operating your Receiver

Retrieving preset stations

1. Press FM/AM to select tuner mode

2. Press MEMORY/MENU button to enter preset set-

ting mode (MEMORY icon shows on display), Press

TUNING UP/DOWN to select preset station.

6 Channel external input (RT2600 only)

An external decoder (Dts, Dolby Digital, etc…) or a

device with built-in multi-channel decoder and 6

channel output connector (DVD player, TV…) can be

connected to the 6CH input. It is therefore possible

to play any future 6 Channels coding (SACD, DVD

Audio) thanks to this connection. The external

decoder device will send the separated audio infor-

mation to the receiver that will then amplify the sig-

nal and send to appropriate speakers.

To activate 6 Channel external input, press the source

key on the receiver until 6 CH is selected or press

DVD/6 CH twice on the remote control.

TUNING ME

SOURCE

FM/AM

M TUNING MEMORY

OPTICAL 1

OPTICAL 2

SUB

CEN

RT2600 ONLY

6 CH. EXTERNAL INPUT

SUBWOOFER

PRE OUT

FM/AM

SOURCE

NOTE

During 6-Channel direct input mode, TAPE OUT

and REC OUT of VCR mode will not be available.

NOTE

To enable all 6 CHANNELS in 6CH external Input

mode,make sure that when the receiver is in

DVD source, Dolby Prologic or Dolby digital/DTS

is always selected first before switching to

DVD/6 CH mode (otherwise only 2

channels/speakers will be enable in 6 CH mode).

Advanced Sound Control

Sound Enhancement Systems

This receiver is equipped with several built-in sound

enhancement systems.

Dolby Pro Logic II (RT2600 only)

The Pro Logic II mode uses the built-in circuit to steer the

Left, Center, Right and Surround left and right channel

audio signals and uses all five speakers to play both stereo

and Dolby Pro Logic program source, such as TV and VCR.

Dolby Pro Logic II includes Dolby Pro Logic II Movie, Dolby

Pro Logic II Music and Dolby Pro Logic.

Use this mode to suit the type of program (such as VCR).

Dolby Digital

The Dolby Digital mode lets you enjoy full digital

surround from software processed in the Dolby Digital

format. Dolby Digital provides better sound quality and

more powerful presence than conventional Dolby

Surround.

This unit is equipped with Dolby Digital 5.1-channel so

that you can enjoy enhanced full digital surround sound.

Being different from Dolby Pro Logic in which only four

channels ( Front Left, Front Right, Centre and Rear ) are

used, the new system provides stereo separation of the rear

speakers (Rear-Right, Rear-Left ). These 5 channels,

together with the subwoofer channel for bass sounds

(counted as 0.1 channel ), constitute as 5.1-Channel ( or 6

Channels ) Input for Dolby Digital that brings you the most

sophisticated sound enjoyment.

Digital Theater Systems (DTS) (RT2600 only)

DTS is a digital surround system which delivers six channels

of master-quality, 20-bit audio. It offers five full-range

channels plus a special low frequency effect (LFE) channel

for subwoofer, resulting commonly know 5.1 channels. It

can be applied with existing 5.1 speaker configurations.

DTS is available in DVD, SAT/CAB, TV and CD mode. (When

digital cable is connected)

Front Left Speaker Front Right Speaker

Subwoofer

Center Speaker

Rear Right Speaker

Rear Left Speaker

Listening

Zone

[

Front Left Speaker Front Right Speaker

Subwoofer

Center Speaker

Rear Right Speaker

Rear Left Speaker

Listening

Zone

Advanced Sound Control

Stereo

The Stereo mode uses the two main channel outputs

from the front speakers. Use this mode if you have

connected the front speakers only.

DSP (Digital Sound Processor)

These digital sound effects resemble sounds in a real

environment such as (STADIUM / THEATER / CONCERT /

CLUB / CHURCH / ARENA). DSP automatically converts

analog audio signals to digital ones which enables

you to adjust the sound without degrading the sound

quality. Different modes will give you different feel of

size and type of listening environment. (Not available

in Dolby Digital/DTS)

Night Mode

By using Dynamic Range Compression technology (pressing

OK), you can enjoy enhanced Dolby Digital sound quality at

night without interrupting your roommates or neighbors.

Night Mode will compress the difference in volume

between normal voices and sound like explosions, while still

enjoying a Dolby Digital enable component (DVD, SAT).

Night Mode can be activated by pressing the OK

button repeatedly until NORMAL appears on the display.

While Normal is still on the display, press the LEFT or RIGHT

Adjustment buttons on the remote control,around the OK

button, on the remote control until you select the desired

mode. There are three modes (NORMAL, SOFT, SOFTER) for

you to choose the extents of compression.

Fine Setting of the Components

The receiver has pre-selected surround mode once

you turn on the unit by pressing the Source Buttons

(like DVD, SAT, CD) directly. The default surround

modes for different components are listed in the

table below.

If you decide to change the surround mode, you can

press the SURR MODE repeatedly to toggle among

the different surround mode choices and select the

one you want.

DOLBY PL2 MOVIE (RT2600 only)/

DOLBY PL2 MUSIC (RT2600 only)/

DTS (RT2600 only)/ Stereo

DOLBY PROLOGIC/

DOLBY DIGITAL

The receiver will keep the last selection in memory.

Input Signal Setting

The receiver defaults to the most convenient settings

for your easiest use (see table).

If your connection is different from the default set-

ting,

1. Select the source

2. Press DIGITAL INPUT button to toggle among opti-

cal/ coaxial/ analog to match your connection. Your

selection will be stored automatically.

The selected source and input source will be displayed

on the display as long as they are active, except for

some temporary change of display (e.g. adjusting vol-

ume).

Digital Input

Select this setting to play digital signals from a DVD,

CD, LD player, SAT or TV.

Analog Input

Select this setting to play analog signals from a cas-

sette deck, VCR or turntable.

Source/ If Digital Input (optical If Analog Input

Input or coaxial) is selected is selected

DVD Dolby Digital/DTS(RT2600 only) PRO LOGIC

SAT Dolby Digital/DTS(RT2600 only) PRO LOGIC

VCR N/A PRO LOGIC

V-AUX N/A PRO LOGIC

TV Dolby Digital/DTS(RT2600 only) STEREO

CD STEREO STEREO

TAPE N/A STEREO

TUNER N/A STEREO

DEFAULT INPUT (as seen on display)

Analog (SAT/ ANL)

Analog (DVD/ ANL)

Analog (CD/ ANL)

Analog (VCR/ ANL)

Analog (V-AUX/ ANL)

Built-in Tuner

Analog (TAPE/ ANL)

Analog (TV / ANL)

SOURCE

SAT

DVD

VCR

V-AUX

FM/AM

TAPE

NOTE

Digital input is only available for DVD, SAT, CD

and TV

AVAILABLE INPUT

Analog / Optical / Optical2 (RT2600 only) / Coaxial

Analog / - / -

Analog / Optical / Optical2 (RT2600 only) / -

SOURCE

SAT

DVD

VCR

V-AUX

TAPE

NOTE

If linear PCM source (CD), format wil be Dolby

Prologic even with Digital Input.

Advanced Sound Control

Fine Setting of the Speakers

This receiver supports a wide range of speakers and

subwoofers. For optimal surround sound enjoyment,

you need to register the speaker selection settings of

your audio system. If you buy this receiver with

accompanied speaker package, then this step has

been done for you.

Also, to make the surround sound more effective and

suit the acoustic conditions in your listening room,

you need to delay the signal from some of the speak-

ers. Such channel delay compensates for center or

surround speakers that are closer to listening position

than the front speakers. You can make use of the

SETUP button to adjust the speakers’ relative loud-

ness.

The TEST TONE button

You can adjust the relative loudness of the individual

speakers by the TEST TONE button.

1. In Surround (Dolby Digital/Pro Logic/DTS) modes,

press TEST TONE briefly. A short noise will be heard

in the speakers one by one. The speaker having the

noise at that moment will be shown in the display.

2. To adjust the volume level of the test tone, turn

up/down the VOLUME knob or press VOL UP/DOWN

key on the remote control.

3. To adjust individual speaker volume level, press the

LEVEL key on the main unit when the short noise is

played on the speaker you want to adjust then turn

the VOLUME knob to modify the output level.

4. Press LEVEL again to save your setting.

5. Repeat step 3 to adjust other speaker volume lev-

els.

Advanced Setting

Factory defaulted Advance setting indication

from VFD

The receiver has defaulted the following distances:

Front speakers

(L/R) 15 ft

Center speaker

(Cch) 15 ft

Rear speaker

(SUR) 10 ft

Speaker Configurations

You can also change the setup of the speakers by

pressing the SETUP button until the display shows

L/R SML or L/R LRG which enables you to set the size

of the front speaker.

Available Selections:

Pressing SETUP button once, while the display is still

showing L/R LRG, you may press the OK button to

toggle among: front, center, surround, subwoofer,

subwoofer phase and speakers’ distance, sleep and

dimmer setup. Set the speaker size or speakers’ dis-

tance by pressing UP/DOWN ARROW button.

R/S

L/S

Rch

Cch

Lch

Front

Left

Rear

Right

Rear

Left

Front

Right

Center

Front Speaker selection Large/ Small

Center Speaker selection Large/ Small/ None

Surround Speaker selection Large/ Small/ None

Subwoofer selection Yes/ No

Subwoofer Phase + / -

Front Speaker distance 3-40 ft

Centre Speaker distance 0-40 ft

Rear Speaker distance 0-40 ft

EQ DIGITAL INPUT

ST / MONO

OK SETUP TEST TONE

MODE

BASS/TREBLE

VOLUME

LEVEL

NOTE

To adjust the level of all speakers (center and

surround speakers), you must select Pro Logic

mode first by pressing the SURROUND key

BASS/TREBLE LEVEL

VIDEO

V-AUX L - AUDIO - R

Advance Sound Control

Use a subwoofer to enjoy optimum sound.

• Subwoofer Phase: Try both settings and select the

sound preferred.

• Speaker distance: For optimum surround experi-

ence measure the distance between the speaker and

your favorite listening position.

1. Press SETUP once.

2. While the VFD display is showing L/R SML, press

UP/DOWN ARROW button to select.

3. Press OK button once to move to the next

speaker setting.

4. Repeat step 3 to set up the next speaker

5. When set up is done,

wait for 5 seconds to

automatically save your

settings or press any key

to save your selection

and set up mode.

Speaker Icons

The receiver shows you the speakers’ types and set-

tings on the display with the following icons:

Displaying Program Formats

When a digital source is playing, the receiver will

automatically switch to the proper surround mode

and indicates on the speaker icons on the right-hand

side of the display. (See diagram)

It is important to note, however, that not all Dolby

Digital sources are encoded with the full complement

of five channels plus LFE*. Speaker icons show how

many and which speaker you have enabled (See “Fine

Setting of the Speakers”) and the letters inside the

speaker icons show which channel is present in the

source information. For example, the diagram shown

means you have all the five speakers and subwoofer

enabled and the digital sources you played have five

channels plus LFE complemented.

* LFE stands for Low Frequency Effect. The indication

“LFE” appears if the digital source contains LFE infor-

mation. In this case, the bass signal will be delivered

to the subwoofer, offering more dynamic deep bass

sound effects. If the letter is flashing, the signal is

either too weak or just gone.

LS RS

LFE

Large front speakers

Small front speakers

Large center speaker

Small center speaker

Large rear speakers

Small rear speakers

Subwoofer present

EQ DIGITAL I

ST / MO

OK SETUP TEST TONE

SETUP TEST TONEMEMORY OK

LS RS

LFE

TUNI

FM/AM

SOURCE

NOTE

• The sub-woofer selection will always be YES

when the main speakers are set to small

(SML).

• For the subwoofer phase setting, it will be

affected by how you locate the subwoofer.

Try both + and - settings and select the one

that has better bass effect.

• If your unit comes with speakers, always set

all speakers size to “small” to protect them

and optimize the sound quality.

• When left and right front speakers are set

to SMALL, center and surround speakers can

not be set to LARGE.

Care and Maintenance

Troubleshooting Tips

Receiver/Tuner Operation

ST indicator is off.

• Adjust the antenna.

• Press DIGITAL INPUT/ST/MONO button to insure you

are not outputting in mono.

The signal is Mono. Severe hum or noise.

• The signal is too weak. Connect an external antenna.

• Adjust Antenna

• Reposition Antenna away from any electronics.

Remote Control Operation

The remote control does not operate the unit.

• Another source mode is selected on the remote. Press

the correct Source Button.

• No batteries installed. (included with your system)

Install the batteries before attempting to operate the

remote. Be sure to match the + and - ends of each bat-

tery to the symbols shown in the remote battery com-

partment.

• The batteries are weak. Replace all batteries.

• The remote is not pointed at the remote control sen-

sor on the main unit or there is an obstacle between the

remote and the main unit.

• The remote control is too far from the main unit,

move closer.

Remote loses Programmed codes.

• Weak batteries, replace batteries.

Remote forgets what source was selected.

• Weak batteries, replace batteries.

General

No audio.

• Make sure the speakers are connected.

• Check the input connections.

• Check the power cord connections.

• Make sure the MUTE signal on the front panel is off.

• Make sure the digital setting (optical, coaxial or ana-

log) is correct.

• Check that the headphone is not inserted.

No audio from one channel.

• Check the speaker level setting.

• Check the speaker wire or external source cable con-

nections.

Noise occurs when the TV is turned on.

• The TV is too close to the audio system.

Specific instruments sound displaced.

• Check the connections between the receiver and the

speakers if the sound does not match the video.

• Check if the video and audio cable are correctly inserted.

TAPE OUT and REC OUT do not operate in VCR mode.

• Check to make sure the unit is not in 6-channel direct

input mode.

Cleaning the Exterior

• Disconnect the system from AC power before cleaning

the exterior of the system with a soft dust cloth, or

with a slightly damp leather chamois. Never use strong

solvents.

Equipment Specifications:

AMPLIFIER SECTION:

RT2600

All 5 channels: each 100W at 8 ohm. <0.9% THD

@40Hz to 20KHz

Subwoofer channel: 150w at 8Ω, <0.9% THD @100 Hz

Muting Attenuation: 65dB

Frequency Response: 40Hz to 20kHz +/-3dB

Signal to Noise Ratio: 65dB (Dolby digital mode mode)

RT2350/RT2350BK

All 5 channels: each 50W at 8 ohm. <10% THD @1 kHz

Subwoofer channel: 50w at 8Ω, <10% THD @100 kHz

Muting Attenuation: 65dB

Frequency Response: 40Hz to 20kHz +/-3dB

Signal to Noise Ratio: 65dB (Dolby digital mode mode)

VIDEO SECTION:

Input ( Sensitivity/ Impedance ):1Vp-p/ 75ohm

Output (Level/ Impedance): 1Vp-p/ 75 ohm

Frequency Response: 10Hz to 6MHz at +/- 3dB

Signal to noise ratio: 40dB

Crosstalk @3.58MHz: 40dB

AM TUNER SECTION:

Frequency Response: 80Hz – 2kHz +/-6dB

Usable Sensitivity: 800uV/m @ S/N 20dB

Signal to Noise: 38dB

Image Ratio: 27dB @ 1000kHz

IF Rejection: 35dB

FM TUNER SECTION:

Frequency Response: 40Hz – 15kHz +/-3dB

Quieting: 24dBu

Signal to Noise: 60dB(stereo) / 65dB(mono)

Image Ratio: 40dB

IF Rejection: 50dB

Dimensions (H x W x D inch) :

Unit - 5.1 x 17 x 16.5

Speaker - 6.9 x 4.6 x 4.5

Subwoofer - RT2350/RT2350BK:14 x 6.3 x 14

RT2600: 14 x 7.8 x 14.2

Remote Codes

CABLE CODES

ABC 5002, 5003, 5004, 5005, 5006, 5009, 5053

ANTRONIX 5008, 5009

ARCHER 5008, 5009, 5010, 5011

CABLETENNA 5008

CABLEVIEW 5008

CENTURY 5011

CITIZEN 5011

COLOUR VOICE 5012, 5013

COMTRONICS 5014, 5015

CONTEC 5016

EASTERN 5017

GARRARD 5011

GC ELECTRONICS 5009

GEMINI 5018, 5019, 5049

GENERAL INSTRUMENT 5003

HAMLIN 5020, 5021, 5022, 5035, 5045

HITACHI 5003

HYTEX 5002

JASCO 5011

JERROLD 5003, 5005, 5007, 5018, 5023,

5024, 5046, 5053

MAGNAVOX 5025

MEMOREX 5026

MOVIE TIME 5002, 5027, 5028

NSC 5002, 5027, 5028

OAK 5002, 5016, 5029

PANASONIC 5048, 5052

PARAGON 5026

PHILIPS 5011, 5012, 5013, 5019, 5025,

5030, 5031, 5032

PIONEER 5033, 5034

PULSAR 5026

RCA 5047, 5049, 5052

REALISTIC 5009, 5049

REGAL 5022, 5035

REGENCY 5017

REMBRANDT 5003

RUNCO 5026

SAMSUNG 5014, 5034

SCIENTIFIC ATLANTA 5006, 5036, 5037, 5038

SIGNAL 5014, 5018

SIGNATURE 5003

SL MARX 5014

SPRUCER 5052

STARCOM 5007, 5018, 5053

STARGATE 5014, 5018

STARQUEST 5018

TANDY 5040

TELEVIEW 5014

TOCOM 5004, 5023, 5041

TOSHIBA 5026

TUSA 5018

TV86 5027

UNIKA 5008, 5009, 5011

UNITED ARTISTS 5002

UNITED CABLE 5053

UNIVERSAL 5008, 5009, 5010, 5011

VIDEOWAY 5044

VIEWSTAR 5015, 5025, 5027, 5040

ZENITH 5026, 5050, 5051

VCR CODES

ADMIRAL 2131

ADVENTURA 2026

AIKO 2027

AIWA 2002, 2026

AKAI 2003, 2004, 2005, 2007, 2008, 2111, 2112,

2113

AMERICAN HIGH 2021

ASHA 2013

AUDIO DYNAMICS 2009, 2010

AUDIOVOX 2014

BELL & HOWELL 2011

BEAUMARK 2013

BROKSONIC 2012, 2025

CALIX 2014

CANDLE 2013, 2014, 2015, 2016, 2017,

2018, 2019

CANON 2021, 2022, 2114

CAPEHART 2020, 2110

CARVER 2062

CCE 2027, 2061

CITIZEN 2013, 2014, 2015, 2016, 2017,

2018, 2019, 2027

COLORTYME 2009

COLT 2061

CRAIG 2013, 2014, 2023, 2061

CURTIS-MATHES 2000, 2002, 2009, 2013, 2016,

2018, 2021, 2022, 2024, 2115

CYBERNEX 2013

DAEWOO 2015, 2017, 2019, 2025, 2026,

2027, 2028, 2110

DAYTRON 2110

DBX 2009, 2010

DIMENSIA 2000

DYNATECH 2002, 2026

ELECTROHOME 2014, 2029

ELECTROPHONIC 2014

EMERSON 2002, 2012, 2014, 2015, 2021, 2024, 2025,

2026,

2029, 2030, 2032, 2033, 2034, 2035, 2036,

2037,

2038, 2039, 2040, 2041, 2042, 2044, 2045,

2047,

2065, 2105, 2113, 2116, 2117, 2130

FISHER 2011, 2023, 2048, 2049, 2050, 2051, 2052,

2118

FUJI 2021, 2119

FUNAI 2002, 2026

GARRARD 2026

GE 2000, 2001, 2013, 2021, 2022, 2053, 2115,

2120

GOLDSTAR 2009, 2014, 2018, 2054, 2121

GRADIENTE 2026

HARLEY DAVIDSON 2026

HARMAN KARDON 2009

HARWOOD 2061

HEADQUARTER 2011

HITACHI 2002, 2055, 2056, 2057, 2107,

2111, 2120, 2122

HI-Q 2023

INSTANT REPLAY 2021

JCI 2021

JC PENNEY 2009, 2010, 2011, 2013, 2014,

2021, 2022, 2055, 2056, 2058,

2059, 2060, 2107, 2118

JENSEN 2055, 2056, 2111

JVC 2009, 2010, 2011, 2018, 2058,

2111, 2123

KENWOOD 2009, 2010, 2011, 2016, 2018,

2058, 2111, 2123

KLH 2061

KODAK 2014, 2021

LLOYD 2002, 2026

LOGIK 2061

LXI 2014

MAGNAVOX 2021, 2022, 2062, 2063, 2104,

2108, 2124

MAGNIN 2013

MARANTZ 2009, 2010, 2011, 2016, 2018,

2021, 2058, 2062, 2064

MARTA 2014

MASUSHITA 2021

MEI 2021

Remote Codes

MEMOREX 2002, 2011, 2013, 2014, 2021, 2023, 2026,

2104, 2131

MGA 2029, 2065, 2113

MGN TECHNOLOGY 2013

MIDLAND 2053

MINOLTA 2055, 2056, 2107

MITSUBISHI 2029, 2055, 2056, 2065, 2066, 2067, 2069,

2070, 2071, 2072, 2073, 2074, 2106, 2113,

2123

MONTGOMERY WARD 2075, 2131

MOTOROLA 2021, 2131

MTC 2002, 2013, 2026

MULTITECH 2002, 2013, 2016, 2026, 2053, 2061

NEC 2009, 2010, 2011, 2016, 2018, 2058, 2064,

2076, 2078, 2079, 2111, 2123

NIKKO 2014

NOBLEX 2013

OLYMPUS 2021

OPTIMUS 2014, 2131

OPTONICA 2096

ORION 2035

PANASONIC 2021, 2022, 2109, 2125, 2126, 2127

PENTAX 2016, 2055, 2056, 2107, 2120

PENTEX RESEARCH 2018

PHILCO 2021, 2022, 2062, 2063

PHILIPS 2021, 2062, 2096, 2124

PILOT 2014

PIONEER 2010, 2055, 2080, 2081, 2123

PORTLAND 2016, 2017, 2019, 2110

PROSCAN 2000, 2001

PROTEC 2061

PULSAR 2104

QUARTER 2011

QUARTZ 2011

QUASAR 2021, 2022, 2125

RCA 2000, 2001, 2003, 2013, 2021, 2055, 2056,

2082, 2083, 2084, 2085, 2086, 2087, 2088,

2089, 2090, 2091, 2107, 2115, 2120, 2125

RADIOSHACK/REALISTIC 2002, 2011, 2013, 2014, 2021, 2022, 2023,

2026, 2029, 2049, 2050, 2096, 2131

RADIX 2014

RANDEX 2014

RICOH 2128

RUNCO 2104

SAMSUNG 2005, 2013, 2015, 2033, 2053, 2112

SANKY 2104, 2131

SANSUI 2010, 2092, 2111, 2123

SANYO 2011, 2013, 2023

SCOTT 2012, 2015, 2025, 2032, 2035, 2038, 2065,

2093, 2116

SEARS 2011, 2014, 2021, 2023, 2048, 2049, 2050,

2051, 2055, 2056, 2107, 2118

SHARP 2002, 2017, 2029, 2094, 2095, 2096, 2131

SHINTOM 2004, 2056, 2061, 2098

SHOGUN 2013

SIGNATURE 2002, 2131

SINGER 2021, 2061, 2128

SONY 2002, 2004, 2098, 2099, 2119, 2128

STS 2021, 2107

SYLVANIA 2002, 2021, 2022, 2026, 2062, 2063, 2065,

2124

SYMPHONIC 2002, 2026

TANDY 2002, 2011

TASHIKO 2014

TATUNG 2058, 2111

TEAC 2002, 2026, 2058, 2085, 2111

TECHNICS 2021, 2109

TEKNIKA 2002, 2014, 2021, 2026, 2100, 2129

TMK 2013, 2024, 2047

TOSHIBA 2015, 2049, 2051, 2055, 2065, 2093, 2116

TOTEVSION 2013, 2014

UNITECH 2013

VECTOR RESEARCH 2009, 2010, 2015, 2016

VICTOR 2010

VIDEO CONCEPTS 2009, 2010, 2015, 2016, 2113

VIDEOSONIC 2013

WARDS 2002, 2013, 2014, 2015, 2021, 2023, 2026,

2029, 2055, 2056, 2061, 2096, 2101, 2102,

2103, 2107, 2116, 2131

XR-1000 2021, 2026, 2061

YAMAHA 2009, 2010, 2011, 2018, 2058, 2111

ZENITH 2004, 2098, 2104, 2119, 2128

TV CODES

ABEX 1172

ADMIRAL 1001, 1173

ADVENTURA 1174

AIKO 1016

AKAI 1002

ALLERON 1046

AMTRON 1038

ANAM NATIONAL 1003, 1038

AOC 1004, 1005, 1006, 1007, 1175, 1176

AUDIOVOX 1038

BELCOR 1004

BELL & HOWELL 1001, 1083, 1162

BRADFORD 1038

BROKWOOD 1004

CANDLE 1004, 1006, 1008, 1174

CAPEHART 1175

CELEBRITY 1002

CENTURION 1009

CITIZEN 1004, 1006, 1008, 1016, 1038, 1105, 1171,

1174, 1177

CLAIRTONE 1176

COLORTYME 1004, 1006

CONCERTO 1004, 1006

CONTEC/CONY 1012, 1013, 1014, 1038, 1176

CRAIG 1038

CROWN 1038, 1171

CURTIS MATHES 1000, 1004, 1006, 1015, 1105, 1162, 1171

CXC 1038

DAEWOO 1004, 1005,1006, 1016, 1017, 1018, 1127,

1171

DAYTRON 1004, 1006, 1171

DIMENSIA 1000

DUMONT 1004, 1151

DYNATECH 1178

ELECTROBAND 1002, 1176

ELECTROHOME 1003, 1004, 1006, 1019, 1022

EMERSON 1004, 1006, 1012, 1014, 1023, 1024,

1025, 1026, 1027, 1028, 1029, 1030,

1031, 1032, 1033, 1034, 1035, 1036, 1037,

1038, 1039, 1041, 1042, 1043, 1044, 1046,

1047, 1123, 1124, 1162, 1171, 1176, 1177,

1179, 1191

ENVISION 1004, 1006

FISHER 1048, 1049, 1050, 1051, 1162, 1180

FUJITSO 1046

FUNAI 1038, 1046

FUTURETEC 1038

GE 1000, 1003, 1004, 1006, 1022, 1052, 1054,

1055, 1087, 1164, 1165, 1166, 1167, 1168,

1181

GIBRALTER 1004, 1151

GOLDSTAR 1004, 1005, 1006, 1012, 1019, 1056, 1057,

1058, 1155, 1156, 1171, 1172

GRUNDY 1038, 1046, 1171

HALLMARK 1004, 1006

HARVARD 1038

HITACHI 1004, 1006, 1012, 1013, 1059, 1060, 1061,

1135, 1136, 1137, 1138, 1139, 1140, 1141,

1142, 1143, 1144, 1145, 1146, 1148, 1150,

1179

IMA 1038

INFINITY 1062

JANEIL 1174

JBL 1062

JCB 1002

JC PENNY 1000, 1004, 1005, 1006, 1008, 1022, 1052,

1054, 1058, 1063, 1064, 1072, 1087, 1105,

1128, 1171, 1172, 1181

JENSEN 1004, 1006

JVC 1012, 1013, 1054, 1060, 1065, 1066, 1067,

1089, 1157, 1158, 1159, 1182

Remote Codes

KAWASHO 1002, 1004, 1006

KAYPANI 1175

KENWOOD 1004, 1006, 1019

KLOSS NOVABEAM 1068, 1069, 1174, 1183

KTV 1038, 1070, 1171, 1176, 1177

LOEWE 1062

LOGIK 1083

LUXMAN 1004, 1006

LXI 1000, 1006, 1049, 1062, 1071, 1072, 1073,

1162, 1181

MAGNAVOX 1004, 1006, 1008, 1019, 1062, 1068, 1069,

1074, 1075, 1076, 1077, 1088, 1089, 1130,

1131, 1132, 1133, 1134, 1183, 1184

MAJESTIC 1083

MARANTS 1062

MARANTZ 1004, 1006, 1062, 1078

MEGATRON 1006, 1059

MEI 1176

MEMOREX 1001, 1006, 1082, 1083, 1162

MGA 1004, 1005, 1006, 1019, 1022, 1051, 1079,

1080, 1082

MIDLAND 1054, 1151, 1171, 1172, 1181

MINUTZ 1052

MITSUBISHI 1004, 1005, 1006, 1019, 1022, 1051, 1079,

1080, 1081, 1082, 1082, 1083, 1125

MONTGOMERY WARD 1083

MOTOROLA 1003, 1173

MTC 1004, 1005, 1006, 1105, 1176, 1178

MULTITECH 1038, 1178

MULTIVISION 1084

NAD 1006, 1071, 1072, 1185

NEC 1003, 1004, 1005, 1006, 1089

NIKKO 1006, 1016

NTC 1016

ONWA 1038

OPTIMUS 1185

OPTONICA 1095, 1173

ORION 1035, 1191

PANASONIC 1003, 1054, 1062, 1170

PHILCO 1003, 1004, 1005, 1006, 1008, 1012, 1019,

1062, 1068, 1069, 1074, 1075, 1077, 1183,

1184

PHILIPS 1003, 1004, 1008, 1012, 1019, 1062, 1068,

1069, 1074, 1075, 1076, 1086, 1087, 1088,

1089

PILOT 1004, 1171

PIONEER 1004, 1006, 1090, 1091, 1092, 1179, 1185

PORTLAND 1004, 1005, 1006, 1016, 1171

PRICE CLUB 1105

PRISM 1054

PROSCAN 1000, 1181

PROTON 1004, 1006, 1012, 1093, 1175

PULSAR 1151

PULSER 1004

QUASAR 1003, 1054, 1070, 1094

RADIO SHACK/REALISTIC 1000, 1004, 1006, 1012, 1038, 1049, 1095,

1162, 1171, 1172

RCA 1000, 1003, 1004, 1005, 1006, 1007, 1019,

1096, 1098, 1099, 1100, 1101, 1102, 1103,

1129, 1179, 1181, 1187, 1188, 1190

RHAPSODY 1176

RUNCO 1151

SAMPO 1004, 1006, 1171, 1172, 1175

SAMSUNG 1004, 1005, 1006, 1012, 1015, 1019, 1104,

1105, 1106, 1171, 1172

SAMSUX 1171

SANSUI 1191

SANYO 1004, 1048, 1049, 1050, 1080, 1107, 1108,

1162, 1169, 1180, 1189

SCOTCH 1006

SCOTT 1004, 1006, 1012, 1024, 1035, 1038, 1046

SEARS 1000, 1004, 1006, 1013, 1019, 1046, 1048,

1049, 1050, 1051, 1066, 1071, 1072, 1109,

1110, 1162, 1180, 1181, 1189

SHARP 1004, 1006, 1012, 1029, 1095, 1111, 1112,

1113, 1122, 1171, 1173

SHOGUN 1004

SIGNATURE 1001, 1083, 1115

SIMPSON 1008

SONIC 1176

SONY 1002

SOUNDESIGN 1004, 1006, 1008, 1038, 1046

SQUAREVIEW 1189

SSS 1004, 1038

STARLITE 1038

SUPRE-MACY 1174

SUPREME 1002

SYLVANIA 1004, 1006, 1008, 1019, 1062, 1068, 1069,

1074, 1075, 1076, 1077, 1088, 1116, 1161,

1183, 1184

SYMPHONIC 1033, 1038, 1189

TANDY 1173

TATUNG 1003, 1178

TECHNICS 1054

TECHWOOD 1004, 1006, 1054

TEKNIKA 1004, 1005, 1006, 1008, 1012, 1013, 1016,

1038, 1046, 1076, 1082, 1083, 1105, 1170,

1171

TELECAPTION 1117

TMK 1004, 1006

TOSHIBA 1049, 1071, 1072, 1089, 1105, 1109, 1117,

1118, 1160, 1162

TOTEVISION 1171

UNIVERSAL 1052, 1087

VICTOR 1066, 1182

VIDTECH 1004, 1005, 1006

VIKING 1174

WARDS 1000, 1001, 1004, 1005, 1006, 1019, 1024,

1033, 1046, 1052, 1062, 1069, 1074, 1075,

1076, 1083, 1087, 1088, 1095, 1119, 1120,

1184

YAMAHA 1004, 1005, 1006, 1019

ZENITH 1004, 1083, 1151, 1152, 1153, 1154

Satellite Receivers

CHAPPARAL 5056, 5057

DRAKE 5058, 5059

GE SATELLITE RECEIVER 5000, 5001

GENERAL INSTRUMENTS 5060, 5061, 5062

PANASONIC SATELLITE RECEIVER

5075

PRIMESTAR DBS 5076

PROSCAN SATELLITE RECEIVER

5000, 5001

RCA SATELLITE RECEIVER 5000, 5001

REALISTIC 5063

SONY SATELLITE RECEIVER 5072

STS1 5064

STS2 5065

STS3 5066

STS4 5067

TOSHIBA 5068

TOSHIBA SATELLITE RECEIVER 5073

UNIDEN SATELLITE RECEIVER 5069

Audio (RCA/Dimensia only)

AM/FM 4003

AUX 4004

PHONO 4005

CD 4007

TAPE 4006

Laser disc Players

PROSCAN 2001

RCA 2001

Limited Warrranty (U.S.)

What your warranty covers:

• Defects in materials or workmanship.

For how long after your purchase:

• One year from date of purchase for labor and parts

• The warranty period for rental units begins with the first

rental or 45 days from date of shipment to the rental firm,

whichever comes first.

What we will do:

• Pay any Authorized RCA Audio Service Center the labor

charges to repair your unit.

• Pay any Authorized RCA Audio Service Center for the

new or, at our option, refurbished replacement parts

required to repair your unit.

How you get service:

• Take your unit to any Authorized RCA Audio Service

Center. To identify your nearest Authorized RCA Audio

Service Center, ask your dealer, look in the Yellow Pages, or

call 1-800-336-1900.

• Show the Authorized Service Center Representative your

evidence of purchase date or first rental.

• Pick up your unit when repairs are completed.

• Proof of purchase in the form of a bill of sale or receipt-

ed invoice which is evidence that the product is within the

warranty period must be presented to obtain warranty

service. For rental firms, proof of first rental is also

required.

What your warranty does not cover:

• Customer instruction. (Your Owner’s Manual describes

how to install, adjust, and operate your unit. Any addition-

al information should be obtained from your dealer.)

• Installation and related adjustments.

• Signal reception problems not caused by your unit.

• Damage from misuse or neglect.

• Cleaning of audio heads.

• Batteries.

• A unit that has been modified or incorporated into other

products or is used for institutional or other commercial

purposes.

• A unit purchased or serviced outside the U.S.A.

• Acts of nature, such as but not limited to lightning dam-

age.

Product Registration:

• Please complete and mail the Product Registration Card

packed with your product. It will make it easier to contact

you should it ever be necessary. The return of the card is

not required for warranty coverage.

Limitation of Warranty:

• THE WARRANTY STATED ABOVE IS THE ONLY WAR-

RANTY APPLICABLE TO THIS PRODUCT. ALL OTHER

WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL

IMPLIED WARRANTIES OF MERCHANTABILITY OR FIT-

NESS FOR A PARTICULAR PURPOSE) ARE HEREBY DIS-

CLAIMED. NO VERBAL OR WRITTEN INFORMATION

GIVEN BY THOMSON MULTIMEDIA INC., ITS AGENTS

OR EMPLOYEES SHALL CREATE A GUARANTY OR IN

ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.

• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS

WARRANTY IS THE EXCLUSIVE REMEDY OF THE CON-

SUMER. THOMSON MULTIMEDIA INC. SHALL NOT BE

LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAM-

AGES RESULTING FROM THE USE OF THIS PRODUCT OR

ARISING OUT OF ANY BREACH OF ANY EXPRESS OR

IMPLIED WARRANTY ON THIS PRODUCT. THIS DIS-

CLAIMER OF WARRANTIES AND LIMITED WARRANTY

ARE GOVERNED BY THE LAWS OF THE STATE OF INDI-

ANA. EXCEPT TO THE EXTENT PROHIBITED BY APPLIC-

ABLE LAW, ANY IMPLIED WARRANTY OF MER-

CHANTABILITY OR FITNESS FOR A PARTICULAR PUR-

POSE ON THIS PRODUCT IS LIMITED TO THE APPLICA-

BLE WARRANTY PERIOD SET FORTH ABOVE.

How State Law relates to warranty:

• Some states do not allow the exclusion nor limitation of

incidental or consequential damages, or limitations on how

long an implied warranty lasts, so the above limitations or

exclusions may not apply to you.

• This warranty gives you specific legal rights, and you also

may have other rights that vary from state to state.

If you purchased your unit outside the United

States:

• This warranty does not apply. Contact your dealer for

warranty information.

Service calls which do not involve defective materials

or workmanship are not covered by this warranty.

Costs of such service calls are the sole responsibility

of the purchaser.

Limited Warranty (Canada)

What your warranty covers:

• Defects in materials or workmanship.

For how long after your purchase:

• One year from date of purchase for labor and parts

• The warranty period for rental units begins with the first

rental or 45 days from date of shipment to the rental firm,

whichever comes first.

What we will do:

• Pay any Authorized RCA Audio Service Center the labor

charges to repair your unit.

• Pay any Authorized RCA Audio Service Center for the

new or, at our option, refurbished replacement parts

required to repair your unit.

How you get service:

• Take your unit to any Authorized RCA Audio Service

Center. To identify your nearest Authorized RCA Audio

Service Center, ask your dealer, look in the Yellow Pages, or

call 1-800-336-1900.

• Show the Authorized Service Center Representative your

evidence of purchase date or first rental.

• Pick up your unit when repairs are completed.

• Proof of purchase in the form of a bill of sale or receipt-

ed invoice which is evidence that the product is within the

warranty period must be presented to obtain warranty

service. For rental firms, proof of first rental is also

required.

What your warranty does not cover:

• Customer instruction. (Your Owner’s Manual describes

how to install, adjust, and operate your unit. Any addi-

tional information should be obtained from your dealer.)

• Installation and related adjustments.

• Signal reception problems not caused by your unit.

• Damage from misuse or neglect.

• Cleaning of audio heads.

• Batteries.

• A unit that has been modified or incorporated into other

products or is used for institutional or other commercial

purposes.

• A unit purchased or serviced outside Canada.

• Acts of nature, such as but not limited to lightning dam-

age.

Product Registration:

• Please complete and mail the Product Registration Card

packed with your product. It will make it easier to contact

you should it ever be necessary. The return of the card is

not required for warranty coverage.

Limitation of Warranty:

• THE WARRANTY STATED ABOVE IS THE ONLY WAR-

RANTY APPLICABLE TO THIS PRODUCT. NO VERBAL OR

WRITTEN INFORMATION GIVEN BY THOMSON MULTI-

MEDIA LTD., ITS AGENTS OR EMPLOYEES SHALL CRE-

ATE A GUARANTY OR IN ANY WAY INCREASE THE

SCOPE OF THIS WARRANTY.

• REPAIR OR REPLACEMENT AS PROVIDED UNDER

THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE

CONSUMER. THOMSON MULTIMEDIA LTD. SHALL NOT

BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAM-

AGES RESULTING FROM THE USE OF THIS PRODUCT.

EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE

PROVINCIAL LAW, ANY IMPLIED WARRANTY OF MER-

CHANTABILITY OR FITNESS FOR A PARTICULAR PUR-

POSE ON THIS PRODUCT IS LIMITED TO THE APPLICA-

BLE WARRANTY PERIOD SET FORTH ABOVE.

How Provincial Laws relates to warranty:

• This warranty gives you specific legal rights which are in

addition to statutory warranties that may vary from

Province to Province.

If you purchased your unit outside Canada:

• This warranty does not apply. Contact your dealer for

warranty information.

Service calls which do not involve defective materi-

als or workmanship are not covered by this warran-

ty. Costs of such service calls are the sole responsi-

bility of the purchaser.

Rca Rt2350 Users Manual RT2600 EN Rev.2

RT2350 to the manual 7312bbd9-0e25-4901-9af3-bf10df7a3adc

Navigation menu

Versions of this User Manual:

Views

Navigation
