Roche Diagnostics UU18 HBM 4 User Manual Kassenbuch

Roche Diagnostics GmbH HBM 4 Kassenbuch

UserManual.pdf

Frequency Band
Standard
Data Rates IEEE 802.11b
IEEE 802.11g
Modulation IEEE 802.11b
IEEE 802.11g
Transmit Power Output (max.) IEEE 802.11b
Maximum Receive Level IEEE 802.11b
Transmit Power Output (max.) IEEE 802.11g
Maximum Receive Level IEEE 802.11g
Intended transmission output power tolerance
EMC/Immunity
± 2dB
Canada: Industry Canada
European Union: CE Mark
Handheld Base Module Version 4 (HBM4)
24 Mbps, 10% PER
36 Mbps, 10% PER
48 Mbps, 10% PER
54 Mbps, 10% PER
PER<10%
United States: FCC Part 15
PER<8%
7 dBm
6 Mbps, 10% PER
9 Mbps, 10% PER
12 Mbps, 10% PER
18 Mbps, 10% PER
OFDM
12 dBm
1 Mbps, 8% PER
2 Mbps, 8% PER
5.5 Mbps, 8% PER
11 Mbps, 8% PER
Receive Sensitivity
IEEE 802.11g
Certifications of used WiFi-Chip
The Handheld base module in version 4 (HBM4), is
exclusiveley available as built-in modules in devices for
in vitro diagnostic use for quantitative determination of
health parameters in human body liquids (i.e. blood
glucose levels or blood coagulation parameters). The
devices are indicated for use by healthcare
professionals. For healthcare professionals, the device
is a bedside mobile or stationary unit that can help you
provide quality patient care by measuring health
parameters and by automating the record keeping
associated with the parameter specific control test.
Devices with wireless enabled use WiFi as a redundant
communication option to exchange data with the DMS.
2.4 GHz ISM band
WEP encryption (40 bit/104 bit)
WPA TKIP security
WPA2
Security
Wireless LAN
Receive Sensitivity
IEEE 802.11b
IEEE 802.11b/g
1, 2, 5.5 and 11 Mbps
6, 9, 12, 18, 24, 36, 48 and 54 Mbps
DSSS/CCK
r
Features
WPA PSK
Security
Device specific distinctions
The module will be used in 2 different configurations, to
meet the arrangement of device specific cable
connections for further components (digital display,
power supply and parameter specific measurement
modules). The conducting paths are identical for each
configuration, but the mechanical ports are getting
installed device specific.
This will ensure, that the WLAN functionality will not be
affected due to different configurations.
V1.3
