Rhine Electronics Co 7220T Transmitter of Remote Control User Manual
Rhine Electronics Co Ltd Transmitter of Remote Control
User manual
Page: 1/2
Model : UC7220T
INSTRUCTIONS FOR OPERATION
SETING THE OPERATING CONTROLS
1.This unit operates on CR 2032 a 3 volts battery (not included).
To prevent possible damage if the battery should leak , be sure to remove
the battery when the unit is not use .
2. Store the controller away from excess heat or humidity .
3. This remote control unit is required with 24bit code combinations to prevent
possible interference from or to other remote units such as garage door
openers, car alarm or security system . If you find that your fan and light
kit go on and off without using your control , simply change the combination
code in your transmitter and receiver .
4.Operation buttons on the panel of transmitter .
5.
key – For fan 1 2 3 4 --> 4 3 2 1 speed cycle.
OFF key – For fan speed off .
key – For fan speed Reverse.
key – For upper light brightness and ON/OFF control .
key – For bottom light brightness and ON/OFF control .
6.Start the fan :
Press the fan button to run the fan at the desired .
7.Turn off the fan :
Press the OFF button .
8.Light control :
Turn the light on or off by only touching the LIGHT CONTROL button .
Keep pressing the button in excess of 0.7 second it becomes a dimmer ,
the light varies cyclically in 0.8 second .
One of the important feature of this control is AUTO-RESUME . After power
on , it allows the light return to where it was off .
GENERAL INFORMATION :
This REMOTE controller is designed to separately control your
ceiling fan speed and light brightness . The Light
ON/OFF button will control the light brightness ON/OFF .
The LED indicator on the transmitter will light when the button is pressed .
INSTRUCTIONS FOR INSTALLATION AND OPERATION OF FAN SPEED
CONTROLLER
1. Setting the code on your new transmitter .
Page: 2/2
Within 60 seconds of turning the AC power on, press and hole the OFF/STOP button for 5
seconds. The receiver will then lock in the chosen frequency. If your fan has a light it it will blink twice,
for fans without lights check operation using the transmitter
NOTICE :
The changes or modifications not expressly approved by the
party responsible for compliance could void user’s authority
to operate the equipment .
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to
the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
