Wireless IP Camera
Quick Start Guide
QG1_A
For Windows Client & Mac Client, please download the PC software:
https://reolink.com/software-and-manual/
For advanced setup, please download the user manual:
https://reolink.com/software-and-manual/
For more troubleshooting, please go to FAQs on our website:
https://reolink.com/faqs/
For other technical support, please contact us at
support@reolink.com
Technical Support
![](/img.php?id=3701087&img=bg2.png)
Camera Connection Diagram
Power Adapter
Router
Your Smart
Device
Wireless IP Camera
For initial setup, please connect the camera to your router LAN port with an Ethernet
cable, and then follow the steps below to set up your camera. Make sure that your
camera and your smart devices are in the same network.
This Quick Start Guide is applied to Reolink C1, C1 Pro, C2, RLC-410WS, RLC-411WS,
RLC-422W & RLC-423WS.
Access the
Camera by
Smartphones
01.
Power CableNetwork Cable
![](/img.php?id=3701087&img=bg3.png)
Install Reolink App
There are two ways to get the Reolink App:
1. Search “Reolink” in App Store (for iOS), or Google Play (for Android), download and
install the app.
2. Scan the QR code below to download and install the app.
Available on the
Add the Device
When in WAN
(Wide Area Network)
1
In LAN
1. Connect your smartphone to
the WiFi network of your router. 2. Launch Reolink App. The camera
will automatically display in the
camera list in LAN.
When in LAN
(Local Area Network)
1
2
The camera will be automatically added. You need to add the camera either by
scanning the QR code on the camera or
by entering the UID number manually.
C1 Pro
lnit
![](/img.php?id=3701087&img=bg4.png)
Add New Device
4. Start live view or go to “Device
Settings” for more configurations.
3. Tap to sync the time
and create your password.
In WAN
lnit
lnit
1. Click “Add New Device” on the app. 2. Scan the QR code on the camera, and
then tap “Login”. (There is no password at
the factory default status.)
2
![](/img.php?id=3701087&img=bg5.png)
Tap the Wi-Fi settings icon
to enter the Wi-Fi settings page.
3. Name your camera, create a password, and then start live view.
1. Choose the Wi-Fi network you
want to join in, enter the password
of the Wi-Fi network, and then click
“OK”.
2. Wi-Fi Test:
a) If the Wi-Fi test succeeds, press
the “Save” button to save the
settings.
b) If the Wi-Fi test fails, please
check your Wi-Fi password and the
network connection, and then try
again.
3. Remove the Ethernet cable and
then you can access the camera via
the wireless connection.
Wi-Fi Settings
WiFi
Camera 1
This icon only displays if the camera supports 2-way audio.
This icon only displays if the camera supports pan & tilt (zoom).
Reolink
![](/img.php?id=3701087&img=bg6.png)
Install Reolink Client
Launch the Reolink Client software on the PC. By
default, the client software will automatically search
the cameras in your LAN network and display them in
the “Device List” on the right-side menu.
Click the “Start” button, and you can view the live
streaming now.
Access the
Camera by
Computer
02.
website: https://reolink.com/software-and-manual.
Please install the client software from the recourse CD or download it from our official
Start Live View
Camera1
State: login success
Device list
![](/img.php?id=3701087&img=bg7.png)
Launch the Reolink Client software on the PC. By
default, the client software will automatically search
the cameras in your LAN network and display them in
the “Device List” on the right-side menu.
Click the “Start” button, and you can view the live
streaming now.
Wi-Fi Settings
Alternatively, you can manually add the camera to the client.
Please follow the steps below.
Add the Device
Add Device
Device list
Add Device
Device Basic Infomation
Device Name
Register Mode
User Name
Media Port
IP Address
Password
CancelOKScan Device In LAN
NO. Device Name IP Address Port Mac Addr UID
Camera1
Camera11
admin
9000
9000
192.168.10.10
******
192.168.10.10 EC:71:DB:B1:6D:85
IP Address
1
2
4
3
5
Camera1
Stae: login success
1. Click “Add Device” on the right-side menu.
2. Click "Scan Device in LAN".
3. Double click on the camera you want to add. The information will be filled in automatically.
4. Input the password for the camera. The default password is blank. If you have created
the password on Reolink App, you need to use the password to log in.
5. Click “OK” to log in.
Add Device
Device list
1
Camera1
Stae: login success
Click the “Basic Settings” button, and go to Network >> Wi-Fi Settings.
Note:
The SD card icon only displays after you’ve inserted the SD card into your camera.
![](/img.php?id=3701087&img=bg8.png)
1. Scan the SSID.
2. Double click the SSID which you choose. Enter the password.
3. Click “Wi-Fi Test” to test the password.
4. Wi-Fi Test
a) If the Wi-Fi test succeeds, please go to step 5.
b) If the Wi-Fi Test fails, please check your Wi-Fi password and the network connection,
and then try again.
5. Click “OK”.
Device Settings
Scan succeed!
Device Settings Wifi Settings
Wifi Settings
SSID Reolink
******
SSID
Password Show Password
Wi-Fi Test
Wi-Fi Signal
Wi-Fi Test
OK
Scan
Reolink
TP-LINK_5G_F8F4
ASUS 2.4G
1
5
2
4
3
Remove the Ethernet cable and you can access the camera via Wi-Fi on computer now.
![](/img.php?id=3701087&img=bg9.png)
FCCCaution
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothe
followingtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)
thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay
causeundesiredoperation.
AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser'sauthoritytooperatetheequipment.
Note: ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClass
Bdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedto
providereasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.
Thisequipmentgeneratesusesandcanradiateradiofrequencyenergyand,ifnot
installedandusedinaccordancewiththeinstructions,maycauseharmfulinterference
toradiocommunications.However,thereisnoguaranteethatinterferencewillnot
occurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferenceto
radioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoff
andon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthe
followingmeasures:
-Reorientorrelocatethereceivingantenna.
-Increasetheseparationbetweentheequipmentandreceiver.
-Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe
receiverisconnected.
-Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforan
uncontrolledenvironment.Thisequipmentshouldbeinstalledandoperatedwith
minimumdistance20cmbetweentheradiator&yourbody.
