User Manual
1
4-Button Rolling
Code
Wireless Transmitter
Model:
WL 132KF1
EN
Installation Instructions
EN
1 General Description
The keyfob is a 4-button rolling code wireless transmitter with four
transmitting channels, which allows you to arm, partial arm and
disarm your alarm system as well as send a panic alarm. The
keyfobs can be mounted on a key chain or worn as a pendant on a
nylon cord.
To operate the keyfob, press the required button for 1 second. The
LED lights up after each press, indicating a successful signal
transmission.
2 Replacing the Battery
Remove the screw on the back of the keyfob and carefully separate
the two sides of the keyfob’s plastic casing. Remove the old battery
from the metal clips and place a new one instead. To close reattach
the two sides of the keyfob’s plastic casing.
3 Quick Device Allocation at the Control
Panel
The keyFob is automatically programmed to your control panel
during the on-line installation wizard setup. If you later purchase an
extra keyfob you can enroll it as follows:
To quickly allocate a keyfob at the control panel:
If the control panel is not already in Learn mode, press the
button on the control panel for 5 seconds; the unit beeps once
as it enters Learn mode (all the LEDs also light up, one after the
other).
Make sure batteries are installed in each keyfob before allocating
them.
Send a signal transmission from the keyfob by pressing and
simultaneously for at least 2 seconds; the control panel beeps
once to accept or beeps three times to reject. Once accepted, the
system announces the device type and its zone (for example,
“Keyfob, zone 1”).
When the keyfobs have been enrolled, short-press the control panel
button to exit Learn mode; the unit beeps once and the LEDs
stop flashing.
Note: For future use, it is recommended to write down the keyfob
description, zone number, and installation location of each allocated
keyfob.
4 Technical Specifications
Operates up to 650 feet (200m) range (LOS)
Frequency 915MHz
Temperature range 0° – 50°C (32° – 122°F)
Battery type CR2430, 3V lithium battery
Battery life 3 years (10 button press a day)
Current consumption 1µA stand by
RISCO Group Limited Warranty
RISCO Group and its subsidiaries and affiliates ("Seller") warrants its products to be free from
defects in materials and workmanship under normal use for 24 months from the date of
production. Because Seller does not install or connect the product and because the product may
be used in conjunction with products not manufactured by the Seller, Seller can not guarantee
the performance of the security system which uses this product. Sellers' obligation and liability
under this warranty is expressly limited to repairing and replacing, at Sellers option, within a
reasonable time after the date of delivery, any product not meeting the specifications. Seller
makes no other warranty, expressed or implied, and makes no warranty of merchantability or of
fitness for any particular purpose. In no case shall seller be liable for any consequential or
incidental damages for breach of this or any other warranty, expressed or implied, or upon any
other basis of liability whatsoever. Sellers obligation under this warranty shall not include any
transportation charges or costs of installation or any liability for direct, indirect, or not be
compromised or circumvented; that the product will prevent any persona; injury or property loss
by intruder, robbery, fire or otherwise; or that the product will in all cases provide adequate
warning or protection. Buyer understands that a properly installed and maintained alarm may
only reduce the risk of intruder, robbery or fire without warning, but is not insurance or a guaranty
that such will not occur or that there will be no personal injury or property loss as a result.
Consequently seller shall have no liability for any personal injury, property damage or loss based
on a claim that the product fails to give warning. However, if seller is held liable, whether directly
or indirectly, for any loss or damage arising from under this limited warranty or otherwise,
regardless of cause or origin, sellers maximum liability shall not exceed the purchase price of the
product, which shall be complete and exclusive remedy against seller. No employee or
representative of Seller is authorized to change this warranty in any way or grant any other
warranty.
WARNING: This product should be tested at least once a week.
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries
according to local regulations.
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment
FCC Note
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment on and off, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on to a different circuit from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
© RISCO Group 07/16 5IN2578
FCC ID: JE4WL132KF1915
