Realtek Semiconductor RTL8812AE 802.11a/b/g/n/ac RTL8812AE miniCard User Manual
Realtek Semiconductor Corp. 802.11a/b/g/n/ac RTL8812AE miniCard
user manual
Half Mini-Card User’s Manual
Rev. 1.0
29 November 2012
Realtek Semiconductor Corp.
No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan
Tel.: +886-3-578-0211. Fax: +886-3-577-6047
www.realtek.com.tw
RTL8812AE
RTL8812AE
Half Mini-Card User Manual
ii Rev.1.0
COPYRIGHT
©2012 Realtek Semiconductor Corp. All rights reserved. No part of this document may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means without the written permission of Realtek Semiconductor Corp.
DISCLAIMER
Realtek provides this document “as is”, without warranty of any kind. Realtek may make improvements and/or
changes in this document or in the product described in this document at any time. This document could include
technical inaccuracies or typographical errors.
TRADEMARKS
Realtek is a trademark of Realtek Semiconductor Corporation. Other names mentioned in this document are
trademarks/registered trademarks of their respective owners.
USING THIS DOCUMENT
This document is intended for the software engineer’s reference and provides detailed programming
information.
Though every effort has been made to ensure that this document is current and accurate, more information may
have become available subsequent to the production of this guide.
RTL8812AE
Half Mini-Card User Manual
iii Rev.1.0
Table of Contents
1. GENERAL DESCRIPTION................................................................................................................................................ 1
2. FEATURES........................................................................................................................................................................... 1
3. PRODUCT SPECIFICATIONS.......................................................................................................................................... 3
3.1. ENVIRONMENTAL ............................................................................................................................................................. 3
3.1.1. Operating ............................................................................................................................................................... 3
3.1.2. Storage.................................................................................................................................................................... 3
3.2. FUNCTIONAL SPECIFICATIONS .......................................................................................................................................... 3
3.3. WARNING......................................................................................................................................................................... 5
3.3.1 Federal Communication Commission Interference Statement ...................................................................................... 5
3.3.2 Industry Canada Statement .......................................................................................................................................... 6
3.3.3 NCC
警語
..................................................................................................................................................................... 7
List of Tables
TABLE 2. FUNCTIONAL SPECIFICATIONS ......................................................................................................................................... 3
RTL8812AE
Half Mini-Card User Manual
1 Rev.1.0
1. General Description
The Realtek RTL8812AE is a highly integrated single-chip MIMO (Multiple In, Multiple Out) Wireless LAN
(WLAN) PCI Express network interface controller complying with the wireless very high throughput IEEE
802.11ac Draft 2.0 and high throughput 802.11n specification. The RTL8812AE provides a complete solution
for a high-performance wireless client and also supports WiFi Direct feature that can easily build a WiFi P2P
PAN network.
The RTL8812AE baseband implements Multiple Input, Multiple Output (MIMO) Orthogonal Frequency
Division Multiplexing (OFDM) with two transmit and two receive paths (2T2R). Features include two spatial
stream transmissions, short Guard Interval (GI) of 400ns, spatial spreading, and support for 20MHz, 40MHz
and 80MHz channel bandwidth. Moreover, RTL8812AE provides one spatial stream space-time block code
(STBC), Transmit Beamforming (TxBF) and Low Density Parity Check (LDPC) to extend the range of
transmission. At the receiver, extended range and good minimum sensitivity is achieved by having receiver
diversity up to 2 antennas. As the recipient, the RTL8812AE also supports explicit sounding packet feedback
that helps senders with beamforming capability. With 2 independent RF blocks, the RTL8812AE can perform
fast roaming without link interruption.
For legacy compatibility, Direct Sequence Spread Spectrum (DSSS), Complementary Code Keying (CCK) and
OFDM baseband processing are included to support all IEEE 802.11b, 802.11g and 802.11a data rates.
Differential phase shift keying modulation schemes, DBPSK and DQPSK with data scrambling capability are
available, and CCK provides support for legacy data rates, with long or short preamble. The high speed
FFT/IFFT paths, combined with BPSK, QPSK, 16QAM, 64QAM and 256QAM modulation of the individual
subcarriers, and rate compatible coding rate of 1/2, 2/3, 3/4, and 5/6, provide up to 866.7Mbps for IEEE
802.11ac MIMO OFDM.
The RTL8812AE builds in an enhanced signal detector, an adaptive frequency domain equalizer, and a
soft-decision Viterbi decoder to alleviate severe multi-path effects and mutual interference in the reception of
multiple streams. For better detection quality, receive diversity with Maximal-Ratio-Combine (MRC) applying
up to two receive paths is implemented. Robust interference detection and suppression are provided to protect
against Bluetooth, cordless phone, and microwave oven interference.
Receive vector diversity for multi-stream application is implemented for efficient utilization of the MIMO
channel. Efficient IQ-imbalance, DC offset, phase noise, frequency offset, and timing offset compensations are
provided for the radio frequency front-end. Selectable digital transmit and receive FIR filters are provided to
meet transmit spectrum mask requirements and to reject adjacent channel interference, respectively.
The RTL8812AE supports fast receiver Automatic Gain Control (AGC) with synchronous and asynchronous
control loops among antennas, antenna diversity functions, and adaptive transmit power control functions to
obtain better performance in the analog portions of the transceiver.
RTL8812AE
Half Mini-Card User Manual
2 Rev.1.0
The RTL8812AE MAC supports 802.11e for multimedia applications, 802.11i and WAPI (Wireless
Authentication Privacy Infrastructure) for security, and 802.11n/802.11ac Draft 2.0 for enhanced MAC
protocol efficiency. Using packet aggregation techniques such as A-MPDU with BA and A-MSDU, protocol
efficiency is significantly improved. Power saving mechanisms such as Legacy Power Save, U-APSD, and
MIMO power saving reduce the power wasted during idle time, and compensate for the extra power required to
transmit MIMO OFDM. The RTL8812AE provides simple legacy, 20MHz/40MHz/80MHz co-existence
mechanisms to ensure backward and network compatibility.
RTL8812AE
Half Mini-Card User Manual
1 Rev.1.0
2. Features
General
QFN76 9x9mm package
CMOS MAC, Baseband PHY and RF in a
single chip for IEEE 802.11a/b/g/n/ac Draft
2.0 compatible WLAN
802.11ac MIMO solution for 5G band
Complete 802.11n MIMO solution for
2.4GHz and 5Ghz band
2x2 MIMO technology for extended reception
robustness and exceptional throughput
Maximum PHY data rate up to 173.3 Mbps
using 20MHz bandwidth, 400Mbps using
40MHz bandwidth, and 866.7Mbps using
80MHz bandwidth.
Backward compatible with 802.11a/b/g
devices while operating at 802.11n data rates
Backward compatible with 802.11a/n devices
while operating at 802.11ac data rates.
Host Interface
Complies with PCI Express Base Specification
Revision 1.1
Standards Supported
IEEE 802.11a/b/g/n/ac Draft 2.0 compatible
WLAN
IEEE 802.11e QoS Enhancement (WMM)
IEEE 802.11i (WPA, WPA2). Open, shared
key, and pair-wise key authentication services
IEEE 802.11h TPC, Spectrum Measurement
IEEE 802.11k Radio Resource Measurement
WAPI (Wireless Authentication Privacy
Infrastructure) certified.
Cisco Compatible Extensions (CCX) for
WLAN devices
MAC Features
Frame aggregation for increased MAC
efficiency (A-MSDU, A-MPDU)
Low latency immediate High-Throughput
Block Acknowledgement (HT-BA)
Long NAV for media reservation with CF-End
for NAV release
PHY-level spoofing to enhance legacy
compatibility
MIMO power saving mechanism
Channel management and co-existence
Multiple BSSID feature allows the
RTL8812AE-CG to assume multiple MAC
identities when used as a wireless bridge
Transmit Opportunity (TXOP) Short
Inter-Frame Space (SIFS) bursting for higher
multimedia bandwidth
WiFi Direct supports wireless peer to peer
applications.
Other Features
Supports Wake-On-WLAN via Magic Packet
and Wake-up frame
Transmit Beamforming
CCA on secondary through RTS/CTS
handshake.
Support TCP/UDP/IP checksum offload
RTL8812AE
Half Mini-Card User Manual
2 Rev.1.0
Peripheral Interfaces
Up to 12 General Purpose Input/Output pins
Three configurable LED pins (mux with GPIO
pins)
Configurable Bluetooth Coexistence Interface
(mux with GPIO pins)
Generates 40MHz clock for peripheral chip.
Single external power source 3.3V only
PHY Features
IEEE 802.11ac MIMO OFDM
IEEE 802.11n MIMO OFDM
Two Transmit and Two Receive paths
5MHz / 10MHz / 20MHz / 40MHz / 80MHz
bandwidth transmission
Support 2.4Ghz and 5Ghz band channels
Short Guard Interval (400ns)
Sounding packet.
DSSS with DBPSK and DQPSK, CCK
modulation with long and short preamble
OFDM with BPSK, QPSK, 16QAM, 64QAM
and 256QAM modulation. Convolutional
Coding Rate: 1/2, 2/3, 3/4, and 5/6
Maximum data rate 54Mbps in 802.11g,
300Mbps in 802.11n and 866.7Mbps in
802.11ac.
OFDM receive diversity with MRC using up to
2 receive paths. Switch diversity used for
DSSS/CCK
Support STBC
Support LDPC
Hardware antenna diversity
Selectable digital transmit and receiver FIR
filters
Programmable scaling in transmitter and
receiver to trade quantization noise against
increased probability of clipping
Fast receiver Automatic Gain Control (AGC)
On-chip ADC and DAC
Build-in both 2.4GHz and 5GHz PA
Build-in both 2.4GHz and 5GHz LNA
RTL8812AE
Half Mini-Card User Manual
3 Rev.1.0
3. Product specifications
3.1.
Environmental
3.1.1. Operating
Operating Temperature: 0 to 70 C
Relative Humidity: 5-90% (non-condensing)
3.1.2. Storage
Temperature: -55 to 125 C
Relevant Humidity: 5-95% (non-condensing)
3.2.
Functional Specifications
Table 1. Functional Specifications
Standards
IEEE 802.11a/b/g/n/e/i/h/k/r/draft-ac
Bus Interface
PCI Express
Form Factor
Half Size Mini Card
Data Rate
802.11b:
11, 5.5, 2, 1 Mbps;
802.11g:
54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n:
MCS 0 to 15 for HT20MHz;
MCS 0 to 15 for HT40MHz
802.11ac:
MCS 0 to 8 for HT20MHz;
MCS 0 to 9 for HT40MHz;
MCS 0 to 9 for HT80MHz
Media Access Control
CSMA/CA with ACK
Modulation Techniques
802.11b:
CCK, DQPSK, DBPSK
802.11a/g/n:
64 QAM, 16 QAM, QPSK, BPSK
802.11ac:
256QAM, 64 QAM, 16 QAM, QPSK, BPSK
Network Architecture
WiFi:
Ad-hoc mode (Peer-to-Peer )
Infrastructure mode
RTL8812AE
Half Mini-Card User Manual
4 Rev.1.0
Operating Channel
WiFi 2.4GHz:
11: (Ch. 1-11) – United States
13: (Ch. 1-13) – Europe
14: (Ch. 1-14) – Japan
WiFi 5GHz:
20MHz band width :
Ch 36, 40, 44, 48,
Ch 52, 56, 60, 64,
Ch 100, 104, 108, 112, 116, 120, 124, 128,132,136, 140,
Ch 149,153, 157,161, 165.
40MHz band width :
Ch 38, 46,
Ch 54, 62,
Ch 102, 110, 118, 126, 134,
Ch 151, 159.
80MHz band width :
Ch 42
Ch 58
Ch 105, 122
Ch 155.
Frequency Range
2.400GHz ~ 2.4835 GHz
5.1500GHz ~ 5.3500GHz
5.4700GHz ~ 5.7250GHz
5.7250GHz ~ 5.8500GHz
Security
WPA, WPA-PSK, WPA2, WPA2-PSK, WEP 64bit & 128bit, IEEE
802.11x, IEEE 802.11i
Operating Voltage
3.3 V ±9% I/O supply voltage
RTL8812AE
Half Mini-Card User Manual
5 Rev.1.0
3.3.
Warning
3.3.1 Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Operations in the 5.15-5.25GHz band are restricted to indoor usage only.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through 11.
This device is intended only for OEM integrators under the following conditions:
1.)The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2.)The transmitter module may not be co-located with any other transmitter or antenna,
3.)For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by
supplied firmware programming tool. OEM shall not supply any tool or info to the end-user regarding to
Regulatory Domain change.
As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements required
with this module installed (for example, digital device emissions, PC peripheral requirements, etc.).
RTL8812AE
Half Mini-Card User Manual
6 Rev.1.0
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the FCC authorization is no longer considered
valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be
responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC
authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm
may be maintained between the antenna and users. The final end product must be labeled in a visible area with
the following: “Contains FCC ID: TX2-RTL8812AE”.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
3.3.2 Industry Canada Statement
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following
two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may cause undesired operation of the
device
This device has been designed to operate with an antenna having a maximum gain of 5dBi.
Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required
antenna impedance is 50 ohms.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the
EIRP is not more than required for successful communication.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
This device is intended only for OEM integrators
under the following conditions:
The transmitter module may not be co-located with any other transmitter or antenna.
RTL8812AE
Half Mini-Card User Manual
7 Rev.1.0
As long as conduction above is met, further transmitter test will not be required. However, the OEM integrator
is still responsible for testing their end-product for any additional compliance requirements required with this
module installed (for example, digital device emissions, PC peripheral requirements, etc.). The antenna must be
installed such that 20 cm is maintained between the antenna and users.
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the IC authorization is no longer considered valid
and the IC ID can not be used on the final product. In these circumstances, the OEM integrator will be
responsible for re-evaluating the end product (including the transmitter) and obtaining a separate IC
authorization.
End Product Labeling
The final end product must be labeled in a visible area with the following: “Contains IC :
6317A-RTL8812AE”.
Manual Information That Must be Included
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove.
This RF module in the user’s manual of the end product which integrates this module.
The user’s manual for OEM Integrators must include the following information in a prominent location
“IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements. The antenna must not be
co-located or operating in conjunction with any other antenna or transmitter”.
3.3.3 NCC 警語
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大
功率或變更原設計之特性及功能。
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，
並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射
頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
5.25 ~ 5.35GHz 限室內使用
Note:
1. 本模組於取得認證後將依規定於模組本體標示審合格籤。
2. 系統廠商應於平台上標示「本產品內含射頻模組： XXXyyyLPDzzzz-x (NCC ID) 」字樣。
RTL8812AE
Half Mini-Card User Manual
8 Rev.1.0
Realtek Semiconductor Corp.
Headquarters
No. 2, Innovation Road II, Hsinchu Science Park,
Hsinchu, 300, Taiwan, R.O.C.
Tel: 886-3-5780211 Fax: 886-3-5776047
www.realtek.com.tw
