Reiie intelligent technology RT610 Active Bluetooth In-Ear Headphones User Manual RT610 1 1
Shenzhen Reiie intelligent technology Co., ltd Active Bluetooth In-Ear Headphones RT610 1 1
User Manual
说明书成品尺寸: 63mmx91mm, 80g铜版纸
RT 610
RT 610 说明书
63mm X91mm 12p 2017/11/15
Ben
VER: 1.1
Long press (+)
Next song
Long press (-)
Last song
Short press (+)
Volume +
Short press (-)
Volume -
Thanks for your purchase of 1Mii Active Bluetooth
In-Ear Headphones, the first choice for freedom
when you play sports. With the magnet, the
earpieces can be hold together like a necklace
to prevent headphone from falling off. The 1Mii lasts
up to 9 hours on a 1-hour charge. 1Mii Active
Bluetooth In-Ear Head phones with high sensitive
microphone provide the best quality voice
transmission, IPX4 waterproof, Android and iOS
compatible.
Model : 1Mii C01
Transmission distance : 10 meters
Working time : 9 hours
Charging time : about 1 hours
Charging Voltage : DC5V
Operating Voltage : DC3.3V-4.2V
Sleeping Current : 700uA
Power off Current : 2uA
Charging Current : 100mA
Bluetooth Standard : V4.1
Battery Capaciy : 120mAH
Weight :28g
Dimension : 42*56*30mm
Stereo Audio : APT-X
Response Frequency : 20HZ-20KHZ
Speaker Impedance :
Support Agreements : HSP, HFP, A2DP and AVRCP
Double click the center button to call the last
phone number dialed on your phone.
Short press + means V +, Short press - means V -.
Built-in Bluetooth CSR8645 solution
Bluetooth A2DP wireless Stereo
Built-in DSP to is olate the echo and noise
The Magnetic adsorption
Hands-free calls, reconnect with latest connection
Device automatically.
Waterproof, IPX4
Finished the connection with the first Phone, then turn
off the Phone's Bluetooth function.
Turn one the Bluetooth function of the first Phone, and
it will reconnect automatically.
Searching the device name "1Mii C01" in the second
Phone's Bluetooth device list and pairing.
Long press + means next song, Long press - means
last song.
Magnetic adsorption
LED indicator
Incoming call - Press and hold the center button
for 3 seconds to ignore the incoming call.
Incoming call - Press the center button once to
answer the call and press it again to hang up.
Long press 3s
Double click
MiddleSmall Big
Function
Power Saving Mode: When no music is playing, the
headphones will power off automatically to conserve
battery life.
Connect the charging cable to the USB port on the
headphones. A red LED is displayed to indicate that
the headphones are charging. The red LED will
disappear when the headphones are fully charged.
ChargingAnswer / HangupExchange Song / Volume Connect 2 phones Specifications
Product Features
Try wearing headphones Power on/off
Always dispose the used appliance at
a recycling center. Do not dispose the
used appliance together with the
household waste.
Note:
In line with the policy of continued development,
the manufacturer reserves the right to amend The
specifications without prior notification. The illustrations
in the usermanual are for reference only. Please
operate according to the real design.
Disposal
On your phone, enable Bluetooth and search / connect
to, "1Mii C01". The Blue LED will begin to flash at a slower
pace, indicating a connection was established.
1Mii C01
1Mii C01
1Mii C01
1Mii C01
Ear Tip
Left Earphone
Ear Hook
Right Earphone
LED indicator
Cable Clip
Vol+ / Next
Pause/Play
Vol- /
Previous
Enter pairing mode:
1.
Hold on play button for 5S, the Earphones will powered
on and enter pairing mode ,the Red and Blue LED will
flash alternately at the same time.
2.
Hold on play button for 2S to powered on, if the
earphones can not connect your phone automatically
in
10 seconds, short press play button , the earphones
will
enter pairing mode.
Connection
The Red and Blue LED flash alternately
Play button
The Red and Blue LED flash alternately
Long press 5S to Power off
Hold on for 5S to pair
Power on
Power off
Hold on for 1-2S to power on
Insert the earphone in to the ear canal gently and the soft
material earphone hook can be very easy to adapt to the
curvature of the ear.
There are three different sizes of Ear Tip to provide for your
choice (Middle size ear tips has been already pre assembled
on headphones)
North America:
E-mail: Support@1mii.com (US)
Support-ca@1mii.com (CA)
Europe:
E-mail: Support-uk@1mii.com (UK)
Support-de@1mii.com (DE)
Support-fr@1mii.com (FR)
Support-es@1mii.com (ES)
Support-it@1mii.com (IT)
Asia:
E-mail: Support-jp@1mii.com (JP)
Global customer services:
Red and Blue LED
flashing alternately
Blue LED 5S flashing
Blue LED 10S flashing
Red LED flashing
Red LED on
State LED behaviors
Pairing mode
No device connected
Device connected
Low battery
Charging battery
FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
