Resmed Sensor Technologies BM14 Field Disturbance Sensor User Manual Item 09 FCC IC BM14 Users Manual

Resmed Sensor Technologies Ltd Field Disturbance Sensor Item 09 FCC IC BM14 Users Manual

Item-09_FCC-IC_BM14_Users_Manual

ResMed Sensor Technologies Ltd
NexusUCD
Block 9 & 10
Belfield Office Park
Clonskeagh
Dublin 4
Ireland
Tel: +353 1 2096400
Fax: +353 1 2096499
Only to be released under the cover of a mutual NDA
Only to be released under the cover of a mutual NDA
ResMed Sensor Technologies Ltd, NexusUCD, Block 9 & 10, Belfield Office Park, Clonskeagh, Dublin 4, Ireland. Tel: + 353 1 2096400 Fax: + 353 1 2096499
Registered in Ireland no:372477 VAT Reg: 6392477W Directors: C. Hanley D. Pendarvis(USA)
BM14
Advice to OEMs
Content for User Leaflets
ResMed Sensor Technologies Ltd
NexusUCD
Block 9 & 10
Belfield Office Park
Clonskeagh
Dublin 4
Ireland
Tel: +353 1 2096400
Fax: +353 1 2096499
Only to be released under the cover of a mutual NDA
Only to be released under the cover of a mutual NDA
ResMed Sensor Technologies Ltd, NexusUCD, Block 9 & 10, Belfield Office Park, Clonskeagh, Dublin 4, Ireland. Tel: + 353 1 2096400 Fax: + 353 1 2096499
Registered in Ireland no:372477 VAT Reg: 6392477W Directors: C. Hanley D. Pendarvis(USA)
Introduction
The following items are provided for OEMs to include in the user leaflets of products that incorporate the ResMed
Sensor Technologies BM14 Sensor.
The items are categorised as Mandatory and Information.
Mandatory items are required by regulatory authorities to be included in device documentation.
The Information items are for guidance and can be altered in tone and language to suit the house style.
It is recommended that the draft device labels and user information leaflet are reviewed by ResMed Sensor
Technologies to ensure their accuracy and regulatory compliance.
Mandatory
Device Label:
(For US Market)
The final end product must be labeled in a visible area with the following:
“Contains TX FCC ID: YAKBM14” or “Contains FCC ID:YAKBM14”
(For Canadian Market)
The final end product must be labeled in a visible area with the following:
“ Contains transmitter module IC ID: 11415A-BM14” or “Contains IC ID: 11415A-BM14”.
User Leaflet:
(For US Market)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the following measures:
ResMed Sensor Technologies Ltd
NexusUCD
Block 9 & 10
Belfield Office Park
Clonskeagh
Dublin 4
Ireland
Tel: +353 1 2096400
Fax: +353 1 2096499
Only to be released under the cover of a mutual NDA
Only to be released under the cover of a mutual NDA
ResMed Sensor Technologies Ltd, NexusUCD, Block 9 & 10, Belfield Office Park, Clonskeagh, Dublin 4, Ireland. Tel: + 353 1 2096400 Fax: + 353 1 2096499
Registered in Ireland no:372477 VAT Reg: 6392477W Directors: C. Hanley D. Pendarvis(USA)
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired operation.
FCC Caution:
Any changes or modifications not expressly approved by “OEM name” could void the user's authority to operate
this equipment.
Note for OEM:
This transmitter module is authorized to be used in other devices only by OEM, further transmitter testing will not
be required. However, the OEM integrator is still responsible for testing their end-product for any additional
compliance requirements required with this module installed (for example, digital device emissions, PC peripheral
requirements, etc.).
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove
this RF module in the user manual of the end product.
(For Canadian Market)
This equipment has been tested and found to comply with the limits for a Category 1 device, pursuant to Part RSS-
210 of the IC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Industry Canada Statement:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following
two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
ResMed Sensor Technologies Ltd
NexusUCD
Block 9 & 10
Belfield Office Park
Clonskeagh
Dublin 4
Ireland
Tel: +353 1 2096400
Fax: +353 1 2096499
Only to be released under the cover of a mutual NDA
Only to be released under the cover of a mutual NDA
ResMed Sensor Technologies Ltd, NexusUCD, Block 9 & 10, Belfield Office Park, Clonskeagh, Dublin 4, Ireland. Tel: + 353 1 2096400 Fax: + 353 1 2096499
Registered in Ireland no:372477 VAT Reg: 6392477W Directors: C. Hanley D. Pendarvis(USA)
The device meets the exemptions from the routine SAR and RF exposure evaluations as per sections 2.5.1 & 2.5.2
of document RSS-102. (Radio Frequency (RF) Exposure Compliance of Radio Communication Apparatus (All
Frequency Bands))
Note for OEM:
This transmitter module is authorized to be used in other devices only by OEM, further transmitter testing will not
be required. However, the OEM integrator is still responsible for testing their end-product for any additional
compliance requirements required with this module installed (for example, digital device emissions, PC peripheral
requirements, etc.).
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove
this RF module in the user manual of the end product.
Information
Device Information
The non-contact sensor is a very low power Radio Frequency (RF) emitter. The sensor has a maximum range of
1.5m and is designed to measure the breathing and body movement of an adult within range. If there are 2
persons in the bed, the sensor is will measure the parameters of the nearer person.
Device Placement
The product should be placed on a bedside table on the same side of the bed as the user. The height of the
bedside table should ensure that there is a clear line of sight between the sensor and your upper chest when you
are lying on the bed. This is typically a table top height of level with the mattress to around 6” (15cm) above the
mattress. Do not place the product so that it has to “look” through the mattress at you: the springs in the mattress
are likely to disrupt the RF beam. The product should be placed on the bedside table such that it is within easy
arm’s reach of your normal sleeping position.
ResMed Sensor Technologies Ltd
NexusUCD
Block 9 & 10
Belfield Office Park
Clonskeagh
Dublin 4
Ireland
Tel: +353 1 2096400
Fax: +353 1 2096499
Only to be released under the cover of a mutual NDA
Only to be released under the cover of a mutual NDA
ResMed Sensor Technologies Ltd, NexusUCD, Block 9 & 10, Belfield Office Park, Clonskeagh, Dublin 4, Ireland. Tel: + 353 1 2096400 Fax: + 353 1 2096499
Registered in Ireland no:372477 VAT Reg: 6392477W Directors: C. Hanley D. Pendarvis(USA)
Device Specifications
Parameter Value Remarks
Centre frequency
10.525 GHz
Antenna Beam width
40
to 60 deg
ie
40
to
6
0 deg either side of
direct line of sight
Typical breathing
detection range
1.5m
Target aspect not important, ie
can be sitting, lying down on
back/side/front
