Reflying Electronic CY2376PPWIR PowerBase Wireless Desk Charger User Manual 1
Shenzhen Reflying Electronic Co., Ltd. PowerBase Wireless Desk Charger 1
Users Manual
Wireless Charger
Use Manual
Product Introduction
Wireless charger is an intelligent product, with simple design and compatible
with any mobile phones with Qi standard. Mobile phone is without plug when
charging, which is more convenient and efficient . It can bring you with
limitless life experience as well as safe and free experience with wireless
charging function.
Product Outline
LED
indicator area
Aviation
aluminum shell
Frosted PC plate
Applicable Devices
1, Devices with built-in wireless charging receiver(Nokia 1520,LG,Nexus 5
and more).
2, Devices with reserved wireless charging interface beside it
battery(Samsung Galaxy S3,S4,S5,S6,S7,Note2,Note3,Note4,Note5,etc).
3.Devices with wireless charging receiver in its protection
case(iPhone5/5s,iPhone6,iPhone6 plus,iPhone7,iPhone8,iPhoneX,etc).
Note:All devices must be Qi standard.
Input Port of Power Supply
Non-slip Pads
Instructions
1, Insert one end of USB charging cable into power adaptor or computer.
shown as below.
Power adaptor should be 5V 2A, 9V 1.67A with PD function.
2. Insert another end of USB
charging cable into Micro USB port
of the wireless charger. The LED
indicator lights up to indicate well
connectivity.
3. Place your phone on the wireless
charger. Make sure that the phone
is well located at the charging area
of wireless charger. When the
phone is being charged. the LED
indicator will light up automatically
to show charging status.
Wireless Charger
USB cable
User Manual
Standard Accessories
Input: 9V/1.67A
5V/2A
Output: 5V/2A (max)
9V/1.47A(max)
Charging Distance:≤8mm
Charging Efficiency:≥76%
Size:Φ100mm X 5MM
Product Specification
1, Please keep the charger away from water or other liquid.
2.If you need to clean the charger, please make sure it is not connected power
supply.
3. Using Environment temperature remains 0-45℃
Attention:
NOTE: This equipment has been tested and found to comply with the limits for a
wireless power charger, pursuant to Part 18 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.”
This equipment has been tested and found to comply with the limits for a WPC device,
pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
“CAUTION: Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the product.”
