Mounting locations
Primary considerations
Avoiding false alarm sources
Installation
Open the cover
Mounting procedure
Without swivel:
Remove knockouts for mounting screws and cable entry
Insert cable
Attach the base to location.
With the swivel
Punch out knockout.
Remove knockout for cable entry
Attach base to swivel
Feed the cable into the detector
Screw swivel base on the wall or ceiling
Terminal connections
12VDC: Power supply input
ALARM: NC dry contact switch
TAMPER: NC dry contact switch
Seal holes
PC Board Adjustment
Loosen PC board holding screw
Position the board according to the lens used
Wide engle:
Height 2.5m (8.2ft)
Room size: 3-6m (10-20ft) scale position - Short
Room size: 6-15m (20-50ft) scale position - Long
Long range lens:
Height 2.5m (8.2ft)
Scale position - long
Pet alley lens:
Height 1m (3.3ft)
PET scale position
Higher mounting heights
Lower mounting heights
Jumper settings
LED
PULSE COUNT
Long range lens use pulse count of 1
Walk test
Replace front cover
Apply power and wait until stabilized (> 2 minutes)
Walk through protected area
Observe LED confirm coverage
Adjust swivel if necessary. When completed tighten the screw
SPECIFICATIONS
Voltage: 9-16 V CC
Current consumption: 12mA at 12V
Alarm contacts: 0.1A, 24V, NC
Tamper contacts: 0.1A, 24V, NC
Dimensions: 10.7 X 5.8 X 3.9 cm
(without swivel)
Swivel regulation: Horizontal: + 25°
Vertical: + 5°, -20°
Filter: Immunity to white light,
Pigmented lens
Operational temperature: 10 to + 50° C
Store temperature: –20 to + 55° C
Warranty
Rokonet Electronics, Ltd. and its subsidiaries and affiliates ("Seller") warrants its products to
be free from defects in materials and workmanship under normal use for 6 years from the
date of production. Because Seller does not install or connect the product and because the
product may be used in conjunction with products not manufactured by the Seller, Seller can
not guarantee the performance of the security system which uses this product. Sellers
obligation and liability under this warranty is expressly limited to repairing and replacing, at
Sellers option, within a reasonable time after the date of delivery, any product not meeting the
specifications. Seller makes no other warranty, expressed or implied, and makes no warranty
of merchantability or of fitness for any particular purpose.
In no case shall seller be liable for any consequential or incidental damages for breach of this
or any other warranty, expressed or implied, or upon any other basis of liability whatsoever.
Sellers obligation under this warranty shall not include any transportation charges or costs of
installation or any liability for direct, indirect, or consequential damages or delay.
Seller does not represent that its product may not be compromised or circumvented; that the
product will prevent any persona; injury or property loss by burglary, robbery, fire or
otherwise; or that the product will in all cases provide adequate warning or protection. Buyer
understands that a properly installed and maintained alarm may only reduce the risk of
burglary, robbery or fire without warning, but is not insurance or a guaranty that such will not
occur or that there will be no personal injury or property loss as a result.
Consequently seller shall have no liability for any personal injury, property damage or loss
based on a claim that the product fails to give warning. However, if seller is held liable,
whether directly or indirectly, for any loss or damage arising from under this limited warranty
or otherwise, regardless of cause or origin, sellers maximum liability shall not exceed the
purchase price of the product, which shall be complete and exclusive remedy against seller.
No employee or representative of Seller is authorized to change this warranty in any way or
grant any other warranty.
WARNING: This product should be tested at least once a week.
NOTE
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment on and off, the
user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and the receiver
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by the
party responsible for compliance (Rokonet Electronics Ltd.) could void the
user’s authority to operate the equipment.
