Renqing Excellent Investment RAU0587 S50 Wireless CD Player User Manual 15 RAU0587 UserMan r2
Shenzhen Renqing Excellent Investment Co.,Ltd S50 Wireless CD Player 15 RAU0587 UserMan r2
15_RAU0587 UserMan r2
Bluetooth mode. Search Bluetooth to connect
CD Mode
Previous Song Next Song
Pause/Play
Bluetooth Mode
Decrease Volume Increase Volume
Power Switch
Audio Output
Power Charge
Power Signal
Mode Signal
(blue light in Bluetooth mode;
green light in CD mode)
(red light when charging;
dark red when fully charged)
Stop
Compatible CD Type
Input Voltage
Power
Output
Frequency
Harmonic Distortion
Speaker Units
Signal to Noise Ratio
Signal Output
CD, LPCD
Product Model
AC110V-240V 50/60Hz
≤10W
12V 3A
≤0.1%
2 inches 3Ω/5W x2
80dB±3dB
Stereo
Bluetooth Distance 32 feet
Lithium Battery 2000mAh
CD Play Time 2-3h
Bluetooh Play Time 4-5h
User Instructions About the Remote Control
Shenzhen Renqing Excellent Investment Co., Ltd.
Address: 3/F, Block A7, Nanshan iPark,
No. 1001 Xueyuan Road, Nanshan District, Shenzhen, China
Email: techsupport@rockspace.cc
Website: www.rockspace.hk
Contact
About the Buttons & Signals
● Your rock space CD Player is best used indoors. Please stay
away from liquids. Avoid damp weather, extreme sunlight and
rainfalls.
● Please do not use water, alcohol and other chemicals to clean
the surface, especially the laser components; these delicate areas
are only to be cleaned by a nozzle.
● Please use only our charger for charging. We are not responsible
for any damage due to unauthorized charging.
● A CD should always be placed upon the laser head. Only remove
CD when it has fully stopped. Do not remove while playing. Caution
against scratching when removing.
On Maintenance
Q: Cannot pair the CD player with your Bluetooth device.
A: Make sure the CD player is on Bluetooth mode, indicated by blue
light. Make sure the Bluetooth capability of your Bluetooth device is
turned on. Try moving it closer to the player. If possible, turn off all
other nearby Bluetooth device. Reset the CD player and your
Bluetooth connection.
Q: Paired Bluetooth device will not connect to the CD player.
A: Make sure Bluetooth capability is enabled on your source device.
Reset the CD player and your Bluetooth connection. Turn the power
off and back on, then reconnect.
Q: Replacing the battery of your remote control.
A: The battery should be replaced when your remote control is
unresponsive or noticeably slower. It is suggested after 3 months of
repeated using that battery be replaced.
Q: Low battery for CD Player.
A: A low battery alarm will be heard and volume noticeably
decreased. If this happens, please charge your CD player
immediately.
Trouble Shootings
CD Player Parameters
● Use power switch to start your rock space CD Player. The
default CD play mode shows green light. Wait for 3 seconds and
your beloved vinyl CD will be played. Use power switch to switch off.
● To switch to Bluetooth mode, press “switch play mode” button
for 3 seconds. When blue light is shown, your CD player is now on
your phone, your tablet with your new rock space CD Player.
Please read the following instructions carefully
and refer to the manual in case of need.
User Manual
XCaution
● The use of optical instruments with this product will increase eye
hazard. As the laser beam used in this CD player is harmful to eyes,
do not attempt to disassemble the player. Refer servicing to
qualified personnel only.
● To change CD, use power switch. Do not remove the CD until it
stops completely. To use your remote control, please aim the
speaker area. Its working distance is within 13 feet.
FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
Caution
FCC STATEMENT :
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This equipment should be installed and
operated with minimum distance 20cm between the radiator & your
body.
RAU0587
RAU0587
2402~2480MHz
RAU0587
