Revolution RMTHD2 2 Way Remote User Manual

Industrial Revolution 2 Way Remote

User manual

LIMITED WARRANTY: This product has a limited 1 year warranty, to the
original purchaser, to be free from defects in materials and workmanship.
Follow all product instructions and warnings as warranty does not cover
damage due to misuse, improper care, accidents, or alterations.
See www.intova.com for further details, limitations, and restrictions.
FCC STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
» Reorient or relocate the receiving antenna.
» Increase the separation between the equipment and receiver.
» Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
» Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
A. Video Light/Flash
B. Shutter Button
» Video mode: start/stop
recording.
» Photo mode: shutter button.
» Power ash on/o
(press & hold).
» Thumbnail view mode: select.
» Playback mode: Return to
thumbnail view.
C. Power Button
» Power the camera on/o (press
& hold).
» Video/Photo/View mode: Select.
» Playback mode: exit menu and
return to video screen.
D. Indicator Light
» Red LED is ON while charging
and OFF when charge is
complete. FLASHES when video
recording is in progress.
L. Video Record
» Start/stop recording.
M. Power OFF
» Power the camera o.
N. Photo Button
» Take photo.
C
D
E
G
L
M
N
H
I
K
J
F
B
AE. Door Lock
F. Removable Housing Door
G. Tripod Mount
H. Float Strap Attachment
K/I. Up/Down Buttons
» Scroll up/down to select
thumbnail to view.
» Video/photo mode: Adjust
digital zoom.
» Playback mode: speed up video
playback (down button) and
slow down video playback (up
button).
» Down button: one touch LCD o.
J. Menu/OK Button
» Access Menu.
» Select.
» Playback mode: start and pause
video.
BUTTONS AND INTERFACE
REMOTE
HD2
QUICK START GUIDE
For complete instructions go
to www.intova.com.
Precautions
» Before using the camera, read the precautions to ensure correct use, the
best performance and longer lifespan.
» Do not leave or store the camera in direct sunlight, especially the lens, as
prolonged exposure to direct sunlight can damage the image sensor.
» Store in a cool, dry environment.
» During storage, note that battery must be recharged periodically to
maintain operating ability. Allowing total discharge may ruin the battery.
» Clean with a soft dry cloth and take special care around lens.
» Format Memory Card prior to rst use.
» Do not use a memory card that contains les from a dierent device as
this may cause camera to malfunction.
Need help using your camera?
WE’RE HERE FOR YOU.
Visit our website:
www.intova.com
Call customer support:
+1(808) 837-0074
Email customer support:
info@intova.net
INSERT # 1195 - 4/16
INDUSTRIAL REVOLUTION, INC.
SEATTLE, WA • (888) 297-6062
1.OPEN HOUSING DOOR
4. INSERT MICRO SD CARD
2.INSERT BATTERY
5. POWER ON (press & hold)
3. CHARGE
PRESS SHUTTER (press & hold) FOR LIGHT6. PRESS SHUTTER TO SHOOT/RECORD
HD2
QUICK START GUIDE For complete instructions go to www.intova.com.
(Up to 32GB class 10 microSD card)
