Rca Truflat 27F500Tdv Users Manual

27F500TDV to the manual 5d668007-4f28-412b-9e88-a0e453ece1dd

2015-01-23

: Rca Rca-Truflat-27F500Tdv-Users-Manual-274293 rca-truflat-27f500tdv-users-manual-274293 rca pdf

Open the PDF directly: View PDF .
Page Count: 64

TV/VCR/DVD

User's Guide

Changing Entertainment. Again.

This symbol indicates

"dangerous voltage"

inside the product that

presents a risk of electric

shock or personal injury.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE THIS PRODUCT

TO RAIN OR MOISTURE.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates

important

instructions

accompanying the

product.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Caution: To prevent electric shock, match wide

blade of plug to wide slot, fully insert.

Attention: Pour éviter les chocs électriques,

introduire la lame la plus large de la fiche dans

la borne correspondante de la prise et pousser

jusqú au fond.

Refer to the identification/rating label located on the back panel of

your product for its proper operating voltage.

FCC Regulations state that unauthorized changes or modifications to

this equipment may void the user’s authority to operate it.

This Class B digital apparatus complies with Canadian ICES-003.

Caution: Using video games or any external accessory with

fixed images for extended periods of time can cause them to be

permanently imprinted on the picture tube (or projection TV

picture tubes). ALSO, some network/program logos, phone

numbers, etc. may cause similar damage. This damage is not

covered by your warranty.

Cable TV Installer: This reminder is provided to call your attention to

Article 820-40 of the National Electrical Code (Section 54 of the

Canadian Electrical Code, Part 1) which provides guidelines for proper

grounding and, in particular, specifies that the cable ground shall be

connected to the grounding system of the building as close to the point

of cable entry as practical.

Product Registration

Please fill out the product registration card (packed separately) and return it immediately. Returning the card allows us to

contact you if needed.

Product Information

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the

serial and model numbers in case you need them. These numbers are located on the product.

Model No. _____________________________________ Serial No.______________ Purchase Date:____________

Dealer/Address/Phone:______________________________________________________________________________

CAUTION

THIS PRODUCT UTILIZES A LASER. USE OF

CONTROLS OR ADJUSTMENTS OR

PERFORMANCE OF PROCEDURES OTHER

THAN THOSE SPECIFIED HEREIN MAY

RESULT IN HAZARDOUS RADIATION

EXPOSURE. DO NOT OPEN COVERS AND

DO NOT REPAIR YOURSELF. REFER

SERVICING TO QUALIFIED PERSONNEL.

Note:

This DVD player is designed and

manufactured to respond to the Region

Management Information. If the Region

number of a DVD disc does not

correspond to the Region number of this

DVD player, this DVD player cannot play

the disc. The Region number for this

DVD player is Region No 1.

Information

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CLASS 1

LASER

PRODUCT

Note:

This device is protected by U.S. patent

numbers 4,631,603 amd 4.577,216 amd

4,819,098 and other intellectual property

rights. The use of Macrovision's copy

protection technology in the device must be

authorized by Macrovision and is intended

for home and other limited pay-per-view

uses only, unless otherwise authorized in

writing by Macrovision. Reverse

engineering or disassembly is prohibited.

IMPORTANT SAFEGUARDS

In addition to the careful attention devoted to quality standards in the manufacture of your product, safety is

a major factor in the design of every product. However, safety is your responsibility too.

This sheet lists important information that will help to assure your enjoyment and proper use of the product

and accessory equipment. Please read them carefully before operating and using your product.

Installation

1Read and Follow Instructions—All the safety and operating instructions should be read

before the product is operated. Follow all operating instructions.

2Retain Instructions—The safety and operating instructions should be retained for future

reference.

3Heed Warnings—Comply with all warnings on the product and in the operating instructions.

4Polarization/Grounding—This product is equipped with either a polarized, non-polarized, or a

grounding type power cord plug. If equipped with the non-polariz-ed type (two blades of identical size),

the following does not apply.

•A polarized power plug (two blades, one wider than the other) will fit into a power receptacle only

one way. This is a safety feature. Do not defeat it. If you are unable to insert the plug fully, try

reversing it, or have an electrician change the receptacle. If you need an extension cord, use only a

polarized extension cord.

•A grounding type power plug (two blades and a round pin) will fit only into a grounding type

receptacle with matching openings. This is a safety feature. Do not defeat it. You may need an

electrician to install a grounding type receptacle. If you need an extension cord, use only a

grounding type extension cord.

5Power Sources—This product should be operated only from the type of power source indicated on the

product's marking label. If you are not sure of the type of power supply to your home, consult your dealer

or local power company. For products intended to operate from battery power, or other sources, refer to

the operating instructions.

6Overloading—Do not overload wall outlets or extension cords as this can result in a risk of

fire or electric shock. Overloaded AC outlets, extension cords, frayed power cords, damaged

or cracked wire insulation, and broken plugs are dangerous. They may result in a shock or

fire hazard. Periodically examine the cord, and if its appearance indicates damage or

deteriorated insulation, have it replaced by your service technician.

7 Power-Cord Protection—Power-supply cords should be routed so that they are not likely to be walked

on or pinched by items placed upon or against them. Pay particular attention to cords where they are

attached to plugs, convenience receptacles and at the point where they exit from the product.

8Ventilation—Slots and openings in the enclosure are provided for ventilation to ensure reliable

operation of the product and to protect it from overheating. These openings must not be blocked or

covered. These openings should never be blocked by placing the product on a bed, sofa, rug, or other

similar surface. This product should never be placed near or over a radiator or heat register, or another

heat source (including amplifiers). This product should not be placed in a built-in instal-lation such as a

bookcase or equipment rack unless proper ventilation is provided or the product manufacturer’s

instructions have been followed.

9Attachments—Do not use attachments unless recommended by the product manufacturer as they may

cause hazards.

10 Water and Moisture—Do not use this product near water—for example, near a bath tub, wash bowl,

kitchen sink or laundry tub, in a wet basement, or near a swimming pool and the like.

11 Accessories—Do not place this product on an unstable surface or support. The product may fall, causing

serious injury to a child or adult as well as serious damage to the product. Any mounting of the product

should follow the manufacturer’s in-structions and use only a mounting accessory recommended by the

manufacturer.

IMPORTANT SAFEGUARDS

Example of Antenna Grounding

13 Power Lines —An outside antenna system should not be located in the vicinity of overhead power lines,

other electric light or power circuits, or where it can fall into such power lines or circuits. When installing

an outside antenna system, extreme care should be taken to keep from touching or approaching such

power lines or circuits as contact with them might be fatal. Installing an outdoor antenna can be hazardous

and should be left to a professional antenna installer.

Use

14 Cleaning —Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol

cleaners. Use a damp cloth for cleaning.

15 Object and Liquid Entry —Never push objects of any kind into this product

through openings as they may touch dangerous voltage or “short-out” parts

that could result in a fire or electric shock. Never spill liquid of any kind on the

product.

16 Lightning —For added protection for this product during a lightning storm, or

when it is left unattended and unused for long periods of time, unplug it from

the wall outlet and disconnect the antenna or cable system. This will prevent

damage to the product due to lightning and power line surges.

Service

17 Servicing —Do not attempt to service this product yourself as opening or remov-ing covers may expose

you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

18 Conditions Requiring Service — Unplug this product from the wall outlet and refer servicing to

qualified service personnel under the following conditions.

A. When the power-supply cord or plug is damaged.

B. If liquid has been spilled, or objects have fallen into the product.

C. If the product has been exposed to rain or water.

ANTENNA

LEAD IN

WIRE

GROUND CLAMP

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)

ELECTRIC SERVICE

EQUIPMENT

ANTENNA

DISCHARGE UNIT

(NEC SECTION 810-20)

11AA product and cart combination should be moved with care. Quick stops, excessive force, and

uneven surfaces may cause the product and cart combination to overturn.

12 Outdoor Antenna Grounding—If an outside antenna or cable system is connected to the product, be

sure the antenna or cable system is grounded so as to provide some protection against voltage surges and

built-up static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70-1984 (Section 54 of

Canadian Electrical Code, Part 1) provides information with respect to proper grounding of the mast and

supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding

conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for

the grounding electrode. See following example.

IMPORTANT SAFEGUARDS

TO USE AC POWER SOURCE

Use the AC polarized line cord provided for operation on AC. Insert

the AC cord plug into a standard 120V 60Hz polarized AC outlet.

NOTES:

•Never connect the AC line cord plug to other than the

specified

voltage (120V 60Hz). Use the attached power cord only.

•If the polarized AC cord does not fit into a non-polarized AC

outlet, do not attempt to file or cut the blade. It is the user’s

responsibility to have an electrician replace the obsolete

outlet.

•If you cause a static discharge when touching the unit and the

unit fails to function, simply unplug the unit from the AC

outlet and plug it back in. The unit should return to normal

operation.

Polarized AC Cord Plug

(One blade is wider than the other.)

AC Outlet

Wider Hole

and Blade

Power Source

Important Stand and Base Safety Information

Choose the location for your TV carefully. Place the TV on a stand or base that is of adequate size and strength

to prevent the TV from being accidentally tipped over, pushed off, or pulled off. This could cause personal

injury and/or damage to TV. Refer to the Important Safety Instructions on page 3 of this manual.

D. If the product does not operate normally by following the operating instructions. Adjust only those controls

that are covered by the operating instructions. Improper adjustment of other controls may result in damage

and will often require exten-sive work by a qualified technician to restore the product to its normal

operation.

E. If the product has been dropped or the cabinet has been damaged.

F. When the product exhibits a distinct change in performance, such as the inability to perform basic

functions —this indicates a need for service.

19 Replacement Parts —When replacement parts are required, have the service technician verify that the

replacement parts he uses have the same safety characteristics as the original parts. Use of replacements

specified by the product manufacturer can prevent fire, electric shock, or other hazards.

20 Safety Check— Upon completion of any service or repairs to this product, ask the service technician to

perform safety checks recommended by the manufacturer to determine that the product is in safe

operating condition.

Features

Color TV with DVD/CD Player/Video Cassette Recorder

• Color TV with DVD/CD player with Video Cassette Recorder - Unique space saving design combines a color TV, a DVD/CD

player and a Hi-Fi Video cassette recorder. The DVD disc has much more capacity, but is the same size as the audio CD disc.

Picture quality is higher than Super VHS. Audio quality is higher than audio CD. The DVD PLAYER can play back audio CDs.

• High Quality Picture - More than 400 lines (VCR mode: 220 lines) of Horizontal Resolution.

TV Section

•On-Screen 3 Language Display -

You can select one of 3 languages, English, Spanish or French for on-screen program-

ming.

•Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for hearing

impaired viewers.

•Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control adjustment of

BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS.

•Programmable TV Sleep Timer - Operable from the remote control, the TV can be programmed up to 120 minutes to turn

off automatically.

•V-Chip - The V-Chip function can read the rating of a TV program or movie content if the program is encoded with this

information. V-Chip will allow you to set a restriction level.

•Surround Sound - The surround sound feature expands the audio listening field wider and deeper to create exceptional

sound quality from the TV’s speakers.

•Stable Sound - The stable sound feature limits the highest volume level to prevent extreme changes in volume when the

signal source is changed.

VCR Section

• Stereo/SAP Reception - This VCR is designed to receive stereo and second audio program (SAP) broadcasts where

available.

• 4 Video Heads - Provides optimal picture quality for special effects playback.

• 19µm HEAD - For superior picture quality even in SLP mode, 19micron width technology helps to avoid crosstalk and boost

SLP picture quality to near SP levels. With precision technology, ghosts and color beats are virtually eliminated.

• Hi-Fi Stereo Sound - With a frequency response of 20 to 20,000 Hz and a dynamic range of better than 90dB, this VCR

provides a level of excellence that rivals compact discs.

• One-touch Timer Recording (OTR) - Simply by pressing the REC/OTR button, the VCR can be programmed for up to 6

hours of recording with an immediate start.

DVD Section

• Compatible with a wide range of DVD audio outputs

Digital Audio Jack:

• When a component with a built-in Dolby Digital decoder is connected, Dolby Digital sound can produce the effect of being

in a movie theater or a concert hall.

• Surround standard different from Dolby Digital. This format is already in use in many theaters. By connecting this unit to a

DTS decoder or an AV amplifier with a built-in DTS decoder, the DTS audio of DVD discs recorded in this format can be

enjoyed. However, audio will not be output from the analog audio output jacks.

• The MPEG audio of DVD discs recorded in this format can be enjoyed.

• The Linear PCM sound of a 48 kHz/16 bit through 96 kHz/24 bit exceeds audio CD sound.

• Multi-Language - Since this DVD matches with 136 language-subtitles/-soundtracks, you can enjoy selecting a favorite one.

(You cannot select the language that is not recorded on the disc.)

• Multi-Angle - Pictures of Sports or a Live Concert are recorded with many cameras. When you play such a disc, you can

change the angles during playback. (If a Multi-Angle is not recorded on the disc, you cannot change the angle.)

• Repeat Playback - You can repeat chapter, track, title, sides or material between two selected points.

• Memory/Random Playback - You can play back tracks, titles or chapters in programmed or random-selected sequences.

• Zoom - You can zoom in on the selected subject on the screen during playback.

• Video Aspect Ratio - You can change the aspect ratio of the screen for your monitor/television on a suitable disc.

• Parental Control - You can limit the playback of scenes or sounds of adult DVD discs which have a parental level rating.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents

and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright

protection technology must be authorized by Macrovision Corporation, and is intended for home use only unless

otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Labo-

“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

Unauthorized recording of copyrighted television programs, films, video cassettes and other materials may infringe the

rights of copyright owners and be contrary to copyright laws.

Contents

IMPORTANT SAFEGUARDS .......................... 3

Power Source................................................... 5

Features ........................................................... 6

Contents ........................................................... 7

Parts and functions ..........................................8

Remote control .................................................9

Antenna connections ..................................... 11

Cable TV connections ....................................12

Connections to other equipment ....................13

Setting the language ......................................15

Auto clock setting ...........................................16

Manual clock setting....................................... 18

Before using your unit

Recording a TV program ................................ 35

One-touch Timer Recording (OTR) ................ 37

Timer recording .............................................. 38

Recording

Advanced function of VCR section

Loading and Unloading a cassette tape ......... 31

Cassette tape playback .................................. 32

Special playback ............................................ 33

ZERO RETURN function................................ 34

Video index search system ............................ 34

Tape playback operation

TV operation................................................... 19

Closed caption ............................................... 21

To memorize channels ................................... 22

Setting the V-Chip .......................................... 24

To set the on timer.......................................... 27

To set the off timer.......................................... 28

Picture control adjustment.............................. 29

Sound control adjustment .............................. 30

TV operation

Disc ................................................................ 43

Preparation..................................................... 44

Status display of disc ..................................... 44

Playback procedure ....................................... 45

Special playback ............................................ 46

mp3 playback ................................................. 47

Zooming ......................................................... 48

Locating desired scene .................................. 48

Repeat/Random/Program playback and

Repeat A-B ..................................................... 49

Changing soundtrack language ..................... 50

Subtitles ......................................................... 50

Changing angles ............................................ 51

Title selection ................................................. 51

DVD menu...................................................... 51

Disc playback operation

Setting language ............................................ 52

Setting the aspect ratio of TV screen ............. 53

Setting on screen display ............................... 53

Dynamic Range Control ................................. 54

Parental control setting .................................. 55

To change parental level ................................ 56

Temporary disabling of rating by DVD disc .... 57

Advanced function of DVD section

Language code list ......................................... 58

Problems and troubleshooting ....................... 59

Video head cleaning....................................... 60

Specifications ................................................. 61

Warranty ........................................................ 62

Additional information

Setting the surround sound ............................ 40

Setting the stable sound................................. 40

Stereo recording and playback ...................... 41

Second Audio Program (SAP)........................ 41

Duplicating a video tape ................................. 42

Parts and functions

Front

Rear

VOL ▲/▼ buttons (TV)

Headphones

jack

VIDEO IN jack

AUDIO IN (L/R) jacks

REW (Rewind) button (VCR)

F.FWD button (VCR)

REC/OTR button (VCR)

PLAY button (VCR)

STOP/EJECT button (VCR)

STOP button (DVD)

PLAY button (DVD)

OPEN/CLOSE button (DVD)

Disc tray

SKIP buttons

POWER button

CH ▲/▼ buttons (TV)

Power indicator

Remote sensor

REC/OTR indicator (VCR)

T.REC (Timer Recording)

indicator (VCR)

Cassette Loading Slot

LINE 1 IN

VIDEO

AUDIO

(MONO)

VIDEO

AUDIO

OUT PUT

DIGITAL AUDIO

VHF/UHF

COAXIAL

LINE 1 IN

VIDEO

AUDIO

(MONO)

VIDEO

AUDIO

OUT PUT

DIGITAL AUDIO

VHF/UHF

COAXIAL

AUDIO IN (L/R) jacks

COAXIAL DIGITAL AUDIO OUT jack

VIDEO IN jack

AUDIO OUT (L/R) jacks

RF IN (VHF/UHF) jack

VIDEO OUT jack

AC power cord

POWER Power on/off 15

TV/VCR

Press to operate TV/VCR

DVD

Press to operate DVD

CH +/– Select channel 20,35,37

0-9 Number buttons 19,23,35

Input setting 48,49

Enter a password 24,26,55~57

VOL +/– Adjust volume of TV 19

MUTE Switch off the sound 20

DISPLAY/CALL

Display TV/VCR or DVD operation status 16,20,34,36,44

JUMP Locate the desired scene 48

QUICK VIEW Switch between present/last channel 20

/ / / Arrow buttons for navigation 15,45

ENTER Enter information in the menu 15

Select option in the menu 45

SETUP/TV MENU Display menu of setup 15,52~56

Removes DVD set up menu 52~56

CANCEL Delete Timer program 27,28,39

Cancel input data in the setting mode

18,24,26,48,49,55,56

STOP Stop 32,36,37,45

PLAY Playback 32,45

PAUSE/STILL Still picture/Recording pause on/off 33,36,46

REW/SEARCH Rewind/Review playback 32,33,46

F.FWD/SEARCH Fast Forward/Forward search playback 32,33,46

INDEX +/– Search for the INDEX mark of a tape 34

SKIP +/– Skip chapter to forward or reverse direction 46

REC/OTR Recording 35,37

TIMER REC

Set the unit to start recording at a preset time

38,39

TV MONITOR Temporarily watch a TV channel while playing a

VCR tape. 33

SLOW Slow-motion playback 33,46

SLEEP Sleep timer 20

CLOSED CAPTION

Switch between TV/Caption/Text in Closed

Caption mode 21

AUDIO SELECT Switches sound between mono and stereo 41

Change sound track language of DVD 50

30 Sec ADV Skip the unwanted short material of a tape 33

MAIN MENU Select title of a DVD disc 51

ATR Digital AUTO TRACKING (VCR) 33

SUB TITLE Set Subtitle of a DVD disc 50

ZERO RETURN

Stop the tape when the counter reaches 00:00:00

ANGLE Change playback angle of a DVD disc 51

COUNTER RESET

Reset the counter to 00:00:00 34

MENU Select menu of a DVD disc 51

TRACKING + Manual tracking button in playback mode 33

ZOOM Zoom (for DVD playback) 48

INPUT SELECT Switch the connected TV to external mode 14

RETURN Takes you to the previous menu 52~57

SPEED Sets the tape speed for recording 35,37

REPEAT A-B Repeat playback between A and B (DVD/CD) 49

PROGRAM

Confirm the timer program

28,39

PLAY MODE Select playback mode 49

TRACKING – Manual tracking button in playback mode 33

EJECT Eject a cassette tape 31

OPEN/CLOSE Open or Close the disc tray 45

Remote control

Page

Button descriptions (top left to

right)

Inserting Batteries

123

Operation

•Aim the remote control at the remote sensor and press control buttons

to operate.

•Operate the remote control within 30° angle on either side of the remote

sensor, up to a distance of approximately 5 meters (16 ft.)

Remote control (continued)

Replace the compartment

cover.

Install two "AAA" batteries

paying

attention to the polarity diagram in

the battery compartment.

Open the battery compartment

cover in the direction of the

arrow.

Approximately 5

meters (16 ft.)

Battery precautions

The precautions below should be followed when using batteries in this device:

1.Use only the size and type of batteries specified.

2.Be sure to follow the correct polarity when installing the batteries as indicated in the battery compartment.

Reversed batteries may cause damage to the device. To avoid a potential short circuit, insert the “–” end first.

Do not mix different types of batteries together (e.g. Alkaline and Carbon-zinc) or old batteries with fresh ones.

4.If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury

from possible battery leakage.

5.Do not try to recharge batteries not intended to be recharged; they can overheat and rupture. (Follow battery

manufacturer’s directions.)

•Press POWER to turn the unit on or off.

•Select your desired operating mode (TV/VCR or DVD) using TV/VCR or DVD.

•Press CH +/– to move through the channels one channel at a time.

•The Arrow buttons ( ///) are also used to navigate on-screen menu system.

•You can directly access specific channels using the number buttons.

Remote control basics

If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna

system. If you are using cable TV service (CATV), see page 12 for Cable TV connections.

Combination VHF/UHF Antenna (Separate VHF and UHF 300 ohm Twin-lead Wires)

Combination VHF/UHF Antenna (Single 75 ohm Cable or 300 ohm Twin-lead Wire)

Antenna connections

75 ohm

Coaxial

Cable 300-75 ohm

Matching

Transformer

300-75 ohm

Matching

Transformer

UHF 300 ohm

VHF 300 ohm

UHF 300 ohm

VHF 75 ohm

Separate VHF/UHF Antennas (75 ohm VHF Cable and 300 ohm UHF Twin-lead Wires)

RF IN

jack RF IN

jack

RF IN

jack

Combiner

RF IN

jack

Combiner

Connect the 75 ohm Cable from the Combination

VHF/UHF Antenna to the RF IN Jack.

If your Combination VHF/UHF Antenna has a 300

ohm Twin-lead Wire, the use of the 300-75 ohm

Matching Transformer may be necessary (not sup-

plied).

Connect the UHF 300 ohm Twin-lead Wire to the

Combiner (not supplied). Connect the VHF 300

ohm Twin-lead Wire to the 300-75 ohm Matching

Transformer. Attach the Transformer to the Com-

biner, then attach the Combiner to the RF IN Jack.

Connect the VHF 75 ohm cable and UHF 300 ohm

Twin-lead Wire to the Combiner. Attach the Com-

biner to the RF IN Jack.

IMPORTANT: Go to page 22 to choose the signal and search for channels.

FOR SUBSCRIBERS TO BASIC CABLE TV SERVICE

For basic cable service not requiring a Converter/Descrambler

box, connect the CATV 75 ohm Coaxial Cable directly to the

RF IN Jack on the back of the unit.

Cable TV connections

FOR SUBSCRIBERS TO SCRAMBLED CABLE TV SERVICE

75 ohm

Coaxial Cable

If you subscribe to a cable TV service in which basic channels are unscrambled and premium channels require the

use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available from

the Cable company or an electronics supply store). Follow the connections shown below. With the switch in the “B”

position, you can directly tune any nonscrambled channels on your unit. With the switch in the “A” position, tune your

unit to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler

box to tune scrambled channels.

FOR SUBSCRIBERS TO UNSCRAMBLED BASIC CABLE TV SERVICE WITH

SCRAMBLED PREMIUM CHANNELS

Splitter B

Incoming

75 ohm

CATV Cable A/B Switch

75 ohm Cable

to unit

Incoming

75 ohm

CATV Cable 75 ohm Cable to

unit

Converter/

Descrambler

RF IN

jack

RF IN

jack

RF IN

jack

Converter/

Descrambler

This unit has an extended tuning range and can tune most cable channels without using a Cable TV

Converter box. Some cable companies offer “premium pay channels” in which the signal is

scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device

which is generally provided by the cable company.

If you subscribe to a cable TV service which requires the use of a Converter/Descrambler box, connect the

incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial Cable,

connect the output jack of the Converter/Descrambler box to the RF IN Jack on the unit. Follow the connections

shown below. Set the unit to the output channel of the Converter/Descrambler box (usually channel 3 or 4) and

use the Converter/Descrambler box to select channels.

IMPORTANT: Go to page 22 to choose the signal and search for channels.

LINE 1 IN

VIDEO

AUDIO

(MONO)

VIDEO

AUDIO

OUT PUT

DIGITAL AUDIO

VHF/UHF

COAXIAL

Using an Audio Amplifier

Using an AV Amplifier with built-in digital surround

If you are using an Amplifier with a built-in digital surround as follows, you can enjoy the various audio systems

including Dolby Digital Surround audio that sounds just like the movie.

Connect an AV amplifier with built-in Dolby Digital decoder, DTS decoder, MPEG decoder or etc as

shown below.

Connections to other equipment

The exact arrangement you use to interconnect various video and audio components to the unit is dependent

on the model and features of each component. Check the Owner's Manual provided with each component for

the location of video and audio inputs and outputs.

To Audio (L) Input

To Audio (R) Input

AUDIO cord (not supplied)

Amplifier

Rear of unit

Audio (R) Output

Audio (L) Output

NOTES:

•

When you make the connections above, do not set DOLBY DIGITAL to DOLBY DIGITAL, MPEG to MPEG to ON on the AV

Amplifier. If you do, a loud noise will suddenly come out from the speakers, affecting your ears or causing the speakers to be

damaged.

Some DTS decoders which do not support DVD-DTS interface may not work properly with the unit.

LINE 1 IN

VIDEO

AUDIO

(MONO)

VIDEO

AUDIO

OUT PUT

DIGITAL AUDIO

VHF/UHF

COAXIAL

Coaxial digital cable (not supplied)

AV Amplifier with built-in digital surround

decoder as listed above

Center Speaker

Front

Speaker

(Left)

Front

Speaker

(Right)Subwoofer

Surround

Speaker (Left) Surround

Speaker

(Right)

Coaxial Digital

Audio Output

To Coaxial Digital

Audio Input

Rear of unit TV

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby

“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

Video Game Console

Using the audio/video inputs

If you connect the unit to camcorder or a TV game, you can select by pressing INPUT SELECT.

Press INPUT SELECT repeatedly to select the desired mode.

“LINE1”, “LINE2” or TV channel will display on the screen for 4 seconds.

To connect the unit to a camcorder

To playback from the camcorder, connect the camcorder to the unit as shown.

To connect the unit to a Video Game Console

The unit can also be used as a display device for many video games. However, due to the wide variety of formats,

they have not all been included in the suggested connection diagram. You'll need to consult each component's

Owner's Manual for additional information.

Front of unit

Audio/Video cord (not supplied)

To Audio/Video OUT

VIDEO IN

AUDIO IN (L)

AUDIO IN (R)

LINE 1

NOTE:

In the DVD mode this key will not

operate.

Front of unit

Camcorder

To Audio/Video OUT

Audio/Video cord (not supplied)

VIDEO IN

AUDIO IN (L)

AUDIO IN (R)

TV Channel LINE 1

(Back) LINE 2

(Front)

Connections to other equipment (continued)

Setting the language

You can choose from three different

languages (English, French and

Spanish) for the on-screen displays.

NOTES:

•Both the TV/VCR and the DVD have

their own menu option (See page 52).

•If no buttons are pressed for more

than 60 seconds, the MENU screen

will return to normal TV-operation

automatically.

1Press POWER to turn on the unit.

2Press TV/VCR to select the TV/VCR mode.

Press TV MENU. Press or to

select “SYSTEM SETUP”, then

press ENTER.

If you use the unit for the first time

and press TV MENU, instead of

the main menu screen on the right

the “LANGUAGE” screen in step 5

may appear.

Press or to select the de-

sired language: English (EN-

GLISH), Spanish (ESPAÑOL) or

French (FRANCAIS), then press

ENTER.

4Press or to select “LAN-

GUAGE”, then press ENTER.

6Press TV MENU until the MENU screen is cleared.

▲ ▼

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

The Auto Clock function will

automatically set the built-in clock

(Month, Day, Year and Time) when the

unit is connected to an Antenna or

Cable system and it is turned off. As

the unit searches for a receivable sta-

tion in your area and it receives a

broadcast signal for Auto Clock, the

Auto Clock needs several minutes to

set itself.

NOTES:

After a power failure or disconnection

of the power, the timer settings will be

lost. In this case, reset the time.

• If you live in Newfoundland, Canada

and the Auto Clock does not function

properly, set the AUTO CLOCK menu

option to “OFF” and set the clock

manually.

1Connect the Antenna or Cable system.

• If you use a cable box, turn it on.

2Plug the AC Power cord to the AC outlet.

3Make sure the TV/VCR/DVD is turned off.

• If you press POWER, Auto Clock set is not effective.

4Wait at least three minutes and press POWER.

5Press DISPLAY/CALL to check the clock on the screen.

6If the clock is not set, make sure you are receiving TV channels.

The Auto Clock may not function properly if the reception condition

is not good.

The Auto Clock Adjustment will be performed at 12:00 PM

everyday if you turn off the unit.

•If you use a cable box and you want Auto Clock adjustment to be

performed, the cable box must be left on.

•The Auto Clock Adjustment won’t work if there is more than 5

minutes between the built-in clock time and the actual time.

1Turn on the unit.

2Press TV MENU.

3Press or to select “SYSTEM

SETUP”, then press ENTER.

4Press or to select “AUTO

CLOCK” .

5Press ENTER to select “OFF”.

6Press TV MENU repeatedly to

return to the normal screen.

•When “AUTO CLOCK” is set

to “OFF”, the Auto Clock

adjustment does not function.

•Set the clock manually (see

page 18).

AUTO CLOCK ADJUSTMENT

TO SET AUTO CLOCK TO OFF

When shipped from factory “ AUTO CLOCK” is set to “ON”.

But if you do not want Auto Clock set (Adjustment):

AUTO CLOCK SETTING

Auto clock setting

▲ ▼

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

▲ ▼

TO SET STANDARD TIME

In the rare event that you live within broadcast range of two

stations in two different time zones, the unit may recognize the

wrong station for the Auto Clock set.

To correct the situation:

1Press TV MENU.

2Press or to select “SYSTEM SETUP”, then press

ENTER.

3Press or to select “STANDARD TIME”, then press

ENTER.

4Press or to select your time zone, then press ENTER.

ATLANTIC : GMT – 4 hours

(GMT: Greenwich Mean Time)

EASTERN : GMT – 5 hours

CENTRAL : GMT – 6 hours

MOUNTAIN : GMT – 7 hours

PACIFIC : GMT – 8 hours

ALASKA : GMT – 9 hours

HAWAII : GMT – 10 hours

AUTO : AUTO SET

5Press TV MENU repeatedly to return to the normal screen.

NOTE: To be able to select the standard time, the clock must first

be set by “AUTO CLOCK” once.

1Press TV MENU. Press or to

select “SYSTEM SETUP”, then

press ENTER.

2Press or to select

“DAYLIGHT SAVING TIME”, then

press ENTER.

3Press or to select one of the

options, then press ENTER. Press

TV MENU until the MENU screen

is cleared.

ON: for manual setting

(forward one hour)

OFF: for manual setting

(back one hour)

AUTO: for automatic setting

(read XDS in the signal)

You can set the Daylight Saving Time automatically or manually.

ON



OFF



AUTO

〈

▲/▼/ENTER/MENU

〉

DAYLIGHT SAVING TIME



NOTES:

•When shipped from the factory,

“DAYLIGHT SAVING TIME” is

set to “AUTO”.

•When you want to set the Daylight

Saving Time manually, on the first

Sunday in April you set to “ON”, and

on the last Sunday in October you set

to “OFF”.

•When the clock is not set, Daylight

Saving Time setting is not available.

•If there is no Daylight Saving

Time in your area, always select

“OFF” in step 3.

Auto clock setting

DAYLIGHT SAVING TIME SETTING

▲ ▼

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

Manual clock setting

You must set the date and time

manually for Timer Recordings, ON/

OFF Timer and Daylight Saving Time

if the Auto Clock process did not set

them correctly.

Press or to set the month,

then press ENTER.

3Press or to select the

“CLOCK SET” option, then press

ENTER.

After a power failure or disconnection

of the power, the timer settings will be

lost. You’ll need to reset the time.

NOTE:

1Press TV MENU. The TV/VCR menu screen will appear.

5Set the day, year and time as in

step 4.

6After setting the clock, date and

time starts functioning

automatically.

To make corrections any time during the process

Press CANCEL repeatedly until the item you want to change

blinks, then press or .

EXAMPLE: Setting the clock to "8:30 AM" October, 29 (WED), 2003.

▲ ▼

Press or to select the

“SYSTEM SETUP” menu, then

press ENTER.

▲ ▼

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

CATV

VHF

2-13

STD/HRC/IRC

14-36

(A) (W)

37-59

(AA) (WW)

60-85

(AAA) (ZZZ)

86-94

(86) (94)

95-99

(A-5) (A-1)

100-125

(100) (125)

(5A)

VHF

2-13

UHF

14-69

TV operation

If a channel with no broadcast is

selected, the sound will automati-

cally be muted.

If a station being viewed stops

broadcasting, the TV will automati-

cally shut itself off after 15 minutes.

To turn on the unit, press POWER.

Set the TV/CATV menu

option to the appropriate

position. (See page 22.)

TV - Antenna Connection

CATV - CABLE Connection

Adjust the volume level by

pressing VOL + or – . The volume

level appears.

Press the number

buttons to select

the channel.

Channels can be instantly selected

by using two buttons. (for example,

to select channel 2, press “0”, then

“2”. If you press only “2”, channel

selection will be delayed for a few

seconds.)

For channels 10 and above, Press

the 2 digits in order. For example,

to select channel 36, press "36".

You can also press “0”, then the

remaining 2 digits. For example, to

select channel 12, press "012".

For 3 digit numbers, press the 3

digits in order. For example, to

select channel 120, just press

"120".

NOTE:

To view channels above 69 the

TV must be set to CATV mode in

the CH SETUP menu. Go to

page 22 for more information.

CHANNEL +/–

Press and release CH + or –. The

channel automatically stops at

the next channel set into memory.

Before selecting channels with

the CH+ and CH- buttons, you

must put the channels into

memory. See pages 22 and 23.

NOTES:

•

CALL

Press DISPLAY/CALL to display the

current information on the screen.

Press DISPLAY/CALL again to clear

the call display.

QUICK VIEW

Press QUICK VIEW to return to the

last channel you were watching.

SLEEP

To set the unit to turn off after a

preset amount of time, press SLEEP

on the remote control. The clock will

count down 10 minutes for each

press of SLEEP (120, 110, ...10, 0).

After the sleep time is programmed,

the display will appear briefly every

ten minutes to remind you that the

sleep timer is operating. To confirm

the sleep timer setting, press

SLEEP and the remaining time will

be displayed for a few seconds. To

cancel the sleep timer, press SLEEP

repeatedly until the display turns to 0.

SLEEP

120

Press MUTE to switch off the sound.

The unit’s sound will be silenced and

“MUTE” will briefly appear on the

screen. The sound can be switched

back on by pressing this button

again or VOL + or –.

MUTE

NOTE:

To listen through the headphones,

insert a headphones (not supplied)

with a 1/8" mini plug into PHONES

jack on the front. The sound from the

TV speaker is muted.

CH 125

8 : 47AM MON

TV/VCR

00 : 00 : 00 SP

STEREO SAP

TV operation (continued)

NOTES:

Captions: This Closed Caption Mode will display text on the

screen in English or another language (depending on the set-

ting of the Closed Captions CH 1/2).

Generally, Closed Captions in English are transmitted on Cap-

tions Channel 1 and Closed Captions in other languages are

transmitted on Captions Channel 2.

Text: The Text Closed Caption Mode will usually fill the screen

with a programming schedule or other information.

After selecting a Closed Caption Mode, it will stay in effect until

it is changed, even if the channel is changed.

If the Captions signal is lost due to a commercial or a break in

the signal, the Captions will reappear when the signal is received

again. If the channels are changed, the Captions will be delayed

approximately 10 seconds. The Captions will appear in places

on the screen where they will least interfere with the picture,

usually on the bottom of the screen. News programs will usually

show three-line Closed Captions which scroll onto the screen.

Most other shows provide two or three lined Captions placed

near the character who is speaking so the viewer can follow the

dialogue. Words in italics or underlined describe titles, words in

foreign languages or words requiring emphasis. Words that are

sung usually appear enclosed by musical notes.

For television programs broadcasting with Closed Captions, look

in your TV guide for the Closed Captions symbol (CC).

•When selecting Closed Captions, the captioning will be delayed approximately 10 seconds.

•If no caption signal is received, no captions will appear, but the television will remain in the Caption Mode.

•Misspellings or unusual characters may occasionally appear during Closed Captioning. This is normal with

Closed Captioning, especially with live programs. This is because during live programs, captions are also

entered live. These transmissions do not allow time for editing.

•When Captions are being displayed, on-screen displays, such as volume and mute may not be seen or may

interfere with Closed Captions.

•Some cable systems and copy protection systems may interfere with the Closed Captioned signal.

•If using an indoor antenna or if TV reception is very poor, the Closed Caption Decoder may not appear or

may appear with strange characters or misspelled words. In this case, adjust the antenna for better reception

or use an outdoor antenna.

Closed caption

WHAT IS CLOSED CAPTIONING?

This television has the capability to decode and display Closed Captioned television programs. Closed Captioning

will display text on the screen for hearing impaired viewers or it will translate and display text in another language.

TO VIEW CLOSED CAPTIONS

Press CLOSED CAPTION to

switch between normal TV and the

two closed caption modes (cap-

tions and full screen text). Closed

captioning will display text on the

screen for hearing impaired

viewers.

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

To memorize channels

Press TV/VCR. Press TV/MENU,

the TV/VCR menu screen will

appear.

Press or to select “CH

SETUP”, then press ENTER.

This unit is equipped with a channel memory feature which allows channels to skip up or down to the next

channel set into memory, skipping over unwanted channels. Before selecting channels, they must be pro-

grammed into the unit’s memory. In addition to normal VHF and UHF channels, this unit can receive up to 113

Cable TV channels. To use this unit with an antenna, set the TV/CATV menu option to the TV mode. When

shipped from the factory, this menu option is in the CATV mode.

TV/CATV SELECTION

Press ENTER to select “TV” or

“CATV”.

Press SETUP to remove the CH

SETUP menu or to stop this

operation.

Press or to select “TV/

CATV”. If you connected an

antenna, select TV. If you have

cable service, select CATV.

TV - VHF/UHF channels

CATV - CABLE TV channels

CH SETUP

TV CATV

AUTO CH MEMORY

ADD/DELETE

〈

▲/▼/ENTER/MENU

〉

CH SETUP

TV CATV

AUTO CH MEMORY

ADD/DELETE

〈

▲/▼/ENTER/MENU

〉

Press SETUP to remove the CH

SETUP menu or to stop this

operation.

▲ ▼

CH SETUP

TV CATV

AUTO CH MEMORY

ADD/DELETE

〈

▲/▼/ENTER/MENU

〉

▲ ▼

Press TV/VCR. Press TV/MENU, the TV/VCR menu

screen will appear.

Press or to select “CH SETUP”,

then press ENTER.

AUTOMATIC MEMORY TUNING

Press or to select “AUTO CH

MEMORY”.

Press TV MENU until the MENU

screen is cleared.

TO ADD/DELETE CHANNELS

Press ENTER to select “ADD” or

“DEL”, whichever function you want

to perform.

Select the desired channel to be

memorized or deleted using the

number buttons

(0-9),

or .

Press or to select “ADD/

DELETE”, then press ENTER.

Press TV MENU. The TV/VCR

menu screen will appear.

4Press ENTER. The TV will begin

memorizing all the channels

available in your area.

Press or to select “CH SETUP”,

then press ENTER.

▲ ▼

CH 002AUTO

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

Press or to select “ TV

SETUP”, then press ENTER.

Setting the V-Chip

Press TV/VCR. Press TV/MENU, the TV/VCR menu

screen will appear.

Enter a password (4 digits) using

the number buttons (0-9), then

press ENTER.

If you enter an incorrect number,

press CANCEL.

Enter the same password again

then press ENTER.

The password is now registered

and V-Chip setting menu appears.

TO REGISTER PASSWORD

An age limitation can be set to forbid children to see and hear

violent scenes or pictures for adults, etc. The unit

corresponds to "TV RATING" and "MOVIE RATING". To use

the V-Chip function, you must register a password.

"" appears instead of the number.

Press or to select “V-

CHIP SET”, then press ENTER.

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

TV SETUP

V-CHIP SET

ON/OFF TIMER


AUDIO

SURROUND

STABLE SOUND

SAP

〈

▲/▼/ENTER/MENU

〉

ON OFF

V-CHIP SET

PASSWORD:

CONFIRM

〈

9/ENTER/CANCEL/MENU

〉

NOTES:

•

To avoid forgetting the password,

write it down and keep it in a safe

place.

•

If you forget the password...

1. Disconnect the AC cord plug from

the AC outlet and leave the unit

unplugged for more than two

minutes.

2. Insert the AC cord plug again, and

turn the volume level to a minumum.

3. Press the VOL- button on the unit

and the 0 button on the remote

control for more than 2 seconds

simultaneously.

V-CHIP SET

V-CHIP : ON

TV RATING : TV

MOVIE RATING : PG

CHANGE PASSWORD

▲/▼

/ENTER/MENU

V-CHIP SET

V-CHIP : OFF

TV RATING : TV

MOVIE RATING : PG

CHANGE PASSWORD

▲

▼

/ENTER/MENU

V-CHIP SET

V-CHIP : OFF

TV RATING : TV

MOVIE RATING : PG

CHANGE PASSWORD

▲/▼/ENTER/MENU

V-CHIP SET

V-CHIP : OFF

TV RATING : TV

MOVIE RATING : OFF

CHANGE PASSWORD

▲/▼/ENTER/MENU

▲ ▼

Press or to select “MOVIE

RATING”, then press ENTER.

TO SET THE V-CHIP

Press or to display the

desired setting, then press ENTER.

In the V-CHIP SET menu, press

or to select “ TV RATING”,

then press ENTER.

When you select TV- Y7, TV-PG, TV-14 or TV-MA, press

DISPLAY/CALL to show the contained rating. Press / to

select the desired item you want. Press ENTER to select the

setting “ON” or “OFF”.

OFF : TV RATING is not set

TV-Y : All children

TV-Y7 : 7 years old and above

TV-G : General Audience

TV-PG: Parental guidance

TV-14 : 14 years old and above

TV-MA: 17 years old and above

Press or to select

desired

rating

, then press ENTER.

OFF : MOVIE RATING is not set

G:All ages

PG : Parental guidance

PG-13 : Parental guidance

less than 13 years old

R:Under 17 years old

Parental guidance suggested

NC-17 : 17 years old and above

X:Adult only

Press TV MENU until the MENU

screen is cleared.

Press or to select

“V-CHIP”.

Press ENTER to display “ON”.

Now your settings were set into

the memory.

To use the TV after the V-Chip is

activated.

When the program applied to the V-Chip

setting is received, enter the password,

then press ENTER. When the password is

entered correctly the protection will be

temporarily overridden.

NOTE:

The V-Chip function is activated only on

programs that support the rating system.

V-CHIP SET

V-CHIP : OFF

TV RATING : OFF

MOVIE RATING : OFF

CHANGE PASSWORD

〈

▲/▼/ENTER/MENU

〉

TV SETUP

V-CHIP SET

ON/OFF TIMER


AUDIO

SURROUND

STABLE SOUND

SAP

〈

▲/▼/ENTER/MENU

〉

ON OFF

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

V-CHIP SET

V-CHIP : ON

TV RATING : TV-PG

MOVIE RATING : PG-13

CHANGE PASSWORD

▲/▼/ENTER/MENU

TO CHANGE PASSWORD

Press TV/VCR. Press TV/MENU, the TV/VCR menu screen

will appear.

Press or to select “TV

SETUP” then press ENTER.

Press or to select the “V-

CHIP SET”, then press ENTER.

Press or to select

“CHANGE PASSWORD”, then

press ENTER.

Enter a new password using

number buttons (0-9), then

press ENTER.

Enter the same password again

to confirm, then press ENTER.

Press TV MENU repeatedly to

return to normal screen.

Enter your Password using

number buttons (0-9), then

press ENTER.

If you enter an incorrect number,

press CANCEL.

Setting the V-Chip (continued)

To set the on timer

EXAMPLE: Turning on the TV to channel 12 at 7:00 AM, MON-

DAY-FRIDAY.

This feature allows you to have the

unit automatically turn on at a prede-

termined time. If you program the ON

TIMER once, the unit will turn on on

the programmed day (daily/weekly) at

the same time to the same channel.

ON/OFF TIMER

〈

▲/▼/ENTER/CANCEL/MENU

〉

ON TIMER

 7:00AM CH 001

 SUN-SAT CANCEL

OFF TIMER

 12:00AM CANCEL

ON/OFF TIMER

〈

▲/▼/ENTER/CANCEL/MENU

〉

ON TIMER

 7:00AM CH 012

 MON-FRI CANCEL

OFF TIMER

 12:00AM CANCEL

ON/OFF TIMER

〈

▲/▼/ENTER/CANCEL/MENU

〉

ON TIMER

 7:00AM CH 012

 MON-FRI SET

OFF TIMER

 12:00AM CANCEL

Press TV MENU. Press or

to select “TV SETUP”, then

press ENTER.

ON/OFF TIMER

〈

▲/▼/ENTER/CANCEL/MENU

〉

ON TIMER

 12:00AM CH 001

 SUN-SAT CANCEL

OFF TIMER

 12:00AM CANCEL

TV SETUP

V-CHIP SET

ON/OFF TIMER


AUDIO

SURROUND

STABLE SOUND

SAP

〈

▲/▼/ENTER/MENU

〉

ON OFF

Press or to select “SET”,

then press ENTER. Press TV

MENU repeatedly to return to

normal screen.

Set the desired minute, channel

and daily or weekly timer date as

in step 4.

Press or to set the desired

hour, then press ENTER.

Press or to select “ON

TIMER”, then press ENTER.

Press or to select “ON/

OFF TIMER”, then press

ENTER.

NOTES:

•The unit will automatically turn off

approximately 1 hour later after the

ON TIMER turns on if no OFF TIMER

has been set. To continue watching

the TV, press any button to cancel the

one hour automatic shut off.

•To cancel ON TIMER, follow above

steps 1-5, then press or to

select “CANCEL”. Press TV MENU

repeatedly to return to the normal

screen.

•After setting the ON TIMER, " " of the

OFF TIMER will flash on and off. If you

wish to set the OFF TIMER, press

ENTER then follow the steps 4-6 on

page 28 " To set the off timer" .

•If you want to correct the digits while

setting, press CANCEL until the item

you want to correct, then press or

to correct the desired setting.

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

To set the off timer

ON/OFF TIMER

〈

▲/▼/ENTER/CANCEL/MENU

〉

ON TIMER

 7:00AM CH 012

 MON-FRI SET

OFF TIMER

 11:00PM CANCEL

ON/OFF TIMER

〈

▲/▼/ENTER/CANCEL/MENU

〉

ON TIMER

 7:00AM CH 012

 MON-FRI SET

OFF TIMER

 11:30PM CANCEL

ON/OFF TIMER

〈

▲/▼/ENTER/CANCEL/MENU

〉

ON TIMER

 7:00AM CH 012

 MON-FRI SET

OFF TIMER

 11:30PM SET

ON/OFF TIMER

〈

▲/▼/ENTER/CANCEL/MENU

〉

ON TIMER

 7:00AM CH 012

 MON-FRI SET

OFF TIMER

 12:00AM CANCEL

NOTES:

•If a station being viewed stops

broadcasting, the TV will

automatically shut itself off after 15

minutes.

•

To cancel OFF TIMER, follow above steps

1-5, then press or to select

“CANCEL”. Press TV MENU to return

to the normal screen.

•To confirm the ON/OFF TIMER:

Press PROGRAM twice to indicate

the programs on the screen.

EXAMPLE: Turning off the TV at 11:30 PM.

This feature allows you to have the

unit turn off automatically at a

predetermined time. If you program

the OFF TIMER once, the unit will

automatically turn off at the same

time everyday.

Press TV MENU. Press or

to select “TV SETUP”, then

press ENTER.

Press or to select “OFF

TIMER”, then press ENTER.

Press or to select “ON/

OFF TIMER”, then press

ENTER.

5Press or to set the desired

minute, then press ENTER.

Press or to set the desired

hour, then press ENTER.

Press or to select “SET”,

then press TV MENU repeatedly

to return to the normal screen.

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

TV SETUP

V-CHIP SET

ON/OFF TIMER


AUDIO

SURROUND

STABLE SOUND

SAP

〈

▲/▼/ENTER/MENU

〉

ON OFF

Picture controls are factory preset

but you can adjust them

individually.

Picture control adjustment

Press or to select “TV

SETUP”, then press ENTER.

Press TV/VCR. Press TV/MENU, the TV/VCR menu screen

will appear.

CANCEL

To return all setting to the factory levels, press CANCEL while

you’re in the Picture menu.

NOTES:

Press or to select “PIC-

TURE”, then press ENTER.

4Press ENTER to select the item

you want to adjust. Press or

to adjust the setting.

5After your desired setting press TV MENU until the MENU

screen is cleared.

BRIGHTNESS

CONTRAST

COLOR

TINT

SHARPNESS

increase brightness

increase contrast

brilliant color

greenish color

decrease brightness

decrease contrast

pale color

reddish color

makes picture softer

makes picture clearer

TV SETUP

V-CHIP SET

ON/OFF TIMER


AUDIO

SURROUND

STABLE SOUND

SAP

〈

▲/▼/ENTER/MENU

〉

ON OFF

•

The CONTRAST default setting is set

to maximum at the factory.

•

The On-screen display will disappear

6 seconds after finishing an adjustment

or by pressing TV MENU three times.

The setting can only be adjusted when

they are displayed on the TV screen.

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

TV SETUP

V-CHIP SET

ON/OFF TIMER


AUDIO

SURROUND

STABLE SOUND

SAP

〈

▲/▼/ENTER/MENU

〉

ON OFF

Sound control adjustment

Sound controls are factory preset

but you can adjust them individually.

BASS:

Press or to adjust the

bass sound.

TREBLE:

Press or to adjust the

treble sound.

BALANCE:

Press or to obtain an

equal sound level from both

speakers.

Press or to select “TV

SETUP”, then press ENTER.

Press TV/VCR. Press TV/MENU, the TV/VCR menu screen will

appear.

Press or to select

“AUDIO”, then press ENTER.

4Press ENTER to select the item

you want to adjust. Press or

to adjust the setting.

5After your desired setting press TV MENU until the MENU

screen is cleared.

CANCEL

Pressing CANCEL while making sound adjustments will return all

adjustments to the factory preset levels.

NOTE:

•

The On-screen display will disappear

6 seconds after finishing an adjustment

or by pressing TV MENU three times.

The setting can only be adjusted when

they are displayed on the TV screen.

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

Tape speed and maximum recording time

Video cassette tape

Tape Speed

SLP (Super Long Play)

Loading and Unloading a cassette tape

To prevent accidental erasure

Remove the erase prevention tab with a screwdriver. Cover the hole with a piece of adhesive tape.

To record again

Erase prevention tab

Screwdriver

Adhesive tape

Automatic tape eject

This unit will automatically rewind the tape when the tape has ended. When the tape is rewound to the

beginning, it will eject automatically.

Press EJECT on the unit or the Remote. Remove the cassette tape.

Push the center of the tape until it is automatically

inserted. Insert the cassette tape with its labeled side facing up

and the erase prevention tab positioned at your left.

An inverted cassette tape cannot be inserted.

Erase prevention tab

Automatic playback

When you insert a cassette tape without an erase prevention tab, playback will start automatically.

Automatic power ON

When you insert a cassette tape the unit power will turn ON automatically.

Unloading

Use only video cassette tapes marked .

T-160 T-120 T-90 T-60 T-30

2-2/3 hours 2 hours 1-1/2 hours 1 hour 30 minutes

8 hours 6 hours 4-1/2 hours 3 hours 1-1/2 hours

SP (Standard Play)

Cassette tape playback

Insert a prerecorded tape

(When loading a cassette tape

without the erase prevention

tab, playback will start auto-

matically).

Press PLAY.

Playback will start.

" " will appear on the screen

temporarily.

If the tape doesn’t start

playing automatically.

Press STOP once.

The tape will stop but remain

fully loaded and ready to play.

" " will appear on the screen

temporarily.

To stop playback

To rewind the tape or forward it rapidly

Stop the playback or recording by pressing STOP.

To rewind the tape:

Press REW.

To forward the tape:

Press F.FWD.

To stop the tape-winding, press STOP. To switch to playback

directly (without STOP), press PLAY.

Forward/Reverse picture search mode

When the tape is being winded, you can switch to picture search

mode (see next page). To do this, press REW or F.FWD and hold

it down. The unit will resume the tape winding as soon as the

button is released.

•This unit selects the playback tape

speed SP, LP or SLP automatically.

•If you play a prerecorded tape after

the DVD playback, you must set the

unit to TV/VCR mode using TV/VCR.

•When you select the TV/VCR mode

during DVD playback, DVD playback

will change to the still mode, and after

5 minutes it will change to the stop

mode automatically.

NOTES:

Press TV/VCR to select the TV/VCR mode.

Preparation:

•

Adjusting tracking condition

Special playback

Reverse picture search function

Press REW x 1 or x 2 during the playback.

Picture Search

Forward picture search function

Press F.FWD x 1 or x 2 during the playback.

To return to playback: Press PLAY.

Still Picture

Press PAUSE/STILL during playback. To resume

normal playback: Press PLAY.

Slow Motion

During playback press SLOW.

To return to playback: Press PLAY or SLOW.

Whenever you insert a tape and start playback,

automatic tracking starts working and continuously

analyzes the signal to enable optimum picture quality

during playback.

Press PAUSE/STILL during playback.

Press SLOW repeatedly. The picture advances frame

by frame.

To return to playback: Press PLAY or PAUSE/STILL.

Frame by Frame picture

NOTES:

•

The audio output is muted during SPEED SEARCH,

STILL, FRAME ADVANCE and SLOW MOTION.

•During picture search mode there will be noise bars

which are caused by the system.

•If the tape is paused during playback for more than

approximately 5 minutes the pause function will

automatically release the tape back to play mode to

protect the video tape against excessive wear.

Slow tracking and vertical lock adjustment

If noise bars appear in the picture during slow motion,

press the TRACKING + or – to reduce the noise bars.

If the still picture jitters excessively, press TRACKING

+ or – to stabilize the still picture.

Automatic tracking adjustment

If automatic tracking cannot eliminate noises well during

playback, press TRACKING +/– to eliminate the noises.

“MANUAL TR.” will appear. Press it briefly for a fine

adjustment, or press and hold for a coarse adjustment.

Manual tracking adjustment

Repeat playback

The entire video tape will be played until its end. The

tape will then automatically rewind to the beginning and

the playback will be repeated.

1Press TV MENU. Press or to select

“AUTO REPEAT”.

3Press TV MENU until the menu screen is cleared.

if you press DISPLAY/CALL, "" will appear on

the screen.

Then press ENTER

select “ON” or “OFF”.

If “ON” is selected, the

playback will be re-

peated endlessly.

4To start the playback, press PLAY.

The playback will be repeated endlessly.

To cancel repeat mode:

Follow the above step 1, then press ENTER to select

the OFF position. Press TV MENU to return to the TV.

Press ATR to reactivate automatic tracking again.

“AUTO TR.” will appear.

•

PICTURE SEARCH SPEED

PRESS TWICE

TAPE SPEED PRESS ONCE

SP (Standard Play)

LP (Long Play)

SLP (Super Long Play)

5 X

9 X

15 X

3 X

7 X

9 X

SPEED SEARCH TIMES

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

To monitor a TV program

Press TV MONITOR while in the playback mode. The

video tape will continue to play while the picture

switches to the TV channel selected on the unit.

Press the button to return to the playback picture.

Advancing

Press 30 Sec ADV in the PLAY mode. The unit will

search forward through approximately 30 seconds of

the tape each time you press 30 Sec ADV (maximum

six presses) and then resume normal playback.

For example:1 press: 30 second of tape

2 press: 60 second of tape

3 press: 90 second of tape

Press DISPLAY/CALL.

The counter display shows the tape

running time during playback or

recording.

ZERO RETURN function

This function makes tape-rewinding

stop at the counter 00:00:00 position

automatically.

NOTES for Counter Display:

•

If you rewind the tape beyond

“00:00:00”, a minus sign (“–”) will be

displayed in front of the time.

•

When you load a tape, the counter

will reset to “00:00:00”.

•

The counter does not function on

nonrecorded (blank) sections of the

tape. When you rewind, fast forward

or play tapes through blank sections,

the counter stops.

Press COUNTER RESET at the desired

tape position. The counter display will be

reset to the "00:00:00" position (e.g. the

beginning of recording).

Press STOP when playback or recording is finished.

Press ZERO RETURN.

The tape will rewind or fast forward and automatically stop at the

”00:00:00” position.

Video index search system

This function enables you to locate the beginning of any recording

made on the VCR.

Recording an INDEX MARK

The Index Search function automatically

records an INDEX mark on the tape

whenever a recording is initiated.

Index Search

Press INDEX + or – during stop or play

mode.

For Succeeding programs: Press INDEX +.

For Preceding programs: Press INDEX – .

(Additional press increases the INDEX NO.

up to 9.)

When the INDEX + or – is pressed, the unit

starts searching the INDEX NO. selected

and finds the portion, then playback starts

automatically.

To stop the Index Search, press STOP.

NOTES for Video index search system:

•

When you record an INDEX mark at

the very beginning of the tape, the

mark may not be found.

•

During INDEX search, the tape may

stop and begin to play at a slightly

different location.

•

INDEX may not function properly with

old or worn out video tapes.

•

INDEX marks may not be found if it is

extremely close to the point where the

search began.

•

In recording, if you stop recording

temporarily, the INDEX mark is not

recorded on the tape.

Press TV/VCR to select the TV/VCR mode.

Preparation:

•

CH 001

INDEX

INDEX NO. (up to 9)

ZERO RETURN function / Video index search system

9 or 8 is displayed

00 : 00 : 00 SP

CH 110

INDEX

Recording a TV program

Load a cassette tape with the erase

prevention tab intact.

The unit will automatically turn on.

Make sure the TV/CATV option is set to the appropriate

position (See page 22).

2Press SPEED to select the desired tape

speed SP or SLP.

The tape counter and SP or SLP will

appear on the screen temporarily.

TV - VHF/UHF channels

CATV - CABLE TV channels

Recording and viewing the

same TV program

Press the number buttons (0-9) or CH +/– to select the

channel to be recorded.

VHF/UHF/CATV CHANNELS

TV CATV

VHF

2-13

UHF

14-69

VHF

2-13

STD/HRC/IRC

14-36 (A) (W)

37-59 (AA) (WW)

60-85 (AAA) (ZZZ)

86-94 (86) (94)

95-99 (A-5) (A-1)

100-125 (100)(125)

01 (5A)

5Press REC/OTR.

" " will appear on the screen

temporarily and the REC/OTR

indicator will light.

NOTES:

•If power is switched off during

recording, the TV and the DVD turn

off and the VCR continues to record.

Press STOP to halt the

recording and turn off the VCR.

•The unit channel cannot be

changed during recording.

•If you record the TV program after

playing a DVD, you must set the unit

to TV/VCR mode by pressing

TV/VCR.

•You cannot record disc material in

DVD, Audio CD, etc. onto a video

tape with this unit.

• Press TV/VCR to select the TV/VCR mode.

Preparation:

1-9 Press 0 twice and then 1-9 as required. Example: To

select 2, Press “002”.

10-12 Press 0 first and then the remaining 2 digits in order

from left to right.

Example: Press 012 for “12”.

13-99 Press 2 digits in order.

Example: Press 22 for “22”.

100-125 Press the 3 digits in order.

Example: Press 110 for “110”.

8 : 30

MON

00 : 15 : 12 SP

HI-FI

TV/VCR

Recording a TV program

Press STOP to stop recording.

" " will appear on screen for about 4

seconds.

To stop recording

Press PAUSE/STILL to avoid recording

unwanted material. Press again to continue

the recording.

"" will appear on screen temporarily.

To stop recording temporarily

NOTES:

The pause function will be released after 5 minutes to prevent damage

to the tape or the unit. The unit will change to the STOP mode.

You can select a recording channel in the recording pause mode.

•

Auto Rewind feature

This VCR will automatically rewind the

tape when the tape has ended (except

during OTR and TIMER REC). It will

also eject the tape.

To Display VCR operation Status

Press DISPLAY/CALL. The clock, day of the week and other

information will appear.

To cancel the display: Press DISPLAY/CALL until all indicators

disappear.

While watching TV DAY OF THE WEEK

CHANNEL

REAL TIME COUNTER

CLOCK

STEREO AND

SECOND AUDIO

PROGRAM (SAP)

While operating a tape

VCR

OPERATING

MODE

TAPE INAUTO REPEAT

HI-FI STEREO

TV/VCR

(continued)

TAPE SPEED

00 : 00 : 00 SP

CH 110

CH 125

INDEX

OTR 0 : 30

One-touch Timer Recording (OTR)

Load a cassette tape with the erase

prevention tab intact.

The unit will automatically turn on.

Set the TV/CATV option to the appropriate position (See page

22).

2Press SPEED to select the desired tape

speed SP or SLP.

The tape counter and SP or SLP will

appear on the screen temporarily.

TV - VHF/UHF channels

CATV - CABLE TV channels

The One-touch Timer Recording

feature provides a simple and

convenient way to make a timed

recording.

Press Direct Channel Selection (0-9)

or CH +/– to select the channel to be

recorded.

NOTES:

•If you wish to watch the DVD playback

during the recording or the OTR, press

DVD to change to DVD mode and

perform the DVD playback.

•The channel cannot be changed

during recording.

Example: One-touch Timer Recording for 30 minutes.

Press REC/OTR. Press the button again to stop recording after

30 minutes. Each additional press of REC/OTR will increase

recording time as shown in the chart below, up to a maximum of

6 hours. The OTR and recording time will appear on the screen

temporarily.

Press STOP.

" " will appear on screen temporarily.

To cancel OTR

Press

once

twice

3 times

4 times

5 times

NORMAL REC

0:30

1:00

1:30

2:00

3:00

4:00

5:00

6:00

NORMAL REC

Recording time Press

6 times

7 times

8 times

9 times

10 times

Recording time

Press TV/VCR to select the TV/VCR mode.

Preparation:

•

----- --- -

-----

----- -

-- --- --

--- -

----- --- -

/ /ENTER/CANCEL/MENU

TIMER REC SET

DATE

START

END

SPEED

23 (THU)

8 : 30 AM

-- : --

012

/ /ENTER/CANCEL/MENU

TIMER REC SET

DATE

START

END

SPEED

23 (THU)

7 : 00 PM

9 : 30 PM

125

SLP

/ /ENTER/CANCEL/MENU

----- -

-- --- -

----- -

23 TH 125

--- -

----- --- -

7:00

9:30

PM SLP

/ /ENTER/CANCEL/MENU

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

Timer recording

Press TV MENU. Select “TIMER

REC SET”, then press ENTER.

Press or to select the date, then

press ENTER.

NOTE:

To set up a daily or weekly timer, go to

page 39.

2Press or to select one of the

program line, then press ENTER.

Press TV/VCR to select the TV/VCR mode.

Load a cassette tape with the erase prevention tab intact.

Press DISPLAY/CALL to verify that the time and date are

correct (see page 36).

Preparation:

•

Timer recording can be programmed

on-screen with the remote control.

The built-in timer allows automatic

unattended recording of up to 8

programs within 1 month.

Set the start time, end time, channel

and tape speed as in step 3.

Example: Program a timer recording for the 23rd day, channel 125

(CATV), 7:00 - 9:30 PM on timer program number 1 (Tape speed: SLP).

NOTES:

Press CANCEL to move cursor backward

for correction.

To record from external source set the

channel to "L1" or "L2". "L1" or "L2" will

appear next to CH 125 (or 69).

•

5To enter other programs, repeat step

2 through 4.

• To return to the normal screen,

press TV MENU twice.

6Press TIMER REC. The T.REC indicator will light and the

VCR stands by for recording.

The timer recording will start at 5 seconds before the time you

predetermined.

NOTES:

If the T.REC indicator does not light in spite of the pressing of

TIMER REC, the cassette may not have been loaded yet. (see

page 31)

If the cassette is ejected in spite of the pressing of TIMER REC,

the erase prevention tab of the cassette may have been

removed. (see page 31)

•

NOTES:

If the T.REC indicator blinks when the

timer recording ended, the TV program

has not been completely recorded

because of an insufficient tape supply.

Press TIMER REC to cancel the timer

program or press EJECT to remove

the cassette tape.

During timer recording standby mode,

the VCR operation cannot be used. To

use the VCR operation, press TIMER

REC to deactivate the timer. After you

use the VCR,

press TIMER REC again

to put the VCR into timer recording

standby mode.

If you press TIMER REC during timer

recording, the recording operation will

be interrupted. If you press TIMER

REC again within the programmed time,

the recording operation will start again.

After a power failure or disconnection

of the power plug, all programmed

recording settings and time display

will be lost upon resumption of power.

In this case, reset the clock (see pages

16-18) and reprogram any timer

recordings.

•

----- --- -

-----

----- -

-- --- --

--- -

----- --- -

〈

/ /ENTER/CANCEL/MENU

〉

ON/OFF TIMER

ON TIMER

7:00AM CH012

MON-FRI SET

OFF TIMER

11:30PM SET

〈

/ /ENTER/CANCEL/MENU

〉

----- -

-- --- -

----- -

23 TH 007

--- -

----- --- -

7:00

9:30

PM SLP

〈

/ /ENTER/CANCEL/MENU

〉

Timer recording special case

Weekly (e.g. WKL-TUE: each Tuesday) or daily (e.g.

MON-SAT: Monday to Saturday) Timer recording

Follow the procedure of timer recording on the previous

page. At picture 3 press or repeatedly until the

desired setting appears. Then press ENTER.

When you press repeatedly, the indicator at DATE

will change as follows, in this case the day is Friday.

In case Timer programs-overlap

Do not overlap timer programs as portions of the

conflicting programs will be lost. The first recording

time has priority over the next recording time as shown

in the diagram below.

•

NOTES:

The daily/weekly recording can be made continu-

ously until the recording is canceled or the tape

reaches the end.

During timer recording the automatic rewinding

mechanism does not function.

•

The current day (Friday) SUN-SAT (Sunday to Saturday)

MON-SAT (Monday to Saturday)

MON-FRI (Monday to Friday)

WKL-WED WKL-THU (Weekly Thursday)

(Weekly Wednesday)

One month later

minus one day

8 : 00 11 : 00

9 : 00 10 : 00

Program 1

Prog.1

Deleted Parts

Non Recorded Portion Parts

Prog.2 Prog.3

Program 2

Program 3

Recording 

Control Settings

NOTES:

•If there are other timer record programs remaining,

TIMER REC must be pressed to reactivate the timer,

otherwise the remaining timer record programs will be

ignored.

•You can correct or cancel a programmed setting in

program confirm mode.

Press PROGRAM once. The TV screen displays the

timer program list. Press PROGRAM again. The TV

screen displays the ON/OFF TIMER setting.

Press PROGRAM 3 times. The screen returns to the

normal screen.

Press or to select

“TIMER REC SET” in the

MENU, then press ENTER.

Press or to select the

unnecessary program, and

press CANCEL to cancel the

program.

(once) (twice)

To confirm the settings

To cancel a program

Setting the surround sound / Setting the stable sound

The surround sound feature expands the audio listening field

wider and deeper to create exceptional sound quality from

the TV’s speakers.

Setting the surround sound

Press TV/VCR. Press or

to select “TV SETUP”, then

press ENTER.

2Press or to select

“SURROUND”. Then press ENTER

to select “ON”.

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

TV SETUP

V-CHIP SET

ON/OFF TIMER


AUDIO

SURROUND

STABLE SOUND

SAP

〈

▲/▼/ENTER/MENU

〉

ON OFF

3Press TV MENU repeatedly until the menu screen is cleared.

To cancel the surround sound mode:

Follow the above step 2, then press ENTER to select “OFF”

position. Press TV MENU repeatedly until the menu screen is

cleared.

The stable sound feature limits the highest volume level to

prevent extreme changes in volume when the signal source is

changed.

Setting the stable sound

Press TV MENU in the TV/VCR

mode. Press or to select “TV

SETUP”, then press ENTER.

2Press or to select “STABLE

SOUND”. Then press ENTER to

select “ON”.

M E N U

TIMER REC SET

TV SETUP

CH SETUP

AUTO REPEAT ON OFF

SYSTEM SETUP

〈

▲/▼/ENTER/MENU

〉

TV SETUP

V-CHIP SET

ON/OFF TIMER


AUDIO

SURROUND

STABLE SOUND

SAP

〈

▲/▼/ENTER/MENU

〉

ON OFF

3Press TV MENU repeatedly until the menu screen is cleared.

To cancel the stable sound mode:

Follow the above step 2, then press ENTER to select “OFF”

position. Press TV MENU repeatedly until the menu screen is

cleared.

STEREO

STEREO SAP

SAP

TV SETUP

V-CHIP SET

ON/OFF TIMER


AUDIO

SURROUND

STABLE SOUND

SAP

〈

▲/▼/ENTER/MENU

〉

ON OFF

Stereo recording and playback / Second Audio Program (SAP)

When a MTS STEREO broadcast is

received, the word STEREO will ap-

pear on the screen and the program can

be viewed or recorded in stereo.

The Hi-Fi STEREO recording procedure

is the same as for normal recordings.

The VHS Hi-Fi audio system permits high

fidelity recording of MTS STEREO TV

broadcasts.

NOTES:

When playing back a tape that is not

recorded in Hi-Fi stereo mode, the

audio will automatically be monaural.

When listening to a VHS Hi-Fi video

tape or MTS broadcast through the

VHF/UHF jack (Audio/Video cord not

connected), the sound will be

monaural.

Stereo recording and

playback

NOTE:

When using a CATV system, stereo TV programs may be transmitted

over a mono cable channel. In this case the word "STEREO" will not

appear and the sound will be in mono.

When viewing an MTS STEREO TV program, or playing a prerecorded

VHS Hi-Fi STEREO video tape, press AUDIO SELECT to select how

the audio will be heard through the speakers. Normally set to the Hi-Fi

STEREO position, this button can be set to the MONO position if the

stereo broadcast or videotape audio is of poor quality. The "R" and "L"

positions allow the audio from the Right or Left Hi-Fi channel to be heard

over both TV speakers. This button has no effect when viewing a MONO

video tape or TV program. Each time when you press the button, OUT-

PUT SELECTION display appears on the screen for several seconds.

Refer to the chart below.

Output selection

OUTPUT

SELECTION

STEREO

L ch

R ch

MONO

SOUND HEARD ON BOTH

SPEAKERS

STEREO

LEFT CHANNEL AUDIO

RIGHT CHANNEL AUDIO

MONO

Your unit is fitted with a SAP broadcast system which enables

you to switch to a second audio program when viewing a

selected channel.

This function applies only when the program is broadcast in

multi-languages through the SAP broadcast system.

Second Audio Program (SAP)

Press TV MENU in the TV/VCR mode. Then press or to

select "TV SETUP", then press ENTER.

2Press or to select “SAP”.

Then press ENTER

to select “ON”.

Then press TV MENU until the

menu screen is cleared.

When the unit is turned on or a channel selection is made, make

certain the letters "SAP" appear on the screen. This means that the

"Second Audio Program" broadcasting is available.

Listening to SAP

•

LINE 1 IN

VIDEO

AUDIO

(MONO)

VIDEO

AUDIO

OUT PUT

DIGITAL AUDIO

VHF/UHF

COAXIAL

If you connect the unit to another VCR or camcorder, you can duplicate a previously recorded tape.

Make all connections before turning on the power.

Duplicating a video tape

Load a blank cassette tape with the erase preven-

tion tab intact into the recording unit.

Load a previously recorded tape into the playback

VCR or CAMCORDER.

Press SPEED to select the desired tape speed SP

or SLP.

It is recommended that you set the speed to the

SP mode on the recording unit for best results.

Press INPUT SELECT to select AUDIO/VIDEO

input position. "LINE 1" or "LINE 2" will appear on

the screen.

Press REC/OTR on the recording unit, then press

PAUSE/STILL.

Press the PLAY button on the playback VCR or

CAMCORDER, then press the PAUSE/STILL

button.

Release the recording pause and the playback still

simultaneously to begin the duplicating process.

For duplicating a previously recorded tape from a

camcorder, follow the camcorder manufacturer’s

instructions. A typical camcorder dubbing hookup

is shown above.

To AUDIO (L) OUT

AUDIO/VIDEO

Cord (not supplied)

Playback VCR

To VIDEO OUT To AUDIO (R) OUT

AUDIO/VIDEO Cord (not supplied)

To AUDIO (R) IN

To AUDIO (L) IN

To VIDEO IN

Recording unit

To AV Jack

Playback Camcorder

Connection with second Video recorder Connection with Video camera

Duplicating a video tape

LINE1: on the rear panel

LINE2: on the front panel

Recording unit

To AUDIO (L) IN

To VIDEO IN

To AUDIO (R) IN

Disc

This unit applies to DVD discs from Region 1 only.

The loaded Disc (DVD, Audio-CD and mp3-CD) will be recognized automatically.

The suitable Disc-formats are: DVD, CD-R and CD-RW.

Some CD-R/RW discs may be incompatible.

WARNING

Do not attempt to play DVD-ROM, DVD-Audio, CDV, Video-CD, CD-G or Photo CD. These formats are not supported

by this model.

Title

When two or more movies are recorded on a disc,

the disc is divided into two or more sections. Each

section is called a “TITLE”.

Chapter

The titles can be subdivided into many sections.

Each section is called a “CHAPTER”.

Track

An Audio CD can contain several items.

Each item is called a track.

Removing Disc from Case

Be sure to hold the edge of disc. Do not touch the surface of the disc.

Pick up the disc gently from the case.

• Do not scratch the disc.

• Do not get dirt on the surface of the disc.

• Do not stick a label or adhesive tape on the disc.

• Do not drop or bend the disc.

Storing Disc

• Store the disc in the case to avoid risk of scratches, dirt or damage.

• Do not leave disc exposed to direct sunlight or in hot or humid places.

Cleaning Disc

Wipe the disc with a clean, dry cloth from center to edge.

• Do not wipe the disc around in a circle.

• Do not use liquid or aerosol cleaners.

CHAPTER 1

TITLE1 TITLE2

DVD DISC

CHAPTER 2 CHAPTER 2 CHAPTER 3CHAPTER 1

TRACK 1 TRACK 2 TRACK 3 TRACK 4 TRACK 5

Audio-CD

Preparation / Status display of disc

NOTE:

If the unit does not operate properly:

Static electricity, etc., may affect the play-

er's operation. Disconnect the AC power

cord once, then connect it again.

DVD

Audio CD

To make status display disappear, press DISPLAY/CALL again.

Status display of disc

Press DISPLAY/CALL. The status display of the disc will appear

on the screen.

•When you play a CD disc, the status display will appear

and remain on the screen.

Preparation

Before DVD/CD operation, please make preparations as follows.

Insert the AC cord plug into a standard 120V 60Hz polarized

AC outlet.

•If the AC cord plug is plugged in for the first time, wait for

about 5 seconds before pressing POWER.

NOTE: When connecting to other equipment, unplug the unit

from the AC outlet.

Press POWER on the unit or on the remote control to turn on

the unit. The POWER indicator will light.

•Every time you press POWER, the TV/DVD starts from TV

mode.

•When using an amplifier, switch on the amplifier.

Press DVD to select DVD mode.

The DVD startup screen will ap-

pear on the screen.

Disc operation

Chapter number

Title number Title elapsed playing time

Title total time

Audio language

Type of audio

Subtitle language

Camera angle

Disc operation

Track elapsed playing time

Track number Track total time

Play list

The following pages describe the

setup/operation in DVD mode.

Playback procedure

Press OPEN/CLOSE or

PLAY.

The disc tray closes auto-

matically.

On the TV-screen,

changes to “ ” and then

playback commences.

• A menu screen will

appear on the TV screen,

if the disc has a menu

feature.

1Press DVD to select DVD

mode. Press OPEN/

CLOSE on the unit or the

remote control.

The disc tray will open.

2Place a disc onto the tray.

Position it with the printed

label side up, align it with

the guides, and place it in

its proper position.

Press / or /to make a selection.

Press ENTER.

• Title is selected and play commences.

Press STOP to end playback.

•The unit memorizes the stopped point, depending on the

disc. “ ” appears on the screen. Press PLAY to resume

playback (from the scene point).

•If you press STOP again or unload the disc (“

” appears

on the screen.), the unit will clear the stopped point.

7Press OPEN/CLOSE.

The disc tray opens.

Remove the disc and press OPEN/CLOSE then press

POWER.

The disc tray closes automatically and unit turns off.

NOTES:

•If a non-compatible disc is loaded, “Incor-

rect Disc”, “Region Code Error” or “Paren-

tal Error” will appear on the TV screen ac-

cording to the type of loaded disc. If these

appear, check your disc again (see pages

43 and 55).

•Some discs may take a minute or so to

start playback.

•When you set a single-faced disc label

downwards (ie. the wrong way up) and

press PLAY or OPEN/CLOSE on the unit,

“” will appear on the display for about 6

seconds and then “No Disc” or “Incorrect

Disc” will be displayed.

•Some playback operations of DVDs may

be intentionally fixed by software produc-

ers. Since this unit plays DVDs according

to the disc contents the software produc-

ers designed, some playback features may

not be available. Also refer to the instruc-

tions supplied with the DVDs.

Special playback

Press SEARCH during normal playback.

Each press of the SEARCH button will increase the speed

of the search (x 2), (x 4), (x 8), (x 15).

[(CD: (x 2), (x 4), (x 8), (x 20)]

• To resume normal playback, press PLAY.

Fast Forward Playback

Press SEARCH during normal playback.

Each press of the SEARCH button will increase the speed

of the search (x 2), (x 4), (x 8), (x 15).

[(CD: (x 2), (x 4), (x 8), (x 20)]

• To resume normal playback, press PLAY.

Review Playback

Press PAUSE/STILL during

normal playback to pause play-

back.

Still Playback

To resume normal playback, press PLAY.

Press PAUSE/STILL during still playback.

One frame is advanced each time you press PAUSE/STILL.

Frame Advance

• To resume normal playback, press PLAY.

• To resume the still playback, press PAUSE/STILL.

Press SLOW

( )

during

normal playback or still playback.

Each press of SLOW will change the speed of the slow x1/2,

x1/4, x1/6, x1/8.

Slow-motion Playback

To resume normal playback,

press PLAY.

Locating a chapter or track

NOTE:

The unit is capable of holding a still video

image or On screen display image on your

television screen indefinitely. If you leave

the still video image or On screen display

image displayed on your TV for an ex-

tended period of time, you risk permanent

damage to your television screen. Pro-

jection televisions are especially

susceptible to such damage.

Press SKIP( ) Forward or SKIP( ) Reverse during

playback to locate a chapter that you want to watch.

Each time you press the button, a chapter or track is

skipped.

Note: There may be a slight delay be-

tween when you press the button and

when the function is activated.

mp3 playback

This player can play back the mp3-data

which has been recorded on CD-R or CD-

RW. To produce the mp3-data, you need a

Windows-PC with CD-ROM drive and a mp3-

encoding Software (not supplied).

The Apple-HFS-System cannot be played.

Limitations on mp3 CD playback

•mp3 CD is the disc that is standardized by

ISO9660, its file name must include 3-digits

extension letters, “mp3”.

•The directory and file names of the mp3

CD must correspond to the ISO

standardized files.

•This unit can read 200 files per disc. If

one directory has more than 200 files, it

reads up to 200 files, the remaining files will

be omitted.

•mp3 CD’s cannot be used for playback for

the purpose of recording.

•It may take more than one minute for this

unit to read mp3 files depending on its

structure.

•Music recorded by “Joliet Recording

Specification” can be played back, the file

name is displayed on the screen. Long file

names will be condensed.

•The music files recorded by “Hierarchical

File System” (HFS) cannot be played.

A mp3 menu screen will appear

on the TV screen.

Press / or / or Number

buttons (0-9) to select the desired

track, then press ENTER. Track

is selected and play commences.

• In case the folder includes more than 11 tracks, press

or to display next track list.

Notes on mp3 files

To play back an mp3 CD in the recorded order,

1. Use mp3 software that records data

alphabetically or numerically.

2. Name each file including two-digit or three-

digit number (e.g. “01” “02” or “001” “002”).

3. Refrain from making too many sub-folders.

CAUTION:

•Some mp3 CDs cannot be played back

depending on the recording conditions.

•The CD-R/RW that has no music data or

non-mp3 files cannot be played back.

4Press STOP to end playback.

• The unit records the stopped point. “ ” appears on the

screen. Press PLAY to resume playback (from the

stopped point).

• If you press STOP again or unload the disc, the unit will

clear the stopped point.

5Then press OPEN/CLOSE.

The disc tray opens.

Remove the disc and press POWER.

The disc tray closes automatically and the unit turns off.

1Press OPEN/CLOSE.

The disc tray will open.

Place a disc onto the tray.

2Press PLAY or OPEN/CLOSE.

The disc tray closes automatically.

On the TV-screen, “Scanning...”

will appear. Scanning will take as

much time as the number of files.

mp3 CD Information

NOTES:

During mp3-Playback, you cannot use SEARCH or A-B

Repeat functions.

You can use Repeat (Track or All), Random functions and

Program playback for mp3 CD Playback. (See page 49)

•

Turn ON the TV and set to the video input mode.

Press DVD to select the DVD mode.

Preparation:

•

Zooming / Locating desired scene

NOTES:

•You can select the Pause, Slow or

Search playback in the zoom mode.

• Some discs may not respond to zoom

feature.

This unit will allow you to zoom in on the frame image. You

can then make selections by switching the position of the

frame.

In the zoom mode press ZOOM repeatedly to return to a

1:1 view ( Off).

1Press DVD to select DVD

mode.

Press ZOOM during play-

back.

The center part of the

image will be zoomed in.

Each press of ZOOM will

change the ZOOM 1

(x 2), 2 (x 3) and 3

(x 4).

Zooming

Use the title, chapter and time recorded on the disc to

locate the desired point to play back.

Press Number buttons (0–9) to input the number.

• If you input a wrong number, press CANCEL.

• Refer to the package supplied with the disc to check the

numbers.

1Press JUMP during play-

back.

Locating Desired Scene

Press ENTER.

• Playback starts.

• When you change the title, playback starts from

Chapter 1 of the selected title.

• Some discs may not work in the above operation.

Press / / / to view a different part of the frame.

You may move the frame from the center position to UP,

DOWN, LEFT or RIGHT direction.

2Press or to select the “

(Chapter)”, “

(Title/

Track)” or “ (Time)”.

/Enter/0 9/Cancel/Jump

Jump

0:00:00 / 2:02:31

1 / 8

_ _ / 19

T

C

NOTES:

•Some discs may not work with the repeat operation.

•In Repeat A-B mode, subtitles near point A or B may not appear.

•You may not be able to set Repeat A-B, depending on the scenes of the DVD.

•Repeat A-B does not work with MP3 CD and interactive DVDs.

Repeat/Random/Program playback and Repeat A-B

Press PLAY MODE during playback or stop mode.

Each time you press PLAY MODE, playback mode changes as follows.

Repeat A-B playback allows you to repeat material between two selected points.

To resume normal playback press REPEAT A-B again. “ Off” appears on the

screen.

1Press REPEAT A-B during playback.

The start point is selected.

2Press REPEAT A-B again.

The end point is selected. Playback starts at the point that you selected. Playback

stops at the end point, returns to Point A automatically, then starts again.

Repeat A-B

DVD

On screen Operation

display

→ Title: Repeats the current title.

↓

Chapter: Repeats the current chapter.

↓

Off: Resumes normal playback.

•During stop mode, PLAY MODE key is not effective.

Audio CD /mp3 CD

On screen Operation

display

→ All: Repeats entire disc.

↓

Track: Repeats the current track.

↓

Random Play:

Plays the tracks in random order.

↓

*Program: Plays the tracks in program order.

↓

(Status display)

:Resumes normal playback.

•During stop mode, you cannot select “ Track”.

*Program menu

Use number buttons (0–9) to

enter the track’s number you

want to program, then press

ENTER. The track number and

total time are displayed. Repeat

this step to enter additional

tracks. When you have finished

entering tracks, press PLAY to

start Program playback.

A playlist of your programmed

tracks is displayed.

NOTES:

•If you enter a incorrect number – press CANCEL.

•To cancel program play, press STOP 3 times.

•To clear the programs on the program menu – press CANCEL until all programs

are cleared.

•The program is cancelled when you open the disc tray or turn off the power.

1/32 Eng

Off

1/8 Eng Dolby Digital

2/8 Fra Dolby Digital

Subtitles

Turning the Subtitles On and Off

When playing back a disc recorded with subtitles, you

can turn the subtitles on or off.

Press SUB TITLE during play-

back until “Off” appears.

NOTE:

Subtitles are not available on all discs.

Changing the subtitle language

You can select the language when playing back a disc

recorded with multi-lingual subtitles.

1Press SUB TITLE repeat-

edly during playback until

your desired language ap-

pears.

2The on-screen display will disappear after a few seconds.

Changing soundtrack language / Subtitles

1Press AUDIO SELECT

during playback.

NOTES:

•If the desired language is not heard af-

ter pressing AUDIO SELECT several

times, the language is not recorded on

the disc.

•Changing soundtrack language is can-

celled when you open the disc tray. The

initial default language or available lan-

guage will be heard if the disc is played

back again.

•Changing subtitle language is cancelled

when you open the disc tray or turn the

power off.

•Some functions may not work on some

DVDs. You may not be able to turn sub-

titles on or off or change subtitles. While

playing the DVD, the subtitle may

change when:

-you open or close the disc tray

-you change the title.

•In some cases, the subtitle language is

not changed to the selected one imme-

diately.

Press AUDIO SELECT

repeatedly until the desired

language is selected.

The current soundtrack

language will appear.

The on-screen display will

disappear after a few sec-

onds.

Changing soundtrack language

You can select the language when you play a multilingual

disc.

1/9

Changing angles / Title selection / DVD menu

When playing back a disc recorded with multi-angles, you

can change the view angle.

1Press ANGLE during play-

back.

The current angle will ap-

pear.

2Press ANGLE repeatedly until the desired angle is selected.

Changing angles

Two or more titles are recorded on some discs. If the title

menu is recorded on the disc, you can select the desired

title.

Press ENTER or PLAY.

The playback of the selected title will start.

1Press MAIN MENU during playback.

Title menu appears on the screen.

2Press / or / to select the desired title.

Title selection

Some DVDs allow you to select the disc contents using the

menu.

When you play back these DVDs, you can select the sub-

title language and sound-track language,etc. using the

DVD menu.

DVD menu

NOTES:

•Depending on the DVD, you may not

be able to change the angles even if

multi-angles are recorded on the DVD.

•Depending on the DVD, you may not

be able to select the title. Depending

on the DVD, a “title menu” may simply

be called a “menu” or “title” in the in-

structions supplied with the disc.

1Press MENU during playback.

The DVD menu appears on the screen.

•Press MENU again to resume playback at the scene

when you pressed MENU.

2Press / or / to select the desired item.

3Press ENTER.

The menu continues to another screen. Repeat steps 2

and 3 to set additional items if any.

1Press DVD to select DVD

mode.

Press SETUP in the stop

mode or No Disc.

Press or to select

“Language”, then press

or ENTER.

2Press or to select

“OSD Language”, then

press or ENTER.

3Press or to select de-

sired language (e.g. Eng-

lish), then press ENTER.

The menu returns to “Lan-

guage” menu automatically.

•If you want to return to the

previous menu, press

or RETURN.

4Repeat steps 2-3 for other “Language” setting.

Other Selection: (Menu/Audio/Subtitle)

If you want to select another language, enter the language

code (see the Language code list on page 58).

Off: (subtitle)

Subtitles do not appear.

5Press SETUP to remove the Menu screen.

/Enter/Setup/Return

OSD Language

Francais

Espanol

English

/Enter/Setup/Return

Language

Menu English

Audio English

Subtitle English

OSD Language English

Setting language

You can change the default settings

to customize performance to your

preference.

NOTES:

•If the selected soundtrack language is

not recorded on the disc, the original

language will be heard.

•If the selected subtitle language is not

recorded on the disc, the first-priority

language is selected.

Main Menu

/Enter/Setup/Return

Language


Sound

Parental


Display

On

TV Screen

4:3

Setting the aspect ratio of TV screen / Setting on screen display

1Press DVD to select DVD

mode.

Press SETUP in the stop

mode or No Disc.

Press or to select

“Picture”, then press or

ENTER.

2Press or to select

“TV Screen”, then press

or ENTER.

3Press or to select

your desired screen type,

then press ENTER.

You have the following screen sizes to choose from:

16:9 Wide screen

Select this mode when connecting to a wide-screen TV.

A wide screen picture is displayed full size.

4:3 Letterbox

Select this mode when connecting to a conventional TV.

When playing back a wide screen-DVD disc, it displays

the wide picture with black bands at the top and bottom of

screen.

4:3 Panscan

It displays the wide picture on the whole screen with left

and right edges automatically cut off.

•If you want to return to the previous menu, press or

RETURN.

4Press SETUP to remove the Menu screen.

NOTE:

If the DVD disc is not formatted in the pan

& scan style, it displays 4:3 style.

Setting the aspect ratio of TV screen

You can select the aspect ratio for your TV.

TV Screen

4:3

16:9

1Press DVD to select DVD mode. Press SETUP in the stop

mode or No Disc. Press or to select “Picture”, then

press or ENTER.

2Press or to select

“Display”.

3Press or ENTER to

select “On” or “Off”.

On: On screen displays

appear when you press the buttons (factory setting).

Off: On screen displays do not appear when you press

any buttons.

•If you want to return to the previous menu, press or

RETURN.

4Press SETUP to remove the Menu screen.

Status on screen display

On screen display can be switched on or off when you

press the buttons.


TV Screen

4:3

Display

On


TV Screen

4:3

Display

Off

Main Menu

/Enter/Setup/Return

Language


Sound

Parental

1Press DVD to select DVD

mode.

Press SETUP in the stop

mode or No Disc.

Press or to select

“Sound”.

2Press or ENTER to se-

lect “DRC”.

3Press or ENTER to se-

lect “On” or “Off”.

•If you want to return to the previous menu, press or

RETURN.

4Press SETUP to remove the Menu screen.

/Enter/Setup/Return

Sound

DRC On

Dynamic Range Control

DRC (Dynamic Range Control) ena-

bles you to control the dynamic range

so as to achieve a suitable sound for

your equipment.

NOTES:

•This function works only during play-

back of Dolby Digital recorded discs.

•The level of Dynamic Range Reduction

may differ depending on DVD video

disc.

Main Menu

/Enter/Setup/Return

Language


Sound

Parental

/Enter/Setup/Return

Sound

DRC Off

Parental control setting

Parental

Password Off

Parental Level Off

Password

Password 1234

If you want to limit the types of discs

that can be played, set up the Parental

Control feature.

NOTES:

•If each setup (P.52–56) has been

completed, the unit can always be

operated under the same conditions

(especially with DVD discs).

Each setup will be retained in the

memory when you turn the power off.

•Depending on the discs, the unit can-

not limit playback.

•Some discs may not be encoded with

specific rating level information though

its disc jacket says “adult.” For those

discs, the parental control restriction will

not work.

1Press DVD to select DVD

mode.

Press SETUP in the stop

mode or No Disc.

Press or to select

“Parental”, then press or

ENTER.

2Press or to select

“Parental Level”, then press

or ENTER.

3Press or to select a

level from Off or 1–8. Press

or ENTER to set the se-

lected level.

• Level Off: The parental control setting does not func-

tion.

• Level 8: Almost all DVD software can be played back.

• Level 1: DVD software for adults cannot be played

back.

• Select from the level 1 to level 8. The limitation will be

more severe as the level number is lower.

4Press or to select

“Password”, then press

or ENTER.

5Press number buttons

(0–9) for the password.

Don’t forget the password.

•If you input a wrong

number, press CANCEL.

6Press ENTER to store the

password.

Note: Now the rating is

locked and the setting can-

not be changed unless you

enter the correct password.

•If you want to return to the previous menu, press

or RETURN.

7Press SETUP to remove the parental control screen.

/Enter/Setup/Return

Parental Level

Off

Main Menu

/Enter/Setup/Return

Language


Sound

Parental

Password Off

Parental Level 1

Parental

Password On

Parental Level 1

To change the parental level

1Press DVD to select DVD mode.

Press SETUP in the stop mode or No Disc.

Press or to select “Parental”, then press or

ENTER.

2Press or to select

“Password”, then press

or ENTER.

3Press number buttons

(0–9) to enter the password

you have stored.

•If you input a wrong number, press CANCEL.

4Press ENTER.

The password is now Off.

5Press or to select

“Parental Level”. Then

press or ENTER. The

Parental Level screen is

displayed.

6Press or to select a

level from Off or 1–8 and

then press or ENTER.

7Press or to select

“Password” and then press

or ENTER.

8Press number buttons

(0–9) to enter a 4-digit pass-

word.

Note: You can enter a new password.

9Press ENTER.

The parental level is now

changed and locked.

•If you want to return to the previous menu, press or

RETURN.

Press SETUP to remove the parental control screen.

Parental

Password Off

Parental Level1

Password

Password ____

Parental

Password On

Parental Level 1

Parental

Password Off

Parental Level 1

Parental

Password Off

Parental Level 8

Password

Password 1234

Parental

Password On

Parental Level 8

NOTES:

If you forget the password...

1. Disconnect the AC cord plug from the

AC outlet and leave the unit unplugged

for more than two minutes.

2. Insert the AC cord plug again.

3. In the No Disc DVD mode, press and

hold the STOP button on the unit, and

simultaneously press and hold the 7

button on the remote control for more

than 3 seconds.

4. “PASSWORD CLEAR” appears on the

screen. The password has been

cleared.

Temporary disabling of rating level by DVD disc

1Load a DVD disc and press

PLAY (see page 45).

2If the DVD disc has been designed to temporarily cancel

the Rating level, the screen which appears after inserting a

DVD will change, depending on which disc is played. If you

select “YES” with the ENTER key, “Your disc exceeds the

parental control level.” screen will then appear.

3If you wish to cancel the set rating level temporarily, enter

the 4-digit password.

Then press ENTER.

Alternatively, if the password has not been set, playback

will commence. If you don’t know (or have forgotten) the

password, select “STOP”.

The setting screen will disappear. Press OPEN/CLOSE to

remove the disc.

To quit entering, press RETURN.

4Playback will commence if the entered password was cor-

rect.

NOTE:

The rating level will remain disabled until

the disc is ejected.

When the disc is ejected, the original rating

level will be set again automatically.

Depending on the DVD disc, the disc

may try to temporarily cancel the

rating level that you have set.

It is up to you to decide whether to

cancel the rating level or not.

Your disc exceeds the parental control level.

Password

____

Enter/0—9/Cancel/Return

Language code list

Enter the appropriate code number for the initial settings "AUDIO", "SUBTITLE" and/or "MENU LANGUAGE"

(see page 52).

Abkhazian 1112 Fiji 1620 Lingala 2224 Singhalese 2919

Afar 1111 Finnish 1619 Lithuanian 2230 Slovak 2921

Afrikaans 1116 French 1628 Macedonian 2321 Slovenian 2922

Albanian 2927 Frisian 1635 Malagasy 2317 Somali 2925

Amharic 1123 Galician 1722 Malay 2329 Spanish 1529

Arabic 1128 Georgian 2111 Malayalam 2322 Sundanese 2931

Armenian 1835 German 1415 Maltese 2330 Swahili 2933

Assamese 1129 Greek 1522 Maori 2319 Swedish 2932

Aymara 1135 Greenlandic 2122 Marathi 2328 Tagalog 3022

Azerbaijani 1136 Guarani 1724 Moldavian 2325 Tajik 3017

Bashkir 1211 Gujarati 1731 Mongolian 2324 Tamil 3011

Basque 1531 Hausa 1811 Nauru 2411 Tatar 3030

Bengali; Bangla 1224 Hebrew 1933 Nepali 2415 Telugu 3015

Bhutani 1436 Hindi 1819 Norwegian 2425 Thai 3018

Bihari 1218 Hungarian 1831 Oriya 2528 Tibetan 1225

Breton 1228 Icelandic 1929 Panjabi 2611 Tigrinya 3019

Bulgarian 1217 Indonesian 1924 Pashto, Pushto 2629 Tonga 3025

Burmese 2335 Interlingua 1911 Persian 1611 Turkish 3028

Byelorussian 1215 Irish 1711 Polish 2622 Turkmen 3021

Cambodian 2123 Italian 1930 Portuguese 2630 Twi 3033

Catalan 1311 Japanese 2011 Quechua 2731 Ukrainian 3121

Chinese 3618 Javanese 2033 Rhaeto-Romance 2823 Urdu 3128

Corsican 1325 Kannada 2124 Romanian 2825 Uzbek 3136

Croatian 1828 Kashmiri 2129 Russian 2831 Vietnamese 3219

Czech 1329 Kazakh 2121 Samoan 2923 Volapük 3225

Danish 1411 Kirghiz 2135 Sanskrit 2911 Welsh 1335

Dutch 2422 Korean 2125 Scots Gaelic 1714 Wolof 3325

English 1524 Kurdish 2131 Serbian 2928 Xhosa 3418

Esperanto 1525 Laothian 2225 Serbo-Croatian 2918 Yiddish 2019

Estonian 1530 Latin 2211 Shona 2924 Yoruba 3525

Faroese 1625 Latvian, Lettish 2232 Sindhi 2914 Zulu 3631

Language Name Code Language Name Code Language Name Code

Language Name Code

No reception above

channel 13.

Problems and troubleshooting

Use the following check list for troubleshooting when you have problems with your unit. Consult your local

dealer or service outlet if problems persist.

Be sure all connections are properly made when using with other units.

SYMPTOMS CAUSE POSSIBLE SOLUTIONS

PAGE

Try another channel.

Check picture control adjustments.

Check for source of reception distur-

bance.

Check CATV connection or VHF/UHF

antenna, reposition or rotate antenna.

Try another channel.

Check picture control adjustments.

Check for source of reception disturbance.

Check CATV connection or VHF/UHF

antenna, reposition or rotate antenna.

Try another channel.

Check CATV connection or VHF/UHF

antenna, reposition or rotate antenna.

Try another channel.

Check all CATV connections.

Set the TV/CATV Menu option to the

CATV mode.

Contact your Cable TV company.

Make sure TV/CATV menu option is in

the appropriate mode.

Check UHF antenna.

Try another channel.

Check CATV connection or VHF/UHF

antenna, reposition or rotate antenna.

Check for source of reception disturbance.

Check the MUTE button has not been

pressed.

Tune new channel.

Set Sleep Timer to "0".

Try another channel.

Check CATV connection of VHF/UHF

antenna, reposition or rotate antenna.

Press the CLOSED CAPTION button to

turn on the closed caption.

TV station experiencing problems.

Picture control is not adjusted.

Possible local interference.

Antenna (CATV) connector is not connected

or possible local interference.

TV station experiencing problems.

Picture control is not adjusted.

Possible local interference.

Antenna (CATV) connector is not connected

or possible local interference.

TV station experiencing problems.

Antenna (CATV) connector is not connected

or possible local interference.

Cable TV channel is scrambled.

CATV connector is not connected.

TV/CATV Mode menu option is set to the

TV mode.

Cable TV service interrupted.

TV/CATV Mode menu option is not set to

the appropriate mode.

UHF antenna is not connected.

TV station experiencing problems.

Antenna (CATV) connector is not connected

or possible local interference.

Possible local interference.

The MUTE button is depressed.

The AC power cord is not connected.

Cassette or disc is not inserted.

The TIMER REC buttons are depressed.

No power.

Closed caption is not

activated.

TV shuts off.

Poor or no picture.

Poor or no sound.

No CATV reception.

Picture wobbles or drifts.

Poor or no color.

Although the power is on, the

unit does not operate.

Connect the AC power cord to the AC

outlet.

Insert a video cassette or disc.

Press the TIMER REC buttons.

POWER

TV BROADCAST RECEPTION

31, 45

11, 12

The video cassette's erase prevention tab

is broken off.

The time is not set correctly.

The recording start/end time is not set

correctly.

Tape is old or worn.

Tracking adjustment is beyond range of

automatic tracking circuit.

Video heads are dirty.

Timer recording does not

work.

TV recording does not work. Place a piece of adhesive tape over the

hole.

Reset the present time.

Reset the start/end time.

Replace the tape.

Adjust tracking manually using the

TRACKING +/– buttons on the remote control.

Clean the video heads.

16~18

VCR

The CLOSED CAPTION button is not

depressed.

TV signal is weak.

TV station experiencing problems or program

tuned is not closed captions.

Sleep timer is set.

TV station stopped broadcasting.

Noise bars appear on the

screen.

–

Problems and troubleshooting (continued) / Video head cleaning

NOTES: •DO NOT ATTEMPT TO CLEAN THE VIDEO HEADS OR SERVICE THE UNIT BY REMOVING THE

REAR COVER.

•Video heads may eventually wear out and should be replaced when they fail to produce clear pictures.

•To help prevent video head clogging, use only good quality VHS tapes. Discard worn out tapes.

Video head cleaning

Video head clogging

The video heads are the means by which the unit reads the picture from the tape during playback. In the unlikely event

that the heads become dirty enough to be clogged, no picture will be played back. This can easily be determined if, during

playback of a known good tape, there is good sound, but no picture (picture is extremely snowy). If this is the case, have

the unit checked by qualified service personnel.

The playback picture has

occasional distortion.

The disc is dirty.

It is in fast forward or fast reverse

playback.

No disc is inserted.

An unplayable disc is inserted.

The disc is placed upside down.

The disc is not placed within the guide.

The disc is dirty.

The parental lock function is set.

It is in the mode of repeat playback,

memory playback, etc.

The function is prohibited with the unit or

the disc.

Eject the disc and clean it.

Some times a small amount of picture

distortion may appear. This is not a

malfunction.

Insert a disc.

Insert a playable disc (Check the disc

type and Region Number). This is a

Region 1 player.

Place the disc with the playback side

down.

Place the disc correctly inside the

guide on the disc tray.

Clean the disc.

Cancel the parental lock function or

change the parental lock level.

These operations may prevent

proper progression of the contents.

The unit does not start

playback.

Playback does not follow the

course of the disc’s program

appears on the screen.

–

55, 56

–

––

SYMPTOMS CAUSE POSSIBLE SOLUTIONS

PAGE

DVD

Remote control does not

operate.

REMOTE CONTROL

The remote control is not aimed at the

sensor.

Distance is too far or too much light in the

room.

There is an obstacle in the path of the

beam.

The batteries are weak.

The batteries are not inserted correctly.

Aim the remote control at the remote

sensor.

Operate within 5 m or reduce the light

of the room.

Clear the path of the beam.

Replace the batteries.

Insert correctly.

Specifications

GENERAL

Power supply:

Power consumption:

Weight:

Dimensions:

Inputs/Outputs:

Video:

Audio:

Hi-Fi frequency response:

Hi-Fi dynamic range:

TELEVISION

Picture tube:

Tuner type:

Receiving channels:

Antenna input:

Speaker:

Audio output power:

VCR section

Video head:

Audio track:

Tuner:

F.FWD/REW Time at 25˚C (77˚F):

DVD section

Signal system:

Applicable disc:

Frequency response:

S/N Ratio:

Harmonic distortion:

Wow and flutter:

Output:

Pickup:

ACCESSORIES:

20F500TDV

AC 120V 60Hz

Operation: 110W

Stand by: 4W

59.5lbs (27.0 kg)

Width : 22-9/16 inches (573 mm)

Height : 20-3/8 inches (517 mm)

Depth : 19-1/8 inches (485 mm)

In: 1Vp-p/75 ohm

Out: 1Vp-p/75 ohm

In: –8dBm/50 K ohm

Out: –8dBm/1 K ohm

20Hz to 20,000Hz

More than 90dB

20” (508 mm diagonal)

Quartz PLL Frequency Synthesized

VHF 2-13

UHF 14-69

CATV 14-36 (A)-(W)

37-59 (AA)-(WW)

60-85 (AAA)-(ZZZ)

86-94 (86)-(94)

95-99 (A-5)-(A-1)

100-125 (100)-(125)

01 (5A)

VHF/UHF In 75 ohm coaxial

1-13/16" (46 mm) x 3-7/8" (99 mm), 8 ohm x 2

1.5W + 1.5W

4 Rotary Heads

Hi-Fi Sound - 2 Tracks / MONO Sound - 1 Track

181 Channel Freq. Synthesized

VHF 2-13

UHF 14-69

CATV 14-36 (A)-(W)

37-59 (AA)-(WW)

60-85 (AAA)-(ZZZ)

86-94 (86)-(94)

95-99 (A-5)-(A-1)

100-125 (100)-(125)

01 (5A)

Approx. 1minute and 48 seconds (with T-120 Cassette Tape)

NTSC

DVD (12cm, 8cm), CD (12cm, 8cm)

DVD: 4Hz - 22KHz/CD: 4Hz - 20KHz

90dB

0.06%

Below Measurable Level

Video : (RCA) 1 Vp-p/75 ohm

Audio : (RCA) –12 dBm/1 K ohm

Digital Audio : 0.5Vp-p/75 ohm

CD : Wavelength: 775 - 805 nm

Maximum output power: 0.5 mW

DVD : Wavelength: 640 - 660 nm

Maximum output power: 1.0 mW

Remote control x 1

Batteries (AAA) x 2

24F500TDV

Operation: 135W

Stand by: 4W

79.4lbs (36.0 kg)

25-13/16 inches (655 mm)

22-13/16 inches (580 mm)

18-3/4 inches (477 mm)

24” (600 mm diagonal)

27F500TDV

Operation: 145W

Stand by: 4W

99.2lbs (45.0 kg)

29-1/8 inches (740 mm)

25-3/8 inches (645 mm)

19-7/16 inches (494 mm)

27” (676.6 mm diagonal)

2.5W + 2.5W

RCA TruFlat TV/DVD/VCR Combination

Limited Warranty

What your warranty covers:

•Defects in material or workmanship.

For how long after your purchase:

•One year from date of purchase for labor charges.

•One year from date of purchase for parts.

•Two years from date of purchase for picture tube.

The warranty period for rental units begins with the first rental or 45 days from date of shipment to the rental

firm whichever comes first.

What we will do:

•Pay any Authorized RCA Television Service Center the labor charges to repair your unit.

•Pay any Authorized RCA Television Service Center for the new or, at our option, rebuilt replacement parts

and picture tube required to repair your unit.

How you get service:

• For 20” screen size: Take your unit to any Authorized RCA Television Service Center and

pickup when repairs are complete.

•For screen sizes larger than 20”: Request home or pick up, repair and return service from any

Authorized RCA Television Service Center, provided that your unit is located within the

geographic territory covered by an Authorized RCA Television Service Center. If not, you must

take your unit to the Service Center location at your own expense, or pay for the cost the Service

Center may charge to transport your unit to and from your home.

•To identify your nearest Authorized RCA Service Center, ask your dealer, look in the Yellow

Pages, visit www.rca.com, or call 1-800-336-1900.

•Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that the

product is within the warranty period must be presented to obtain warranty service. For rental

firms, proof of first rental is also required.

What your warranty does not cover:

•Customer instruction. (Your Owner’s Manual describes how to install, adjust, and operate your

television. Any additional information should be obtained from your dealer.)

•Installation and related adjustments.

•Signal reception problems not caused by your unit.

•Damage from misuse or neglect.

•Cleaning of audio/video heads.

• Batteries.

•A product that has been modified or incorporated into other products or is used for institutional

or other commercial purposes.

•Images burnt onto the screen.

• Acts of nature, such as but not limited to lightning damage.

•A unit purchased or serviced outside the U.S.A.

Warranty

Product Registration:

Please complete the online Product Registration on www.rca.com or complete and mail the Product

Registration Card packed with your unit. It will make it easier to contact you should it ever be necessary. The

return of the card is not required for warranty coverage.

Limitation of Warranty:

THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT.

ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED.

NO VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON INC., ITS AGENTS OR

EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS

WARRANTY.

REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE

REMEDY OF THE CONSUMER. THOMSON INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR

CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT

OF ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS

DISCLAIMER OF WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF

THE STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY

IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON

THIS PRODUCT IS LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.

How state law relates to this warranty:

Some states do not allow the exclusion nor limitation of incidental or consequential damages, or limitations on

how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.

This warranty gives you specific legal rights, and you also may have other rights that vary from state to state.

If you purchased your product outside the United States:

This warranty does not apply. Contact your dealer for warranty information.

Service calls which do not involve defective materials or workmanship are not covered

by this warranty. Costs of such service calls are the sole responsibility of the purchaser.

Thomson Inc.

10330 North Meridian Street

Indianapolis, IN 46290

Please do not send any products to the Indianapolis address listed in this manual or on the carton. This will

only add delays in service for your product.

Trademark(s)® Registered

Marca(s) Registrada(s)

Printed in Thailand

TOCOM 16255920

THOMSON

Visit the RCA web site at www.rca.com

Rca Truflat 27F500Tdv Users Manual

27F500TDV to the manual 5d668007-4f28-412b-9e88-a0e453ece1dd

Navigation menu

Versions of this User Manual:

Views

Navigation
