Remotesolution CRB61A Low Power Communications Transmitter User Manual
Remote Solution Co., Ltd. Low Power Communications Transmitter
User Manual
Enhance your
XFINITY® TV
experience with the
Aim Anywhere™
Adapter!
Pair your adapter and XFINITY
Remote to get started.
Your XFINITY Remote can be paired
with the Aim Anywhere Adapter
(also known as the XR8) allowing
you to control your set-top box or
DTA even when the device is placed
out of line-of-sight (for example, in
an entertainment center or behind
your TV). XFINITY Remotes can be
identied by an XR model number on
the back of the remote.
See the “Compatible Devices” section
on the back of this user guide to
verify that your set-top box or DTA
and remote are compatible with the
adapter.
To pair your XFINITY Remote with
the Aim Anywhere Adapter, follow the
steps below.
HERE’S HOW:
1. Turn on your TV and set-top box
or DTA.
2. Plug the Aim Anywhere Adapter
into the IR Input port* located on
the rear panel of your set-top box
or DTA.
*Note: This port may also be la-
beled IR, IR-In, IR Receive, or EXT
IR IN.
3. Wait 3-5 seconds for the solid red
LED on top of the adapter to turn
off.
It’s simple to pair your XFINITY Remote with
the Aim Anywhere Adapter.
XFINITY Remote
Aim Anywhere Adapter
USER’S GUIDE
XFINITY Remote
Aim Anywhere Adapter
USER’S GUIDE
4. Press and release the PAIR button
on the back of the adapter. The LED
on top of the adapter will turn on
when the PAIR button is pressed.
5. Press and hold the Setup button
on your XFINITY Remote until the
remote’s LED changes from red to
green. Then, press and release the
XFINITY button.
Note: You must press the PAIR but-
ton on the adapter before you press
the XFINITY button on your XFINITY
Remote.
6. If the LED on the XFINITY Remote
blinks green twice, pairing was
successful. Press CH ^ to verify that
your set-top box or DTA responds
as expected.
7. If the LED on your XFINITY Remote
blinks red, then green, and then red,
pairing was unsuccessful. Check
the “Compatible Devices” section to
verify that your set-top box or DTA
supports the Aim Anywhere Adapter.
xfinity.com ©2013 Comcast Corporation. All rights reserved.
FCC Compliance Statement
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reason-
able protection against harmful interference
in a residential installation. This equipment
generates, uses, and can radiate radio fre-
quency energy and, if not used in accordance
with the instructions, may cause harmful
interference to radio communications.
There is no guarantee that interference will
not occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, the user is
encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase or decrease the separation
between the equipment and receiver.
• Connect the equipment into an outlet
on a circuit different from that which
the receiver is connected.
• Consult the dealer or an experienced
remote control/TV technician for help.
• It is strongly recommended that the TV
be plugged into a separate wall outlet.
The user is cautioned that changes and mod-
ications made to the equipment without the
approval of the manufacturer could void the
user’s authority to operate this equipment.
This device complies with part 15 of the FCC
rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
:QCan I pair more than one
XFINITY Remote with the XR8
adapter?
:AYes, the XR8 supports pairing
with up to ve XFINITY Re-
motes.
:QWhy can’t I use my other re-
motes after pairing my XFINITY
Remote with the XR8 adapter?
:ASome set-top boxes only
support XFINITY Remotes when
using the XR8. You can replace
your old remote with another
XFINITY Remote and pair it with
the XR8.
:QDuring pairing, why does the
LED blink red and then green on
the XFINITY Remote?
:AEither a button other than the
XFINITY button was pressed,
or the XFINITY Remote timed
out before the XFINITY button
was pressed. Repeat the pairing
steps.
:QDuring pairing, why does the
LED blink red, then green, then
red on the XFINITY Remote?
:AThe XFINITY Remote you are
trying to pair cannot nd the
XR8. Unplug the XR8 and plug
it back in, making sure the
red LED on top of the adapter
turns on for 3-5 seconds. Then,
COMPATIBLE
DEVICES:
DTA
uDTA
RNG100
RNG110
RNG150
RNG150N
RNG200N
DCX3200
DCX3200-M
DCX3400
DCX3400-M
DCX3501
FREQUENTLY ASKED QUESTIONS
ABOUT THE AIM ANYWHERE ADAPTER
repeat the steps to pair the XR8
and XFINITY Remote. Be sure to
press the PAIR button on the XR8
before you press the XFINITY
button on your XFINITY Remote.
:QWhen paired, why does the LED
blink green, then red on the
XFINITY Remote when a button is
pressed?
:AThe XR8 may have lost power or
may be out of communication
range. Try moving closer to your
set-top box or DTA and make sure
the XR8 is securely connected. If
this does not x the issue, follow
the steps to re-pair the XR8 and
XFINITY Remote.
:QWhy is the XR8 adapter not re-
sponding to button presses from
my XFINITY Remote?
:AIf the XR8 stops responding to an
already paired XFINITY Remote,
unplug the XR8 and plug it back
in. If this does not x the issue,
follow the steps to re-pair the XR8
and XFINITY Remote.
:QWhy does the LED continuously
blink when I plug in the XR8
adapter?
:AYour device is not compatible
with the XR8; please refer to the
“Compatible Devices” section for
a list of supported devices.
SET-TOP BOXES AND DTAS
The Aim Anywhere Adapter can be
used for out-of-sight control with the
set-top boxes and DTAs listed below:
XFINITY REMOTES
XFINITY Remotes that can be paired
with the Aim Anywhere Adapter
include:
XR2
XR5
XR11
XR13
For additional information
about XFINITY Remotes visit
xnity.com/remotes.
Note: The Cisco RNG200 is not com-
patible with the adapter.
