SALES FACT SHEET

GENERAL TERMS OF LIMITED WARRANTY*

Rheem will furnish a replacement for any part of this product

which fails in normal use and service within the applicable period

stated, in accordance with the terms of the limited warranty.

Heat Exchanger . . . . . . . . . . . . . . . . . . . . . .Limited Lifetime

Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Ten (10) Years

Conditional Unit Replacement

(Registration /Required) . . . . . . . . . . . . . . . .Ten (10) Years

Rheem Heating, Cooling and Water Heating FORM NO. G11-540-SFS REV. 4

P.O. Box 17010, Fort Smith, AR 72917 PRINTED IN U.S.A. QG 10-14

MODEL INPUT-

BTU/HR [kW] ➀

HEATING CAPACITY

BTU/HR [kW]

HEATING CFM @ .2"

[.049 kPa] W.C. E.S.P. [L/s]

COOLING CFM @ .5"

[.124 kPa] W.C. E.S.P. [L/s]

APPROX. SHIPPING

WEIGHT (LBS.) [kg] PRICE

R96VA040 42,000 [12.31] 40,320 [11.82] 1050 [496] 1050 [496] 128 [58]

R96VA060 56,000 [16.41] 53,760 [15.75] 1025 [484] 1050 [496] 128 [58]

R96VA070 70,000 [20.51] 67,200 [19.68] 1015 [479] 1050 [496] 132 [60]

R96VA085 84,000 [24.62] 80,640 [23.63] 1470 [694] 1750 [826] 147.5 [67]

R96VA100 98,000 [38.71] 94,080 [37.16] 1710 [807] 1750 [826] 152 [69]

R96VA115 112,000 [32.82] 107,520 [31.51] 1450 [684] 1750 [826] 165 [75]

Rheem

Prestige

™Series

Two Stage Variable Speed

Multi position Gas Furnaces

Features

■Up to 96% residential gas furnace CSA certified

■4 way multi-poise design

■Two stages of operation to save energy and maintain optimal comfort level

■Variable speed blower motor technology provides ultimate humidity control,

quieter sound levels, and year round energy savings.

■EcoNet™enabled HVAC Product

■PlusOne™Diagnostics 7-Segment LED all units

■PlusOne™Ignition System – DSI for reliability and longevity

■PlusOne™Water Management System with patented Blocked Drain Sensor

■Heat exchanger is removable for improved serviceability. Primary is con-

structed of aluminized steel, secondary is constructed of stainless steel for

maximum corrosion resistance and thermal fatigue reliability.

■Low profile “34 inch” cabinet ideal for space constrained installations.

■Blower Shelf design – serviceable in all furnace orientations

■Pre marked hoses – insures proper system drainage

■Vent with 2" or 3" PVC

■Replaceable Collector box

■Hemmed edges on cabinet and doors

■Quarter turn fasteners for tool less access

■Integrated control boards feature dip switches for easy system set up

■Self priming condensate trap

■Solid bottom included

■Compatible with single or two stage thermostats. For optimal performance

a two stage thermostat is recommended.

Note: Above data and specs are for upflow models.

[ ] Designates Metric Conversions

R96V- SERIES

96% A.F.U.E.†

Models with Input Rates of

40 to 115 kBTU

[11.72 to 33.71 kW]

✝A.F.U.E. (Annual Fuel Utilization Efficiency) calculated in accordance with

Department of Energy test procedures.

*For complete details of the Limited and Conditional Warranties,

including applicable terms and conditions, contact your local contractor

or the Manufacturer for a copy of the product warranty certificate.

(All Models except R96VA085)

SALES FACT SHEET

Description Part No.

Condensate Pump Kit

External Bottom Filter (Upflow/Horizontal) Rack

External Side Filter Rack

External Downflow Top Filter Rack

Downflow/Horizontal Conversion Kit

Downflow/Horizontal Left Zero Clearance Conversion Kit

Combustible Floor Base

Combustible Floor Base

Combustible Floor Base

Direct Vent Furnace Side Wall Vent 2" or 3"

LP Conversion Kit

Neutralizer Kit

Return Air Plenum

Return Air Plenum

Return Air Plenum

Vent Termination Kit - Concentric Horizontal/Vertical (US & Canadian Installations) 3" Pipe

Vent Termination Kit - Concentric Horizontal/Vertical (US & Canadian Installations) 2" Pipe

Vent Termination Kit - Concentric Horizontal/Vertical (US Installation Only) 2" Pipe

Vent Termination Kit - Concentric Horizontal/Vertical (US Installation Only) 3" Pipe

Indoor Coil Casing

Indoor Coil Casing

Indoor Coil Casing

Indoor Coil Casing

Combustion Air Drain Kit 2"

Combustion Air Drain Kit 3"

EcoNet Control

EcoNet Control Wall Plate

EcoNet Control Face Plate

EcoNet Translator

1PCB151TUL

RXGF-CB

RXGF-CD

RXGF-CC

RXGY-CK

RXGY-ZK

RXGC-B17

RXGC-B21

RXGC-B24

RXGY-G02

RXGJ-FP34

RXGY-A01

RXGR-C17B

RXGR-C21B

RXGR-B24C

RXGY-E03A

RXGY-E02A

RXGY-E02

RXGY-E03

RXBC-D17AI

RXBC-D21AI

RXBC-D24AI

RXBC-D21B1

RXGY-D05

RXGY-D06

RETST600SYS

RCPN-AMC08

RETSTFPL

RETRN620CC2

Rheem Heating, Cooling and Water Heating FORM NO. G11-540-SFS REV. 4

P.O. Box 17010, Fort Smith, AR 72917 PRINTED IN U.S.A. QG 10-14

R96V ACCESSORIES

Price
