How to mount your Ring Base Station on a
wall (optional)
You can mount the Ring Base Station on a wall using two
wall anchors, two screws, and the mounting slots located on
the unit. The base station can be horizontally mounted.
Before you begin
Before you begin, choose an appropriate mounting place.
The wall can be made of cement, wood, or drywall. The
mounting location should be free of obstructions on all
sides, and the cables should be able to easily reach the
base station without strain. Leave sufficient clearance
between the bottom of the base station and any flooring or
shelving underneath to allow access to cabling. In addition,
leave enough slack in all cables so that the base station
can be removed for any required maintenance without
disconnecting the cables. Also, you will need the following
items:
•Two wall anchors for #8 x 1-inch screws
•Two #8 x 1-inch pan head screws
•Drill with a 3/16-in. wood or masonry bit, as appropriate
for the wall composition
•A copy of the wall-mounting illustrations shown in figure
2 (at right).
•Mount the base station as shown in figure 1 (at right)
Location and dimensions of the wall-mounting
slots
The following illustration shows the location and
dimensions of the wall-mounting slots on the bottom of the
base station. Use the information in figure 2 (at right) as a
guide for mounting your base station to the wall.
Mounting
Screws
Mounting
Holes
Horizontal Mounting
1/4 in
(0.65 cm)
Screw
Concrete,
Wood, or
Drywall
4”
101.6mm
Top for
Horizontal Mounting
AA
Mounting Slots
Not Drawn
To Scale
Fig. 1: Horizontal Mounting
Fig. 2: Wall Mount
Ring_Protect_Kit_Wall_Mount_and_Legal.indd 1 9/1/17 3:52 PM
