Realtek Semiconductor RTL8723AS 802.11b/g/n RTL8723AS combo module User Manual

Realtek Semiconductor Corp. 802.11b/g/n RTL8723AS combo module

User Manual

User’s Manual
Rev. 1.0
10 Jan. 2012
Realtek Semiconductor Corp.
No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan
Tel.: +886-3-578-0211. Fax: +886-3-577-6047
www.realtek.com.tw
RTL8723AS
RTL8723AS
User Manual of combo module
ii Rev.1.0
COPYRIGHT
© 2011 Realtek Semiconductor Corp. All rights reserved. No part of this document may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means without the written permission of Realtek Semiconductor Corp.
DISCLAIMER
Realtek provides this document “as is”, without warranty of any kind, neither expressed nor implied,
including, but not limited to, the particular purpose. Realtek may make improvements and/or changes in this
document or in the product described in this document at any time. This document could include technical
inaccuracies or typographical errors.
TRADEMARKS
Realtek is a trademark of Realtek Semiconductor Corporation. Other names mentioned in this document are
trademarks/registered trademarks of their respective owners.
USING THIS DOCUMENT
This document is intended for the software engineer’s reference and provides detailed programming
information.
Though every effort has been made to ensure that this document is current and accurate, more information
may have become available subsequent to the production of this guide. In that event, please contact your
Realtek representative for additional information that may help in the development process.
RTL8723AS
User Manual of combo module
iii Rev.1.0
Table of Contents
1. GENERAL DESCRIPTION ................................................................................................................................................ 1
1.1. .............................................................................................................................................................................................. 1
2. FEATURES ............................................................................................................................................................................... 1
1.2. ENVIRONMENTAL ............................................................................................................................................................ 5
1.2.1. Operating ............................................................................................................................................................... 5
1.2.2. Storage .................................................................................................................................................................... 5
1.3. FUNCTIONAL SPECIFICATIONS .......................................................................................................................................... 5
1.4. WARNING ........................................................................................................................................................................ 7
4.5.1 Federal Communication Commission Interference Statement ...................................................................................... 7
4.5.2 Industry Canada Statement .......................................................................................................................................... 8
4.5.3 NCC
警語
................................................................................................................................................................... 11
List of Tables
TABLE 2. FUNCTIONAL SPECIFICATIONS ........................................................................................................................................ 5
List of Figures
RTL8723AS
User Manual of combo module
1 Rev.1.0
1. General Description
1.1.
The Realtek is a highly integrated single-chip for 802.11n Wireless LAN and Bluetooth 2.1/3.0/4.0.It was
composed of MAC, baseband, and RF, providing a complete solution for a high-performance integrated
WLAN and BT. There are two kind of interface operation: one is SDIO for WLAN and UART for BT. The
other one is USB for both WLAN and BT.(USB multi-function)
The integration provides better coordination between 802.11 and Bluetooth, and with sophisticated
dynamic power control and packet traffic arbitration, is able to provide the best coexistence performance.
also integrates RF/PA/LNA for both of 802.11n and Bluetooth, so the external part numbers is reduced to
minimum.
The 802.11 part supports 150Mbps PHY rate and delivers reliable throughput from an extended distance.
The Bluetooth part supports latest 3.0+HS/4.0+LE operation and provides smooth user experience under all
usage scenarios. Optimized RF architecture and baseband algorithms provide superb performance and
lowest power consumption.
2. Features
2.1 General
68-pin QFN
CMOS MAC, Baseband PHY, and RF in a single chip for IEEE 802.11b/g/n compatible WLAN
Complete 802.11n solution for 2.4GHz band
72.2Mbps receive PHY rate and 72.2Mbps transmit PHY rate using 20MHz bandwidth
150Mbps receive PHY rate and 150Mbps transmit PHY rate using 40MHz bandwidth
Compatible with 802.11n specification
Backward compatible with 802.11b/g devices while operating in 802.11n mode
Qualified Bluetooth v2.1+EDR and v3.0+HS Systems
Support for v4.0 Bluetooth Low Energy
Integrated class1, class2, and class3 PA and modem in Bluetooth Controller
RTL8723AS
User Manual of combo module
2 Rev.1.0
Standards Supported
IEEE 802.11b/g/n compatible WLAN
IEEE 802.11e QoS Enhancement (WMM)
IEEE 802.11h TPC, Spectrum Measurement
802.11i (WPA, WPA2). Open, shared key, and pair-wise key authentication services
Cisco Compatible Extensions (CCX) for WLAN devices
Host Interface
SDIO for WLAN / UART for BT
Multi-function USB for WLAN and BT
WLAN MAC Features
Frame aggregation for increased MAC efficiency (A-MSDU, A-MPDU)
Low latency immediate High-Throughput Block Acknowledgement (HT-BA)
Long NAV for media reservation with CF-End for NAV release
PHY-level spoofing to enhance legacy compatibility
Power saving mechanism
Channel management and co-existence
Multiple BSSID feature allows the RTL8723AS to assume multiple MAC identities when used as a
wireless bridge
Transmit Opportunity (TXOP) Short Inter-Frame Space (SIFS) bursting for higher multimedia
bandwidth
WLAN PHY Features
IEEE 802.11n OFDM
One Transmit and one Receive path (1T1R)
20MHz and 40MHz bandwidth transmission
Short Guard Interval (400ns)
RTL8723AS
User Manual of combo module
3 Rev.1.0
DSSS with DBPSK and DQPSK, CCK modulation with long and short preamble
OFDM with BPSK, QPSK, 16QAM, and 640QAM modulation. Convolutional Coding Rate: 1/2, 2/3,
3/4, and 5/6
Maximum data rate 54Mbps in 802.11g and 150Mbps in 802.11n
Switch diversity for DSSS/CCK
Hardware antenna diversity
Selectable receiver FIR filters
Programmable scaling in transmitter and receiver to trade quantization noise against increased
probability of clipping
Fast receiver Automatic Gain Control (AGC)
On-chip ADC and DAC
BT Controller
Integrated MCU to execute Bluetooth protocol stack
Support 3 SCO links simultaneously
Support 3 scatternets
Enhanced BT/WIFI Coexistence Control to improve transmission quality in different profiles
Bluetooth Low Energy Dual Mode support
Bluetooth Transceiver Features
Fast AGC control to improve receiving dynamic range
Support AFH to dynamically detect channel quality to improve transmission quality
Integrated internal class1, class2, and class3 PA
Bluetooth 3.0 compliant
Bluetooth Low Energy supported
Integrated 32K oscillator
Peripheral Interfaces
General Purpose Input/Output (11 pins)
RTL8723AS
User Manual of combo module
4 Rev.1.0
4-wire EEPROM control interface (93C46)
Three configurable LED pins
Configurable Bluetooth Coexistence Interface
RTL8723AS
User Manual of combo module
5 Rev.1.0
1.2.
Environmental
1.2.1. Operating
Operating Temperature: 0 to 70 C
Relative Humidity: 5-90% (non-condensing)
1.2.2. Storage
Temperature: -55 to 125 C
Relevant Humidity: 5-95% (non-condensing)
1.3.
Functional Specifications
Table 1. Functional Specifications
Standards
WiFi:
IEEE 802.11b, IEEE 802.11g, Draft IEEE 802.11n, IEEE 802.11d,
IEEE 802.11e, IEEE 802.11h, IEEE 802.11i
BT:
BT v3.0, v4.0
Bus Interface
SDIO for WiFi and UART for BT
Multi-function USB for WiFi and BT
Form Factor
Half Size Mini Card
Data Rate
802.11b:
11, 5.5, 2, 1 Mbps;
802.11g:
54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n:
MCS 0 to 7 for HT20MHz;
MCS 0 to 7 for HT40MHz
BT:
1/2/3 Mbps
Media Access Control
WiFi:
CSMA/CA with ACK
WiFi + BT:
AFH, Time Division
Modulation Techniques
802.11b:
CCK, DQPSK, DBPSK
802.11g:
64 QAM, 16 QAM, QPSK, BPSK
802.11n:
BPSK, QPSK, 16-QAM, 64-QAM
BT:
GFSK, /4 DQPSK, 8DPSK
Network Architecture
WiFi:
Ad-hoc mode (Peer-to-Peer )
Infrastructure mode
RTL8723AS
User Manual of combo module
6 Rev.1.0
Operating Channel
WiFi 2.4GHz:
11: (Ch. 1-11) – United States
13: (Ch. 1-13) – Europe
13: (Ch. 1-14) – Japan
BT 2.4GHz:
Ch. 0 ~78
Frequency Range
2.400GHz ~ 2.4835 GHz
Security
WiFi :
WPA, WPA-PSK, WPA2, WPA2-PSK, WEP 64bit & 128bit, IEEE
802.11x, IEEE 802.11i
BT:
Simple Paring
Operating Voltage
3.3 V ±9% I/O supply voltage
RTL8723AS
User Manual of combo module
7 Rev.1.0
1.4.
Warning
4.5.1 Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator & your
body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through
11.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna,
3) For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by supplied
firmware programming tool. OEM shall not supply any tool or info to the end-user regarding to Regulatory Domain
change.
As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM
RTL8723AS
User Manual of combo module
8 Rev.1.0
integrator is still responsible for testing their end-product for any additional compliance requirements
required with this module installed (for example, digital device emissions, PC peripheral requirements,
etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the FCC authorization is no longer considered
valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will
be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC
authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20
cm may be maintained between the antenna and users. The final end product must be labeled in a visible
area with the following: “Contains FCC ID: TX2-RTL8723AS”.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
4.5.2 Industry Canada Statement
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the
following two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may cause undesired operation of the
device
French translation:
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts
de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire
de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage
susceptible de provoquer un fonctionnement indésirable.
This device has been designed to operate with an antenna having a maximum gain of 5dBi.
Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required
antenna impedance is 50 ohms.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that
the EIRP is not more than required for successful communication.
French translation:
Ce dispositif a été conçu pour fonctionner avec une antenne ayant un gain maximum de 5 dBi. Une antenne
à gain plus élevé est strictement interdite par les règlements d'Industrie Canada. L'impédance d'antenne
RTL8723AS
User Manual of combo module
9 Rev.1.0
requise est de 50 ohms.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peutfonctionner avec une
antenne d'un type et d'un gain maximal (ou inférieur) approuvé pourl'émetteur par Industrie Canada. Dans le
but de réduire les risques de brouillage radioélectriqueà l'intention des autres utilisateurs, il faut choisir le
type d'antenne et son gain de sorte que lapuissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l'intensité nécessaire àl'établissement d'une communication satisfaisante.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your
body.
French translation:
NOTE IMPORTANTE: (Pour l'utilisation de dispositifs mobiles)
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement
non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la
source de rayonnement et votre corps.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna,
3) For all products market in Canada, OEM has to limit the operation channels in CH1 to CH11 for 2.4G
band by supplied firmware programming tool. OEM shall not supply any tool or info to the end-user
regarding to Regulatory Domain change.
As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements
required with this module installed.
French translation :
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions suivantes: (Pour
utilisation de dispositif module)
1) L'antenne doit être installée de telle sorte qu'une distance de 20 cm est respectée entre l'antenne et les
utilisateurs, et
2) Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou antenne,
3) Pour tous les produits vendus au Canada, OEM doit limiter les fréquences de fonctionnement CH1 à
CH11 pour bandes de fréquences 2.4G grâce aux outils de microprogrammation fournis. OEM ne doit pas
RTL8723AS
User Manual of combo module
10 Rev.1.0
fournir d'outil ou d'informations à l'utilisateur final en ce qui concerne le changement de réglementation de
domaine.
Tant que les 3 conditions ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne seront pas
nécessaires. Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour
toutes exigences de conformité supplémentaires requis pour ce module installé.
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the IC authorization is no longer considered
valid and the IC ID can not be used on the final product. In these circumstances, the OEM integrator will be
responsible for re-evaluating the end product (including the transmitter) and obtaining a separate IC
authorization.
French translation:
NOTE IMPORTANTE:
Dans le cas où ces conditions ne peuvent être satisfaites (par exemple pour certaines configurations
d'ordinateur portable ou de certaines co-localisation avec un autre émetteur), l'autorisation du Canada n'est
plus considéré comme valide et l'ID IC ne peut pas être utilisé sur le produit final. Dans ces circonstances,
l'intégrateur OEM sera chargé de réévaluer le produit final (y compris l'émetteur) et l'obtention d'une
autorisation distincte au Canada.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20
cm may be maintained between the antenna and users. The final end product must be labeled in a visible
area with the following: “Contains IC: 6317A-RTL8723AS”.
French translation:
Plaque signalétique du produit final
Ce module émetteur est autorisé uniquement pour une utilisation dans un dispositif où l'antenne peut être
installée de telle sorte qu'une distance de 20cm peut être maintenue entre l'antenne et les utilisateurs. Le
produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC:
6317A-RTL8723AS ".
Manual Information To The End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
RTL8723AS
User Manual of combo module
11 Rev.1.0
French translation:
Manuel d'information à l'utilisateur final
L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à la façon
d'installer ou de supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre ce
module.
Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et avertissements
comme indiqué dans ce manuel.
4.5.3 NCC 警語
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功
率或變更原設計之特性及功能。
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並
改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電
機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
本模組於取得認證後將依規定於模組本體標示審合格籤。
系統廠商應於平台上標示「本產品內含射頻模組： XXXyyyLPDzzzz-x (NCC ID) 」字樣。
Realtek Semiconductor Corp.
Headquarters
No. 2, Innovation Road II, Hsinchu Science Park,
Hsinchu, 300, Taiwan, R.O.C.
Tel: 886-3-5780211 Fax: 886-3-5776047
www.realtek.com.tw
Page No.: 1 of 12
Antenna List
Page No.: 2 of 12
Table for Filed Antenna
No. Brand Ant.
Type
Con.
Type
Peak Gain
(dBi) Model No.
01 LYNwave PIFA IPEX 3.5 ALA110-222050-300010
02 JOYMAX Dipole IPEX 3.0 TWF-614XMPXX-500
03 ACON PIFA IPEX TX 1: -0.19
TX 2: -0.99 AWP6P
04 Yageo PIFA IPEX TX 1: -0.11
TX 2: 0.07
TX 1: CAN4313ZP0648WXA1
TX 2: CAN4313ZP0648WXA2
05 WNC PIFA IPEX TX 1: 1.32
TX 2: 1.50
TX 1: 81.EJT15.GVM
TX 2: 81.EJT15.GVN
06 Foxconn PIFA IPEX TX 1: 1.47
TX 2: 1.38 WDAN-T1WM
07 Hitachi PIFA IPEX Main: 2.19
Aux.: -0.33 HBY07
08 Hitachi PIFA IPEX Main: 2.91
Aux.: 2.82 HBY051
09 Hitachi PIFA IPEX TX 1: 0.27
TX 2: 0.02 HBY052
10 Hitachi PIFA IPEX TX 1: 1.30
TX 2: 2.42 HBY061
11 Hitachi PIFA IPEX TX 1: -1.04
TX 2: -1.19 HBY062
12 Hitachi PIFA IPEX TX 1: -1.74
TX 2: 1.16 HFT65
13 Hitachi PIFA IPEX TX 1: 0.87
TX 2: 1.94 HCT01
14 Hitachi PIFA IPEX TX 1: 0.58
TX 2: 1.12 HFT40
15 Hitachi PIFA IPEX TX 1: -1.65
TX 2: -0.92 HFT60
16 FOXCONN PIFA IPEX TX 1: -0.43
TX 2: -0.7 WDAN-TQ
17 WNC PIFA IPEX TX 1: 0.54
TX 2: 0.58
TX 1: 25.90AAP.011
TX 2: 25.90AAO.011
18 WNC PIFA IPEX
Main: 0.42
Aux.: 0.79
MIMO: 0.14
81.EJZ
19 WNC PIFA IPEX Main: 0.96
Aux.: -0.08 81.EJT
Page No.: 3 of 12
20 ETHERTRONICS PIFA IPEX TX 1: 0.12
TX 2: -3.87
TX 1: 5002011-1
TX 2: 5002012-1
21 ETHERTRONICS PIFA IPEX TX 1: 0.76
TX 2: 0.59
TX 1: 5002015-1
TX 2: 5002016-1
22 ETHERTRONICS PIFA IPEX TX 1: -1.76
TX 2: -2.61
TX 1: 5010011-1
TX 2: 5010012-1
23 ETHERTRONICS PIFA IPEX TX 1: -0.84
TX 2: -2.07
TX 1: 5010015-1
TX 2: 50100161
24 ACON PIFA IPEX TX 1: 0.00
TX 2: 1.89 AMP6P
25 WNC PIFA IPEX Main: -1.08
Aux.: -0.62 81.EJZ15.G52
26 WNC PIFA IPEX Main: -0.58
Aux.: -1.26 81.EJT15.GJC
27 WNC PIFA IPEX Main: 0.52
Aux.: 0.77 81.EJT15.GGW
28 WNC PIFA IPEX Main: -0.78
Aux.: -2.14 81.EJZ15.G53
29 QUANTA PIFA IPEX TX 1: -0.7
TX 2: -1.9
TX 1: AN-070-G(R)
TX 2: AN-070-G(L)
30 QUANTA PIFA IPEX TX 1: -0.3
TX 2: -1.9
TX 1: AN-070-G(R)
TX 2: AN-070-G(L)
31 QUANTA PIFA IPEX TX 1: -0.4
TX 2: -0.3
TX 1: AN-120-F(R)
TX 2: AN-120-F(L)
32 QUANTA PIFA IPEX TX 1: -1.8
TX 2: -4.4
TX 1: AN-120-F(R)
TX 2: AN-120-F(L)
33 JEM PIFA IPEX Main: 1.27
Aux.: -1.27
Main: IA-100193
Aux.: IA-100194
34 Tyco
(20-D1130002D) PIFA IPEX
TX1: -0.10
TX2: -0.92
TX 3: 0.56
TBN008
35 Smart Approach PIFA IPEX TX 1: 1.51
TX 2: 1.56 03-FR021-026
36 Hitachi Cable PIFA IPEX
TX 1: -0.42
TX 2: 0.59
TX 3: 1.24
HBY17
37 Hitachi PIFA IPEX TX 1: 2.97
TX 2: 0.90 HFT60
38 WNC PIFA IPEX TX 1: 0.30
TX 2: 0.94
TX 1: 25.90AAN.011
TX 2: 25.90AAM.011
Page No.: 4 of 12
39 Smart Approach PIFA IPEX TX 1: 1.66
TX 2: 1.83 03-FR021-020
40 WHAYU PIFA IPEX Main: -2.12
Aux.: -2.49 MSA-00005A
41 Toshiba PIFA IPEX -0.80 HFS23
42 Toshiba PIFA IPEX 0.64 HFS40
43 TYCO
(20238740-1) PIFA IPEX
TX 1: 0.47
TX 2: 0.06
TX 3: 1.65
TBN008
44 TYCO
(2023750-1) PIFA IPEX TX 1: 0.47
TX 2: 0.06 TBN008
45 TYCO
(2023772-1) PIFA IPEX
TX 1: -2.60
TX 2: -0.26
TX 3: -0.91
TBN008
46 TYCO PIFA IPEX
TX 1: 1.98
TX 2: 1.97
TX 3: -0.88
TBN007
47 TYCO PIFA IPEX
TX 1: 0.22
TX 2: 0.33
TX 3: 2.20
TBN009
48 TYCO PIFA IPEX
TX 1: 1.68
TX 2: 1.45
TX 3: 0.29
TBN010
49 Smart Approach PIFA IPEX TX 1: 2.37
TX 2: 1.59 03-FR021-016
50 Foxconn PIFA IPEX TX 1: 2.58
TX 2: 1.39
TX 1: WDAN-T1AM1001-DH
TX 2: WDAN-T1AM1002-DH
51 WNC PIFA IPEX Main: -2.76
Aux.: -3.64 WNC005
52 TYCO
(20238740-1) PIFA IPEX
TX 1: 0.47
TX 2: 0.06
TX 3: 1.65
TBN008
53 Toshiba PIFA IPEX TX 1: 0.28
TX 2: -0.83 TBN004
54 WNC PIFA IPEX Main: -1.10
Aux.: 1.76 WNC001
55 WNC PIFA IPEX Main: 1.18
Aux. 1.75 WNC002
56 Tyco PIFA IPEX Main: -1.11
Aux.: -1.11 TBN003
Page No.: 5 of 12
MIMO: -0.95
57 WNC PIFA IPEX Main: 2.40
Aux.: 1.50 WNC004
58 WNC PIFA IPEX Main: 1.19
Aux.: 0.28 WNC001
59 WNC PIFA IPEX Main: 0.52
Aux.: 1.07 WNC003
60 Quanta PIFA IPEX TX 1: 1.0
TX 2: 0.2 3ASP8AATP20
61 Quanta PIFA IPEX TX 1: -0.5
TX 2: -1.9 AS-070-F
62 Tyco PIFA IPEX
Main: 3.45
Aux: 2.41
MIMO: 1.04
TBN001
63 Well Green PIFA IPEX TX 1: 1.79
TX 2: 0.66
TX 1: SK81WMPB01+A
TX 2: SK81WMPB02+A
64 Tyco PIFA IPEX -1.11 TBN005 & TBN006
65 Well Green PIFA IPEX TX 1: -1.07
TX 2: -0.64 SKW31WMPB01+A
66 FVC PIFA IPEX WiMAX-1: 1.58
WiMAX2: 1.75 K05007012102
67 FVC PIFA IPEX WiMAX-1: 2.7
WiMAX-2: 2.19 K05007013402
68 Well Green PIFA IPEX TX 1: -1.84
TX 2: -2.93
TX 1: SKM11WMPB03+A
TX 2: SKM11WMPB02+D
69 FVC PIFA IPEX WiMAX-1: 1.84
WiMAX-2:1.8 N01001218001
70 Well Green PIFA IPEX TX 1: -1.63
TX 2: -0.99 SKW24WMPB01
71 FVC PIFA IPEX
TX 1: 2.05
TX 2: 1.88
TX 3: 3.04
TX 1: N01001199001
TX 2: N01001199001
TX 3: N01001182002
72 FVC PIFA IPEX TX1: 3.11
TX2: 0.55
TX1: N01001193001
TX2: N01001193001
73 WNC PIFA IPEX TX1: -0.61
TX2: 1.91
TX1: 25.90AAL.001
TX2: 25.90AAK.001
74 TE Connectivity PIFA IPEX TX1: 1.29
TX2: 0.04
TX1: 25.90AAL.011
TX2: 25.90AAK.011
75 TE Connectivity PIFA IPEX TX1: -0.01
TX2: 0.39
TX1: 25.90AAN.001
TX2: 25.90AAM.001
Page No.: 6 of 12
76 TE Connectivity PIFA IPEX TX1: 1.20
TX2: 0.65
TX1: 25.90AAP.001
TX2: 25.90AAO.001
77 Quanta PIFA IPEX TX1: 0.70
TX2: -1.40 35AX6AATP10
78 Quanta PIFA IPEX TX1: 1.80
TX2: -0.30 37LX6AATP00
79 Quanta PIFA IPEX TX1: 0.30
TX2: 1.70 37LX7AATP00
80 WNC PIFA IPEX TX1: -0.10
TX2: 2.30 WNC003
81 WNC PIFA IPEX TX1: 2.72
TX2: 2.66
TX1: 81.EJZ15.G94
TX2: 81.EJZ15.G95
82 WNC PIFA IPEX TX1: 1.33
TX2: 1.95
TX1: 81.EJZ15.G98
TX2: 81.EJZ15.G99
83 WNC PIFA IPEX TX1: 1.84
TX2: 1.64 81.EJZ15.GTP
84 WNC PIFA IPEX TX1: 2.36
TX2: 1.13
TX1: 81.EK515.G15
TX2: 81.EK515.G16
85 WNC PIFA IPEX TX1: 1.15
TX2: 0.59
TX1: DC33000YV20
TX2: DC33000YV30
86 WNC PIFA IPEX TX1: 0.79
TX2: -0.32
TX1: DC33000YV60
TX2: DC33000YV70
87 HONGLIN PIFA IPEX TX1: 1.85
TX2: 1.77 260-23249
88 Yageo PIFA IPEX TX1: -2.69
TX2: -1.09
TX1: 6036B0086801
TX2: 6036B0087101
89 WNC PIFA IPEX TX1: -1.30
TX2: -0.49
TX1: 6036B0086802 (81.EHC15.G63)
TX2: 6036B0087102 (81.EHC15.G64)
90 WNC PIFA IPEX TX1: 1.21
TX2: -0.07
TX1: 6036B0088203
TX2: 6036B0088303
91 WNC PIFA IPEX TX1: 2.34
TX2: 1.28
TX1: 6036B0087303
TX2: 6036B0087203
92 WNC PIFA IPEX TX1: 0.50
TX2: 0.12
TX1: 6036B0088203
TX2: 6036B0088303
93 Yageo PIFA IPEX TX1: 0.61
TX2: 0.71
TX1: 6036B0088401
TX2: 6036B0088501
94 Yageo PIFA IPEX TX1: 1.46
TX2: 0.95
TX1: 6036B0088901
TX2: 6036B0089001
95 WNC PIFA IPEX TX1: -1.11
TX2: -0.95
TX1: 6036B0091201
TX2: 6036B0091401
Page No.: 7 of 12
96 Yageo PIFA IPEX TX1: 0.80
TX2: 0.25
TX1: 6036B0091202
TX2: 6036B0091402
97 TE Connectivity PIFA IPEX TX1: -0.23
TX2: -0.49
TX1: 1556465-1
TX2: 1556466-1
98 TE Connectivity PIFA IPEX TX1: 1.29
TX2: 0.04
TX1: 1556495-1
TX2: 1556496-1
99 TE Connectivity PIFA IPEX TX1: -0.87
TX2: -1.24
TX1: 1556505-1
TX2: 1556506-1
100 ACON PIFA IPEX TX1: 1.96
TX2: 1.91
TX1: AMP8P-700186
TX2: AMP8P-700187
101 ACON PIFA IPEX TX1: 2.79
TX2: 0.74
TX1: APM8P-700016
TX2: APM8P-700017
102 ACON PIFA IPEX TX1: 2.66
TX2: 2.27
TX1: APM8P-700018
TX2: APM8P-700019
103 ACON PIFA IPEX TX1: 1.10
TX2: 1.99
TX1: APP8P-700341
TX2: APP8P-700342
104 Wha Yu PIFA IPEX TX1: -0.18
TX2: 2.58
TX1: C107-520757-A
TX2: C107-520756-A
105 Wellshine PIFA IPEX TX1: 1.17
TX2: -0.06 DQ67KJQUT33
106Wha Yu PIFA IPEX TX1: 1.74
TX2: 1.41
TX1: C435-520023-A
TX2: C435-520024-A
107Wha Yu PIFA IPEX TX1: 1.92
TX2: -1.03
TX1: C680-520278-A
TX2: C680-520277-A
108Wha Yu PIFA IPEX TX1: 1.09
TX2: -0.55 C680-520279-A
109Yageo PIFA IPEX TX1: 0.59
TX2: 0.90
TX1: CAN4313LC0613WLA3
TX2: CAN4313LC0613WLA4
110Yageo PIFA IPEX TX1: 0.97
TX2: 0.59
TX1: CAN4313LC0630WLA3
TX2: CAN4313LC0630WLA4
111Yageo PIFA IPEX TX1: 2.32
TX2: 1.85
TX1: CAN4313WICO03241
TX2: CAN4313WICO03242
112Yageo PIFA IPEX TX1: 0.23
TX2: 1.53
TX1: CAN43130WIFO04921
TX2: CAN43130WIFO04922
113WNC PIFA IPEX TX1: 0.18
TX2: 0.60
TX1: 81.EKG15.G38
TX2: 81.EKG15.G37
114WNC PIFA IPEX TX1: 0.54
TX2: -0.03
TX1: 81.EKG15.G41
TX2: 81.EKY15.G42
115Jess-Link PIFA IPEX TX1: 1.89
TX2: 1.56
TX1: PANT11A00008-1
TX2: PANT11A00009-1
Page No.: 8 of 12
116Jess-Link PIFA IPEX TX1: 1.84
TX2: 1.98
TX1: PANT11A00026-1
TX2: PANT11A00027-1
117ACON PIFA IPEX TX1: -0.70
TX2: -0.29 DQ60APM6P02
118ACON PIFA IPEX TX1: -0.60
TX2: -1.02 DQ60APM6P03
119Well Shine
(QUA) PIFA IPEX TX1: 1.66
TX2: 0.05
TX1: DQ67KJQUT35
TX2: DQ67KJQUT36
120Amphenol PIFA IPEX TX1: -1.41
TX2: -0.77 FL5202-11-001-C
121MAG. LAYERS PIFA IPEX 1.77 FPA-2423-25GC1-A1
122Amphenol PIFA IPEX TX1: 0.76
TX2: -2.11
TX1: FX5170-15-004-C
TX2: FX5170-15-001-C
123Amphenol PIFA IPEX TX1: 0.55
TX2: 0.31
TX1: IV5218-11-002-C
TX2: IV5218-11-001-C
124Amphenol PIFA IPEX TX1: 0.54
TX2: -0.53
TX1: IV5233-15-003-C
TX2: IV5233-15-002-C
125FVC PIFA IPEX TX1: 2.85
TX2: 1.29 K05007014701
126FAVORTRON PIFA IPEX TX1: 2.81
TX2: 1.97
TX1: N01001205001
TX2: N01001206001
127MAG. LAYERS PIFA IPEX 2.17 PCA-2111-25GC1-A1
128Wha Yu PIFA IPEX TX1: 2.43
TX2: -0.41 PSAM-002
129Quanta PIFA IPEX TX1: 1.6
TX2: 0.3 R12_AN-090-A/B
130Quanta PIFA IPEX TX1: 0.8
TX2: 0.4 R15_AN-090-A/B
131Quanta PIFA IPEX TX1: 1.5
TX2: 0.5 R18_AN-090-A/B
132Smart Approach PIFA IPEX TX1: 1.70
TX2: 1.53 SE-ECFKA-001
133Smart Approach PIFA IPEX TX1: 2.53
TX2: 2.92
TX1: SE-ECLA1-001
TX2: SE-ECLA1-002
134Tyco
(2023770-1) PIFA IPEX TX1: -2.60
TX2: -0.26 TBN008
135Tyco
(2023772-1) PIFA IPEX TX1: -2.60
TX2: -0.26 TBN008
136Foxconn PIFA IPEX TX1: -0.99
TX2: -0.09
TX1: WDAN-HMCH1401-DH
TX2: WDAN-HMCH1402-DH
Page No.: 9 of 12
137Foxconn PIFA IPEX TX1: -0.35
TX2: 0.38
TX1: WDAN-HMCH1501-DH
TX2: WDAN-HMCH1502-DH
138Foxconn PIFA IPEX TX1: -1.85
TX2: 1.33 WDAN-HMEDW005-DH
139Tyco PIFA IPEX TX1: -0.38
TX2: 1.04
TX1: 25.90A2G.021
TX2: 25.90A2H.021
140WNC PIFA IPEX TX1: 1.23
TX2: 0.29
TX1: 25.90A2G.001
TX2: 25.90A2H.001
141Yageo PIFA IPEX TX1: 0.48
TX2: -1.37
TX1: 25.90A2G.011
TX2: 25.90A2H.011
142Quanta PIFA IPEX TX1: 0.40
TX2: -1.00
TX1: QADCGC5_WL_M
TX2: QADCGC5_WL_A
143Quanta PIFA IPEX TX1: 0.10
TX2: -0.40
TX1: DQ6GC200100
TX2: DQ6GC200200
144Quanta PIFA IPEX TX1: -1.30
TX2: 0.70
TX1: DQ6GC300100
TX2: DQ6GC300200
145Quanta PIFA IPEX TX1: 0.7
TX2: 1.2
TX1: QADCGC6_WL_M
TX2: QADCGC6_WL_A
146ACON PIFA IPEX TX1: 1.84
TX2: 0.07
TX1: APP8P-700188
TX2: APP8P-700187
147ACON PIFA IPEX TX1: 1.84
TX2: 0.07
TX1: APP8P-700186
TX2: APP8P-700185
148Wha Yu PIFA IPEX TX1: 1.96
TX2: 1.97
TX1: C435-520044-A
TX2: C435-520043-A
149Wha Yu PIFA IPEX TX1: 1.91
TX2: 1.88
TX1: C435-520042-A
TX2: C435-520045-A
150ACON PIFA IPEX TX1: -0.96
TX2: -0.86
TX1: APM6P-700033
TX2: APM6P-700034
151Amphenol PIFA IPEX TX1: -1.85
TX2: -1.60
TX1: 14G152168231LV
TX2: 14G152168131LV
152ACON PIFA IPEX TX1: -1.32
TX2: -0.23
TX1: APM6P-700027
TX2: APM6P-700029
153Tyco PIFA IPEX TX1: -2.39
TX2: 1.52
TX1: 2023940-1
TX2: 2023944-1
154ACON PIFA IPEX TX1: -1.16
TX2: -0.74
TX1: APM6P-700028
TX2: APM6P-700030
155Tyco PIFA IPEX TX1: -0.58
TX2: -0.11
TX1: 2023946-1
TX2: 2023950-1
156Amphenol PIFA IPEX TX1: 1.61
TX2: 1.57
TX1: LX-0980-11-000-R
TX2: LX-0983-11-000-R
Page No.: 10 of 12
157NISSEI PIFA IPEX TX1: 1.35
TX2: 1.99
TX1: 3172525
TX2: 3172566
158ACON PIFA IPEX TX1: -0.39
TX2: 0.64
TX1: 25.90675.001
TX2: 25.90676.001
159WNC PIFA IPEX TX1: -1.53
TX2: 1.32
TX1: 25.90669.001
TX2: 25.90670.001
160WNC PIFA IPEX TX1: 1.94
TX2: -0.85
TX1: 25.90A1E.001
TX2: 25.90A1F.001
161WNC PIFA IPEX TX1: 1.89
TX2: -0.90
TX1: 25.90A1E.001
TX2: 25.90A1F.001
162Yageo PIFA IPEX TX1: 1.94
TX2: 1.78
TX1: 25.90A1E.011
TX2: 25.90A1F.011
163WNC PIFA IPEX TX1: 0.51
TX2: 1.73
TX1: 25.91370.021
TX2: 25.91371.021
164Yageo PIFA IPEX TX1: 1.06
TX2: 0.16
TX1: 25.91370.011
TX2: 25.91371.011
165Tyco PIFA IPEX TX1: 0.06
TX2: 0.18
TX1: 25.90A4C.021
TX2: 25.90A4D.021
166WNC PIFA IPEX TX1: 1.52
TX2: -0.60
TX1: 25.90A4C.001
TX2: 25.90A4D.001
167Yageo PIFA IPEX TX1: 0.93
TX2: -0.17
TX1: 25.90A4C.011
TX2: 25.90A4D.011
168NISSEI PIFA IPEX TX1: 1.88
TX2: 1.26
TX1: 3209970
TX2: 3210002
169ACON PIFA IPEX TX1: -0.04
TX2: 1.16
TX1: 25.90929.001
TX2: 25.90930.001
170Ethertronics PIFA IPEX TX1: 0.60
TX2: -0.59
TX1: 25.90934.001
TX2: 25.90935.001
171WNC PIFA IPEX TX1: 0.87
TX2: -0.93
TX1: 25.90919.001
TX2: 25.90920.001
172WNC PIFA IPEX TX1: 0.60
TX2: -0.59
TX1: 25.90934.001
TX2: 25.90935.001
173Quanta PIFA IPEX TX1: 0.10
TX2: -0.30
TX1: QADC FL8_WL_M
TX2: QADC FL8_WL_A
174Quanta PIFA IPEX TX1: -0.1
TX2: -0.1
TX1: QADCFL3_WL_M
TX2: QADCFL3_WL_A
175Amphenol PIFA IPEX TX1: 1.47
TX2: 1.68
TX1: LX0970-11-000-R
TX2: LX0968-11-000-R
176FOXCONN PIFA IPEX TX1: -0.40
TX2: 1.10
TX1: WDAN-L1ML3001-DF
TX2: WDAN-L1ML3002-DF
Page No.: 11 of 12
177NISSEI PIFA IPEX TX1: 0.54
TX2: 1.80
TX1: 3172467
TX2: 3172509
178ACON PIFA IPEX TX1: 1.17
TX2: 1.04
TX1: 25.90598.001
TX2: 25.90597.001
179WNC PIFA IPEX TX1: 1.94
TX2: 0.59
TX1: 25.90587.001
TX2: 25.90586.001
180WNC PIFA IPEX TX1: -1.21
TX2: 1.27
TX1: 25.90700.001
TX2: 25.90702.001
181ACON PIFA IPEX TX1: 1.37
TX2: 1.21
TX1: 25.90800.001
TX2: 25.90802.001
182Yageo PIFA IPEX TX1: 0.07
TX2: -0.06
TX1: 25.90A4W.001
TX2: 25.90A4V.001
183FOXLINK PIFA IPEX TX1: 1.98
TX2: 1.97
TX1: 25.90A4W.011
TX2: 25.90A4V.011
184Amphenol PIFA IPEX TX1: -0.37
TX2: -2.64
TX1: C-1334-11-000-26
TX2: C-1335-11-000-26
185WNC PIFA IPEX TX1: 0.77
TX2: 0.74
TX1: 25.90979.001
TX2: 25.90980.001
186Amphenol PIFA IPEX TX1: 0.35
TX2: -1.20
TX1: C-1952-11-000-26
TX2: C-1953-11-000-26
187Amphenol PIFA IPEX TX1: -1.31
TX2: -3.09
TX1: C-2238-11-000-26
TX2: C-2239-11-000-26
188Foxconn PIFA IPEX TX1: 1.14
TX2: 0.61
TX1: WDAN-LFNZ3001-DH
TX2: WDAN-LFNZ3002-DH
189Amphenol PIFA IPEX TX1: 0.35
TX2: -1.20
TX1: C-3033-11-000-26
TX2: C-3034-11-000-26
190Amphenol PIFA IPEX TX1: -1.31
TX2: -3.09
TX1: C-3068-11-000-26
TX2: C-3069-11-000-26
191Foxconn PIFA IPEX TX1: -0.11
TX2: 0.35
TX1: WDAN-L1NZ4003-DH
TX2: WDAN-L1NZ4004-DH
192Foxconn PIFA IPEX TX1: -0.11
TX2: 0.35
TX1: WDAN-L1NZ4001-DH
TX2: WDAN-L1NZ4002-DH
193Tyco PIFA IPEX TX1: 0.64
TX2: -0.92
TX1: 1556219-1
TX2: 1556220-1
194ACON PIFA IPEX TX1: 2.00
TX2: 0.13
TX1: APP8P-700191
TX2: APP8P-700192
195ACON PIFA IPEX TX1: 2.00
TX2: 0.13
TX1: APP8P-700189
TX2: APP8P-700190
196Tyco PIFA IPEX TX1: 0.64
TX2: -0.92
TX1: 1556216-1
TX2: 1556215-1
Page No.: 12 of 12
197ACON PIFA IPEX TX1: -0.42
TX2: -0.13
TX1: 25.90653.001
TX2: 25.90654.001
198WNC PIFA IPEX TX1: -0.52
TX2: 0.31
TX1: 25.90649.001
TX2: 25.90650.001
199Quanta PIFA IPEX TX1: -0.10
TX2: 0.00
TX1: QADC PS3_WL_M
TX2: QADC PS3_WL_A
200Foxconn PIFA IPEX TX1: 1.16
TX2: -0.88
TX1: 024-01F0-2242
TX2: 024-01F0-2243
201NISSEI PIFA IPEX TX1: -0.83
TX2: -0.61
TX1: 3176658
TX2: 3176674
202Amphenol PIFA IPEX TX1: -1.54
TX2: -2.93
TX1: C-2381-11-000-26
TX2: C-2382-11-000-26
203Foxconn PIFA IPEX TX1: 0.87
TX2: 0.49
TX1: WDAN-LWSN3001-DH
TX2: WDAN-LWSN3002-DH
204Foxconn PIFA IPEX TX1: 1.71
TX2: 1.43
TX1: WDAN-L1WK1001-DF
TX2: WDAN-L1WK1002-DF
205Hitachi PIFA IPEX TX1: 1.82
TX2: 1.54
TX1: HMT14-MAIN
TX2: HMT14-AUX
206ACON PIFA IPEX TX1: -1.21
TX2: 1.27
TX1: 25.90700.001
TX2: 25.90702.001
207ACON PIFA IPEX TX1: 1.37
TX2: 1.21
TX1: 25.90800.001
TX2: 25.90802.001
208Quanta PIFA IPEX TX1: -0.5
TX2: -1.4
TX1: QADCPS1_WL_M
TX2: QADCPS1_WL_A
209WNC PIFA IPEX TX1: 0.30
TX2: 0.39
TX1: 81.EK515.G13
TX2: 81.EK515.G14
210ZTX PIFA IPEX TX1: 2.01
TX2: 1.69 ZTX-A162-Q18000-00

Navigation menu
