Resolution RE103F Wireless Panic Transmitter User Manual RE103 GE Compat Panic RevF
Resolution Products, Inc. Wireless Panic Transmitter RE103 GE Compat Panic RevF
User Manual
Wireless
Security
Solutions
RE103 GE-Compatible Panic
Features
•Portable device for emergency initiation of system.
•Single, red button with comfortable feel.
•Fully sealed, water resistant housing.
•Strong, reliable RF signal.
•“Heartbeat” LED blinks every minute to assure user.
•Comes with comfortable, elastic band for easy removal.
•4-6 year battery life.
Key Instructions
•Enrolling:
Refer to the GE control unit installation manual.
Put the control panel in RF Learning mode.
•Press button to enroll in panel.
•Valid groups: 00 – 07
May be in a supervised (for user “wander”
monitoring) or a non-supervised group.
…Or if using a Downloader in ID entry mode
•Enter the Download ID the device (located on a label
on the unit’s back).
Operation
User presses button in emergency.
Unit will send low battery signals.
Unit sends supervisory signals hourly.
RE103_GE-Compat_Panic_RevF+.doc Page 1 of 2 12-Aug-11
www.ResolutionProducts.com
Red button is
Alarm
Heartbeat LED blinks
every 60 seconds
Specifications
Compatibly Replaces: 60-578-95 (Soap on a Rope) Panic
60-906-95 Micro Panic
Button Function: Press=Fault, Release=Restore
Supervisory signals: sent every hour.
Battery: Sealed in unit; not replaceable
Water resistant: Not submersible, but tested to 1 meter depth
Temperature Range: 0F to 120F
Housing dimensions: 1.5x1.2x0.6 inches
Specifications subject to change without notice.
Notices
“GE”, “Honeywell”, and “DSC” are trademarks owned by General Electric Company,
Honeywell International Inc., and Tyco Safety Products Canada LTD, respectively.
Resolution Products, Inc. products will function with one of either GE, DSC or Honeywell
systems. However, no Resolution product is produced by, endorsed by, nor is officially
associated with GE, Honeywell or DSC. Resolution recommends verifying operation at
installation.
Warranty
Resolution Products, Inc. will replace products that are defective in their first two (2) years.
FCC Notice
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions:
(1)This device may not cause harmful interference.
(2)This device must accept any interference that may be received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the Resolution Products, Inc. could
void the user's authority to operate this equipment.
FCC ID: U5X-RE103F
IC Notice
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1)This device may not cause interference, and
(2)This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1)l'appareil ne doit pas produire de brouillage, et
(2)l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
IC: 8310A-RE103F
RE103_GE-Compat_Panic_RevF+.doc Page 2 of 2 12-Aug-11
www.ResolutionProducts.com
