Ricoh Wg 30 Quick Start Manual

WG-30 - Quick Start Guide WG-30-SG-EN Free User Guide for Ricoh Camera, Manual

2015-07-27

: Ricoh Ricoh-Wg-30-Quick-Start-Manual-779046 ricoh-wg-30-quick-start-manual-779046 ricoh pdf

Open the PDF directly: View PDF .
Page Count: 60

Using Your Camera Safely
Care to be Taken During Handling
Contents
Checking the Contents of the Package
Names of Parts
Names of Operating Parts
Display Indications
Powering the Camera
- Installing the Battery
- Charging the Battery
Installing an SD Memory Card
Turning the Camera On and Off
- Starting-up in Playback Mode
Initial Settings
- Setting the Display Language
- Setting the Date and Time
Setting the Camera Functions
Taking Still Pictures
Setting the Shooting Functions
Recording Movies
- Recording Movies
- Recording a Movie Quickly Using the Movie Button
Playing Back Images
Deleting Images
- Deleting a Single Image
Appendix

Digital Camera

Start Guide

To ensure the best performance from your camera, please read

this manual before using the camera.

RICOH IMAGING COMPANY, LTD.

2-35-7, Maeno-cho, Itabashi-ku, Tokyo 174-8639, JAPAN

(http://www.ricoh-imaging.co.jp)

RICOH IMAGING EUROPE

S.A.S

112 Quai de Bezons, B.P. 204, 95106 Argenteuil Cedex,

FRANCE

(http://www.ricoh-imaging.fr)

RICOH IMAGING

DEUTSCHLAND GmbH

Am Kaiserkai 1, 20457 Hamburg, GERMANY

(http://www.ricoh-imaging.de)

RICOH IMAGING UK LTD. PENTAX House, Heron Drive, Langley, Slough, Berks

SL3 8PN, U.K.

(http://www.ricoh-imaging.co.uk)

RICOH IMAGING

AMERICAS CORPORATION

633 17th Street, Suite 2600, Denver, Colorado 80202,

U.S.A.

(http://www.us.ricoh-imaging.com)

RICOH IMAGING CANADA

INC.

5520 Explorer Drive Suite 300, Mississauga, Ontario,

L4W 5L1, CANADA

(http://www.ricoh-imaging.ca)

RICOH IMAGING CHINA

CO., LTD.

23D, Jun Yao International Plaza, 789 Zhaojiabang

Road, Xu Hui District, Shanghai, 200032, CHINA

(http://www.ricoh-imaging.com.cn)

http://www.ricoh-imaging.co.jp/english

• Specifications and external dimensions are subject to change without notice.

FOM 01.11.2014 Printed in Europe

Information for Users on Collection and Disposal of Old Equipment

and Used Batteries

1. In the European Union

These symbols on the products, packaging and/or

accompanying documents mean that used electrical and

electronic equipment and batteries should not be mixed with

general household waste.

Used electrical/electronic equipment and batteries must be

treated separately and in accordance with legislation that

requires proper treatment, recovery and recycling of these

products.

By disposing of these products correctly you will help ensure

that the waste undergoes the necessary treatment, recovery

and recycling and thus prevent potential negative effects on

the environment and human health which could otherwise

arise due to inappropriate waste handling.

If a chemical symbol is added beneath the symbol shown

above, inaccordance with the Battery Directive, this indicates

that a heavy metal(Hg = Mercury, Cd = Cadmium, Pb = Lead)

is present in the battery at aconcentration above an

applicable threshold specified in the BatteryDirective.

For more information about collection and recycling of used products,

please contact your local authorities, your waste disposal service or the

point of sale where you purchased the products.

2. In other countries outside the EU

These symbols are only valid in the European Union. If you wish to discard used

products, please contact your local authorities or dealer and ask for the correct

method of disposal.

For Switzerland: Used electrical/electronic equipment can be returned free of

charge to the dealer, even when you don’t purchase a new product. Further

collection facilities are listed on the home page of www.swico.ch or www.sens.ch.

An Operating Manual (PDF) containing information on how touse

this camera is available. Please download it from our website.

Operating Manual Download:

http://www.ricoh-imaging.com/manuals/

In order to better serve you, we request that you complete the user registration,

which can be found on our website. Thank you for your cooperation.

http://www.ricoh-imaging.com/registration/

Information on the Operating Manual

Regarding User Registration

Thank you for purchasing this RICOH WG-30 Digital Camera.

This Start Guide provides information on how to get your RICOH WG-30 ready

for use and its basic operations. To ensure proper operation, please read this

Start Guide before using the camera.

For details on how to use the various shooting methods and settings, please refer

to the Operating Manual (PDF) posted on our website.

Refer to p.57 for details on the Operating Manual.

Regarding copyrights

Images taken with this digital camera that are for anything other than personal

enjoyment cannot be used without permission according to the rights as specified in

the Copyright Act. Please take care, as there are cases where limitations are placed on

taking pictures even for personal enjoyment during demonstrations, performances or

of items on display. Images taken with the purpose of obtaining copyrights also cannot

be used outside the scope of use of the copyright as laid out in the Copyright Act, and

care should be taken here also.

Regarding trademarks

• SDXC logo is a trademark of SD-3C, LLC.

• HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks

or registered trademarks of HDMI Licensing, LLC in the United States and/or

other countries.

• Eye-Fi, the Eye-Fi logo, and Eye-Fi connected are trademarks of Eye-Fi, Inc.

• This product supports PRINT Image Matching III. PRINT Image Matching

enabled digital still cameras, printers and software help photographers to

produce images more faithful to their intentions. Some functions are not

available on printers that are not PRINT Image Matching III compliant.

PRINT Image Matching is a trademark of Seiko Epson Corporation. The PRINT

Image Matching logo is a trademark of Seiko Epson Corporation.

• This product is licensed under the AVC Patent Portfolio License for the personal

use of a consumer or other uses in which it does not receive remuneration to (i)

encode video in compliance with the AVC standard (“AVC video”) and/or (ii)

decode AVC video that was encoded by a consumer engaged in a personal

activity and/or was obtained from a video provider licensed to provide AVC

video. No license is granted or shall be implied for any other use.

Additional information may be obtained from MPEG LA, LLC.

See http://www.mpegla.com.

• All other trademarks are the property of their respective owners.

p57

To users of this camera

• Do not use or store this camera in the vicinity of equipment that generates strong electromagnetic radiation

or magnetic fields.

Strong static charges or the magnetic fields produced by equipment such as radio transmitters could

interfere with the display, damage the stored data, or affect the camera’s internal circuitry and cause

camera misoperation.

•

The liquid crystal panel used for the display is manufactured using extremely high precision technology.

Although the level of functioning pixels is 99.99% or better, you should be aware that 0.01% or fewer of the pixels

may not illuminate or may illuminate when they should not. However, this has no effect on the recorded image.

• There is a possibility that the illustrations and the screen display in this manual are different from the actual

ones.

• In this manual, SD Memory Cards, SDHC Memory Cards and SDXC Memory Cards are referred to as SD

Memory Cards.

• In this manual, the generic term “computer(s)” refers to either a Windows PC or a Macintosh.

• In this manual, the term “battery(ies)” refers to any type of batteries used for this camera and its

accessories.

The meanings of the symbols used in this manual are explained below.

We have paid close attention to the safety of this camera. When using this camera, we

request your special attention regarding items marked with the following symbols.

In this manual, the capture mode, such as for taking still pictures and recording

movies, is referred to as “A mode” (capture mode) (“Still Picture Capture Mode”

refers to the mode for taking still pictures and “Movie Mode” refers to the mode

for recording movies). The playback mode, such as for viewing captured images

on the display, is referred to as “Q mode” (playback mode). In Q mode, you

can perform simple editing operations on the images that are played back.

1Indicates the reference page number for an explanation of the related

operation.

Indicates information that is useful to know.

Indicates precautions to be taken when operating the camera.

Using Your Camera Safely

Warning This symbol indicates that ignoring this item could cause serious

personal injuries.

Caution This symbol indicates that ignoring this item could cause minor or

medium personal injuries, or loss of property.

Warning

• Do not attempt to take the camera apart or modify the camera. High voltages are present within

the camera, and there is a danger of electric shock if the camera is taken apart.

• If the inside of the camera should become exposed as a result of, for example, the camera being

dropped, please do not under any circumstances touch such exposed portions, as there is a

danger of receiving an electric shock.

• Wrapping the strap around a neck is dangerous. Take care that small children do not hang the

strap around their necks.

• If any irregularities occur during use, such as smoke or a strange odor, stop use immediately,

remove the battery or the AC adapter, and contact your nearest service center. Continued use can

cause a fire or electric shock.

Caution

• Do not place your finger on the flash when it is discharging as there is a risk of burns.

• Do not discharge the flash while it is touching your clothing as there is a risk of discoloring.

• Some portions of the camera heat up during use, so please take care, as there is a risk of low

temperature burns if such portions are held for long periods of time.

• Should the display be damaged, be careful of glass fragments. Also, be careful not to allow the

liquid crystal to get on your skin, in your eyes, or in your mouth.

• Depending on your individual factors or physical condition, the use of the camera may cause

itching, rashes or blisters. In case of any abnormality, stop using the camera and get medical

attention immediately.

Warning

• Always use the power adapter or AC adapter exclusively developed for this camera, with the

specified power and voltage. Using a power adapter or AC adapter not exclusive to this camera,

or using the exclusive power adapter or AC adapter with an unspecified power or voltage can

cause a fire, electric shock, or camera breakdown. The specified voltage is 100-240V AC.

• Do not disassemble or modify the product. This can cause a fire or electric shock.

• If the generation of smoke or strange odor from the product or other abnormality occurs,

immediately discontinue its use and consult your nearest service center. Continued use can cause

a fire or electric shock.

• If water should happen to get inside the product, consult your nearest service center. Continued

use can cause a fire or electric shock.

• If you see a lightning flash or hear thunder during use of the power adapter or AC adapter, unplug

the AC plug and discontinue use. Continued use can cause damage to the product, fire, or electric

shock.

• Wipe off the AC plug if it becomes covered with dust. Accumulated dust may cause a fire.

About the Camera

About the Power Adapter and the AC Adapter

Caution

• Do not place or drop heavy objects on or forcefully bend the USB cord or AC plug cord. Doing so

may damage the cord. Should the cord be damaged, consult your nearest service center.

• Do not touch or short-circuit the terminal area of the USB cord or AC plug cord while the cord is

plugged in.

• Do not handle the AC plug with wet hands. This can cause an electric shock.

• Do not subject the product to strong impacts or allow it to drop onto a hard surface. This can cause

a malfunction.

• Do not use the power adapter to charge a battery other than a rechargeable lithium-ion battery

D-LI92. This can cause overheating, explosion, or power adapter failure.

•

To reduce the risk of hazards, use only a CSA/UL certified power supply cord set, cord is Type SPT-2

or heavier, minimum NO.18 AWG copper, one end with a molded-on male attachment plug cap (with a

specified NEMA configuration), and the other is provided with a molded-on female connector body (with

a specified IEC nonindustrial type configuration) or the equivalent.

Warning

• Be sure to store the battery out of the reach of small children. Placing it in their mouths may cause

an electric shock.

• If any leakage from the battery should come in contact with your eyes, it may cause a loss of sight.

Flush your eyes with clean water and get medical attention immediately. Do not rub them.

Caution

• Only use the specified battery with this camera. Use of other batteries may cause an explosion or

fire.

• Do not disassemble the battery. Disassembling the battery may cause an explosion or leakage.

• Remove the battery from the camera immediately if it becomes hot or begins to smoke. Be careful

not to burn yourself during removal.

• Keep wires, hairpins, and other metal objects away from the + and - contacts of the battery.

• Do not short the battery or dispose of the battery in fire. This can cause an explosion or fire.

•

If any leakage from the battery should come in contact with skin or clothes, it may cause irritation to the

skin. Wash the affected areas thoroughly with water.

• Precautions for D-LI92 Battery Usage:

BATTERY MAY EXPLODE OR FIRE IF MISTREATED.

- DO NOT DISASSEMBLE OR DISPOSE OF IN FIRE.

- DO NOT CHARGE EXCEPT SPECIFIED CHARGING CONDITION.

- DO NOT HEAT ABOVE 140°F / 60°C, OR SHORT CIRCUIT.

- DO NOT CRUSH OR MODIFY.

Warning

• Be sure to keep the camera and its accessories out of the reach of small children.

1. Injuries may result from the product falling or from unexpected movement.

2. Suffocation may result from wrapping the strap around the neck.

3. Small accessories such as battery or an SD Memory Card may be swallowed. Seek medical

attention immediately if an accessory is accidentally swallowed.

About the Battery

Keep the Camera and its Accessories out of the Reach of Small

Children

• When the camera has not been used for a long time, confirm that it is still working properly, particularly

prior to taking important pictures (such as at a wedding or when traveling). Contents of the recording

cannot be guaranteed if recording, playback or transferring your data to a computer, etc. is not

possible due to a malfunction of your camera or recording media (SD Memory Card), etc.

• The lens on this camera is not interchangeable. The lens is not removable.

• To keep the battery in optimum condition, avoid storing it in a fully charged state or in high

temperatures.

• If the battery is left inserted and the camera is not used for a long time, the battery will over-

discharge and shorten the battery’s life.

•

Charging the battery a day before use or on the day of use is recommended.

• The AC plug adapter D-PL135 is designed for exclusive use with the Power Adapter D-PA135. Do

not use it with other devices.

•

Hot and humid places should be avoided. Particular care should be taken regarding vehicles, which

can become very hot inside.

• Ensure that the camera is not subjected to substantial vibrations, shocks, or pressure as this may

cause damage, malfunction, or a loss in waterproof performance. Place the camera on a cushion

for protection when the camera is subjected to the vibrations of a motorbike, car, ship, etc. If the

camera is subjected to substantial vibrations, shocks, or pressure, take your camera to your

nearest service center and have it checked.

• The temperature range in which the camera can be used is -10°C to 40°C (14°F to 104°F).

• The display will become black at high temperatures but will return to normal at normal

temperatures.

• The response speed of the display becomes slow at low temperatures. This is due to the

properties of the liquid crystal and is not a malfunction.

• If the camera is subjected to rapid temperature changes, condensation may form on the inside and

outside of the camera. Therefore put the camera in a bag or plastic bag and take it out when the

difference in temperature has subsided.

• Avoid contact with garbage, mud, sand, dust, water, toxic gases, or salt. These could cause the

camera to breakdown. Wipe the camera to dry off any rain or water drops.

• Do not press the display with excessive force. This could cause it to break or malfunction.

• Be careful not to sit down with the camera in your back pocket as this may damage the exterior of

the camera or the display.

• When using a tripod with the camera, be careful not to overtighten the screw in the tripod socket

on the camera.

• Do not clean the camera with organic solvents such as thinner, alcohol or benzine.

• Use a lens brush to remove dust accumulated on the lens. Never use a spray blower for cleaning

as it may damage the lens.

Care to be Taken During Handling

Before Using Your Camera

About the Battery and Power Adapter

Precautions on Carrying and Using Your Camera

Cleaning Your Camera

• Avoid storing the camera where pesticides and chemicals are handled. Remove the camera from

its case and store it in a well-ventilated place to prevent the camera from becoming moldy during

storage.

• Avoid using or storing the camera where it may be exposed to static electricity or electrical

interference.

• Avoid using or storing the camera in direct sunlight or in locations where it may be exposed to rapid

changes in temperature or to condensation.

• Periodic inspections are recommended every one to two years to maintain high performance.

• The SD Memory Card is equipped with a write-

protect switch. Setting the switch to LOCK prevents

new data from being recorded on the card, the

stored data from being deleted, and the card from

being formatted by the camera or computer.

r appears on the display when the card is write-

protected.

• Care should be taken when removing the SD

Memory Card immediately after using the camera,

as the card may be hot.

• Keep the battery/card cover closed and do not remove the SD Memory Card or turn the

camera off while the data is being played back or saved to the card, or the camera is

connected to a computer with the USB cable, as this may cause the data to be lost or the

card to be damaged.

• Do not bend the SD Memory Card or subject it to violent impact. Keep it away from water

and store away from high temperature.

• Do not remove the SD Memory Card during formatting as this may damage the card and

render it unusable.

• The data on the SD Memory Card may be lost in the following circumstances. We do not

accept any liability for data that is deleted

(1) when the SD Memory Card is mishandled by the user.

(2) when the SD Memory Card is exposed to static electricity or electrical interference.

(3) when the SD Memory Card has not been used for a long time.

(4) when the SD Memory Card is ejected or the batteries are removed while the card is

being accessed.

• If it is not used for a long time, the data on the card may become unreadable. Be sure to

regularly make a backup of important data on a computer.

• Be sure to format SD Memory Cards that are unused or have been used on another

camera.

• When using an SD Memory Card with a slow recording speed, recording may stop while

recording a movie even if there is adequate space in the memory, or image capture or

playback may take a long time.

• Please note that deleting data, or formatting the SD Memory Cards or the built-in memory

does not completely erase the original data. Deleted files can sometimes be recovered

using commercially available software. It is user’s responsibility to ensure the privacy of

such data.

Storing Your Camera

Other Precautions

Write-protect

switch

Using Your Camera Safely.................................................................................... 1

Care to be Taken During Handling........................................................................ 4

Contents................................................................................................................ 6

Checking the Contents of the Package ................................................................... 7

Names of Parts........................................................................................................... 8

Names of Operating Parts......................................................................................... 9

Display Indications .................................................................................................. 12

Display in A Mode ............................................................................................. 12

Display in Q Mode ............................................................................................ 13

Guide Display...................................................................................................... 14

Powering the Camera .............................................................................................. 15

Installing the Battery ........................................................................................... 15

Charging the Battery ........................................................................................... 17

Installing an SD Memory Card................................................................................ 19

Turning the Camera On and Off ............................................................................. 21

Starting-up in Playback Mode ............................................................................. 21

Initial Settings .......................................................................................................... 22

Setting the Display Language ............................................................................. 22

Setting the Date and Time .................................................................................. 23

Setting the Camera Functions ................................................................................ 24

Operating the Menus .......................................................................................... 24

Menu List ............................................................................................................ 26

Resetting to Default Settings (Reset).................................................................. 29

Displaying the Clock Display............................................................................... 29

Taking Still Pictures................................................................................................. 30

Taking Pictures ................................................................................................... 30

Using the Zoom................................................................................................... 32

Setting the Shooting Mode.................................................................................. 33

Using the Self-timer............................................................................................. 36

Setting the Shooting Functions.............................................................................. 38

Using the Rec. Mode Menu Items....................................................................... 38

Selecting the Flash Mode ................................................................................... 39

Selecting the Focus Mode .................................................................................. 40

Recording Movies.................................................................................................... 42

Recording Movies ............................................................................................... 42

Recording a Movie Quickly Using the Movie Button ........................................... 43

Playing Back Images ............................................................................................... 44

Playing Back Still Pictures................................................................................... 44

Playing Back a Movie.......................................................................................... 44

Using the Playback Functions............................................................................. 45

Deleting Images ....................................................................................................... 48

Deleting a Single Image...................................................................................... 48

Appendix................................................................................................................... 49

Main Specifications ............................................................................................. 49

Warranty Policy................................................................................................... 54

Information on the Operating Manual.................................................................. 57

Regarding User Registration............................................................................... 57

Contents

Checking the Contents of the Package

*1 Available as optional accessories.

*2 The AC plug adapter is attached to the power adapter.

Camera

RICOH WG-30

Strap

O-ST104 (*1)

USB cable

I-USB157 (*1)

Rechargeable lithium-ion

battery D-LI92 (*1)

Power adapter D-PA135/

AC plug adapter D-PL135 (*2)

Macro stand

O-MS1

Start Guide (this manual)

Regarding Waterproof,

Dustproof, and Shockproof

Design

Names of Parts

Front

Back

Shutter

release button

Lens

Power switch/Power lamp (green)

Flash

Microphone

Self timer lamp/

Focus assist light

Remote control receiver

LED Macro Lights

Speaker

Display

Tripod socket

Battery/card cover

USB terminal

Battery lock lever

Terminal cover

lock lever

HDMI terminal

Terminal cover

Battery/card cover

lock lever

Remote control

receiver

Names of Operating Parts

1Power button

Turns the camera on and off (p.21).

2Shutter release button

A Mode:

Focuses the camera on the subject when pressed halfway in Still Picture

Capture Mode (except when the focus mode is set to 3, s, and \) (p.30).

Takes a still picture when pressed down fully (p.31).

Pressing down fully starts and stops movie recording in C (Movie),

(Underwater Movie), and (High Speed Movie) modes (p.42).

Q Mode:

Switches to A mode.

3W/T button

A Mode:

Changes the captured area (p.32).

Q Mode:

In single-image display, pressing f switches to 6-image display. Pressing f

again switches to 12-image display. Press y to return to the previous display.

In single-image display, pressing y magnifies the image. Press f to return to

the previous display.

In 12-image display, press f to change to folder or calendar display.

In folder/calendar display, press y to change to 12-image display.

Adjusts the volume during playback of movies (p.44).

4Q button

A Mode:

Switches to Q mode.

Q Mode:

Switches to A mode.

5Four-way controller

A Mode:

(2) : Changes the drive mode (p.36).

(3) : Displays the Capture Mode Palette (p.34).

(4) : Changes the flash mode (p.39).

(5) : Changes the focus mode (p.40).

(23) : Adjusts the focus when the focus mode is set to \ (p.41).

Q Mode:

(2) : Plays back and pauses a movie (p.44).

(3) : Displays the Playback Mode Palette (p.47).

Stops a movie during playback (p.44).

(45) : Displays the previous or next image during single-image display

(p.44).

Fast-forwards, fast-reverses, frame forwards, and frame

reverses during movie playback (p.44).

(2345) : Changes the position of the area to be magnified during zoom

display.

Selects an image in 6- or 12-image display, a folder in folder display,

and a date in calendar display.

Adjusts the position of a frame or an image when you are using

the Original Frame function.

64 button

A Mode:

Changes the information on the display (p.12).

Q Mode:

Changes the information on the display (p.13).

Returns zoom, 6- or 12-image display to single-image display.

Changes to 12-image display of the selected folder during folder display.

Changes to single-image display of the selected date during calendar display.

73 button

A Mode:

In Still Picture Capture Mode, [A Rec. Mode] menu appears. In Movie Mode,

[C Movie] menu appears (p.24).

Q Mode:

Displays the [W Setting] menu during single-image display (p.24).

Returns to single-image display during Playback Mode Palette display (p.46).

Returns zoom, 6- or 12-image display to single-image display.

Switches from folder/calendar display to 12-image display with the cursor

placed on the most recent image.

8Movie button

A Mode:

Starts movie recording in Still Picture Capture Mode (p.43).

9Green/i button

A Mode:

Switches to 9 (Green) mode.

Calls up the assigned function.

Q Mode:

Switches from single-image display to the Delete screen (p.48).

Switches from 6- or 12-image display to the Select & Delete screen.

Switches from folder display to the calendar display screen.

Switches from calendar display to the folder display screen.

In this manual, the method for operating the four-way controller is shown in illustrations,

such as in the ones below.

Macro stand

Attaching the supplied macro stand (O-MS1) reduces camera shake during shooting

in (Digital Microscope) mode. Insert two clips into the slits in upper and lower sides

of the LED Macro Lights part. When attaching and detaching the macro stand, do not

hold the clip part.

* When using the macro stand, the camera may not be able to focus if the objects

have uneven surfaces.

5 or

2 or

3 or

or 4

Display Indications

The display changes in the following sequence each time you press the 4

button: “Normal Display”, “Histogram + Info”, “Grid Display”, “No Info”, “LCD Off”.

Normal Display/ Histogram + Info/ Grid Display in Still Picture Capture Mode

1 to 18 and A1 appear when “Normal Display” is selected. B1 to B6 appear at the

position of 16 when “Histogram + Info” is selected. Only A1 appears when “Grid

Display” or “No Info” is selected.

Display in A Mode

1Shooting mode (p.33) 15 Digital zoom/Intelligent Zoom

icon (p.32)

2Battery level indicator (p.18)

3Face Detection icon 16 Date and time (p.23)

4Date Imprint setting 17 World Time setting

5EV Compensation 18 D-Range Setting

6Shutter speed A1 Focus frame (p.30)

7Aperture B1 Recorded Pixels

8Pixel Track SR icon B2 Quality Level

9Memory status (p.21) B3 White Balance

10 Remaining image storage capacity B4 AE Metering

11 Flash Mode (p.39) B5 Histogram

12 Drive Mode (p.36) B6 Sensitivity

13 Focus Mode (p.40)

14 Eye-Fi communication status

14:2

1 4 : 2 5

14:25

ISISO

20200

AWB

ISO

200

AWB

1212

3 838

+1.

+ 1 . 0+1.0

1/25

1 / 2 5 01/250

F3.

F 3 . 5F3.5

DATE

12/12/20141 2 / 1 2 / 2 0 1 412/12/2014

1511 12 13 14

17 18 B1 B2 B3 B4

* 6 and 7 are only displayed when the shutter release button is pressed half-way.

*For 8, M is displayed when Pixel Track SR is set to O (On) on the [A Rec.

Mode] menu. f is displayed when the shutter release button is pressed

halfway if Pixel Track SR is set to P (Off) and there is a danger of camera

shake.

* For 13, when the focus mode is set to = and the Auto Macro function is

activated, q appears on the display (p.40).

* 14 changes depending on [Eye-Fi] setting in the [W Setting] menu.

* 16 appears for two seconds after the camera is turned on.

* 18 changes depending on [D-Range Setting] settings in the [A Rec. Mode]

menu. No icon is displayed on the screen when [Highlight Correction] and

[Shadow Correction] are both set to [Off].

* When the shooting mode is b (Auto Picture) and if you press the shutter

release button halfway, the automatically selected shooting mode appears in

A1 even when “No Info” is selected.

* If there are overexposed highlight areas in the image, they will blink red on the

display, and if there are underexposed shadow areas, they will blink yellow.

* Some indications may not appear depending on the shooting mode.

The display shows the shooting information of the image in playback mode. The

display changes in the following sequence each time you press the 4 button:

Normal Display/ Histogram + Info in Playback Mode

(All of the display items are displayed here for explanatory purposes.)

The display shows information such as the shooting conditions. In "Normal

Display", A1 to A10 are displayed. In "Histogram + Info", B1 to B8 are displayed

as well.

Display in Q Mode

1 0 0-

003

0 0 3 8

100-0038

F3.

F 3 . 5

F3.5

1/25

1 / 2 5 0

1/250

ISO

200

ISO

200

AWB

Edit

B5 B6 B7 B8

A10

* A1 appears only if the Face Detection function worked when the image was shot.

* In “Normal Display”, A3 disappears if no operation is performed for two seconds.

* A5 appears even when “No Info” is selected, but disappears if no operation is

performed for two seconds. When no operation is performed for two seconds in

“Normal Display” or “Histogram + Info”, only “Edit” disappears.

* A10 appears only when the volume is being adjusted during playback of movies

(p.44).

* When “Normal Display” is selected, the current date and time appears for two

seconds in the B4 to B8 positions.

* If there are overexposed highlight areas in the image, they will blink red on the

display, and if there are underexposed shadow areas, they will blink yellow.

A guide indicator for each available button or key operation appears as follows on

the display during operation.

A1 Face Detection icon A10 Volume icon

A2 Playback mode B1 Shutter speed

Q: Still picture (p.44) B2 Aperture

K: Movie (p.44) B3 Histogram

A3 Battery level indicator (p.18) B4 Sensitivity

A4 Protect icon B5 Recorded Pixels

A5 Four-way controller guide B6 Quality Level

A6 File number B7 White Balance

A7 Folder number B8 AE Metering

A8 Memory status (p.21)

A9 Eye-Fi communication status

Guide Display

2Four-way controller (2) Zoom button

3Four-way controller (3)4 button

4Four-way controller (4) Shutter release button

5Four-way controller (5)X (green), iGreen/i button

3 button (red) Movie button

SHUTTER

Powering the Camera

Use the rechargeable lithium-ion battery D-LI92 that is provided with the camera.

Open the battery/card cover.

Press the battery/card cover lock lever in the direction shown 1, slide the cover

towards 2 and open it towards 3.

Using the side of the battery to press the battery lock lever in

the direction of 4, insert the battery with the PENTAX logo

pointing toward the lens.

Push the battery in until it is locked in place.

Close the battery/card cover.

Push down and slide the battery/card cover with steady but gentle force in the

opposite direction indicated by 2.

The battery/card cover may be difficult to close because the waterproof packing

is very thick to prevent water from entering the camera.

To close the battery/card cover, push down on it toward the camera with your

thumb where it says [PUSH]. Then slide it until the battery/card cover lock lever

slides into place covering the yellow mark on the lock lever.

Installing the Battery

If the battery is incorrectly oriented, malfunction may result.

Battery/card cover

lock lever

Battery lock lever

Battery/card

cover

Battery

Open the battery/card cover.

Push the battery lock lever towards 4.

The battery will be ejected. Take care not to drop the battery when removing it.

Removing the Battery

• Do not use excessive force when opening and closing the battery/card

cover because the waterproof seal may peel off. If the seal is not in the

correct position, the camera will not be waterproof.

• If the battery/card cover is not locked securely, water, sand, or dirt may get

into the camera.

• This camera uses a rechargeable lithium-ion battery D-LI92. Use of any

other type of battery may damage the camera and cause malfunction.

• Insert the battery correctly. If the battery is incorrectly oriented, malfunction

may result.

• Do not remove the battery while the camera is turned on.

• When storing the battery for more than 6 months, charge the battery for 30

minutes using the power adapter and store the battery separately.

Be sure to recharge the battery every 6 to 12 months. Storing the battery

below room temperature is ideal. Avoid storing it in high temperatures.

• The date and time may be returned to the default settings if the camera is

left without the battery for a long time.

• Be careful as the camera or the battery may become hot when the camera

is used continuously for a long period of time.

• Allow the camera to dry completely before changing the battery. Avoid

changing the battery where the camera is likely to get wet or dirty, and

make sure that your hands are dry.

Connect the supplied power adapter (D-PA135) to the camera and charge the

battery before using it for the first time or after a long period of non-use, or when

the [Battery depleted] message appears.

Make sure that the camera is turned off and open the terminal cover.

Move the terminal cover lock lever in the direction shown by 1, slide the cover

in the direction shown by 2 and open the cover in the direction shown by 3.

Connect the USB cable to the power adapter.

Connect the USB cable to the camera.

Plug the power adapter into the power outlet.

The power lamp blinks while charging.

When charging is finished, the power lamp turns off.

The terminal cover will not close while charging. Leave the cover open when

charging and do not attempt to close it.

Unplug the power adapter from the power outlet when

charging is finished.

Remove the USB cable from the camera.

Charging the Battery

USB cable

Power adapter

To power outlet

Power lamp

While charging: Blinks

Charging finished: Turns off

Close the terminal cover.

Close the terminal cover in the opposite direction indicated by 3. While lightly

pressing on the cover, slide it away from 2 until it clicks.

• Image Storage Capacity, Movie Recording Time, and Playback Time

(at 23°C (73.4°F) with the display on and the battery fully charged)

*1 The image storage capacity shows the approximate number of shots recorded

during CIPA-compliant testing (at 23°C (73.4°F) with display on and flash used for

50% of the shots). Actual performance may vary according to operating conditions.

*2 According to the results of in-house testing.

• Battery Level Indicator

You can check the battery level by the indicator on the display.

• Do not charge batteries other than the rechargeable lithium-ion battery

D-LI92 using the supplied power adapter (D-PA135). Doing otherwise may

cause damage or overheating.

• The battery has reached the end of its service life when it starts to run down

soon after being charged. Replace it with a new battery.

• If the camera is connected to the power outlet but the charging indicator

fails to light, the battery may be faulty. Replace it with a new battery.

• The time required to fully charge the battery is about 120 minutes (max.).

(The charging time may vary depending on the ambient temperature and

charging conditions.) The appropriate ambient temperature for charging

the battery is 0°C to 40°C (32°F to 104°F).

•

You cannot turn on the camera while it is charging.

Image Storage Capacity*1

(flash used for 50% of shots) Movie Recording Time*2 Playback Time*2

Approx. 300 pictures Approx. 90 min. Approx. 260 min.

• Battery performance may deteriorate as temperature decreases. When

using the camera in cold regions, we recommend carrying a spare battery

in your pocket to keep it warm. Battery performance will recover when the

temperature returns to normal.

• Be sure to take a spare battery with you when traveling abroad or to a cold

region, or if you intend to take a lot of pictures.

Screen Display Battery Status

(green) Adequate power remains.

(green) Battery is running low.

(yellow) Battery is running very low.

(red) Battery is exhausted.

[Battery depleted] The camera will turn off after this message appears.

Installing an SD Memory Card

This camera uses SD Memory Cards, SDHC Memory Cards or SDXC Memory

Cards. Captured images are saved on the SD Memory Card if a card is inserted

in the camera. They are saved in the built-in memory if a card is not inserted

(p.21).

• Be sure to use this camera to format (initialize) an SD Memory Card that is

unused or has been previously used on other cameras or digital devices.

• Make sure that the camera is turned off before inserting or removing the SD

Memory Card.

• Allow the camera to dry completely before changing the SD Memory Card.

Avoid changing the card where the camera is likely to get wet or dirty, and

make sure that your hands are dry.

• Do not use excessive force when sliding the battery/card cover open and

closed because the waterproof seal may peel off. If the seal is not in the

correct position, the camera will not be waterproof.

• The number of still pictures that can be stored varies depending on the

capacity of the SD Memory Card and the selected number of recorded

pixels and quality level (p.50).

•

The power lamp blinks while the SD Memory Card is being accessed (data

is being recorded or read).

Backing Up Data

The camera may not be able to access data in the built-in memory in the case of a

malfunction. Use a computer or other device to back up important data in another

location.

Displaying data stored in the built-in memory

When an SD Memory Card is inserted in the camera, still pictures and movies on the

SD Memory Card are displayed. If you want to display still pictures and movies stored

in the built-in memory, turn the camera off and remove the SD Memory Card.

Make sure that the camera is turned off before inserting or removing the

SD Memory Card.

Open the battery/card cover.

Press the battery/card cover lock lever in the direction shown 1, slide the cover

towards 2 and open it towards 3.

Insert the SD Memory Card into the SD Memory Card socket

so that the label is facing toward the front of the camera (the

side with the lens).

Push the card in all the way. Images may not be recorded correctly if the card is

not inserted all the way.

To remove the SD Memory Card, push it in once and then pull it out.

Close the battery/card cover.

Push down and slide the battery/card cover with steady but gentle force in the

opposite direction indicated by 2.

If the battery/card cover is not locked securely when you close it, water, sand,

or dirt may get into the camera.

• The image file size varies depending on the number of recorded pixels and

the number of images that can be saved on an SD Memory Card also varies.

•

Set the number of recorded pixels for still pictures from the [

Rec. Mode]

menu and for movies from the [

Movie] menu.

•

For an approximate number of still pictures and amount of time of movies that

can be saved on an SD Memory Card, see “Main Specifications” (p.49).

SD Memory Card

Battery/card cover

SD Memory Card

socket

Turning the Camera On and Off

Press the power button.

The camera turns on and both the power lamp and display turn on.

If the [Language/ ] screen or [Date Adjustment] screen appears when you

turn the camera on, follow the procedure on p.22 to set the display language and/

or current date and time.

Press the power button again.

The camera turns off and both the power lamp and display turn off.

The SD Memory Card is checked when the

camera turns on and the memory status is

displayed.

Use this function when you want to play back images straightaway without taking

any picture.

Press and hold down the Q button.

The display turns on and the camera starts up in playback mode.

Taking Still Pictures 1p.30

Checking the SD Memory Card

aThe SD Memory Card is inserted. Images

will be saved on the SD Memory Card.

+The SD Memory Card is not inserted.

Images will be saved in the built-in memory.

The write-protect switch on the SD Memory

Card is in the LOCK position (p.5). Images

cannot be recorded.

Starting-up in Playback Mode

• To switch from playback mode to capture mode, press the Q button or

press the shutter release button halfway.

• In order to set the camera not to start up in playback mode, set [Playback

Mode] to P (Off) from [Startup Shortcut] in the [W Setting] menu.

Playing Back Still Pictures 1p.44

383 838

Memory status

Initial Settings

The [Language/ ] screen appears when the camera is turned on for the first

time. Perform the operations in “Setting the Display Language” below to set the

language, and in “Setting the Date and Time” (p.23) to set the current date and time.

Use the four-way controller (

2345

) to choose the display language.

Press the 4 button.

The [Initial Setting] screen appears in the

selected language. If the desired settings

for [Hometown] and [DST] (Daylight Saving

Time) appear, proceed to step 9.

Press the four-way controller (3).

The frame moves to [W Hometown].

Press the four-way controller (5).

The [W Hometown] screen appears.

Use the four-way controller (45) to choose a city.

Press the four-way controller (3).

The frame moves to [DST] (Daylight Saving Time).

Use the four-way controller (45) to select O(On) or P (Off).

Press the 4 button.

The [Initial Setting] screen reappears.

Press the four-way controller (3) to select [Settings complete].

Press the 4 button.

The [Date Adjustment] screen appears. Next, set the date and time.

Setting the Display Language

Cancel

Initial Setting

Hometown

New York

Settings complete

English

DST

OFF

Daylight saving time

Cancel

Initial Setting

Hometown

New York

Settings complete

English

DST

OFF

Set the current date and time and the display format.

Press the four-way controller (5).

The frame moves to [mm/dd/yy].

Use the four-way controller (23)

to choose the date and time

display format.

Choose from [mm/dd/yy], [dd/mm/yy] or [yy/

mm/dd].

Press the four-way controller (5).

The frame moves to [24h].

Use the four-way controller (23) to select [24h] (24-hour

display) or [12h] (12-hour display).

Press the four-way controller (5).

The frame returns to [Date Format].

Press the four-way controller (3).

The frame moves to [Date].

Press the four-way controller (5).

The frame moves to the month.

Use the four-way controller (23) to change the month.

Change the day and year in the same manner.

Next, change the time.

Press the four-way controller (3) to select [Settings

complete].

Press the 4 button.

This confirms the date and time.

Setting the Date and Time

If you press the 4 button in step 10, the camera clock is reset to 0 seconds.

To set the exact time, press the 4 button when the time signal (on the TV,

radio, etc.) reaches 0 seconds.

When the [Initial Setting] or [Date Adjustment] screen is displayed, you can

cancel the setting operation and switch to capture mode by pressing the

3 button. In this case, the [Initial Setting] screen will appear next time

you turn the camera on.

mm/dd/yy 24

00:00

Cancel

Settings complete

Date Adjustment

Date Format

Date

Time

01/01/2014

Setting the Camera Functions

To change the camera settings, press the 3 button to display the [A Rec.

Mode] menu or [W Setting] menu. Functions for playing back and editing images

can be accessed from the Playback Mode Palette.

There are three types of menus: [A Rec. Mode], [C Movie] and [W Setting].

Press the 3 button in Still Picture Capture Mode to display the [A Rec.

Mode] menu. Press the 3 button in Movie Mode to display the [C Movie]

menu. Press the 3 button in Q mode to display the [W Setting] menu.

Use the four-way controller (45) to move between menus.

Operating the Menus

SHUTTER

3 8

07:34

0 7 : 3 4

07:34

REC

Edit

Ed it

Edit

1 0 0-

003

0 0 3 8

100-0038

12/12/2014

12 /12/2014

12/12/2014 14:25

14 :25

14:25

Movie

Recorded Pixels

Mov

iSRe

Exit

Wind Suppression

AWB

1/4

Exit

Rec. Mode

Image Tone

Recorded Pixels

Bright

AE Metering

AF Setting

White Balance

Quality Level

Exit

Setting 1/4

Sound

Date Adjustment 01/01/2014

World Time

Alarm

Standard

Text Size

Language

English

In capture mode

In playback mode

Pressed

halfway

Pressed

halfway

• Available button and key operations appear on the display during menu

operation.

• The 3 button function varies depending on the screen. Refer to the

guide indications.

Exit Exits the menu and returns to the original screen.

Returns to the previous screen with the current settings.

Cancel Cancels the current selection, exits the menu and

returns to the previous screen.

The following list shows the items that can be set with the menus and provides

descriptions of each item.

[A Rec. Mode] Menu

This menu provides the functions related to taking still pictures and recording

movies.

Menu List

Item Description Default Setting

(Shooting mode:A)

Image Tone For setting the tone of images Bright

Recorded Pixels For choosing the number of recorded

pixels of still pictures (4608 x 2592)

Quality Level For setting the quality level of still pictures D (Better)

White Balance For adjusting the color balance according

to the lighting conditions F (Auto)

Setting

Focusing

Area

When = (Standard), q (Macro), or

(1cm Macro) is selected as the focus

mode, you can change the autofocus area

(Focusing Area)

J (Multiple)

Auto

Macro

For choosing whether or not to use the

auto macro function O (On)

Focus

Assist

For setting whether or not to use the focus

assist light O (On)

AE Metering For choosing the area of the screen that is

metered to determine the exposure L (Multi-segment)

Sensitivity For setting the sensitivity AUTO (125-1600)

AUTO ISO Range For setting the adjustment range when the

sensitivity is set to AUTO 125-1600

EV Compensation For adjusting the overall brightness of an

image ±0.0

D-

Range

Setting

Highlight

Correction

For setting the bright portion correction

function Auto

Shadow

Correction

For setting the dark portion correction

function Auto

Pixel Track SR For choosing whether to compensate for

camera shake while taking still pictures P (Off)

Face Detection

For automatically setting the focus and

exposure according to faces that are

detected and for setting the Self-portrait

Assist function

(Face Detection On)

Blink Detection

For choosing whether to use the Blink

Detection function with the Face Detection

function

O (On)

*IQ Enhancer = Image Quality Enhancer

[C Movie] Menu

[W Setting] Menu

Digital Zoom For choosing whether or not to use the

digital zoom O (On)

Instant Review For choosing whether to display Instant

Review O (On)

Memory

For choosing whether to save the set

values of the shooting functions or return to

the defaults when the camera is turned off

⎯

Green Button For assigning a function to the Green

button in A mode Green Mode

Sharpness For choosing sharp or soft outlines G (Normal)

Saturation

(Tone Adjustment)

For setting the color saturation. When

[Monochrome] is selected, the item

changes to [Tone Adjustment]

G Normal

(B&W for Tone

Adjustment)

Contrast For setting the image contrast level G (Normal)

Date Imprint For choosing whether to imprint the date

and/or time when taking still pictures Off

IQ Enhancer* For setting whether to apply the IQ

Enhancer process to an image O (On)

Macro Light For setting whether or not to turn on the

LED Macro Lights for macro photography P (Off)

• Use the 9 (Green) mode to enjoy easy picture-taking with standard settings,

regardless of the settings made from the [A Rec. Mode] menu.

• Assigning a frequently used function to the Green button enables you to go

straight to the desired function.

Item Description Default Setting

Recorded Pixels For choosing the number of recorded

pixels and the frame rate for movies (1920 x 1080·30fps)

Movie SR For choosing whether or not to use the

Movie Shake Reduction function O (On)

Wind Suppression For suppressing wind noises while

recording movies P (Off)

Item Description Default Setting

Sound

For adjusting the operation volume and

playback volume, and setting the start-up

sound, shutter sound, key operation

sound, and self-timer sound

⎯

Date Adjustment For adjusting the date and time ⎯

Item Description Default Setting

(Shooting mode:A)

Alarm For setting the alarm ⎯

World Time For setting the Hometown and Destination

cities ⎯

Text Size For setting the text size of the menu Standard

Language/ For setting the language in which menus

and messages appear

According to

initial setting

Folder Name For choosing how names are assigned to

folders for storing images Date

File Name For choosing how names are assigned to

images RIMG

USB Connection

For setting the method for connecting the

camera to a PC by the USB cable (MSC or

PTP) MSC

HDMI Out

For setting the HDMI output format when

connecting to an AV device with an HDMI

terminal

Auto

Eye-Fi For setting whether or not to use Eye-Fi

communication O (On)

Brightness Level For changing the brightness of the display G (Normal)

Power Saving For setting the time until the camera

enters power-saving mode 5 sec.

Auto Power Off For setting the time until the camera turns

off automatically 3 min.

Quick Zoom For choosing whether to use the Quick Zoom

function when playing back images P (Off)

Guide Display

For setting whether to display

explanations for selected items in Capture

Mode Palette and Playback Mode Palette

O (On)

Reset

For returning settings other than the date

and time, language and world time to their

defaults

Cancel

Delete All For deleting all the images at once Cancel

Pixel Mapping For correcting defective pixels on the

image sensor Cancel

Startup

Shortcut

Playback

Mode

For setting whether to start-up the camera

in playback mode. O (On)

LED

Lighting

For setting whether to turn the LED Macro

Lights on with the camera turned off. O (On)

Clock

Display

For setting whether to display the clock

with the camera turned off. O (On)

Format For formatting the SD Memory Card/built-

in memory Cancel

Item Description Default Setting

You can reset the camera settings to their defaults.

Use the four-way controller (23) to select [Reset] in the

[WSetting] menu.

Press the four-way controller (5).

The [Reset] screen appears.

Use the four-way controller (2) to

select [Reset].

Press the 4 button.

The settings return to the defaults.

You can use the camera as a clock. With the camera turned off, press and hold

down the 4 button to display the clock on the display.

Press and hold down the 4

button.

The camera turns on and the clock appears

on the screen.

The camera turns off automatically after

approximately 10 seconds.

Pressing the power button turns the

camera off immediately.

Resetting to Default Settings (Reset)

Displaying the Clock Display

Not to function the Clock Display by pressing 4 button, set [Clock Display]

to P (Off) in [Startup Shortcut] from the [W Setting] menu.

Reset

Returns to default

settings

Reset

Cancel

Taking Still Pictures

This camera has various functions and shooting modes that support a wide array

of scenes and subjects. This section explains shooting with the default settings

when shipped.

Press the power button.

The camera turns on and is ready to take still pictures. In this manual, this is

called Still Picture Capture Mode.

Check the subject and shooting

information on the display.

The focus frame in the middle of the display

indicates the automatic focusing area.

When the camera detects a person’s face,

the Face Detection function is activated and

the face detection frame appears.

You can change the captured area by pressing the zoom button (p.32).

Right (T) Enlarges the subject.

Left (W) Widens the area that is captured by the camera.

Press the shutter release button

halfway.

The camera emits focus assist light in dark

shooting situations.

The focus frame (or face detection frame)

on the display turns green when the camera

focuses on the subject.

Taking Pictures

383 838

Focus frame

3 8

Face detection frame

F4.6

F 4 . 6

F4.6

1/250

3 8

Press the shutter release button fully.

The picture is taken.

The flash discharges automatically depending on the light conditions.

The image appears on the display temporarily (Instant Review) and is saved to

the SD Memory Card or the built-in memory.

The shutter release button works in a two-step action as follows.

Press halfway

This refers to pressing the shutter release button gently to the first position. This

locks the focus setting and exposure. The green focus frame lights on the display

when the shutter release button is pressed halfway and the subject is in focus. If

the subject is out of focus, the frame turns white.

Press fully

This refers to pressing the shutter release button all the way down to the fully

depressed position. This takes a picture.

• Press the Green button to switch to 9 (Green) mode and let the camera

set all the shooting functions automatically.

•f is displayed when the shutter release button is pressed halfway if there

is a risk of camera shake.

Using the Shutter Release Button

Poor focusing conditions

The camera may not be able to focus under the following conditions. In these cases,

lock the focus on an object the same distance away as the subject (by pressing and

holding the shutter release button halfway), then aim the camera at your subject and

press the shutter release button fully.

• Objects that lack contrast such as a blue sky or white wall

• Dark places or objects, or conditions that prevent light being reflected back

• Intricate patterns

• Fast moving objects

• When both an object in the foreground and an object in the background exist in the

captured area

• Strongly reflected light or strong backlighting (bright background)

Not pressed Pressed halfway

(first position)

Pressed fully

(second position)

You can use the zoom to change the captured area.

Press the W/T button in A mode.

W Wide (left)

Widens the area that is captured by the

camera.

T Tele (right)

Enlarges the subject.

If you continue to press T, the camera

automatically switches from optical zoom to

Intelligent Zoom and stops at the point where

the zoom switches to digital zoom.

Once the button is released and pressed again, the camera switches to digital

zoom.

If the digital zoom is set to off in the menu, the optical zoom and the Intelligent

Zoom ranges are available for use. The zoom ratio of the Intelligent Zoom varies

depending on the number of recorded pixels.

The zoom bar is displayed as follows.

*1 You can zoom in to a maximum of 5x optically.

*2 The Intelligent Zoom range varies depending on the number of recorded

pixels. See the following table.

Recorded pixels and the maximum zoom ratio

Using the Zoom

Recorded Pixels Intelligent Zoom

(The zoom ratio includes the 5x optical zoom.) Digital zoom

// Not Available (5x optical zoom only)

Equivalent to

approx. 36x

6/Approx. 7.5x

f/Approx. 8.9x

hApprox. 11.3x

hApprox. 12x

3 8

36.0

Zoom bar

Zoom ratio

Zoom in with high image quality. Zoom in with some degree of image

deterioration.

Optical zoom range*1 Intelligent

Zoom range*2 Digital zoom

range

(*) V can be set only when (Report) mode is set.

This camera has a variety of shooting modes that let you take pictures or record

movies in different situations simply by choosing the right mode for the particular

situation from the Capture Mode Palette.

Press the four-way controller (3) in A mode.

The Capture Mode Palette appears.

Use the four-way controller

(2345) to choose a shooting

mode.

The guide of the selected shooting mode is

displayed in the lower part of the display.

Press the 4 button.

The shooting mode is selected and the camera returns to capture mode.

V (*) Not Available (5x optical zoom only)

lApprox. 22.5x Equivalent to

approx. 36x

mApprox. 36x (same as digital zoom)

• We recommend you use a tripod to prevent camera shake when taking

pictures at high zoom ratios.

• Pictures taken in the digital zoom range appear grainier than pictures taken

in the optical zoom range.

• The image magnified using Intelligent Zoom may appear rough on the

display. This does not affect the quality of the recorded image.

• Intelligent Zoom is available regardless of whether the digital zoom is

turned on or off.

Setting the Shooting Mode

Recorded Pixels Intelligent Zoom

(The zoom ratio includes the 5x optical zoom.) Digital zoom

Landscape

For capturing landscape

views. Enhances colors

of sky and foliage

Cancel

1/2

The following modes can be selected from the Capture Mode Palette.

Item Description Page

bAuto Picture

The camera automatically selects the

appropriate shooting mode from the following

fifteen modes

* When the camera detects the pet’s face, the

shutter is automatically released.

⎯

RProgram

Used for basic shooting. The shutter speed and

aperture are set automatically by the camera

during shooting. However, you can select and set

other functions as desired, such as the flash

mode and the number of recorded pixels

⎯

HDR Combines 3 images into a single image

delivering a wider dynamic range image ⎯

Handheld Night

Snap

Minimizes camera shake for shooting at night or

other low light settings ⎯

CMovie For recording movies. Sound is recorded at the

same time p.42

High Speed Movie Captures frames for slow motion playback ⎯

Digital Microscope Captures the bigger images of the closer objects

(fixed to h)⎯

aLandscape For capturing landscape views. Enhances colors

of sky and foliage ⎯

bFlower For images of flowers. The outline of the flower is

softened ⎯

Standard Night Scene

Night Scene

Portrait

Landscape Flower Portrait

Sport Candlelight Blue Sky

Portrait×

Blue Sky

Portrait×

Backlight

Sunset

Portrait×

Sunset

Group

Photograph

Text

*9 (Green) mode is available in addition to the ones noted above.

cPortrait For capturing portraits. Reproduces a healthy

and bright skin tone ⎯

Underwater For capturing images underwater ⎯

Underwater Movie Use this mode for taking underwater movies ⎯

Interval Shot Shoots a series of images at a specified interval

of time ⎯

Interval Movie Shoots a series of images at a specified interval,

and saves them as a movie ⎯

QSurf & Snow For bright images such as sand or snow.

Accurately meters for bright scenes ⎯

RKids For capturing moving kids. Reproduces a healthy

and bright skin tone ⎯

ePet For capturing images of moving pets ⎯

\Sport For a fast moving subject. Tracks the subject until

the picture is taken ⎯

ANight Scene For night time images. Use of a tripod or other

support is suggested ⎯

BNight Scene

Portrait

For images of people at night. Use of a tripod or

other support is advised ⎯

SFireworks For capturing fireworks. Use of a tripod or other

support is suggested ⎯

KFood For images of food and prepared dishes.

Enhances saturation and contrast ⎯

cDigital SR Higher sensitivity reduces blur ⎯

Report For capturing image with fixed 1280 x 960 pixels

for reports ⎯

Item Description Page

In Self-timer mode, a picture is taken ten seconds or two seconds after the shutter

release button is pressed.

Stabilize the camera with a tripod or other support when taking a picture with the

self-timer.

Press the four-way controller (2) in A mode.

The [Drive Mode] screen appears.

Use the four-way controller (45) to select g and press the

four-way controller (3).

Use the four-way controller (45)

to select g or Z and press the

4 button.

The camera is ready to take a picture using

the self-timer.

When the camera detects a person’s face,

the Face Detection function is activated

and the face detection frame appears.

• In shooting modes other than R (Program), A (Night Scene), C(Movie),

(Digital Microscope), (Handheld Night Snap), (Interval Shot),

(Interval Movie), (High Speed Movie), and c (Digital SR),

Saturation, Contrast, Sharpness, White Balance, etc. are automatically set

to the optimal settings for the selected mode.

• Some functions may not be available or may not function fully depending

on the selected shooting mode.

• The shutter speed tends to be slower when taking pictures of dark scenes.

To prevent camera shake, set the Pixel Track SR to O (On), or put the

camera on a tripod and use the self-timer (p.36) or a remote control unit.

Using the Self-timer

gUse this mode when you want to be included in a group picture. The picture

is taken approximately ten seconds after the shutter release button is pressed.

ZUse this mode to avoid camera shake. The picture is taken approximately two

seconds after the shutter release button is pressed.

MENU OK

Drive Mode

Self-timer

Drive Mode

Self-timer

Cancel

Cancel OK

Press the shutter release button to take a picture.

The countdown starts and the remaining seconds are displayed on the screen.

If you select g

The self-timer lamp and all of the LED Macro Lights turn on.

From 5 seconds before shooting, the LED Macro Lights turn off in order from

the top right.

From 3 seconds before shooting, the self-timer lamp blinks.

If you select Z

The self-timer lamp and the LED Macro Lights blink.

The picture is taken after a countdown of either ten seconds or two seconds.

Focusing may be compromised if you move the camera while the self-timer

lamp is blinking when taking still pictures.

•In C (Movie), (Underwater Movie), and (High Speed Movie)

modes, recording will start after ten seconds or two seconds.

• Press the shutter release button halfway while the self-timer is engaged to

stop the countdown and press fully to restart the countdown.

•Z cannot be selected while the 9 (Green) mode settings remain at

default. Select Z in another shooting mode and then switch the shooting

mode to 9.

• The self-timer lamp and LED Macro Lights do not turn on or blink in e (Pet)

mode.

• In the following situations, the LED Macro Lights remain turned on

regardless of the countdown.

-In (Digital Microscope) mode

- When [Macro Light] in the [A Rec. Mode] menu is set to O (On)

•g/Z cannot be selected in some shooting modes.

Setting the Shooting Functions

Settings for shooting are mostly set from the [A Rec. Mode] menu. Refer to

explanations for each function on how to make these settings.

Press the 3 button in Still Picture Capture Mode.

The [A Rec. Mode] menu appears.

Pressing the 3 button in Movie Mode displays the [C Movie] menu.

Use the four-way controller (2345) to select an item and

set it up.

After setting, press the 3 button.

The camera returns to capture mode.

The setting is saved and the camera returns to the previous screen.

Press the Q button.

When the [A Rec. Mode], [C Movie] or [W Setting] menu is displayed from

Amode, the setting is saved and the camera returns to playback mode.

Press the 3 button.

The changes are canceled and you can select a menu.

Using the Rec. Mode Menu Items

To Save the Setting and Start Taking Pictures

When the [W Setting] menu is displayed from Q mode, you can switch to

Amode by pressing the Q button.

To Save the Setting and Start Playback of Images

To Cancel the Changes and Continue with Menu Operations

Press the four-way controller (4)

in A mode.

The [Flash Mode] screen appears.

The flash mode changes each time the

button is pressed. You can also change the

setting using the four-way controller (23).

The 3 button function varies depending on the screen. Refer to the

guide indications.

Exit Exits the menu and returns to the original screen.

Returns to the previous screen with the current settings.

Cancel Cancels the current selection, exits the menu and returns

to the previous screen.

Selecting the Flash Mode

,Auto The flash discharges automatically depending on the light

conditions.

aFlash Off

The flash does not discharge, regardless of the brightness.

Use this mode to take pictures where flash photography is

prohibited.

bFlash On The flash discharges for each shot regardless of the

brightness.

cAuto + Red-eye

This mode reduces the red-eye phenomenon caused by the

light from the flash being reflected in the subject’s eyes. The

flash discharges automatically.

dFlash On +

Red-eye

This mode reduces the red-eye phenomenon caused by the

light from the flash being reflected in the subject’s eyes. The

flash discharges regardless of the light conditions.

• The available modes differ depending on the selected shooting mode,

focus mode or drive mode.

• If you use the Face Detection function when , is selected, the flash mode

is automatically set to d.

• A pre-flash discharges when using the red-eye reduction function.

Using the flash when capturing images at a close distance may cause

irregularities in the image due to the light distribution.

MENU OK

OKCancel

Cancel

Flash Mode

Auto

Flash Mode

Auto

Press the 4 button.

The setting is saved and the camera returns to capture mode.

Press the four-way controller (5)

in A mode.

The [Focus Mode] screen appears.

The focus mode changes each time the

button is pressed. You can also change the

setting using the four-way controller (23).

About the red-eye phenomenon

Taking pictures using the flash may cause the subject’s eyes to appear red in the

resulting picture. This phenomenon occurs when the light from the flash is reflected

in the subject’s eyes. It can be reduced by increasing the illumination in the area

around the subject and/or decreasing the subject distance and adjusting the lens to

wider angle setting. Setting the flash mode to c (Auto + Red-eye) or d (Flash On +

Red-eye) is also an effective way of reducing red eyes.

Selecting the Focus Mode

=Standard

This mode is used when the distance to the subject is from 50 cm

to ∞. The camera is focused on the subject in the autofocus area

when the shutter release button is pressed halfway.

qMacro

This mode is used when the distance to the subject is from 10 cm

to 60 cm. The camera is focused on the subject in the autofocus

area when the shutter release button is pressed halfway.

1cm Macro

This mode is used when the distance to the subject is from 1 cm

to 30 cm. The camera is focused on the subject in the autofocus

area when the shutter release button is pressed halfway.

3Pan Focus

This mode is used when you ask someone to take pictures for

you, or when taking pictures of the scenery through the window

of a car or train. The entire picture, from the front to the back, is

focused.

sInfinity This mode is used for taking distant objects. The flash is set to

a (Flash Off).

\Manual Focus This mode lets you adjust the focus manually.

MEN

MENU OK

Cancel

Cancel OK

Focus Mode

Standard

Focus Mode

Standard

Press the 4 button.

The setting is saved and the camera returns to capture mode.

The procedure for setting the focus manually (\) is described here.

Press the four-way controller (5) in A mode.

The [Focus Mode] screen appears.

Use the four-way controller (5) to select \.

Press the 4 button.

The central portion of the image is magnified to full screen on the display.

Press the four-way controller

(23).

The \ indicator appears on the display to

indicate the approximate distance to the

subject. Use the four-way controller (23)

to adjust the focus using the indicator as a

guide.

2 for distant focus

3 for closer focus

Press the 4 button.

The focus is locked and the camera returns to capture mode.

After the focus is locked, you can press the four-way controller (5) again to

display the \ indicator and readjust the focus.

• The available modes differ depending on the selected shooting mode.

• The noise from focusing is recorded when a focus mode other than 3 or

s is selected in C (Movie), (Underwater Movie), and (High Speed

Movie) modes.

• When [Auto Macro] is on and shooting with q selected, if the subject is

further than 60 cm away, the camera automatically focuses to ∞ (Infinity).

To Set the Manual Focus

The shooting mode and drive mode cannot be changed while the \

indicator is displayed.

To switch from \ to another focus mode, press the four-way controller (5)

while the \ indicator is displayed.

0.5

\ indicator

Recording Movies

This mode enables you to record movies. Sound is recorded at the same time.

Use the four-way controller (2345) to select C (Movie)

from the Capture Mode Palette.

Press the 4 button.

The C (Movie) mode is selected and the

camera returns to capture mode.

The following information appears on the

display.

1Movie mode icon

2Movie Shake Reduction icon

3Remaining recordable time

4REC indicator (blinks during

recording)

5Focus frame (does not appear during recording)

You can change the captured area by pressing the W/T button.

TEnlarges the subject.

WWidens the area that is captured by the camera.

Press the shutter release button fully.

Recording starts. You can continue recording until the recorded movie time

reaches 25 minutes.

Press the shutter release button fully.

Recording stops.

Recording Movies

Playing Back a Movie 1p.44

07:34

REC

325

If you keep the shutter release button pressed for more than one second,

recording will continue as long as you keep the button pressed. Shooting stops

when you take your finger off the shutter release button.

This camera starts/stops movie recording simply by pressing the Movie button,

without selecting C (Movie) from the Capture Mode Palette. This is useful when

you want to start recording quickly.

Press the Movie button.

Recording starts. You can continue recording until the recorded movie time

reaches 25 minutes.

Press the Movie button again.

Recording stops.

• The focus mode can be changed before recording starts.

• When the focus mode is set to \(Manual Focus), you can adjust the

focus before recording starts and during recording.

• When the shooting mode is set to C (Movie), Face Detection is

automatically set to on. You can select Smile Capture or Face Detection Off

before starting recording a movie. When the Smile Capture function is

activated, movie recording starts automatically when the camera

recognizes the subject’s smile. However, the Smile Capture function may

not work depending on the condition of the recognized faces, and movie

recording may not start automatically. If this happens, press the shutter

release button to start movie recording.

• When you use the SD Memory Card, use SD Speed Class 4 or higher

cards.

• Movies recorded in C mode capture a different area than still pictures.

Keeping the Shutter Release Button Pressed

Recording a Movie Quickly Using the Movie

Button

• You cannot stop recording by pressing the shutter release button. To stop

recording, press the Movie button.

• You cannot start recording a movie by pressing the Movie button when the

shooting mode is set to C (Movie), (Underwater Movie), (Digital

Microscope), k (Interval Shot), (High Speed Movie), (Interval

Movie), or e (Pet), or the camera is in Q mode.

• Movies are recorded with the default settings for the [C Movie] menu when

recording movies with the Movie button (p.27).

Playing Back Images

Press the Q button after taking a

picture.

The camera enters Q mode and the image

appears on the display. Displaying one

image in full in Q mode (default setting) is

called single-image display.

Press the four-way controller (45).

The previous or next image appears.

Press the i button while the image is

displayed to display the Delete screen. Press

the four-way controller (2) to select [Delete]

and press the 4 button.

You can play back the movies you have taken. The sound is played back at the

same time.

Enter Q mode and use the four-way controller (45) to

choose the movie you want to play back.

Press the four-way controller

(2).

Playback starts.

Playing Back Still Pictures

To Play Back the Previous or Next Image

To Delete the Displayed Image

Playing Back a Movie

1 0 0-

003

0 0 3 8

100-0038

Edit

Edit 14:25

14:25

12/12/2014

14:2512/12/2014

File number

100

1 0 0 -

0017

0 0 1 7

100-0017

Delete

Cancel

Edit

0 0 : 3 0

1 0 0-

001

0 0 1 7

00:30

100-0017

14:25

12/12/2014

14:2512/12/2014

The following operations can be performed during playback.

Four-way controller (2) Pauses playback

Zoom button right (y) Increases the volume

Zoom button left (f) Reduces the volume

Press and hold the four-way controller (

)

Fast-forwards playback

Press and hold the four-way controller (

)

Fast-reverses playback

The following operations can be performed while playback is

paused.

Four-way controller (4) Reverses frames(*)

Four-way controller (5) Forwards frames

Four-way controller (2) Resumes playback

(*)In frame-reverse mode, the first frame of every 30 frames appears on the

display with each press of the four-way controller(

). For example, when you

reverse frames from the second frame to the 31st frame, the first frame

appears on the display, and when you reverse frames from the 32nd to 61st,

the 31st frame appears.

Press the four-way controller (3).

Playback stops.

In Q mode, press the four-way controller (3).

The Playback Mode Palette appears.

Use the four-way controller

(2345) to choose an icon.

The guide for the selected function appears

below.

Press the 4 button.

The playback function is recalled.

Only movies taken with this camera can be played back. Movies taken with

other cameras cannot be played back.

Using the Playback Functions

OKMENU

1/2

For continuously playing

back images. Screen or

sound effects can be set

OKCancel

Slideshow

When the frame is placed over an icon on the Playback Mode Palette, the

guide of that function appears.

OKMENU

1/2

OKMENU

Image Rotation

1/2

Slideshow

101 0 0-0030038100-0038

EditEditEdit

Cancel

Rotates captured images.

Useful when viewing

vertical images on a TV

Cancel

14:2514:2512/12/201412/12/2014 14:2512/12/2014

OKMENU

For continuously playing

back images. Screen or

sound effects can be set

OKCancel

SHUTTER

'10/02/02 14:25

3 838

Goes to the screen for

selected playback function.

Closes the Playback Mode

Palette and goes to A mode.

Press halfway

' 1 0 / 0 2 / 0 2 1 4 : 2 5

100-0038

3 8

Edit 14:2502/02/'12

SHUTTER

' 1 0 / 0 2 / 0 2 1 4 : 2 5

100-0038

3 8

Edit 14:2502/02/'12

Playback Mode Palette

Playback Mode Description Default Setting

uSlideshow

For continuously playing back

images. Screen or sound effects can

be set

⎯

sImage Rotation Rotates captured images. Useful

when viewing vertical images on a TV Normal

kSmall Face Filter Reduces the size of faces in the

image, for well-proportioned portraits Approx. 7%

Ink Rubbing Filter Creates an image similar to ink

rubbing from original pictures G (Standard)

Collage Creates a collage print page from

saved image files ⎯

PDigital Filter For modifying images with a Color

filter or Soft filter B&W/Sepia

HDR Filter Processes single image to simulate

HDR effect ⎯

EOriginal Frame

Available to make from the kind and

color of a frame. Available to enter

text

All sides/White

[Movie

Edit

Save as

Still Image

For saving one frame from a movie as

a still picture

⎯

Divide

Movies For dividing a movie into two

Adding

title picture

For adding a title picture to your

movie

ZRed-eye Edit Attempts to edit out the red-eye effect

in image. Success may vary ⎯

nResize

Changes Recorded Pixels and

Quality Level to make the file size

smaller

Depending on the

picture taken

oCropping For cropping images to the size you

like. Saved as a new image

Depending on the

picture taken

pImage Copy To copy images between the built-in

memory and an SD Memory Card

Built-in memory →

SD Memory Card

ZProtect Protects images from delete function.

Format function still erases all

Depending on the

picture taken

Start-up Screen For setting a captured image as the

Start-up Screen Default

Deleting Images

Delete images that you do not want to keep.

You can delete a single image.

Enter Q mode and use the four-way controller (45) to

choose the image you want to delete.

Press the i button.

A confirmation screen appears.

Use the four-way controller (2) to

select [Delete].

Press the 4 button.

The image is deleted.

Deleting a Single Image

Protected images cannot be deleted.

100

1 0 0 -

0017

0 0 1 7

100-0017

Delete

Cancel

Appendix

Main Specifications

Type Fully automatic compact digital camera with built-in zoom lens

Number of Effective

Pixels

Approx. 16 megapixels

Image Sensor 1/2.3 inch CMOS

Number of Recorded

Pixels

Still (4608 x 3456), (3456 x 3456),

(4608 x 2592), 6 (3072 x 2304),

(3072 x 1728), f (2592 x 1944),

(2592 x 1464), h (2048 x 1536),

h (1920 x 1080), l (1024 x 768), m (640 x 480)

* Fixed at h in Digital Microscope mode.

Fixed at f/ in Burst Shooting mode.

* Fixed at V (1280 x 960) in Report mode.

* Fixed at f/ in Original Frame mode.

Movie (1920 x 1080/30fps), (1280 x 720/60fps)

M (1280 x 720/30 fps)

Sensitivity AUTO, Manual (ISO 125, 200, 400, 800, 1600, 3200, 6400)

* The sensitivity is fixed at AUTO (125-6400) in Digital SR mode.

File Formats Still JPEG (Exif 2.3), DCF 2.0,

PRINT Image Matching III

Movie MPEG-4 AVC/H.264, approx. 60 fps/30 fps, PCM system,

monaural sound, Movie SR (Movie Shake Reduction)

Quality Level Still C (Best), D (Better), E (Good)

Movie Fixed at C (Best) *Unchangeable

Storage Media Built-in memory (approx. 68 MB), SD Memory Card, SDHC Memory

Card, SDXC Memory Card

Approximate Image Storage Capacity and Recording Time

Still

• The image storage capacity is for reference only. The actual image storage capacity

may vary depending on the SD Memory Card and the subject.

•V (1280x960) can be set only when (Report) mode is set.

Movie

• The above figures are based on our standard shooting conditions and may vary

depending on the subject, shooting conditions and type of the SD Memory Card

used.

• The maximum length of continuous recording time for a movie is 25 minutes.

Built-in Memory 2 GB

SD Memory Card

CD E CD E

(4608 x 3456) 13 23 38 370 653 1078

(3456 x 3456) 15 30 46 435 853 1307

(4608 x 2592) 15 30 46 435 853 1307

6 (3072 x 2304) 23 43 69 653 1205 1921

(3072 x 1728) 27 53 76 778 1499 2119

f (2592 x 1944) 27 53 76 778 1499 2119

(2592 x 1464) 36 69 99 1024 1921 2794

h (2048 x 1536) 43 85 124 1205 2364 3415

h (1920 x 1080) 63 114 167 1756 3235 4728

V (1280 x 960) 99 181 256 2794 5122 6830

l (1024 x 768) 150 256 335 4098 6830 8782

m(640 x 480) 311 484 545 8782 12295 15368

Built-in Memory 2 GB

SD Memory Card

(1920 x 1080/30 fps) 34 sec. 17 min. 2 sec.

(1280 x 720/60 fps) 34 sec. 17 min. 2 sec.

M(1280 x 720/30 fps) 55 sec. 27 min. 38 sec.

White Balance Auto, Daylight, Shade, Tungsten Light, Fluorescent Light (Daylight

Colors/Daylight White/White Light), Manual

Lens Focal Length 5.0 - 25.0 mm

(approx. 28 - 140 mm in 35 mm format equivalent)

Maximum

Aperture

F3.5 (W) - F5.5 (T)

Lens Construction 11 elements in 9 groups (5 aspherical elements)

Zoom Type Electrically driven

Optical Zoom 5x

Intelligent Zoom 6/ : approx. 7.5x, f/ :approx. 8.9x,

h: approx. 11.3x, h: approx. 12x, l: approx. 22.5x,

m: approx. 36x (when combined with optical zoom)

Digital Zoom Max. approx. 7.2x (combines with 5x optical zoom to give zoom

magnification equivalent to 36x)

Motion Blur Reduction Still Electronic Shake Reduction (Pixel Track SR),

Hi-sensitivity Shake Reduction (Digital SR)

Movie Electronic Movie Shake Reduction (Movie SR)

Display 2.7 inch wide-LCD, approx. 230,000 dots (AR coating (cover only))

Playback Modes Single-frame, 6-frame, 12-frame, Magnified view (max. 10x,

scrollable), Folder Display, Calendar Display, Histogram Display,

Highlight/Shadow Area Alert, Select & Delete, Slideshow, Resize,

Cropping, Image Copy, Image Rotation, Digital Filter, HDR Filter,

Original Frame, Ink Rubbing Filter, Collage, Small Face Filter, Movie

Playback/Edit (Save as Still image, Divide, Adding title picture), Red-

eye Edit, Protect, Start-up Screen

Focus Mode Autofocus, Macro, 1cm Macro, Pan Focus, Infinity, Manual Focus

Focus Type TTL contrast detection system by sensor

Multiple (9-point autofocus)/spot/automatic

tracking changeable

Focus Range

(From lens face)

Standard : 0.5 m - ∞ (Entire zoom range)

Macro : 0.1 m - 0.6 m (Entire zoom range)

1cm Macro : 0.01 m - 0.3 m (Mid-zoom to

telephoto)

* It is possible to switch to Infinity, Pan Focus and

Manual Focus.

* Face Detection AF is available only when the

camera recognizes the subject’s face.

Focus Lock By half-pressing the shutter release button

Exposure Control AE Metering Multi-segment metering, Center-weighted

metering, Spot AE metering

EV Compensation ±2 EV (can be set in 1/3 EV steps)

Face Detection Detection of up to 32 people’s faces (up to 31 face detection frames

on the display), Smile Capture, Blink Detection, Self-portrait Assist,

Self-portrait Assist + Smile Capture

* Face Detection AE is available only when the camera detects the

subject’s face.

Pet Detection Detectable number of pets: 1

Shooting Mode Auto Picture, Program, HDR, Handheld Night Snap, Movie,

Underwater, Underwater Movie, Digital Microscope, Landscape,

Flower, Portrait, Interval Shot, Interval Movie, High Speed Movie,

Digital SR, Surf & Snow, Kids, Pet, Sport, Night Scene, Night Scene

Portrait, Fireworks, Food, Report, Green

Digital Filter B&W/Sepia, Toy Camera, Retro, Color (red, pink, purple, blue, green,

yellow), Extract Color (red, green, blue), Color Emphasis (Sky Blue,

Fresh Green, Delicate Pink, Autumn Leaves), High Contrast,

Starburst (Cross, Heart, Star), Soft, Fish-eye, Brightness, Miniature

Movie Continuous

Recording Time

Approx. 1 second - 25 minutes (however, only until the

built-in memory or SD Memory Card is full)

Shutter Speed 1/4000 sec. - 1/4 sec. (mechanical and electronic shutters),

max. 4 sec. (Night Scene mode)

Built-in Flash Modes Auto, Flash Off, Flash On, Auto + Red-eye, Flash

On + Red-eye

Flash Range Wide-angle: approx. 0.2 - 3.9 m

(approx. 0.66 - 13 ft.) (Sensitivity: AUTO)

Telephoto: approx. 0.2 - 2.5 m

(approx. 0.66 - 8.2 ft.) (Sensitivity: AUTO)

Drive Mode Single-frame, Self-timer (10 sec., 2 sec.), Continuous Shooting, Burst

Shooting, Remote Control (0 sec., 3 sec.), Auto Bracketing

Self-timer Electronic control type, control time: Approx. 10 sec., 2 sec.

Time Function World Time 75 cities (28 time zones)

Clock Display Clock Display by holding down 4 button while

camera is turned off (for approx. 10 sec.)

Alarm Alarm with simultaneous display of the Clock

Display at specified time

Power Source Rechargeable lithium-ion battery D-LI92, AC adapter kit (optional)

Battery Life Image Storage

Capacity

Approx. 300

pictures

* Recording capacity shows the approximate

number of shots recorded during CIPA-compliant

testing (at 23°C (73.4°F) with display on and flash

used for 50% of the shots). Actual performance

may vary according to operating conditions.

Playback Time

Approx. 260 min.

* According to the results of in-house testing.

Movie Recording

Time

Approx. 90 min.

* According to the results of in-house testing.

Interfaces USB 2.0 (Micro-B) /HDMI terminal (Type D)

Waterproof and

Dustproof Rating

JIS waterproof grade 8 and JIS dustproof grade 6 (IP68) Continuous

underwater shooting possible for 2 hours at depth of 12 m.

Impact Resistance

Rating

Our drop test (1.5 m height onto a 5 cm thick plywood surface)

complying with MIL-Standard 810F Method 516.5-Shock testing.

* Waterproof performance is not guaranteed if the camera is exposed

to impact such as being dropped or hit.

* The camera is not guaranteed to be free of trouble or damages

under every condition.

Dimensions Approx. 122.5 (W) x 61.5 (H) x 29.5 (D) mm (approx. 4.8 (W) x 2.4 (H)

x 1.2 (D) inches) (excluding operating or protruding parts)

Weight RICOH WG-30:

Approx. 172 g (approx. 6.1 oz.) (excluding battery and SD Memory

Card)

Approx. 192 g (approx. 6.8 oz.) (including battery and SD Memory

Card)

Accessories Rechargeable lithium-ion battery, Power adapter (AC plug adapter

attached), USB cable, Strap, Macro stand, Start Guide, Regarding

Waterproof, Dustproof, and Shockproof Design

All our cameras purchased through authorized bona fide photographic distribution

channels are guaranteed against defects of material or workmanship for a period of

twelve months from the date of your purchase. Service will be rendered, and defective

parts will be replaced without cost to you within that period, provided the camera does

not show evidence of impact, sand or liquid damage, mishandling, tampering, battery

or chemical corrosion, operation contrary to operating instructions, or modification by

an unauthorized repair shop. The manufacturer or its authorized representatives shall

not be liable for any repair or alterations except those made with its written consent and

shall not be liable for damages from delay or loss of use or from other indirect or

consequential damages of any kind, whether caused by defective material or

workmanship or otherwise; and it is expressly agreed that the liability of the

manufacturer or its representatives under all guarantees or warranties, whether

expressed or implied, is strictly limited to the replacement of parts as hereinbefore

provided. No refunds will be made on repairs by non-authorized service facilities.

Procedure During 12-month Warranty Period

Any camera which proves defective during the 12-month warranty period should be

returned to the dealer from whom you purchased the camera or to the manufacturer. If

there are no representatives of the manufacturer in your country, send the camera to

the manufacturer, with postage prepaid. In this case, it will take a considerable length

of time before the camera can be returned to you owing to the complicated customs

procedures required. If the camera is covered by warranty, repairs will be made and

parts replaced free of charge, and the camera will be returned to you upon completion

of servicing. If the camera is not covered by warranty, regular charges of the

manufacturer or of its representatives will apply. Shipping charges are to be borne by

the owner. If your camera was purchased outside of the country where you wish to

have it serviced during the warranty period, regular handling and servicing fees may be

charged by the manufacturer’s representatives in that country. Notwithstanding this,

your camera returned to the manufacturer will be serviced free of charge according to

this procedure and warranty policy. In any case, however, shipping charges and

customs clearance fees to be borne by the sender. To prove the date of your purchase

when required, please keep the receipt or bills covering the purchase of your camera

for at least a year. Before sending your camera for servicing, please make sure that

you are sending it to the manufacturer’s authorized representatives or their approved

repair shops, unless you are sending it directly to the manufacturer. Always obtain a

quotation for the service charge, and only after you accept the quoted service charge,

instruct the service station to proceed with the servicing.

• This warranty policy does not affect the customer’s statutory rights.

• The local warranty policies available from our distributors in some countries

can supersede this warranty policy. Therefore, we recommend that you review

the warranty card supplied with your product at the time of purchase, or

contact our distributor in your country for more information and to receive a

copy of the warranty policy.

Warranty Policy

The CE Mark is a Directive conformity mark of the European Union.

For customers in USA

STATEMENT OF FCC COMPLIANCE

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

Changes or modifications not approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation.

If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

*Consult the dealer or an experienced radio/TV technician for help.

For customers in Canada

This Class B digital apparatus complies with Canadian ICES-003.

Pour les utilisateurs au Canada

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du

Canada.

FOR CALIFORNIA, U.S.A. ONLY

Perchlorate Material-special handling may apply. The lithium battery used in this

camera contains perchlorate material, which may require special handling. See

www.dtsc.ca.gov/hazardouswaste/perchlorate

Declaration of Conformity

According to 47CFR, Parts 2 and 15 for

Class B Personal Computers and Peripherals

We: RICOH IMAGING AMERICAS

CORPORATION

Located at: 633 17 Street, Suite 2600,

Denver, Colorado 80202, U.S.A.

Phone: 800-877-0155 Fax: 303-790-1131

Declare under sole responsibility that the product identified herein complies with

47CFR Parts 2 and 15 of the FCC rules as a Class B digital device. Each product

marketed is identical to the representative unit tested and found to be compliant

with the standards. Records maintained continue to reflect the equipment being

produced can be expected to be within the variation accepted, due to quantity

production and testing on the statistical basis as required by 47CFR §2.909.

Operation is subject to the following two conditions: (1) This device may not cause

harmful interference, and (2) This device must accept any interference received,

including interference that may cause undesired operation. The above named

party is responsible for ensuring that the equipment complies with the standards

of 47CFR §15.101 to §15.109.

Product Name: Digital Camera

Model Number: RICOH WG-30

Contact person: Customer Service Manager

Date and Place: October, 2014, Colorado

Information for Users on Collection and Disposal of Old Equipment

and Used Batteries

1. In the European Union

These symbols on the products, packaging and/or

accompanying documents mean that used electrical and

electronic equipment and batteries should not be mixed with

general household waste.

Used electrical/electronic equipment and batteries must be

treated separately and in accordance with legislation that

requires proper treatment, recovery and recycling of these

products.

By disposing of these products correctly you will help ensure

that the waste undergoes the necessary treatment, recovery

and recycling and thus prevent potential negative effects on

the environment and human health which could otherwise

arise due to inappropriate waste handling.

If a chemical symbol is added beneath the symbol shown

above, in accordance with the Battery Directive, this indicates

that a heavy metal (Hg = Mercury, Cd = Cadmium, Pb = Lead)

is present in the battery at a concentration above an

applicable threshold specified in the Battery Directive.

For more information about collection and recycling of used products,

please contact your local authorities, your waste disposal service or the

point of sale where you purchased the products.

2. In other countries outside the EU

These symbols are only valid in the European Union. If you wish to discard used

products, please contact your local authorities or dealer and ask for the correct

method of disposal.

For Switzerland: Used electrical/electronic equipment can be returned free of

charge to the dealer, even when you don’t purchase a new product. Further

collection facilities are listed on the home page of www.swico.ch or www.sens.ch.

An Operating Manual (PDF) containing information on how to use

this camera is available. Please download it from our website.

Operating Manual Download:

http://www.ricoh-imaging.com/manuals/

In order to better serve you, we request that you complete the user registration,

which can be found on our website. Thank you for your cooperation.

http://www.ricoh-imaging.com/registration/

Information on the Operating Manual

Regarding User Registration

Digital Camera

Start Guide

To ensure the best performance from your camera, please read

this manual before using the camera.

RICOH IMAGING COMPANY, LTD.

2-35-7, Maeno-cho, Itabashi-ku, Tokyo 174-8639, JAPAN

(http://www.ricoh-imaging.co.jp)

RICOH IMAGING EUROPE

S.A.S

112 Quai de Bezons, B.P. 204, 95106 Argenteuil Cedex,

FRANCE

(http://www.ricoh-imaging.fr)

RICOH IMAGING

DEUTSCHLAND GmbH

Am Kaiserkai 1, 20457 Hamburg, GERMANY

(http://www.ricoh-imaging.de)

RICOH IMAGING UK LTD. PENTAX House, Heron Drive, Langley, Slough, Berks

SL3 8PN, U.K.

(http://www.ricoh-imaging.co.uk)

RICOH IMAGING

AMERICAS CORPORATION

633 17th Street, Suite 2600, Denver, Colorado 80202,

U.S.A.

(http://www.us.ricoh-imaging.com)

RICOH IMAGING CANADA

INC.

5520 Explorer Drive Suite 300, Mississauga, Ontario,

L4W 5L1, CANADA

(http://www.ricoh-imaging.ca)

RICOH IMAGING CHINA

CO., LTD.

23D, Jun Yao International Plaza, 789 Zhaojiabang

Road, Xu Hui District, Shanghai, 200032, CHINA

(http://www.ricoh-imaging.com.cn)

http://www.ricoh-imaging.co.jp/english

• Specifications and external dimensions are subject to change without notice.

FOM 01.11.2014 Printed in Europe

Ricoh Wg 30 Quick Start Manual

WG-30 - Quick Start Guide WG-30-SG-EN Free User Guide for Ricoh Camera, Manual

Navigation menu

Versions of this User Manual:

Views

Navigation
