User Man_TX2-RTL8723AE
RTL8723AE
Combo mini-Card User Manual
ii Rev.1.0
COPYRIGHT
©2011 Realtek Semiconductor Corp. All rights reserved. No part of this document may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means without the written permission of Realtek Semiconductor Corp.
DISCLAIMER
Realtek provides this document “as is”, without warranty of any kind, neither expressed nor implied,
including, but not limited to, the particular purpose. Realtek may make improvements and/or changes in
this document or in the product described in this document at any time. This document could include
technical inaccuracies or typographical errors.
TRADEMARKS
Realtek is a trademark of Realtek Semiconductor Corporation. Other names mentioned in this document are
trademarks/registered trademarks of their respective owners.
USING THIS DOCUMENT
This document is intended for the software engineer’s reference and provides detailed programming
information.
Though every effort has been made to ensure that this document is current and accurate, more information
may have become available subsequent to the production of this guide. In that event, please contact your
Realtek representative for additional information that may help in the development process.
RTL8723AE
Combo mini-Card User Manual
iii Rev.1.0
Table of Contents
1. GENERAL DESCRIPTION ......................................................................................................................................... 1
1.1. RTL8723AE............................................................................................................................................................ 1
2. FEATURES....................................................................................................................................................................... 1
1.2. ENVIRONMENTAL ..................................................................................................................................................... 4
1.2.1. Operating ........................................................................................................................................................ 4
1.2.2. Storage ............................................................................................................................................................ 4
1.3. FUNCTIONAL SPECIFICATIONS................................................................................................................................... 4
1.4. WARNING ................................................................................................................................................................ 6
4.5.1 Federal Communication Commission Interference Statement .................................................................................. 6
4.5.2 Industry Canada Statement .................................................................................................................................... 7
4.5.3 NCC
警語
........................................................................................................................................................... 19
List of Tables
TABLE 2. FUNCTIONAL SPECIFICATIONS ................................................................................................................................. 4
List of Figures
RTL8723AE
Combo mini-Card User Manual
1 Rev.1.0
1. General Description
1.1. RTL8723AE
The Realtek RTL8723AE is a highly integrated single-chip 802.11n Wireless LAN (WLAN) PCI Express
network interface controller with integrated Bluetooth 2.1/3/0/4.0 USB interface controller. It combines a
WLAN MAC, a 1T1R capable WLAN baseband, and RF in s single chip. The RTL8723AE provides a
complete solution for a high-performance integrated wireless and Bluetooth device.
The integration provides better coordination between 802.11 and Bluetooth, and with sophisticated
dynamic power control and packet traffic arbitration, RTL8723AE is able to provide the best coexistence
performance.
RTL8723AE also integrates RF/PA/LNA for both 802.11n and Bluetooth so that the number of external
components is reduced to minimum. The 802.11 part supports 150Mbps PHY rate and delivers reliable
throughput from an extended distance.
The Bluetooth part supports latest 3.0+HS/4.0+LE operation and provides smooth user experience under all
usage scenarios. Optimized RF architecture and baseband algorithms provide superb performance and
lowest power consumption.
2. Features
2.1 General
n 68-pin QFN
n CMOS MAC, Baseband PHY, and RF in a single chip for IEEE 802.11b/g/n compatible WLAN
n Complete 802.11n solution for 2.4GHz band
n 72.2Mbps receive PHY rate and 72.2Mbps transmit PHY rate using 20MHz bandwidth
n 150Mbps receive PHY rate and 150Mbps transmit PHY rate using 40MHz bandwidth
n Compatible with 802.11n specification
n Backward compatible with 802.11b/g devices while operating in 802.11n mode
n Qualified Bluetooth v2.1+EDR and v3.0+HS Systems
n Support for v4.0 Bluetooth Low Energy
n Integrated class1, class2, and class3 PA and modem in Bluetooth Controller
Standards Supported
RTL8723AE
Combo mini-Card User Manual
2 Rev.1.0
n IEEE 802.11b/g/n compatible WLAN
n IEEE 802.11e QoS Enhancement (WMM)
n IEEE 802.11h TPC, Spectrum Measurement
n 802.11i (WPA, WPA2). Open, shared key, and pair-wise key authentication services
n Cisco Compatible Extensions (CCX) for WLAN devices
Host Interface
n Complies with PCI Express Base Specification Revision 1.1 for WLAN
n Complies with USB1.1 Specification for Bluetooth
WLAN MAC Features
n Frame aggregation for increased MAC efficiency (A-MSDU, A-MPDU)
n Low latency immediate High-Throughput Block Acknowledgement (HT-BA)
n Long NAV for media reservation with CF-End for NAV release
n PHY-level spoofing to enhance legacy compatibility
n Power saving mechanism
n Channel management and co-existence
n Multiple BSSID feature allows the RTL8723AE to assume multiple MAC identities when used as a
wireless bridge
n Transmit Opportunity (TXOP) Short Inter-Frame Space (SIFS) bursting for higher multimedia
bandwidth
WLAN PHY Features
n IEEE 802.11n OFDM
n One Transmit and one Receive path (1T1R)
n 20MHz and 40MHz bandwidth transmission
n Short Guard Interval (400ns)
n DSSS with DBPSK and DQPSK, CCK modulation with long and short preamble
n OFDM with BPSK, QPSK, 16QAM, and 640QAM modulation. Convolutional Coding Rate: 1/2, 2/3,
3/4, and 5/6
RTL8723AE
Combo mini-Card User Manual
3 Rev.1.0
n Maximum data rate 54Mbps in 802.11g and 150Mbps in 802.11n
n Switch diversity for DSSS/CCK
n Hardware antenna diversity
n Selectable receiver FIR filters
n Programmable scaling in transmitter and receiver to trade quantization noise against increased
probability of clipping
n Fast receiver Automatic Gain Control (AGC)
n On-chip ADC and DAC
BT Controller
n Integrated MCU to execute Bluetooth protocol stack
n Support 3 SCO links simultaneously
n Support 3 scatternets
n Enhanced BT/WIFI Coexistence Control to improve transmission quality in different profiles
n Bluetooth Low Energy Dual Mode support
Bluetooth Transceiver Features
n Fast AGC control to improve receiving dynamic range
n Support AFH to dynamically detect channel quality to improve transmission quality
n Integrated internal class1, class2, and class3 PA
n Bluetooth 3.0 compliant
n Bluetooth Low Energy supported
n Integrated 32K oscillator
Peripheral Interfaces
n General Purpose Input/Output (11 pins)
n 4-wire EEPROM control interface (93C46)
n Three configurable LED pins
n Configurable Bluetooth Coexistence Interface
RTL8723AE
Combo mini-Card User Manual
4 Rev.1.0
1.2. Environmental
1.2.1. Operating
Operating Temperature: 0 to 70 °C
Relative Humidity: 5-90% (non-condensing)
1.2.2. Storage
Temperature: -55 to 125 °C
Relevant Humidity: 5-95% (non-condensing)
1.3. Functional Specifications
Table 1. Functional Specifications
Standards
WiFi:
IEEE 802.11b, IEEE 802.11g, Draft IEEE 802.11n, IEEE 802.11d,
IEEE 802.11e, IEEE 802.11h, IEEE 802.11i
BT:
BT v3.0, v4.0
Bus Interfa
ce
WiFi:
PCI Express
BT:
USB
Form Factor
Half Size Mini Card
Data Rate
802.11b:
11, 5.5, 2, 1 Mbps;
802.11g:
54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n:
MCS 0 to 7 for HT20MHz;
MCS 0 to 7 for HT40MHz
BT:
1/2/3 Mbps
Media Access Control
WiFi:
CSMA/CA with ACK
WiFi + BT:
AFH, Time Division
Modulation Techniques
802.11b
:
CCK, DQPSK, DBPSK
802.11g:
64 QAM, 16 QAM, QPSK, BPSK
802.11n:
BPSK, QPSK, 16-QAM, 64-QAM
BT:
GFSK, π/4 DQPSK, 8DPSK
RTL8723AE
Combo mini-Card User Manual
5 Rev.1.0
Network Architecture
WiFi
:
Ad-hoc mode (Peer-to-Peer )
Infrastructure mode
Operating Channel
WiFi
2.4GHz
:
11: (Ch. 1-11) – United States
13: (Ch. 1-13) – Europe
13: (Ch. 1-14) – Japan
BT 2.4GHz:
Ch. 0 ~78
Frequency Range
2.400GHz ~ 2.4835 GHz
Security
WiFi
:
WPA, WPA-PSK, WPA2, WPA2-PSK, WEP 64bit & 128bit, IEEE
802.11x, IEEE 802.11i
BT:
Simple Paring
Operating Voltage 3.3 V ±9% I/O supply voltage
RTL8723AE
Combo mini-Card User Manual
6 Rev.1.0
1.4. Warning
4.5.1 Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator & your
body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through
11.
RTL8723AE
Combo mini-Card User Manual
7 Rev.1.0
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna,
As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements
required with this module installed (for example, digital device emissions, PC peripheral requirements,
etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the FCC authorization is no longer considered
valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will
be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC
authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20
cm may be maintained between the antenna and users. The final end product must be labeled in a visible
area with the following: “Contains FCC ID: TX2-RTL8723AE”.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
4.5.2 Industry Canada Statement
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the
following two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may cause undesired operation of
the device
RTL8723AE
Combo mini-Card User Manual
8 Rev.1.0
French translation:
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts
de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire
de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage
susceptible de provoquer un fonctionnement indésirable.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your
body.
French translation:
NOTE IMPORTANTE: (Pour l'utilisation de dispositifs mobiles)
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de
distance entre la source de rayonnement et votre corps.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna,
As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements
required with this module installed.
French translation :
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions suivantes: (Pour
utilisation de dispositif module)
1) L'antenne doit être installée de telle sorte qu'une distance de 20 cm est respectée entre l'antenne et les
utilisateurs, et
2) Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou antenne,
RTL8723AE
Combo mini-Card User Manual
9 Rev.1.0
Tant que les 2 conditions ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne seront pas
nécessaires. Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour
toutes exigences de conformité supplémentaires requis pour ce module installé.
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the IC authorization is no longer considered
valid and the IC ID can not be used on the final product. In these circumstances, the OEM integrator will be
responsible for re-evaluating the end product (including the transmitter) and obtaining a separate IC
authorization.
French translation:
NOTE IMPORTANTE:
Dans le cas où ces conditions ne peuvent être satisfaites (par exemple pour certaines configurations
d'ordinateur portable ou de certaines co-localisation avec un autre émetteur), l'autorisation du Canada n'est
plus considéré comme valide et l'ID IC ne peut pas être utilisé sur le produit final. Dans ces circonstances,
l'intégrateur OEM sera chargé de réévaluer le produit final (y compris l'émetteur) et l'obtention d'une
autorisation distincte au Canada.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20
cm may be maintained between the antenna and users. The final end product must be labeled in a visible
area with the following: “Contains IC: 6317A-RTL8723AE”.
French translation:
Plaque signalétique du produit final
Ce module émetteur est autorisé uniquement pour une utilisation dans un dispositif où l'antenne peut être
installée de telle sorte qu'une distance de 20cm peut être maintenue entre l'antenne et les utilisateurs. Le
produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC:
6317A-RTL8723AE ".
Manual Information To The End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module.
RTL8723AE
Combo mini-Card User Manual
10 Rev.1.0
The end user manual shall include all required regulatory information/warning as show in this manual.
French translation:
Manuel d'information à l'utilisateur final
L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à la façon
d'installer ou de supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre ce
module.
Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et
avertissements comme indiqué dans ce manuel.
DETACHABLE ANTENNA USAGE
This device has been designed to operate with an antenna having a maximum gain of 3.5 dBi. Antenna
having a higher gain is strictly prohibited per regulations of Industry Canada. The required antenna
impedance is 50 ohms.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and
maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio
interference to other users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
This radio transmitter (IC: 6317A-RTL8723AE / Model:RTL8723AE) has been approved by Industry
Canada to operate with the antenna types listed below with the maximum permissible gain and required
antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain
greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
Ce dispositif a été conçu pour fonctionner avec une antenne ayant un gain maximal de 3.5dBi. Une antenne
à gain plus élevé est strictement interdite par les règlements d'Industrie Canada. L'impédance d'antenne
requise est de 50 ohms.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peutfonctionner avec une
antenne d'un type et d'un gain maximal (ou inférieur) approuvé pourl'émetteur par Industrie Canada. Dans
le but de réduire les risques de brouillage radioélectriqueà l'intention des autres utilisateurs, il faut choisir le
type d'antenne et son gain de sorte que lapuissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l'intensité nécessaire àl'établissement d'une communication satisfaisante.
Le présent émetteur radio (IC: 6317A-RTL8723AE / Modèle: RTL8723AE) a été approuvé par Industrie
RTL8723AE
Combo mini-Card User Manual
11 Rev.1.0
Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal
et l'impédance requise pour chaque type d'antenne. Les types d'antenne non inclus dans cette liste, ou dont
le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur.
Approved antenna(s) list
No.
Brand Model Type
Gain
1 JOYMAX TWF-614XMPXX-500 (Main)
TWF-614XMPXX-500 (Aux) Dipole
3
3
2 LYNwave ALA110-222050-150010 (Main)
ALA110-222050-150010 (Aux) PIFA 3.5
3.5
3 ACON APP8P-700186 (Main)
APP8P-700185 (Aux) PIFA 1.84
0.07
4 ACON APP8P-700188 (Main)
APP8P-700187 (Aux) PIFA 1.84
0.07
5 WHAYU C435-520042-A (Main)
C435-520045-A (Aux) PIFA 1.91
1.88
6 WHAYU C435-520044-A (Main)
C435-520043-A (Aux) PIFA 1.96
1.97
7 WNC 25.90A1E.001 (Main)
25.90A1F.001 (Aux) PIFA 1.89
-0.90
8 YAGEO 25.90A1E.011 (Main)
25.90A1F.011 (Aux) PIFA 1.94
1.78
9 WNC 25.91370.021 (Main)
25.91371.021 (Aux) PIFA 0.51
0.58
10
YAGEO 25.91370.011 (Main)
25.91371.011 (Aux) PIFA 1.06
0.16
11
Quanta DQ6GC200100 (Main)
DQ6GC200200 (Aux) PIFA 0.1
-0.4
12
Tyco 25.90A4C.021 (Main)
25.90A4D.021 (Aux) PIFA 0.06
0.18
13
WNC 25.90A4C.001 (Main)
25.90A4D.001 (Aux) PIFA 1.52
-0.60
14
YAGEO 25.90A4C.011 (Main)
25.90A4D.011 (Aux) PIFA 0.93
-0.17
15
ACON 25.90929.001 (Main)
25.90930.001 (Aux) PIFA -0.04
1.16
16
Ethertronics Inc.
25.90934.001 (Main)
25.90935.001 (Aux) PIFA 0.60
-0.59
17
WNC 25.90919.001 (Main)
25.90920.001 (Aux) PIFA 0.87
-0.93
18
Tyco 25.90A2G.021 (Main)
25.90A2H.021 (Aux) PIFA -0.38
1.04
RTL8723AE
Combo mini-Card User Manual
12 Rev.1.0
19
WNC 25.90A2G.001 (Main)
25.90A2H.001 (Aux) PIFA 1.23
0.29
20
YAGEO 25.90A2G.011 (Main)
25.90A2H.011 (Aux) PIFA 0.48
-1.37
21
Amphenol C-2238-11-000-26 (Main)
C-2239-11-000-26 (Aux) PIFA -1.31
-3.09
22
Amphenol C-1952-11-000-26 (Main)
C-1953-11-000-26 (Aux) PIFA 0.35
-1.20
23
Foxconn WDAN-LFNZ3001-DH (Main)
WDAN-LFNZ3002-DH (Aux)
PIFA
Coupling
Type
Inverted F
1.14
0.61
24
Tyco 1556219-1 (Main)
1556220-1 (Aux) PIFA 0.64
-0.92
25
ACON APP8P-700189 (Main)
APP8P-700190 (Aux) PIFA 2.00
0.13
26
ACON APP8P-700191 (Main)
APP8P-700192 (Aux) PIFA 2.00
0.13
27
Tyco 1556216-1 (Main)
1556215-1 (Aux) PIFA 0.64
-0.92
28
Quanta DQ6GC300100 (Main)
DQ6GC300200 (Aux) PIFA -1.3
0.7
29
Amphenol C-2381-11-000-26 (Main)
C-2382-11-000-26 (Aux) PIFA -1.54
-2.93
30
Foxconn WDAN-LWSN3001-DH (Main)
WDAN-LWSN3002-DH (Aux)
PIFA
Coupling
Type
Inverted F
0.87
0.49
31
WNC 25.90A1E.001 (Main)
25.90A1F.001 (Aux) PIFA 1.94
-0.85
32
Quanta QADC FL8_WL_M (Main)
QADC FL8_WL_A (Aux) PIFA 0.1
-0.3
33
YAGEO 25.90A4W.001 (Main)
25.90A4V.001 (Aux) PIFA 0.07
-0.06
34
FOXLINK 25.90A4W.011 (Main)
25.90A4V.011 (Aux) PIFA 1.98
1.97
35
Quanta QADC PS3_WL_M (Main)
QADC PS3_WL_A (Aux) PIFA -0.1
0.0
36
Quanta QADCFL3_WL_M (Main)
QADCFL3_WL_A (Aux) PIFA -0.1
-0.1
37
Quanta QADCGC5_WL_M (Main)
QADCGC5_WL_A (Aux) PIFA 0.4
-1.0
38
Quanta DQ6GC200100 (Main)
DQ6GC200200 (Aux) PIFA 0.1
-0.4
39
Quanta QADCGC6_WL_M (Main)
QADCGC6_WL_A (Aux) PIFA 0.7
1.2
40
Quanta QADCPS1_WL_M (Main)
QADCPS1_WL_A (Aux) PIFA -0.5
-1.4
RTL8723AE
Combo mini-Card User Manual
13 Rev.1.0
41
ACON 25.90700.001 (Main)
25.90702.001 (Aux) PIFA -1.21
1.27
42
ACON 25.90800.001 (Main)
25.90802.001 (Aux) PIFA 1.37
1.21
43
Amphenol C-1334-11-000-26 (Main)
C-1335-11-000-26 (Aux) PIFA -0.37
-2.64
44
WNC 25.90979.001 (Main)
25.90980.001 (Aux) PIFA 0.77
0.74
45
Mag.Layers FPA-2423-25GC1-A1
PCA-2111-25GC1-A1 PIFA 1.77
2.17
46
WNC WNC005 (Main)
WNC005 (Aux) PIFA -2.76
-3.64
47
WNC WNC001 (Main)
WNC001 (Aux) PIFA -1.10
1.76
48
WNC WNC001 (Main)
WNC001 (Aux) PIFA 0.31
-0.75
49
Tyco Holdings
(Bermuda) VII Ltd.
TBN003 (Main)
TBN003 (Aux) PIFA -1.11
-1.11
50
WNC WNC004 (Main)
WNC004 (Aux) PIFA 2.40
1.50
51
WNC WNC002 (Tx1)
WNC002 (Tx2) PIFA 1.18
1.75
52
WNC WNC003 (Main)
WNC003 (Aux) PIFA 0.52
1.07
53
Hitachi Cable, Ltd
HFT40 (Tx1)
HFT40 (Tx2) PIFA 0.58
1.12
54
Hitachi Cable, Ltd
HFT60 (Tx1)
HFT60 (Tx2) PIFA -1.65
-0.92
55
Hitachi Cable, Ltd
HBY07 (Tx1)
HBY07 (Tx2) PIFA 2.19
-0.33
56
Hitachi Cable, Ltd
HBY051 (Tx1)
HBY051 (Tx2) PIFA 2.91
2.82
57
Hitachi Cable, Ltd
HBY052 (Tx1)
HBY052 (Tx2) PIFA 0.27
0.02
58
Hitachi Cable, Ltd
HBY061 (Tx1)
HBY061 (Tx2) PIFA 1.30
2.42
59
Hitachi Cable, Ltd
HBY062 (Tx1)
HBY062 (Tx2) PIFA -1.04
-1.19
60
Hitachi Cable, Ltd
HFT65 (Tx1)
HFT65 (Tx2) PIFA -1.74
1.16
61
Hitachi Cable, Ltd
HCT01 (Main)
HCT01 (Aux) PIFA 0.87
1.94
62
FOXCONN WDAN-TQ (Tx1)
WDAN-TQ (Tx2) PIFA -0.43
-0.7
63
ethertronics 5002011-1 (Tx1)
5002012-1 (Tx2) PIFA 0.12
-3.87
64
ethertronics 5002015-1 (Tx1)
5002016-1 (Tx2) PIFA 0.76
0.59
RTL8723AE
Combo mini-Card User Manual
14 Rev.1.0
65
ethertronics 5010011-1 (Tx1)
5010012-1 (Tx2) PIFA -1.76
-2.61
66
ethertronics 5010015-1 (Tx1)
5010016-1 (Tx2) PIFA -0.84
-2.07
67
ACON AMP6P (Tx1)
AMP6P (Tx2) PIFA 0.00
1.89
68
WNC 81.EJZ15.G52 (Main)
81.EJZ15.G52 (Aux) PIFA -1.08
-0.62
69
WNC 81.EJT15.GJC (Main)
81.EJT15.GJC (Aux) PIFA -0.58
-1.26
70
WNC 81.EJT15.GGW (Tx1)
81.EJT15.GGW (Tx2) PIFA 0.21
0.77
71
WNC 81.EJZ15.G53 (Tx1)
81.EJZ15.G53 (Tx2) PIFA -0.78
-2.14
72
QUANTA AN-070-G(R)
AN-070-G(L) PIFA -0.7
-1.9
73
QUANTA AN-070-G(R)
AN-070-G(L) PIFA -0.3
-1.9
74
QUANTA AN-120-F(R)
AN-120-F(L) PIFA -0.4
-0.3
75
QUANTA AN-120-F(R)
AN-120-F(L) PIFA -1.8
-4.4
76
WHAYU C435-520023-A (Main)
C435-520024-A (Aux) PIFA 1.74
1.56
77
WNC 81.EJZ (Main)
81.EJZ (Aux) PIFA -0.67
-0.35
78
WNC 81.EJT (Main)
81.EJT (Aux) PIFA -0.40
-1.91
79
JEM IA-100193 (Main)
IA-100194 (Aux) PIFA 1.27
-1.27
80
Tyco Holdings
(Bermuda) VII Ltd.
Taiwan Branch
TBN008 (Tx1)
TBN008 (Tx2) PIFA -0.10
-0.92
81
Smart Approach
Co., Ltd. 03-FR021-026 (Main)
03-FR021-026 (Aux) PIFA 1.51
1.56
82
Hitachi Cable HBY17 (Tx1)
HBY17 (Tx2) PIFA -0.36
0.97
83
Hitachi Cable, Ltd
HFT60 (Tx1)
HFT60 (Tx2) PIFA 2.97
0.90
84
Smart Approach
Co., Ltd. 03-FR021-020 (Main)
03-FR021-020 (Aux) PIFA 1.66
1.83
85
WHAYU
INDUSTRIAL
CO.,LTD
MSA-00005A (Main)
MSA-00005A (Aux) PIFA -2.12
-2.49
86
Tyco TBN008 (Tx1)
TBN008 (Tx2) PIFA -2.60
-0.26
87
Tyco TBN007 (Tx1)
TBN007 (Tx2) PIFA 1.98
1.97
RTL8723AE
Combo mini-Card User Manual
15 Rev.1.0
88
Tyco Electronics
Japan G.K. TBN009 (Tx1)
TBN009 (Tx2) PIFA 0.22
0.33
89
Tyco Electronics
Japan G.K. TBN010 (Tx1)
TBN010 (Tx2) PIFA 1.68
1.45
90
Smart
Approach.Co.,Ltd
03-FR021-016 (Tx1)
03-FR021-016 (Tx2) PIFA 2.32
0.49
91
Foxconn WDAN-T1WM (Tx1)
WDAN-T1WM (Tx2) PIFA 1.47
1.38
92
Foxconn WDAN-T1AM1001-DH (Tx1)
WDAN-T1AM1002-DH (Tx2) PIFA 2.58
1.39
93
WNC WNC003 (Main)
WNC003 (Aux) PIFA -0.10
2.30
94
TE Connectivity
1556465-1 TBN003 (Tx1)
1556466-1 TBN003 (Tx2) PIFA -0.23
-0.49
95
ACON APP8P-700341 (Main)
APP8P-700342 (Aux) PIFA 1.10
1.99
96
Smart Approach
SE-ECLA1-001 (Main)
SE-ECLA1-002 (Aux) PIFA 2.53
2.92
97
WNC 81.EK515.G13 (Main)
81.EK515.G14 (Aux) PIFA 0.30
0.39
98
Favortron
CO.,LTD (FVC)
N01001205001 (Tx1)
N01001206001 (Tx2) PIFA 2.81
1.97
99
Favortron
CO.,LTD (FVC)
W270HUQ-WiMAX-1
W270HUQ-WiMAX-2 PIFA 2.85
1.87
100
Favortron
CO.,LTD (FVC)
N01001193001 (Tx1)
N01001193001 (Tx2) PIFA 2.97
0.9
101
Favortron
CO.,LTD (FVC)
N01001199001 (Tx1)
N01001199001 (Tx2) PIFA 2.73
2.87
102
Well Green SKW24WMPB01+A (Tx1)
SKW24WMPB01+A (Tx2) PIFA -1.63
-0.99
103
Favortron
CO.,LTD (FVC)
N01001218001 (Tx1)
N01001218001 (Tx2) PIFA 2.53
2.28
104
Well Green SKM11WMPB03+A (Tx1)
SKM11WMPB02+D (Tx2) PIFA -1.84
-2.93
105
Favortron
CO.,LTD (FVC)
E5120-WiMAX-1
E5120-WiMAX-2 PIFA 2.7
2.19
106
Favortron
CO.,LTD (FVC)
B5100-WiMAX-1
B5100-WiMAX-2 PIFA 1.58
1.75
107
Well Green SKW31WMPB01+A (Tx1)
SKW31WMPB01+A (Tx2) PIFA -1.07
-0.64
108
WhaYu C680-520279-A (Tx1)
C680-520279-A (Tx2) PIFA 1.09
-0.55
109
WhaYu C680-520278-A (Tx1)
C680-520277-A (Tx2) PIFA 1.92
-1.03
110
Wellshine DQ67KJQUT35 (Tx1)
DQ67KJQUT36 (Tx2) PIFA 2.03
0.05
111
ZTX ZTX-A162-Q18000-00 (Tx1)
ZTX-A162-Q18000-00 (Tx2) PIFA 2.014
1.742
RTL8723AE
Combo mini-Card User Manual
16 Rev.1.0
112
Well Green SK81WMPB01+A (Tx1)
SK81WMPB02+A (Tx2) PIFA 1.79
0.66
113
Wellshine DQ67KJQUT33 (Tx1)
DQ67KJQUT33 (Tx2) PIFA 1.17
-0.06
114
Tyco Holding
(Bermuda) VII Ltd.
TBN001 (Main)
TBN001 (Aux) PIFA 3.45
2.41
115
tyco TBN005
TBN006 PIFA 2.09
3.40
116
Tyco Electronic
AMPKK TBN004 (Main)
TBN004 (Aux) PIFA 0.28
-0.83
117
Hitachi HFS23 PIFA -0.8
118
Hitachi HFS40 PIFA 0.64
119
Quanta AS-070-F (Tx1)
AS-070-F (Tx2) PIFA -0.5
-1.9
120
ACON DQ60APM6P02(APM6P-700091) (Main)
DQ60APM6P02(APM6P-700091) (Aux) PIFA -0.7
-0.29
121
ACON DQ60APM6P03(APM6P-700092) (Main)
DQ60APM6P03(APM6P-700092) (Aux) PIFA -0.6
-1.02
122
Quanta Computer
Inc 37LX6AATP00 (Tx1)
37LX6AATP00 (Tx2) PIFA 1.8
-0.3
123
Quanta Computer
Inc 37LX7AATP00 (Tx1)
37LX7AATP00 (Tx2) PIFA 0.3
1.7
124
Quanta Computer
Inc 3ASP8AATP20 (Tx1)
3ASP8AATP20 (Tx2) PIFA 1.0
0.2
125
Quanta Computer
Inc 35AX6AATP10 (Tx1)
35AX6AATP10 (Tx2) PIFA 0.7
-1.4
126
Foxconn
WDAN-HMCH1401-DH/79010T000-600-G
(Tx1)
WDAN-HMCH1402-DH/79010SY00-600-G
(Tx2)
PIFA -0.99
-0.09
127
Yageo
CAN43130WIFO04921/79010SQ00-011-G
(Tx1)
CAN43130WIFO04922/79010SR00-011-G
(Tx2)
PIFA 0.23
1.53
128
WHAYU C107-520757-A/79010T100-12S-G (Tx1)
C107-520756-A/79010SS00-12S-G (Tx2) PIFA -0.18
2.58
129
Foxconn
WDAN-HMCH1501-DH/79010SW00-600-G
(Tx1)
WDAN-HMCH1502-DH/79010SV00-600-G
(Tx2)
PIFA -0.35
0.38
130
ACON AMP8P-700186 (Main)
AMP8P-700187 (Aux) PIFA 1.96
1.91
RTL8723AE
Combo mini-Card User Manual
17 Rev.1.0
131
Amphenol FL5202-11-001-C (Tx1)
FL5202-11-001-C (Tx2) PIFA -1.41
-0.77
132
Amphenol IV5233-15-003-C (Tx1)
IV5233-15-002-C (Tx2) PIFA 0.54
-0.53
133
Amphenol IV5218-11-002-C (Tx1)
IV5218-11-001-C (Tx2) PIFA 0.55
0.31
134
Amphenol FX5170-15-004-C (Tx1)
FX5170-15-001-C (Tx2) PIFA 0.76
-2.11
135
HON HAI WDAN-HMEDW005-DH (Tx1)
WDAN-HMEDW005-DH (Rx2) PIFA -1.85
1.33
136
WNC 6036B0086802 (Tx1)
6036B0087102 (Tx2) PIFA -1.30
-0.49
137
WNC 6036B0088203 (Main)
6036B0088303 (Aux) PIFA 0.50
0.12
138
WNC 6036B0088203 (Main)
6036B0088303 (Aux) PIFA 1.21
-0.07
139
WNC 6036B0087303 (Main)
6036B0087203 (Aux) PIFA 2.34
1.28
140
WNC 6036B0091201 (Main)
6036B0091401 (Aux) PIFA -1.11
-0.95
141
YAGEO CAN43130LIIN03863 (Tx1)
CAN43130LIIN03864 (Tx2) PIFA -2.69
-1.09
142
YAGEO 6036B0091202 (Tx1)
6036B0091402 (Tx2) PIFA 0.80
0.25
143
YAGEO CAN43130LIIN03841 (Tx1)
CAN43130LIIN03842 (Tx2) PIFA 1.46
0.95
144
YAGEO 6036B0088401 (Tx1)
6036B0088501 (Tx2) PIFA 0.61
0.71
145
ACON APM8P-700018 (Tx1)
APM8P-700019 (Tx2) PIFA 2.66
2.27
146
WNC 81.EK515.G15 (Main)
81.EK515.G16 (Aux) PIFA 2.36
1.13
147
ACON APM8P-700016 (Main)
APM8P-700017 (Aux) PIFA 2.79
0.74
148
NISSEI
ELECTRIC CO.,
LTD
3209970 (Rx)
3210002 (Tx) PIFA 1.88
1.26
149
ACON 25.90598.001 (Rx)
25.90597.001 (Tx) PIFA 1.17
1.04
150
WNC 25.90587.001 (Rx)
25.90586.001 (Tx) PIFA 1.94
0.59
151
ACON 25.90653.001 (Rx)
25.90654.001 (Tx) PIFA -0.42
-0.13
152
WNC 25.90649.001 (Rx)
25.90650.001 (Tx) PIFA -0.52
0.31
153
Foxconn 024-01F0-2242 (Rx)
024-01F0-2243 (Tx) PIFA 1.16
-0.88
RTL8723AE
Combo mini-Card User Manual
18 Rev.1.0
154
NISSEI
ELECTRIC CO.,
LTD
3176658 (Rx)
3176674 (Tx) PIFA -0.83
-0.61
155
Foxconn WDAN-L1WK1001-DF (Rx)
WDAN-L1WK1002-DF (Tx) PIFA 1.71
1.43
156
Hitachi HMT14-MAIN (Rx)
HMT14-AUX (Tx) PIFA 1.82
1.54
157
ACON 25.90700.001 (Rx)
25.90702.001 (Tx) PIFA -1.21
1.27
158
ACON 25.90800.001 (Rx)
25.90802.001 (Tx) PIFA 1.37
1.21
159
ACON APM6P-700033 (Rx)
APM6P-700034 (Tx) PIFA -0.96
-0.86
160
Amphenol Taiwan
Corporation 14G152168231LV (Rx)
14G152168131LV (Tx) PIFA -1.85
-1.60
161
ACON APM6P-700027 (Rx)
APM6P-700029 (Tx) PIFA -1.32
-0.23
162
TYCO 2023940-1 (Rx)
2023944-1 (Tx) PIFA -2.39
1.52
163
ACON APM6P-700028 (Rx)
APM6P-700030 (Tx) PIFA -1.16
-0.74
164
Tyco Holding
(Bermuda) VII Ltd.
2023946-1 (Rx)
2023950-1 (Tx) PIFA -0.58
-0.11
165
Amphenol SAA
LX-0980-11-000-R (Rx)
LX-0983-11-000-R (Tx) PIFA 1.61
1.57
166
NISSEI
ELECTRIC CO.,
LTD
3172525 (Rx)
3172566 (Tx) PIFA 1.35
1.99
167
Amphenol LX0970-11-000-R (Rx)
LX0968-11-000-R (Tx) PIFA 1.47
1.68
168
FOXCONN WDAN-L1ML3001-DF (Rx)
WDAN-L1ML3002-DF (Tx) PIFA -0.40
1.10
169
NISSEI
ELECTRIC CO.,
LTD
3172467 (Rx)
3172509 (Tx) PIFA 0.54
1.80
170
ACON 25.90675.001 (Rx)
25.90676.001 (Tx) PIFA -0.39
0.64
171
WNC 25.90669.001 (Rx)
25.90670.001 (Tx) PIFA -1.53
1.32
172
ACON AWP6P (Main)
AWP6P (Aux) PIFA -0.19
-0.99
RTL8723AE
Combo mini-Card User Manual
19 Rev.1.0
4.5.3 NCC 警語
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功
率或變更原設計之特性及功能。
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並
改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電
機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
本模組於取得認證後將依規定於模組本體標示審合格籤。
系統廠商應於平台上標示「本產品內含射頻模組： XXXyyyLPDzzzz-x (NCC ID) 」字樣。
Realtek Semiconductor Corp.
Headquarters
No. 2, Innovation Road II, Hsinchu Science Park,
Hsinchu, 300, Taiwan, R.O.C.
Tel: 886-3-5780211 Fax: 886-3-5776047
www.realtek.com.tw
