3000, 4000, 5000 & 6000 SERIES
INSTRUCTIONS & RECIPES FOR
Rotisseries
Best Rotisserie
“Dollar for dollar, the finest
kitchen appliance ever
made.”
- Malcolm Gladwell,
What the Dog Saw
Set It and Forget It!®
Time is precious. Just set
the timer and we’ll do the
rest, leaving you more time
for family.
Cook Like a GourmetTM
Makes perfectly roasted
chickens, turkey, pork or rib
roasts, and burgers that are
delicious and healthy too!
3000 Series
4000 Series 5000 Series
6000 Series
Table of Contents
Important Safeguards / Cleaning & Care ..................................................................3-5
Rotisserie Models ....................................................................................................... 6
Unpacking Rotisserie .................................................................................................. 6
Parts Included ............................................................................................................. 7
Instructions
Heat Shield / Non-stick Spit Rod Assembly ........................................................... 8
Rotisserie Basket .................................................................................................. 9
How to Tie Chicken & How to Tie Turkey .........................................................10-11
Placing Poultry on the Spit Assembly ................................................................... 12
A or B Cooking Position ....................................................................................... 13
Loading the Spit Assembly .................................................................................. 14
Timers (Dial or Digital)......................................................................................... 15
Carving Platform / Spit Rod Spacer ..................................................................... 16
Time & Temperature Chart .................................................................................. 17
Available Accessories (sold separately) ...............................................................18-22
Cautions & Helpful Hints ......................................................................................23-24
Meal Suggestions & Recipes ................................................................................25-29
6 Easy Steps to Rotisserie Chicken ......................................................................30-31
Warranty ................................................................................................................... 32
Seals in natural juices and drains off unwanted fat as it cooks. About ¼ cup of animal
fat drips off a 4 lb. chicken.
Evenly browns chicken, roasts, seafood, vegetables, chops, steaks, hamburgers,
sausages, hams, pork loin roasts, and even ribs!
Timer makes it easy to use and automatically shuts off when the time is up.
Dishwasher safe. Non-Stick Drip Tray, Non-Stick Grate Cover, Entire Spit Rod
Assembly, Glass Door, Kabob Rods and Heating Tray are all dishwasher safe.
The Rotisserie Basket allows you to enjoy greater variety of Rotisserie foods and
wraps (placing foods in foil, then in Basket).
Lighted Oven makes it easy and fun to watch your food cook.
Dual Heating Tray with Lid (sold separately) fits right on top of the rotisserie
for heating your favorite vegetables, sauces, gravies, etc.
Energy Efficient. Cooks faster than a conventional oven but still uses about
half the electricity!
ST5000 Series Rotisserie
IMPORTANT SAFEGUARDS 3
IMPORTANT SAFEGUARDS
These items: Heat Shield, Non-stick Grate Cover and Drip Tray must always be in
place when using your Rotisserie. When using electrical appliances, basic safety
precautions should always be taken, including the following:
1. VERY IMPORTANT: Read all instructions and watch instructional DVD before using
the machine.
2. To protect against electrical hazards, do not immerse cord, plug or appliance itself
in water or other liquids.
3. Do not touch hot surfaces. NOTE: (Glass Door, top, back and sides of the Rotisserie,
as well as the Dual Heating Tray, Drip Tray, Non-stick Grate Cover, Heat Shield and
Heating Element all get very hot during use and retain heat after use – even when
Glass Door is positioned underneath the unit.) Always use adequate oven mitts or
gloves when handling these hot surfaces and when checking hot foods.
4. FOR ADULT USE ONLY: Close supervision is always necessary when the Rotisserie
is used near children.
5. Unplug Rotisserie from outlet when not in use, and allow unit to cool thoroughly
before putting on or taking off parts, such as the Non-stick Drip Tray, and Non-stick
Grate Cover, and before cleaning.
6. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or is dropped or damaged in any manner. Return the appliance to
Ronco Holdings, Inc. for examination, repair, electrical or mechanical adjustment.
Call 1-855-85-RONCO for return instructions.
7. Turn off and unplug the Rotisserie if you smell or see heavy smoke or fire. After it
has cooled down, make adjustments so nothing touches the Heating Element as the
food rotates. Do not open the Glass Door until it has cooled down. This is an electrical
appliance; never put water in it, or on it to cool it down or stop it from smoking.
8. Do not use any attachments or anything that is not recommended by Ronco Holdings,
Inc. The use of such items may be hazardous.
9. Do not use outdoors.
10. Do not let cord hang over edge of table or counter or touch hot surfaces.
11. Do not place appliance on or near a hot gas or electric burner, in a heated oven
or near easily flammable material.
12. Use only on a stable, heat-resistant surface and place unit at least 8” (inches) from
walls and 8” clear above unit.
13. To disconnect, turn machine Timer to “OFF” position, then grip plug and pull from
wall outlet. Do not pull on cord.
14. Always unplug the unit before attempting to move it. Never move the unit when
it contains hot oil, liquids or hot foods.
15. Use extreme caution when working near the hot pieces and the Heating Element
after using Rotisserie as these parts become (and remain) very hot. Also use maxi-
Showtime® Rotisserie
4 IMPORTANT SAFEGUARDS
mum care when removing Drip Tray or disposing of hot grease or other hot liquids.
16. When using the Rotisserie Baskets, be sure no small bones or other food can fall
between or extend beyond the wires and catch on the Non-stick Grate Cover or
Heating Element or anything else during rotation. It is important to check while
cooking. If the food moves around inside the Basket, stop the machine. Put Oven
Gloves on and carefully take out the Basket. Tighten the lid down further so the
food can’t move or slip around in the Basket as it rotates. The Basket gets hot
so please use caution.
17. Do not clean with a metal scouring pad. Pieces can break off the pad and touch
electrical parts, creating a risk of electrical shock. In addition, scouring pads may
damage Rotisserie finish or the nonstick parts.
18. Do not use appliance for other than its intended use.
19. Oversized foods that touch Heating Element must be trimmed down and metal
utensils must not be inserted in the appliance as they may create a fire or risk
of electrical shock.
20. Front, back, top, bottom and side surfaces become very hot. Do not allow contact
with any objects other than the Dual Heating Tray (sold separately) in its proper op-
erating position. A fire may occur if the Rotisserie is covered or touching flammable
material, including curtains, draperies, walls, and the like, when in operation.
21. Do not place or store any objects or material other than foods and manufacturer’s
recommended accessories in the Rotisserie. Do not place or store anything on top
of the Rotisserie when it is plugged in other than the Dual Heating Tray. (sold sepa-
rately)
22. Unplug unit before changing/replacing the interior light bulb (25 watt small
appliance bulb).
23. Polarized Electrical Plug: To reduce the hazard of potential shock, this item has a
polarized plug (one prong is wider than the other), which will fit only one way in a
polarized outlet. If the plug does not fit the outlet properly, turn the plug the other
way; if it still does not fit, contact a qualified electrician for assistance. Never use
this plug with an extension cord unless it fits properly. DO NOT ATTEMPT TO DEFEAT
THIS SAFETY FEATURE.
24. SHORT CORD INSTRUCTIONS: A short cord is provided to reduce the risks of
becoming tangled in or tripping over a longer cord. Extension cords may be used
if care is exercised in their use and the wattage rating is at least as great as the
wattage stamped on the back of the appliance. If an extension cord is used, it
should be arranged so that it will not drape over the counter or tabletop where
it can be reached by children or tripped over accidentally.
25. HEAR A SQUEAK? No problem. Put a drop or two of vegetable oil on the Gear Wheel
Nub before inserting the Spit Rod Assembly in the machine.
THIS PRODUCT IS FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
Showtime® Rotisserie
CLEANING & CARE 5
IMPORTANT: “Set It and Forget It” ® only after all instructional materials
(written and DVD) have been carefully followed.
Make sure food safely rotates without touching the Heating Element.
Please Don’t Take “Set It and Forget It”® Literally
Always use caution and check on your Rotisserie from time to time.
It is highly unlikely, but if you should see or smell heavy smoke it’s because the food is
rubbing against the hot Heating Element. This indicates that the meat or poultry is too
big or it wasn’t placed properly - or the food is off-center (lopsided) on the spit rods or
in the basket. If this occurs:
Turn off and unplug your machine. Do not open the Glass Door. Let it cool down.
Trim any excess fat or meat, position your food tightly in the basket and be sure the
food is centered in the basket so it always rotates without touching the Heating Element.
Cleaning and Caring for your Rotisserie
The Glass Door: Set the right side pin in the bottom first then slide the left pin in.
After Use: Unplug and allow it to cool before washing any parts. NOTE: The Heating
Element cleans itself and no other maintenance is necessary.
The Light: The light is on when the heat is on. If you need to replace the bulb, it uses
a 25 watt appliance bulb.
Never Use Metal Cleaning Pads on the Non-stick Surfaces. They will permanently
scratch the surfaces of the Grate Cover, Drip Tray, Steaming Tray, etc.
Discoloration? Some discoloration over time is to be expected when you work with
hot food - especially food with fat. It’s normal and will not affect the function. On white
machines it gets slightly browner on the front of the machine behind the Glass Door
and on the Dual Heating Tray. Fat from roast beef can be the worst offender. While not
recommended, you can return your machine and, for a nominal fee, the factory will
refinish the special outside surface.
Any repairs should be handled only by an authorized service facility. Call Customer
Care at 1-855-85-RONCO (there is a 24-hour Phone Message Center after hours). If
all lines are busy, please contact us at support@ronco.com or visit our online support
site at http://support.ronco.com.
BEFORE FIRST USE: Be sure the Rotisserie is not plugged in. Wash and dry the
removable parts in warm soapy water. Never immerse the machine or the cord in
water. Keep at least 8 inches of clearance on all sides and do not place it under a
cabinet when in use. A little smoke is normal when you first use the machine.
Showtime® Rotisserie
6 ROTISSERIE MODELS & UNPACKING
ROTISSERIE MODELS
1-855-85-RONCO
Call the Order Desk to order supplies,
7 Days a Week (and a 24-Hour Phone
Message Center after hours)
www.Ronco.com
Visit us online for more information and
product availability or email us:
support@ronco.com
A. Fold flaps back,
carefully turn box
over and lift up.
B. Tip on one
face of styrofoam
block and carefully
remove Rotisserie.
C. Carefully pull
styrofoam blocks
off the Rotisserie.
NOTE: All included
components are
located in the basket
inside the Rotisserie.
UNPACKING ROTISSERIE
3000 Series
• Dimensions: 17” W x
11” H x 12” D
• 10 lb Cooking
Capacity
• Dial Timer
4000 Series
• Dimensions: 17.25” W
x 13” H x 14.75” D
• 15 lb Cooking
Capacity
• Dial Timer
• Heat Shield
5000 Series
• Dimensions: 18” W x
13” H x 14.75” D
• 15 lb Cooking
Capacity
• Digital Timer
• Heat Shield
6000 Series
• Dimensions: 23.75” W
x 13” H x 14.75” D
• 23 lb Cooking
Capacity
• Dial Timer
• Heat Shield
NOTE: The model number is located on the back of your Showtime® Rotisserie.
Showtime® Rotisserie
PARTS INCLUDED & ASSEMBLY 7
Door is shipped in place. If it is taken off, put
it back on by inserting pin on right side first,
then insert left side pin through the slot.
Before using your Rotisserie, be sure the
Drip Tray with its Non-Stick Grate Cover is
back in place.
Before First Use, be sure the Rotisserie is not plugged in. Wash and dry the removable
parts in warm soapy water. Never immerse the machine or the cord in water. Keep at
least 8” (inches) of clearance on top and 8 inches all sides and do not place it under a
cabinet when in use. A little smoking is normal the very first time you use your machine.
Read the booklet and this sheet as well as watch the DVD for complete instructions
and safeguards.
Never cook foods larger than recommended for your model of Showtime® Rotisserie.
PARTS INCLUDED
How to Assemble
Food Ties
Instructions & Recipes
Rotisserie DVD
Carving Platform
(Also used to load the
Spit Rod Assembly)
Non-stick Rotisserie Basket
Non-stick Spit Rod Assembly
(Gear Wheel and Spit Rods)
Heat Shield
(4000, 5000, & 6000 Series only)
(Refer to page 8
before using)
Non-stick Drip Tray
Non-stick Grate Cover
Glass Door
Oven Gloves
Rotisserie
Showtime® Rotisserie
INSTRUCTIONS
Heat Shield
NOTE: The Heat Shield is not included in the 3000 Series models.
Never operate without Heat Shield in place behind the Heating Element. Insert it from
the top. Discoloration over time is normal. From time to time you can remove it and use
steel wool to remove and clean any grease buildup. It is also dishwasher safe.
Non-stick Drip Tray and Non-stick Grate Cover must always be in place when using
the rotisserie.
Dishwasher Safe! You can put the Drip Tray, Basket and the Glass Door (if it will fit)
all in your dishwasher. Rinse off any grease first.
Even Easier Clean Up! You can line the bottom of your Drip Tray with a small sheet
of aluminum foil. Be sure it is flat against the bottom.
Non-stick Spit Rod Assembly
Removable gear wheel fits on the Spit Rods after food (or
Basket) is loaded in place. It is heavy and has sharp gear
teeth. When carrying the Spit Rod Assembly always tilt
this end upward so it won’t fall off.
CAREFUL! Use CAUTION. Tips are sharp. Please be very
careful with your hands when loading any food onto the Spit
Rods.
Spit Rods are connected with screws to one gear wheel.
Place the removable gear wheel on after the food is loaded.
Carving Platform keeps the Spit Rod Assembly in place so you
can load food in upright position on a counter top or in a sink.
8 INSTRUCTIONS: Non-stick Spit Rod Assembly
VERY IMPORTANT: Always
put the Heat Shield, Non-
Stick Drip Tray and Grate
Cover in place
before operating.
Showtime® Rotisserie
Always use CAUTION with Hot Food and Metal Parts. The
Food, Basket and the Spit Assembly get HOT! Always wear
protective gloves when removing the Basket. If you feel the Oven
Gloves are not insulated enough to adequately protect you from
the hot surfaces you are handling, set whatever you are holding
down immediately and wait until the food and the metal parts
cool down. You may want to use a thicker oven glove or mitt.
Rotisserie Basket
Perfect for hamburgers, chicken pieces, vegetables, whole fish
and fish fillets, steaks, chops, cutlets and smaller flat roasts.
After putting the food in the Basket, compress the Basket lid very
tightly so no food can move, whatsoever. This can be done by
compressing the lid further. CAUTION: The Basket gets hot.
Be sure nothing extends out between the wires. Make sure
wings are all secure inside the Basket with no parts hanging
out so they can’t slip out and hang up on Grate Cover or Heating
Element.
You can use a small strip of aluminum foil inside the Basket
on the top and bottom edges (the edges that rotate near the
Heating Element) to keep the tips of the wings from burning.
Set the Spit Rods in the Carving Platform. Line up the two small
loops on the Basket with the Spit Rods. Then drop the Basket
down on the Spit Rods, and match it to the corresponding loops
on the other end of the Rotisserie Basket.
Check the Basket occasionally and be sure the food is still tight.
If not, stop the machine and carefully take out the Basket and
tighten the lid.
When the food in the Basket is done, you can remove the Basket
by keeping it in a horizontal position.
REMEMBER THE FOOD, SPIT ROD ASSEMBLY AND THE BASKET
ARE ALL HOT – TAKE PRECAUTIONS.
INSTRUCTIONS: Rotisserie Basket & Speed Basket 9
CAUTION: Keep at least 8” clearance all around from walls, cabinets and other
objects when using the rotisserie to prevent heat damage. Don’t put charcoal
briquettes, hickory chips or anything else in the machine that is not authorized by
Ronco Holdings, Inc. Do not use under cabinets. ROTISSERIE IS HOT!
Showtime® Rotisserie
10 INSTRUCTIONS: How to Tie Chicken
How to Tie Chicken
Elastic Food Ties are designed to be an easy-to-use method of securing poultry on
the Spit Rods. It is very important when using your Showtime® Rotisserie that food is
securely tied and fits onto the Spit Rods so that the food will not touch the Heating Ele-
ment and is evenly centered all around.
It is recommended that you cut off the tail from the chicken and remove any excess fat
or loose hanging parts – especially around the main cavity so heat can enter inside the
chicken while it’s cooking.
The illustration shows how to tie a bird with one or two ties.
How to tie a chicken using 1 tie
With one tie you go behind each wing, cross over the back and pull it over the bottom
of the bird and up the front to hold the legs together. Then tuck the wings inside the tie.
If a Food Tie is too long, you can shorten it by tying a knot in it and cutting off the
excess with scissors.
Always use CAUTION with Hot Food and Metal Parts. The Food, Basket and the
Spit Assembly get HOT! Always wear protective gloves when removing the Basket.
If you feel the Oven Gloves are not insulated enough to adequately protect you
from the hot surfaces you are handling, set whatever you are holding down
immediately and wait until the food and the metal parts cool down. You may
want to use a thicker oven glove or mitt.
Finish Breast Side Up
Start Breast Side Down
Showtime® Rotisserie
INSTRUCTIONS: How to Tie Turkey 11
How to tie a chicken using 2 ties
Using two ties, shorten them both and put
one over the wings and one over the legs.
It’s very easy.
You can also use several Food Ties to secure
any bird. If you run out of Food Ties you can
use butcher’s twine until you can order more
Food Ties.
How to Tie Turkey
Tie your turkey right: make it tight! When preparing a Turkey, the wings and legs
must be tied down securely to prevent them from touching the heating element.
REMEMBER: Your must use Heavy Twine or String when fixing your Turkey.
DO NOT use the elastic Food Ties. Keep the cavity open to heat.
Stuffing Rotisserie poultry is not recommended.
Depending on the model of your rotisserie, you will only be able to cook a certain size
turkey. Please see below:
As your Turkey rotates, the wings and legs do have a tendency to bow out. It is VERY
IMPORTANT that you follow these instructions to make sure that no part of your Turkey
touches the Heating Element!
MAKE FOUR OR FIVE TIES WITH HEAVY STRING OR TWINE!
(FOR BEST RESULTS WET THE STRING OR TWINE BEFORE USE)
TIE YOUR TURKEY IN FOUR OR FIVE SPOTS:
Two ties over the Wings, One or Two ties over the
wide part of the Drumsticks, and One tie over
the Legs, as shown above. Be sure that nothing
hangs over or extends beyond the Gear Wheels.
Always center your Turkey on the Spit Rods.
REMEMBER TO TIE EACH STRING AS TIGHTLY
AS POSSIBLE.
If any part of your Turkey (or any game bird or other food) Touches the Heating Element
while cooking, IMMEDIATELY TURN OFF YOUR ROTISSERIE and re-tie the Bird more
securely. If, after re-tying, any part of your Turkey is still touching the Heating Element,
the bird is too big and must be trimmed down, where necessary.
3000 Series
• Dimensions: 18.5” x
13.8” x 15”
• 10 lb maximum
4000 Series
• Dimensions: 20.5” x
17.5” x 15.6”
• 15 lb maximum
5000 Series
• Dimensions: 18.7” x
16.7” x 16.3”
• 15 lb maximum
6000 Series
• Dimensions: 25.6” x
16.5” x 18.7”
• 23 lb maximum
ST5000 Series Rotisserie
12 INSTRUCTIONS: Placing Poultry on the Spit Rod Assembly
Placing Poultry on the Spit Rod Assembly
There are two ways to load the Spit Rods.
Piercing Poultry with Rods Hold the tied poultry or meat down securely with one hand
while firmly pushing the Spit Rods into the bird, through the meaty portion of the breast
area. The Spit Rods are sharp so always be careful not to puncture your hand.
When inserting the Spit Rods, push at a slightly downward angle and then level out
the Spit Rods so that they go through the breast and exit the bird on the other side at
approximately the same level. (Note: You should gently squeeze the legs of the bird
together when pushing the Spit Rods through the bird.)
Carving Platform to Load Chicken Try putting the food on by using the Spit Rods in
the Loading Base and put the chicken on breast first using gravity to help. Be sure you
center the food within the area of the two Gear Wheels. Also balance the food so the
weight is evenly distributed.
Keep hands clear of pointed rods as they
exit from the meat.
Carving Platform to Load Chicken
6000 Series models will
cook up to 3 chickens.
Showtime® Rotisserie
INSTRUCTIONS: A or B Cooking Position? 13
After the food is held securely on the Spit
Rods, put the other Gear Wheel in place.
The Spit Assembly can now be placed in the
Rest Area just inside the Door. Then move on
to A or B.
Rest Area
You can rest your loaded Spit Rods and easily
adjust your food and add Kabob Rods, etc.
Small Chickens or Game Hens Side-by-Side
You can also rotate two small chickens or game hens side-by-side. Place Spit Assembly
in vertical position with platform underneath. Push the birds on the Spit Rods through
their centers, and pierce wing to wing. Place the first tied chicken on its side and run
both Spit Rods through it. Duplicate this method for the second bird. Leave a little
space between the two birds so they can brown faster and more evenly. Keep all parts
within the Gear Wheels and centered all around.
A or B Cooking Position?
The Spit Rods can go to Position A
for normal size foods. Use Position
B for small foods and/or Speed
Basket – to cook them closer to the
Heating Element.
Use Position B for a single chicken
3-1/2 lbs. or less. Tie it tightly. If any
piece touches the Heating Element
while rotating, move it down to
Position A and add a bit more time.
The first position for the Spit Wheel
Assembly is the Rest Position: Use
this for easy loading and unloading.
A
B
REST
Rest – for easy loading/unloading
A – for Normal Sized Foods
B – for Small Foods and/or Speed Basket -
Closer to the Heating Element
CAUTION: To prevent a wheel from acci-
dentally falling off, always carry the end with
the Removable Wheel held slightly higher. The
wheels are heavy and have sharp gear teeth.
Showtime® Rotisserie
14 INSTRUCTIONS: Loading the Spit Rod Assembly
Loading the Spit Rod Assembly
Put the Spit Rods through center of the food so it will be balanced and the food does
not touch the Heating Element as it rotates. This is important for large foods like
turkeys, standing rib roasts, 2 chickens side-by-side or any large piece of meat that
goes directly onto the Spit Rods. Small foods and pieces go in a Basket.
Roast
Standing Rib Roasts should always be loaded with the bones on the left side opposite
from the small turning gear on the right side and the heavier meat on the right side.
Also put the Spit Rods through meat between the bones.
When loading a rib roast start through
the fat, meaty end and move the Spit
Rods between (or on top of) the bones.
Keep the meat evenly distributed on the
Spit Rods. It may take a couple of tries
to not run into a bone.
If any food scrapes or hangs up, stop immediately. Trim with scissors and reload the
Spit Rods so that nothing touches the top, bottom, sides or Heating Element.
Rib Bones Always to the Left and Parallel to
the Spit Rods! - Up to 8 lb. Roasts Only
Trim turkeys, standing rib roasts and other
large food to be sure nothing (bones, meat
or skin) hangs over or extends beyond the
Gear Wheels. Cut off excess and tie it down
with string as necessary. Only turkeys up
to 15 lbs. in the full-sized models. Keep
center cavity clear so heat can enter while
it cooks.
Trim off excess fat and skin or loose pieces
– especially around poultry cavities so heat
can enter as it cooks.
IMPORTANT: Food must be centered.
Showtime® Rotisserie
INSTRUCTIONS: Timers 15
Timers
Dial Timer (3000, 4000, & 6000 Series models)
Automatically shuts off after the allotted time and a bell sounds. Use the Timer
to turn on and off all functions. Always turn to OFF (if the unit is still running) before
removing food.
3-Position Switch
Center: Normal Rotation for heat and rotation.
Right: Pause to Sear allows you to stop food in front of the
Heating Element (especially food in a Basket). Char or sear
equal time on both sides. Try 3-5 minutes per side.
Left: No Heat Rotation for up to 20 minutes to keep the juices
evenly distributed before serving.
Red Light Heat Indicator – Timer must be ON for the heat to
be on.
Digital Timer (5000 Series Only)
Automatically shuts off when time is up. Up to 4-Hour Setting. Timer can be adjusted
while food is cooking without stopping or shutting off.
Hold down the OFF key to turn the spit and position the food in front of Heating Element
or to position the food for easier unloading.
Display Window Shows amount of time remaining
until automatic shut off.
3-Way Function
Normal Rotation: Heat with Rotation. Use this setting
to Rotisserie food. This function will be automatically
selected first.
No Heat Rotation: Use for up to 20 minutes to keep
the juices evenly distributed before serving.
Pause to Sear: Heat with No Rotation. Use this
function to sear steaks and brown food in front of the
Heating Element. Especially for food in the Baskets.
Setting Digital Timer - and Some Other Features
Example: A 4 ¼ lb. chicken will take 1 hour and 17 minutes.
Press once = 1 Hour. Press Key and hold it down to get 10 min.
Showtime® Rotisserie
16 INSTRUCTIONS: Carving Platform & Spit Rod Spacer
Carving Platform
After your roast, leg of lamb, or ham is done,
you can place the Carving Platform under
the Gear Wheel to hold the Spit rod assembly
in a vertical position while you carve the meat.
And, if you want the roast browned further, you
can put the roast back in the Rotisserie - even
after you’ve carved some off.
Spit Rod Spacer (6000 Series only)
The Spit Rod Spacer keeps your Spit Rods from
spreading out as you load heavy food. This is
very helpful when loading 2-3 chickens or large
roasts. Remove the Spacer before cooking.
One end of this tool is a wrench for tightening
the small screws that hold each rod - if they
become loose.
IMPORTANT: The times and temperatures given in this booklet are only a guide
for your reference. Times can vary due to differences in meat shape, size, fat content,
presence of bone, and electrical outlets. Use a cooking thermometer inserted into
the center of the thickest portion of the meat to determine internal temperature and
doneness. Remember to use Position B for small foods.
Then press it 7 more times to get +7 minutes.
Or set the Timer for 20 minutes and deduct 3 minutes with
NOTES: Time can be adjusted while food is cooking.
Add 2 additional minutes to the cooking time to allow it to get hot. Use
the total weight given on the outside of the chicken package to figure time.
The Rotisserie starts about 5 seconds after the Timer is set.
Shuts off the Rotisserie
Turn Rotisserie Spit to Desired Position: If you hold down after turning off
the Rotisserie, you can slowly turn the spit to any position you want. Let go and it stops
turning. This feature allows you to position a filled Basket for searing (like steaks) or
position the food for easier unloading.
INSTRUCTIONS: Time and Temperature Chart 17
ST5000 Series Rotisserie
Estimated Time and Temperature Chart
The times and temperatures given in this booklet are only a guide for your reference and are based on foods
at room temperature (not cold foods). Times can vary due to differences in meat shape, size, and the amount
of fat and bone. Also times can vary depending on the electricity in your home – and it can even vary when
plugged into different electrical outlets. The most accurate method of determining if your food is done is using
a thermometer inserted into the center of the thickest portion of the meat. NOTE: If poultry exceeds 180º
(internal temperature) your poultry will become drier and less juicy. Remember to use Position B for small foods.
FOOD (QTY.) WEIGHT EST. TIME INTERNAL TEMP
POULTRY
Whole Chicken or Duck 5 lbs. 15 min/lb. 165°
2 Chickens or Ducks 4 lbs. each = 8 lbs. 10 min/lb. 165°
Cornish Hens (side by side) 2-4 lbs. total 10 min/lb. 165°
Pause-to-Sear (breast stopped in front of Heating Element) @ 4 min - browner breast if necessary
Whole Turkey Up to 15 lbs. 12-18 min/lb. 165°
Chicken Pieces 3 lbs. (about) 45 minutes 165°
Turkey Burgers 1 ¼ lbs. 30-35 minutes 165°
Chicken Kabobs 8 Kabobs 30-35 minutes 170° Well
PORK
Baby Back Ribs (Parboiled 15 min) 1-3 racks 35 min total 160° Med 170° Well
Rolled Pork Lion up to 8 lbs. 18-25 min/lb. 160° Med 170° Well
Pork Tenderlion 1 ¾ - 2 lbs. 30-35 min/lb. 160° Med 170° Well
Pork Chops 4-6 chops 30-40 min total 160° Med 170° Well
Boneless Pork Chops 6 chops 25-30 min total 160° Med 170° Well
Boneless Ham (cooked) 3 lbs. 13 min/lb. 140°
Italian Sausages
uncooked up to 16 30-35 minutes
cooked up to 16 20-25 minutes
Hot Dogs up to 16 10 minutes
BEEF
Standing Rib Roast up to 8 lbs. 18 min/lb. 145° Med
Roast up to 8 lbs. 16 min/lb. 140° Rare
18 min/lb. 160° Med
20 min/lb. 170° Well
Steaks 1 ¼” thick 20 min total Med
Hamburgers (9) ¼ lb. each 20-30 min total Med
Beef Kabobs 8 Kabobs 20-25 min total Med
LAMB
Leg of Lamb up to 8 lbs. 18-22 min/lb. 160° Med
SEAFOOD
Salmon Steaks (Basket) 4-6 steaks 1 ¼” thick 20-25 min total
Fish Fillets (Basket) ¾” thick 25 min total
thin 18 min total
Shrimp Kabobs 6 Kabobs 20-25 min total
Halibut Fillets (Basket) ¾” thick (breaded with dill) 30 min total
Temperatures based on USDA Food Safety and Inspection Service Guidelines.
Power and energy or rotations may vary based on voltage and speed of the basket.
Showtime® Rotisserie
18
18 ACCESSORIES
AVAILABLE ACCESSORIES
Liquid Flavor Injector (sold separately)
For poultry meat and seafood, just add your favorite liquid, or one of Ron’s marinades,
for the best flavor you’ve ever had. Mix with water, juice, wine, soy sauce, vinegar, olive
oil, etc. Be creative, use the flavored marinating liquids of your choice.
1) Remove the Locking Tip
hidden inside the Plunger.
2) Load Plunger into Cylinder.
Note: Keep a couple of drops of
olive oil or vegetables oil
on the back stopper to keep
it moving smoothly.
3) Snap Locking Tip to the head
of Cylinder.
Plunger Locking Tip Needle
How to Load Injector
For Liquid: Draw back Plunger to pull
liquids into the Cylinder section.
Important Safeguards
Keep all parts clean. Use warm water to
clean. Mild bleach can be added to help
reduce bacteria too. To clean a clogged
needle, soak and use a cotton swab
or fine brush.
Discard used marinade. It can carry
bacteria. Never use leftover marinade on
cooked meat or poultry after the marinade
has had contact with uncooked meat
or poultry. Should your needle stop or
clog when using, you will need to make a
finer marinade. Use the blender to make
smaller particles.
If you inject against bone, it will seem
stuck. Move the needle to one side and
continue.
If you let the meat or poultry sit to mari-
nate, refrigerate until ready to cook the
food.
CAUTION: FOR FOOD PREP ONLY.
KEEP AWAY FROM CHILDREN.
Look inside Cylinder
section to see that
liquid has filled up
to desired amount.
19
Showtime® Rotisserie
ACCESSORIES 19
Solid Flavor Injector (sold separately)
This expanding tip injector can be loaded with pieces of garlic or diced onions, herbs,
spices, diced peppers, fruit pieces or diced ham for flavoring. For pastries try inserting
chocolate chips, sprinkles, nuts and other seasonings.
1) Load the Expanding Tip with
garlic, fresh or dried herbs, nuts
or other solid food items.
2) Insert the filled Expanding Tip
inside the Locking Ring.
3) Place the Insert Rod inside
the injector Cylinder. Plunger
should be pulled back as far as
it can go. The Insert Rod is used
to push the spices through the
Expanding Tip.
4) Inject meat, poultry or pastry
with small pieces of solid food
then withdraw the whole
Injector. Pull the plunger back.
Repeat as necessary.
How to Load Injector
To inject small
whole garlic cloves,
fresh herbs or
seasonings into
meat or poultry, you
must first insert the
filled Expanding Tip
as deep as it can
go into the food,
then depress the
plunger.
Depress plunger while tip is inserted
into the meat (or pastry). Withdraw the
injector then pull the plunger back,
reload the Expanding Tip and repeat
throughout the meat or poultry.
Difficulty in piercing through tough skin,
heavy fat or tough meat? Start a slit
(about 1 ½” deep) into the meat with
the point of a small knife.
CAUTION: FOR FOOD PREP ONLY.
KEEP AWAY FROM CHILDREN.
Important Safeguards
While inserting this Solid Flavor Injector
into meat, poultry, or any other food,
be careful not to push Injector into your
hand. The Expanding Tip is sharp.
Wash Injector thoroughly with soap and
water after each use. Meat and poultry
residue is unhealthy and can cause the
expanding Tip to crack or break.
If the Injector seems too large for your
hand, fill the Expand-
ing Tip only ½ or ¾ full
(then the plunger is
less extended and will
fit smaller hands).
Important: Please
don’t leave the Insert
Rod in the Expanding Tip. It can stretch.
After each use, pull plunger all the way
back and then retract the Insert Rod
from the Expanding Tip by tapping the
point down gently onto a smooth, hard
surface.
Plunger
Cylinder Insert Rod
Expanding Tip Locking Ring
Showtime® Rotisserie
20 ACCESSORIES
Kabob Rods (sold separately)
Set the Spit Rod Assembly in the Rest Area
(just inside the machine). Load the Kabobs
with food then insert them into the holes on
the gear wheels. Start with sharp end on
the left side, then load and snap the Kabob
with the Auto Turn Mechanism (spring
ends) on the right so they will rotate.
Turn the Spit Rod Assembly until all the
Kabobs are loaded in place. Slide the
whole assembly back to the next notch -
the cooking position.
When done, carefully move the Spit Rod
Assembly back to the Rest Area. Use
Oven Gloves to remove the Kabob Rods.
Simply push the spring end inward and
then pull the rods out one at a time.
Dual Heating Tray with Lid (sold separately)
Defrosts and heats frozen vegetables as
well as heats and steams fresh vegetables,
warms gravies, chili and sauces – all while
food is rotating. Use about 1/2 cup water in
each side of the Dual Heating Tray.
Glass Door Shown open and tucked under
the Rotisserie. Always keep the Door in up
position when Heating Element is on. The
glass gets very hot - please don’t touch it.
Showtime® Rotisserie
ACCESSORIES 21
Giant Lobster &
Vegetable Non-stick Basket (sold separately)
The Giant Lobster and Vegetable Basket is
designed to handle extra thick foods like turkey
breasts, super thick T-bone steaks, lobsters and
an assortment of vegetables.
Carving Knife (sold separately)
This is the all-purpose knife that can do just
about anything you ask of it. Slice, chop, dice
and stay sharp with the lifetime edge. The tip
is used for picking up and serving small pieces
of meat. Use it when you want to dice and
slice without having your hand hit the counter.
Use for all vegetables and fruits. Use a gentle
sawing motion. Remember to always use
caution with knives.
Overall length 14-3/8”.
Visit us online at www.Ronco.com for more
information and product availability or email
us: support@ronco.com
Call the Order Desk to order supplies,
7 Days a Week (and a 24-Hour Phone
Message Center after hours)
Call for product availability 1-855-85-RONCO
Always
I
nnovating
Showtime® Rotisserie
22 ACCESSORIES
Round BBQ Rib Basket (sold separately)
1. Place baby back or spare ribs in boiling
water for 15 minutes. Drain ribs and let
them cool. This step makes the ribs more
pliable and tender and reduces fat. When
cooled, cover both sides of the ribs with
BBQ Seasoning.
2. Position hooks over the middle of the last
rib bones. Attach a C Hook at one end of
the slab and attach a Stair Hook at the
other end.
3. Thread the Spit Rod Assembly through
eyelets on both ends of the Rib Basket.
Then attach the removable wheel.
Position the Spit Rod Assembly with
the Rib Basket in the Rest Area.
4. Starting with the C Hook end, attach the
ribs to the basket on any horizontal wire.
Rotate the basket while wrapping the ribs
around the outside of the basket.
After ribs are stretched tight, lock the
slab down by attaching the Stair Hook
on the closest horizontal wire on the Rib
Basket. Make sure it is tight.
5. Slide the Spit Rods with the Rib Basket
back into the cooking position and set the
timer for 35 minutes on Normal Rotation.
While rotating, check to make sure the
ribs are not touching the heating element
or the glass door. If they touch, trim the
ribs. Always check on your food from time
to time.
6. Brush ribs with one coat of BBQ Sauce
onto the ribs 10 minutes before they
are done.
Showtime® Rotisserie
CAUTIONS 23
Never use any aerosol sprays of any kind inside the unit.
Never cook foods larger than recommended in the booklet for your Rotisserie.
Grease Flicker? Foods with high fat content can produce a small flicker of flame
as fat spatters off the Heating Element. This is normal. However, if you see smoke
or fire, turn off and unplug the machine and let it cool off. DO NOT OPEN THE DOOR
until it has cooled down. NEVER PUT WATER IN THE ROTISSERIE - Water and fat
or oil don’t mix. After it has cooled, check to see if food touched, or hung up on the
Heating Element.
Keep out of reach of children.
DO NOT MOVE rotisserie when it is hot or loaded with food.
Always keep at least 8” (inch) clearance all around the rotisserie from walls,
cabinets and other objects when in use to prevent heat damage.
Do not use under cabinets.
Do not put charcoal briquettes, hickory chips or anything else in the machine
that is not authorized by Ronco Holdings, Inc.
CAUTIONS
Rotisserie is HOT!
Glass Door, top, back and sides of the Rotisserie, as well as the Dual Heating Tray,
Drip Tray, Non-stick Grate Cover, Heat Shield and Heating Element all get very
hot during use and retain heat after use – even when Glass Door is positioned
underneath the unit. Always use adequate oven mitts or gloves when handling
these hot surfaces and when checking hot foods.
Showtime® Rotisserie
24 HELPFUL HINTS
Helpful Hints
Use a strip of aluminum foil on your
counter top under the front door opening
to collect any grease or moisture from
a roast beef or a whole turkey during
cooking.
Burnt Edges on Food? You can put a
small strip of aluminum foil on the top
and bottom edges inside the Basket to
prevent burnt edges as it cooks.
Seasonings and spices should be
sprinkled on or rubbed into the food
before it goes into the Rotisserie.
Once the food is rotating, watch it
to be sure nothing is touching the
Heating Element as it goes around.
Have your food at room temperature
when it goes in. Not chilled. Wash food
in warm water inside and out. DO NOT
LEAVE OUT AT ROOM TEMPERATURE MORE
THAN 1 HOUR.
It is not necessary to preheat the
Rotisserie.
Never cook foods larger than
recommended in the booklet for
your Rotisserie.
Avoid burning – Baste with BBQ
sauce only during the last 5 minutes.
It’s tasty and delicious.
Wrap fish with seasonings and mari-
nade in aluminum foil (triple-fold the
edges) and put tightly in the Basket for
a delicious and easy meal!
Be sure wings are all secure inside the
Basket with no parts hanging out.
You can use a small strip of aluminum
foil inside the Basket on the top and
bottom edges (the edges that rotate near
the Heating Element) to keep the tips of
the wings from burning.
Place foil inside on top
and bottom edges
NOTE: The Rotisserie DVD reflect the
3000, 4000, 5000, and 6000 models.
Newer parts and accessories indicated
in the this manual will vary from the
DVD. The basic operation and warnings
of all rotisserie models remain the
same. Visit us online for more informa-
tion and product availability or email us:
customerservice09@ronco.com.
Showtime® Rotisserie
MEAL SUGGESTIONS 25
Meal Suggestions
Here is a list of food that requires little prep to have a fantastic meal with your
Showtime® Rotisserie.
Poultry:
1 or 2 Seasoned Chickens
Turkey - up to 15 lbs.
Cornish Game Hens or Ducks
Wild Game - Venison, Goat , Fowl
Spicy Chicken Wings (basket)
Lemon Herb Chicken Breasts (basket)
Beef:
Prime Rib Roasts- up to 8 lbs.
Carne Asada Burritos
Fajitas - Beef Strips with Bell Peppers and
Onions
New York Steak with Asparagus (basket)
9 Old Fashion ¼ lb. Hamburgers
Chicago Style Hot Dogs
Ribs (BBQ Rib Basket)
Pork and Lamb:
Leg of Lamb Rolled in Rosemary
and Olive Oil - up to 8 lbs.
Pork Loin or Shoulder Roast - up to 8 lbs.
Country Honey Glazed Ham
Ribs (BBQ Rib Basket)
Pineapple Teriyaki Pork Chops (basket)
Apple Cinnamon Pork Chops (basket
Lamb Chops with Bean Salad (basket)
Sausages (basket)
Fish and Seafood:
Cajun Fish (basket)
Fish with Pineapple
Cilantro Sauce (basket)
Halibut with Eggplant (basket)
Shrimp or Scallops with Tarragon
Mustard Dressing (basket)
Vegetables:
Mixed Vegetables (basket)
Kabobs:
Chicken, Lamb, Beef, Seafood
with Vegetables
NOTE:
The 3000 Series oven dimensions are:
13.50” w x 9.50” D x 11.00” H
3000 Series basket dimensions are:
8.50” W x 7.50” L x 1.50” D.
The 4000/5000 Series oven dimensions
are: 14.50” W x 14.00” D x 13.00” H.
4000/5000 Series basket dimensions are:
9.50” W x 9.25” L x 1.50” D.
The 6000 Series oven dimensions are:
19.00” W x 14.00” D x 13.00” H.
6000 Series basket dimensions are:
9.50” W x 9.25” L x 1.50” D.
We have provided you the dimensions of
the above to help you also in figuring out
the size of the turkey/chicken/roast to use.
The baskets are designed so that they
will not touch either the Heat Element or
the Door when in rotation. So, the outer
contour of the potential bird or meat cut
should not exceed the rectangle made by
the boundary of your basket.
For example, the maximum “weight” of
a bird (chicken or turkey) to grill with
the 5000 series is 15 lbs. However, you
need to be mindful of the “volume” as
well. Please note that the length of the
chicken should not exceed 9.50” (which
represents the distance between the gear
wheels) while the width to be at 9.25” or
less (which represents the depth allowed
to occupy without having the chicken
touching the heat element on the back
wall or the glass door at the front during
rotation.)
NOTE: The model number is located on
the back of your Showtime® Rotisserie.
Showtime® Rotisserie
26 RECIPES
Recipes
Roast Chicken with Lemon Herb Rub
One 3½ to 4 pound Whole Chicken
Rind of 2 Lemons, minced
5 Garlic Cloves, minced
1 tablespoon Dried Thyme, finely crumbled
2 teaspoons Dried Rosemary, finely crumbled
2 teaspoons Dried Sage Leaves, finely crumbled
Salt and freshly Ground Pepper
In a small bowl combine lemon rind, garlic, and herbs to form a slightly moist paste.
Wash the chicken and dry thoroughly, inside and out. Loosen the skin across the
breasts and then down around the leg and thigh using a chopstick or your fingers.
Work the seasoning mixture under the skin and into the meat of the breast, leg and
thighs and all over the outside skin as well. Season the cavity of the chicken with salt
and pepper. Using an Elastic Food Tie, truss the chicken. Place the chicken on the Spit
Rods for about 60 minutes or until the internal temperature reaches 165°F on a meat
thermometer inserted in the thigh meat. Remove chicken and cut it into pieces to serve.
(Tip: If you are rotating two small chickens at a time, skewer them side by side on the
Spit Rods and increase the time to 1½ hours.) Serves 3 to 4.
Four Peppercorn Crusted Roast Beef
One 3½ to 4-pound Boneless Beef Rib Roast
2 teaspoons Black Peppercorns
2 teaspoons White Peppercorns
2 teaspoons Green Peppercorns
1 teaspoon Pink Peppercorns
1 teaspoon Salt
Place the peppercorns in a heavy plastic bag and crush with a rolling pin. Stir in the
salt. Coat the outside of the roast with the pepper mixture. Rotisserie the roast on the
Spit Rods 18 to 20 minutes per pound for rare or until the internal temperature reaches
140°F, 25 to 30 minutes per pound for medium or until the internal temperature reaches
160°F, or 35 to 40 minutes per pound for well done or until the internal temperature
reaches 170°F on the meat thermometer inserted in the center. Remove and slice into
1/4 inch thick slices or thinner. Serves 4 to 6.
Showtime® Rotisserie
Jamaican Jerk Pork Tenderloin
2 Pork Tenderloins (About 1 ½ to 2 Pounds Total)
2 tablespoons Chopped Fresh Cilantro
1 tablespoon Finely Minced Fresh Ginger
¼ cup Dark Rum
2 tablespoons Fresh Lime Juice
2 tablespoons Olive Oil
2 tablespoons Light Brown Sugar
1 cup Soy Sauce
½ teaspoon Nutmeg
¼ teaspoon Cayenne
¼ teaspoon Ground Allspice
¼ teaspoon Ground Cinnamon
¼ teaspoon Salt
Combine all ingredients except the pork in a flat baking dish. Reserve 1/3 of the
marinade and keep it separate. Trim all fat and skin from the pork tenderloins and
place them in the marinade. Turn to coat well. Cover and marinate for 15 to 30 minutes
at room temperature. Cook the pork in a Rotisserie Basket for 30 minutes basting it
with the marinade juices often during the last 10 minutes or until the internal temperature
reaches 160°F on a meat thermometer. Slice the pork on the diagonal, place on a
serving platter. Warm the reserved marinade and spoon it over the pork slices and
serve. Serves 4.
Lemon Dill Salmon Steaks
4 Large or 6 Medium Salmon Steaks
¼ cup Fresh Lemon Juice
3 tablespoons Olive Oil
1 tablespoon Minced Fresh Dill or 1 teaspoon Dry Dill Weed
½ teaspoon Salt
½ teaspoon White Pepper
In a small bowl add all ingredients except the salmon. Brush on both sides of the
salmon, wait 5 minutes and repeat. Place the salmon steaks in the Rotisserie Basket.
Cook for 15 to 25 minutes, depending on size of salmon steaks. Serve one salmon
steak per person.
RECIPES 27
Showtime® Rotisserie
28 RECIPES
Roasted Vegetable Skewers with
Balsamic Basil Marinade
1 Red Bell Pepper, cut into 1 inch pieces
1 Yellow Summer Squash, cut into ¼ inch slices
1 Zucchini cut into ¼ inch slices
16 White Button Mushrooms, stems removed
8 Green Onions, cut into 1½ inch pieces
Marinade:
½ cup Olive Oil
6 tablespoons Balsamic vinegar
2 tablespoons minced fresh Basil
2 cloves Garlic
Prepare the vegetables and place them in a large bowl or food storage bag. Combine the
marinade ingredients and pour the marinade over the vegetables. Cover and marinate
1 to 2 hours at room temperature. Drain off the marinade and skewer the vegetables
on the Kabob rods. Rotate the skewered vegetables for 20 to 25 minutes until the
vegetables are slightly brown, but still crunchy. Remove the Kabobs from the Gear
Wheels and slide the vegetables off onto serving plates. Serves 6.
Merlot Marinated Leg of Lamb
One Leg of Lamb (4 ½ to 5 Pounds) boned and tied
1 cup Merlot or other dry red wine
½ cup Soy Sauce
4 cloves Garlic; minced
2 tablespoons Dried Oregano
1 tablespoon Dried Rosemary
1 tablespoon coarsely Ground Pepper
Combine the soy sauce, Merlot, garlic, oregano, rosemary, and pepper in a deep bowl.
Add the lamb and turn it to coat with marinade. Cover and chill at least 6 hours or up
to a day, turning the meat over several times. Remove the lamb from the marinade,
reserving marinade for basting. Place the lamb on the Spit Rods. Cook for 1 hour, 15 to
30 minutes or until the internal temperature reaches 160°F for medium, basting several
times during the last 10 minutes. Serves 6 to 8.
Showtime® Rotisserie
RECIPES 29
Mustard-Brown Sugar Glazed Pork Chops
Three or Four 1 Inch thick Center Cut Pork chops
½ cup Brown Sugar
¼ cup Dijon Mustard
Pinch each of Dried Thyme and Dried Sage
Pat pork chops dry with a paper towel. Stir together mustard, thyme and sage. Coat
pork chops well with the herb mustard. Press brown sugar into the herb mustard. Place
the pork chops in the Rotisserie Basket for 30 to 35 minutes or until cooked through. If
not brown enough, position the Basket facing the Heating Element and turn the switch
to “Pause-to-Sear” for 2 to 3 minutes on each side. Serves 3 to 4.
Apricot-Orange Glazed Game Hens
Two 1 ½ to 2 Pound Rock Cornish Game Hens
3 tablespoons Fresh Orange Juice
3 tablespoons Soy Sauce
½ cup Apricot Preserves
Salt and Fresh Ground Pepper
Stir together the preserves, orange juice and soy sauce. Separate and reserve half of
the sauce and serve it with the hens. Wash and thoroughly dry the game hens inside
and out. Season the inside cavity with salt and pepper and brush the game hens with
the other half of the sauce. Cook 40 to 50 minutes or until the temperature reaches
180°F on a meat thermometer. Serve with warmed reserve sauce. Serves 2 to 4.
BBQ Beef Kabobs
2 pounds Beef Top Sirloin
1 cup BBQ Sauce
2 Bell Peppers; cut in 1 Inch pieces
2 cups whole Mushrooms
1 Purple Onion, cut in 1 Inch pieces
Cut the beef into 1¼ inch cubes and place in a medium bowl. Stir in BBQ sauce; cover
and let marinate for 1 to 4 hours in the refrigerator. Remove the beef from the sauce
and skewer on the Kabob Rods, alternating beef with desired vegetables. Cook for 20 to
25 minutes or until they reach desired doneness. Baste with BBQ sauce only during the
last 5-10 minutes. Serves 6.
Showtime® Rotisserie
30 6 EASY STEPS TO ROTISSERIE CHICKEN
Two Original Style Roast Chickens
Two 3½ to 4 pound whole chicken
2 teaspoons each of Salt and Paprika
1 teaspoon each of Onion Powder, Dried Thyme, White Pepper
½ teaspoon each of Cayenne Pepper, Black Pepper, Garlic Powder
Salt and fresh Ground Pepper
2 Onions, quartered
In a small bowl, mix together salt, paprika, onion powder, thyme, white pepper, black
pepper, cayenne pepper, and garlic powder. Remove and discard giblets from chicken.
Rinse chicken cavity, and pat dry with paper towel. Rub each chicken inside and out
with spice mixture. Place 1 onion into the cavity of each chicken. Place chickens in a
resealable bag or double wrap with plastic wrap. Refrigerate overnight, or at least 4 to
6 hours. Remove onions from cavity. Season the cavity of the chicken with salt and
pepper. Using an Elastic Food Tie, truss the chicken. Place the chickens side by side on
the Spit Rods for about 80-90 minutes or until the internal temperature reaches 165°F
on a meat thermometer inserted in the thigh meat. Remove chickens and cut it into
pieces to serve. Serves 6 to 8.
6 Easy Steps to Great Rotisserie Chicken
1. Wash the chicken with warm water
(so the food is not cold when it goes in the
Rotisserie) and remove any parts from the
cavity (giblets, etc). Cut away excess fat
and skin so hot air can get into the cavity.
Tie the wings and legs down. Use one or
two of the Elastic Food Ties (if they are too
big for your chicken, knot them smaller and
cut off the excess). See page 10 for more
details.
2. Place the chicken on the Spit Rods
breast first - be sure it’s centered and the
weight is evenly distributed. Be careful to
keep your hands clear of the sharp rod tips
when loading food vertically or horizontally.
After loading the food on the Spit Rods, put
the other Gear Wheel on.
Showtime® Rotisserie
6 EASY STEPS TO ROTISSERIE CHICKEN 31
3. Place the loaded Spit Rod Assembly
in the Rest area just inside the Rotisserie.
Then slide it on back to the cooking
position. Pull the Glass Door up.
4. Set the 3-Way Function to Normal
Rotation. Set the Timer for 15 minutes per
pound for a chicken. Example: 4 lbs. = 1
hour. NOTE: Use the total weight- which
includes giblets that’s printed on your
chicken package. If your package does not
include giblets, etc., then add a 1/4 pound
to the actual weight of your chicken to
figure the cooking time.
5. To enjoy the best flavor and taste, serve
your chicken immediately. If you are not
ready to serve it right away, however, set
the 3-Way Function to No Heat Rotation
to keep the juices evenly distributed
throughout the chicken.
6. To Serve: When chicken is done, care-
fully slide the Glass Door under the unit.
Use the Oven Gloves and gently but quickly
lift the chicken and Spit Rod Assembly out
while supporting the chicken. A bowl under
the chicken helps make it easier to remove.
Take off the removable Gear Wheel, slide
out the Spit Rods and serve.
CAUTION: The parts get really hot!
Problem? If a chicken wing comes free or any part touches the Heating Element
or bottom grate during cooking, simply turn the Timer to OFF. Let it cool a bit.
Please be careful – both the food and the Rotisserie get hot. Make any adjustments
or re-tie your chicken. Then reset the Timer.
Ronco Holdings, Inc.
15505 Long Vista Dr., Ste 250
Austin, TX 78728
1-855-85-RONCO
www.Ronco.com
Copyright ©2013 by Ronco Holdings, Inc. All Rights Reserved. 01.13
Manufactured under U.S. patents: 7,424,849; 7,325,484; 7,739,948; 6,782,805; 6,782,806; 7,153,120; 6,250,214;
6,142,064; 6,988,445; 7,021,203; 6,170,390; 5,731,012; 6,874,408; 6,422,136; 6,658,991; 6,393,972; 6,240,838;
6,408,742; 6,568,315; 6,568,316; 6,253,665; 6,330,855; 7,225,729; 7,225,730; 6,536,334; 6,742,445; 7,500,428;
7,878,111; 6,837,150.
Foreign patents pending.
01.13 STDGEN ROTISSERIES
ONE YEAR LIMITED WARRANTY
Ronco Holdings, Inc., warrants to the owner of this product that it is free from defects in
material and workmanship for a period of one year from date of purchase. Please visit
http://www.ronco.com/warranty.html and fill out your Warranty Registration Form.
The manufacturer’s obligation will be limited to repairing or replacing F.O.B. any part of
the product which is defective. Such warranty will not apply to defects resulting from
tamper, cosmetic damage, acts of God, accidental breakage, abuse, negligence, neglect
or misuse. If you must return the product for reasons of malfunction within the one year
warranty period, the following action and steps are required: Remit U.S. Dollars:
1. The machine must be clean and packaged securely to protect from damage or
breakage in shipment.
2. Call and obtain a Return Authorization Number. Then ship prepaid to Ronco Hold-
ings, Inc., by the most convenient method. Ronco Holdings, Inc., will repair or
replace your Rotisserie unit and return it to you prepaid.
Even if not required, the rights in this warranty are granted to you. This warranty gives
you specific legal rights, and you may also have other rights which vary from state to
state. Registering for your warranty is not a condition precedent to warranty coverage.
Ronco Ronco Holdings, Inc., will not be held liable for any special, incidental, or con-
sequential damage, resulting from possession, use or loss of use of this product either
directly or indirectly.
No returns will be accepted without prior authorization.
To receive a Return Authorization Number Call Customer Service at 1-855-85-RONCO.
If all lines are busy, please contact our support site at https://support.ronco.com

Navigation menu
