An Affordable Stage Piano with Uncompromising Action and Sound.
®ÂØÒÅή
RD-150 Digital Stage Piano
1of2
The RD-150 Digital Stage Piano was built around the concept that an entry-level stage piano should
still feel and sound like the real thing. That’s why its 88-note keyboard uses an improved hammer
action that responds like digital pianos costing hundreds more. And with an upgraded sound engine
that’s equally realistic, the RD-150 sets a new standard for affordable digital pianos.
* Product pictured is a prototype model. Actual product appear-
ance may be subject to change.
Faxback # 10508
• 88-key digital stage piano with improved
hammer-action keyboard and velocity sensitivity
• Full 64-voice polyphony using Roland's
top-quality sound engine (equivalent to FP-9)
• 16 Tones include stereo-sampled piano sounds,
electric pianos, vibraphone, acoustic bass and
more, plus 8 variations
• 8 levels of Sympathetic Resonance add realistic
acoustic piano resonance when using the damper
pedal
• Keyboard Split function with separate Volume
controls for Upper and Lower parts
• New Stretch Tuning function provides instant
alternate tunings
• Built-in 2-track Recorder for practice or
accompaniment
• Onboard reverb and chorus effects with eight
levels
• Demo Function for auditioning the RD-150 in a
musical context
®ÂØÒÅÎ RD-150 Digital Stage Piano cont.
®
2 of 2
Faxback # 10508
Keyboard 88 Keys Hammer Action
Max. Polyphony 64 Voices
<Tones>
16 Main Tones Stereo Piano, Pop Piano, Rock Piano,
Honky-Tonk, Stage Rhodes, SA Rhodes, E.Piano, Clav,
Vibraphone, Ac. Bass, Finger Bass, Orch. Strings, Synth
Strings, Synth Pad, Jazz Scat, Choir
8 Variations Piano 1,Classic Piano, Clav 1, Harpsichord,
Marimba, Glockenspiel, Choir 1, Voice Bass
<Key functions>
Master Tuning Tuning (0.1Hz Steps) 415.3Hz ~ 466.2Hz
Transpose Key Transpose (-6 ~ +5 Semitone step)
Touch Control 4 Types of Touch Sensitivity
Tuning 7 Temperament Scale
Stretch Tuning 2 Types
Fixed Velocity Setting
<Composer>
Tracks 2 Track
Song 1 Song
Note Storage Approx. 5,000 notes
Tempo Quarter note = 40 ~ 210
Resolution 120 Ticks per quarter note
Control Play/Stop, Rec, Tempo
Metronome Beat (0,2,3,4,6), 127 volume levels
<Others>
Connections Damper Connector, Soft/Sost ÐExpression
Connector, Headphone Jack x 2 (Stereo), Output Jacks
(L/Mono, R), MIDI Connectors In/Out
Power Consumption 45W (230V, 230VE)
Dimensions 1380 (W) x 320 (D) x 105 (H) mm
Weights Piano: 22 Kg
Supplied Accessories Owner’s Manual, Power Cable,
Music rest, Pedal DP-6
Options MSC Series MIDI cables, KS-12 keyboard stand,
KC series keyboard amplifier, RH series headphone, EV-5
Expression pedal
*The specifications are subject to change.
RD-150 Specifications
Simple, Elegant Design
While other digital pianos are loaded with features and
buttons you’ll likely never use, Roland took a different
approach when designing the RD-150. The front-panel lay-
out is clean and uncluttered for ease-of-use, and the
sounds are comprised of nothing less than the finest
acoustic and electric pianos around. What’s more, this
remarkable digital piano is surprisingly affordable, too.
Rolands Finest Piano Sounds
The RD-150 inherits the top-quality sound engine of the
Roland FP-9 Digital Piano. These stereo-sampled pianos
are amazingly realistic, especially in the upper and lower
registers. Combined with onboard Sympathetic Resonance
- plus lush reverb and chorus effects - the RD-150 sounds
great whatever style of music you play.
Keyboard Split Function
In addition to its keyboard sounds, the RD-150 includes an
assortment of instrument sounds like acoustic and electric
bass, strings, vibraphone and more. And with the
Keyboard Split function, you can play two sounds at once
with slider-based volume control over the Upper and
Lower parts.
Stretch Tuning and Demo Functions
The RD-150’s Stretch Tuning function allows the keyboard
to be tuned to one of two alternate tunings with the touch
of a button. So now you can change tunings instantly as
required by the music being performed. Onboard demo
songs are provided to make auditioning the RD-150 as
simple as pushing a button.
