Ring WL18DBMOD Wifi and Bluetooth Module User Manual

Bot Home Automation, Inc. Wifi and Bluetooth Module

user manual

BOT Home Automation
WL18MODGI
User Manual
Manual Information to the End User
The BOT Home Automation integrator has to be aware not to provide information to the end user
regarding how to install or remove this RF module in the user’s manual of the end product which
integrates this module. The end user manual shall include all required regulatory information/warnings
as shown in this manual.
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Industry Canada Statement
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired
operation of this device.
Le present appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions suivantes :
(1) L’appareil ne doit pas produire de brouillage, etc
(2) L’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le fonctionnement.
CAN ICES-3(B)/NMB-3(B)
The device could automatically discontinue transmission in case of absence of information to transmit, or
operational failure. Note that this is not intended to prohibit transmission of control or signaling
information or the use of repetitive codes where required by the technology.
- The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the
potential for harmful interference to co-channel mobile satellite systems;
- The maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725
MHz shall comply with the e.i.r.p. limit; and
- The maximum antenna gain permitted for devices in the band 5725-5825 MHz shall comly with
the e.i.r.p. limits specified for point-to-point and non point-to-point operation as appropriate.
In addition, high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350
MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN
devices.
Radiation Exposure Statement
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance of 20 cm between the radiator
and your body.
End Product Labeling
When the module is installed in the host device, the FCC/IC ID label must be visible through a window on
the final device or it must be visible when an access panel, door or cover is easily removed. If not, a
second label must be placed on the outside of the final device that contains the following text:
“Contains FCC ID: 2AEUPWL18DBMOD
“Contains IC: 20271-WL18DBMOD
The Grantee’s FCC ID/IC ID can be used only when all FCC/IC compliance requirements are met.
This device is intended only for BOT Home Automation as an integrator under the following conditions:
(1) The antenna must be installed such that 20 cm is maintained between the antenna and users,
(2) The transmitter module may not be co-located with any other transmitter or antenna.
(3) This radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain
approved by BOT Home Automation Inc. Antenna types not included in the list, having a gain
greater than the maximum gain indicated for that type, are strictly prohibited for use with this
transmitter.
Antenna Gain (dBi) @ 2.4GHz: 3.2
Antenna Gain (dBi) @ 5GHz: 4.5
Antenna Types: PCB, Dipole, PCB, Chip, PIFA.
In the event that these conditions cannot be met, then the FCC/IC authorization is no longer
considered valid and the FCC ID/IC ID cannot be used on the final product. In these circumstances,
BOT Home Automation Inc as the integrator will be responsible for re-evaluating the end product
(including the transmitter) and obtaining a separate FCC/IC authorization.
