Riitek Technology RT-MWK07 Android TV Remote User Manual
Shenzhen Riitek Technology Co., Ltd Android TV Remote
User manual
Mini Wireless
Keyboard Touchpad Combo
Installation & User Manual
Ver:2.2
Overview
Thank you for purchasing the Mini Wireless Keyboard
&Touchpad Combo. You can use it for emails, chat, or to
enjoy your favorite games. It is compatible with HTPC,
Smart TV, TV BOX running Android systems. It also
supports Sony Playstation3. Use it with your HTPC on
your Sofa or browse the internet in the most comfortable
fashion.
Product Image
(Pictures for reference only, please in kind prevail)
Package Contents
· Keyboard touchpad Combo
· USB Wireless Receiver
· User Manual
· AAA * 2 battery(Optional)
System Requirements
· HID compatible device
· Terminal with USB port
· Windows 2000
· Windows XP
· Windows Vista, Windows CE, Windows 7, Windows 8
·
Linux (Debian-3.1,Redhat-9.0, Ubuntu-8.10, Fedora-7.0 tested)
· Android OS (With standard USB interface)
Specifications
Receiver(dongle): Nano style
Connection port : With USB2.0 above
Transmission mode: GFSK 2.4GHz, up to 10 meters
Transmission Power: Less than +4db
Power supply: AAA * 2 battery
Charging voltage: 4.4V ~ 5.25V
Charging current: 300mA
Sleeping current class1: 30uA
Operation voltage: 3.7V
Operating current: <15mA
Product Weight: 65g (Contains battery and receiver)
Product Size: 132*40*22mm
Installation
· Open the gift box and pick up USB receiver from back
cover of the remote.
· Insert the USB Receiver into an available USB port.
· The remote will be found automatically. No further actions
are required you are now ready to use your remote!
NOTE: When the battery is low, the low-voltage light will
blink to warn the user. The unit will be automatically turned
off if the battery has been depleted.
Using the Touchpad
The touchpad is activated together with the keyboard.
When the keyboard is on, the keyboard is ready for use.
You will enjoy more convenience and control on-screen
menu easier.
Auto Sleep and Wake-up feature
The keyboard supports auto sleep and wake-up. Without
operation around 3 minutes, the keyboard will enter sleep
mode. In sleep status, all LED indicators are off. Pressing
any key can wake it up.
Warning
·Never try to open or repair this product yourself.
·Keep this device away from fluids, such as water.
Maintenance
· Do not attempt to disassemble the device.
. Doing so will void the warranty.
. The battery will discharge if it is stored for a long time
without operation.
· Do not expose the device in extreme heat or cold
environment, which will shorten the battery life.
Disposal
Always dispose the used appliance at a
recycling centre. Do not dispose the used
appliance together with the household waste.
Note:
Due to 2.4G wave technology adoption, the connection
can be subject to interference from obstacles, like walls,
metals, or other electronic devices. Please keep the space
between the keyboard and USB receiver free of obstacle.
In line with the policy of continued development, the
manufacturer reserves the right to amend. The
specifications without prior notification. The illustrations in
the user manual are for reference only. Please operate
according to the real design.
Federal Communications Commission (FCC) Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications made to this device not expressly approved by Shenzhen
Riitek Technology Co., Ltd may void the FCC authorization to operate this device.
Note: The manufacturer is not responsible for any radio or tv interference caused by unauthorized
modifications to this equipment. Such modifications could void the user’s authority to operate the
equipment.
